56” Ultra High Resolution Display with 8.3 Megapixel Resolution
Integrated Computing Power and Display Performance
TEK PANEL UHR 560
The Tek Panel UHR 560 features an Ultra-High resolution (3840
x 2160), 56 Inch diagonal, active matrix LCD display
integrated with a high-performance computer.
Featuring 4 times the resolution
of full High Denition,
the Tek Panel UHR 560
combines unparalleled
visual clarity and
extreme computing
power.
Typical applications
include: ultra-high
resolution imaging
and analysis,
geospatial intelligence
systems, highly
immersive training
and simulation,
interactive training,
ight simulation, medical diagnostic imaging,
3D modeling and CAD applications. The ability to have multiple high resolution
images or videos on-screen greatly enhances and simplies image analysis and
increases productivity and eciency.
The Best of Both Worlds
The 56” LCD display of the Tek Panel UHR 560 provides a wide range of functionality
from board room presentations to precise image analysis. This is the only single
display system that can display Quad High Denition 4K digital content and also
have the computing power to display
up to four standard high denition
videos simultaneously.
Tek Panel Inc. |1998 Bucktail Lane, Sugar Grove, IL 60554
Tel: (630) 466-7664 | Fax: (630) 466-7678 |www.TekPanel.com
Standard Features and Specications:
Display:
56” TFT/LCD Quad Full High Denition
(QFHD) Display with 3840 x 2160 pixels
(8.3 megapixels) resolution
Ultra-wide 176o viewing angle
Brightness: 500 Nits; Contrast: 1200:1
Ultra-fast 6.5 ms pixel response time
Optional infra-red touchscreen featuring
4096 x 4096 touchpoint density
Processor:
Full line of Intel® and AMD® Processors
available including Dual Core and Quad
Core congurations
Memory:
4GB PC6400 DDR3 RAM
(Up to 16GB RAM Available)
Storage:
Up to 1TB Hard Drives
(Optional Removable Security Drives and
multiple drive RAID Arrays available)
Optical Drive:
Dual Layer CD R/RW - DVD +/- R/RW
Operating System:
Microsoft Windows® XP or Windows Vista
Graphics:
ATI Radeon X1950 Pro Graphics w/ 512MB
Network Connectivity:
Dual Integrated Gigabit Ethernet
(Wireless and Optical Connectivity available)
Input/Output:
Component HD, VGA, Composite, S-Video,
USB 2.0, Firewire, GB Ethernet, Serial,
Parallel Port
Optional Software:
Hitachi® Starboard™ Annotation Software
Suite (when used with touch screen, no
additional hardware needed for digital
whiteboard functionality)
Wireless Keyboard and Mouse
Mounted, Ruggedized, Wireless and
Onscreen Keyboards available
Dimensions:
34.48” x 59.42” x 8.81”; Weight: 140 lbs.
Screen Size: 57” diagonal
Powder-coated black nish
Optional Ruggedization Available
including Optical Bonding for Display
Warranty: 1-year Limited Warranty
(3-year Extended warranty available)
All specications are subject to change without notice.
All registered trademarks are the property of their
respective owners.
©2008 Tek Panel, Inc. All rights reserved.
TEK PANEL UHR 560
Custom cases available
with various nishes
and conveniently
located I/O connections
Custom build the
Tek Panel UHR 560
to suit your individual
needs.
Optional high-density
infra-red toucscreen
available
Digital Whiteboard
software by Hitachi®
available as an upgrade
•
•
•
•
TEK PANEL UHR 560
TEK PANELS
ARE FULLY
UPGRADEABLE
AND
CUSTOMIZABLE
