Hyundai IBT L24C0FAL0 LCD MONITOR User Manual
Hyundai IBT Corp. LCD MONITOR
user manual
24” Wide LED Monitor
User Manual
P247DU
P247D
Precautions
AC outlet
Power cord
Warning
The following information will help you avoid the risk of electric shock, serious injury or death.
Plug the power cord into a
properly grounded outlet.
There is the risk of electric
shock.
Do not unplug from the outlet
by pulling the power cord or
when your hands are wet.
There is the risk of electric
shock or fire.
Do not allow any object or liq-
uid to enter inside the monitor.
There is the risk of electric
shock, fire or damage to the
monitor.
Do not bend the power cord
excessively nor place heavy objects
on it. Keep children and pets away
from the power cord as they may
damage the power cord. There is
the risk of electric shock or fire.
Do not use a damaged power
cord or plug. Make sure the
plug fits snugly into the outlet.
There is the risk of electric
shock or fire.
Do not expose the monitor to
the direct sun light. Keep the monitor away from high
temperature, humidity, and dust.
Operating environment
=10~40degrees Celsius
Operating environment
=20~80relative humidity.
Do not block the fan louvers.
There is the risk of fire or dam-
age to the monitor.
Use a proper voltage/current
level indicated Do not clean the LCD with
abrasive chemicals.
There is the risk of damage to
the LCD.
Do not scratch and damage
the LCD with sharp objects.
Keep the monitor away from
objects and electrical appli-
ances that may generate elec-
tromagnetic fields.
Place the monitor on a flat, sta-
ble surface. The monitor may
fall and there is the risk of
damage or injury.
Unplug the power cord when
the monitor is not in use for a
long period of time.
If you hear a noise or smell
smoke from the computer or
adaptor, unplug the power cord
immediately, and call the service
center. There is the risk of elec-
tric shock or fire.
Do not overload an electrical
outlet with too many devices.
There is the risk of fire.
Do not attempt to disassemble,
fix or modify the monitor.
There is the risk of electric
shock or fire.
Caution
The following information will help you avoid the risk of minor or moderate injury or damage to the monitor.
Precautions
The socket - outlet shall be installed near the equipment and shall be easily accessible.
2
1
1 : For Audio Model Only.
Monitor Stand
Power Cord
24pin DVI Cable Audio Cable
Install CD / Quick guide
* Push the hook until
hanging
2 : For USB Model Only.
*2
*2 : For Audio Model Only.
USB Cable
5
4
15-pin Dsub Cable
“UP, DOWN”
“MENU”
“UP, DOWN”
“UP, DOWN”
DOWN
UP
SCALE Change Ratio (Wide or Normal)
SOURCE Change Input Signal
LCD
LCD
Volume
*1
*1 : For A
9
OSD TIMER Adjusts OSD display time on the screen.
Adjusts transparency of the OSD window.
OSD TRANSLUCENT
AUTO COLOR
AUTO CONFIGURATION
udio Model Only.
DCR Turn on / off DCR Function.
Enhance the definition of outline.
Sharpness
* VGA Only
*2
*2 : Not abailable in DVI
8 9
800 x 600
1024 x 768
1280 x 960
1280 x 1024
1440 x 900
1680 x 1050
1920 x 1080
480p
576p
720p
1080p
35.2 kHz
37.8 kHz
48.3 kHz
60.0 kHz
63.9 kHz
55.9 kHz
64.7 kHz
67.5 kHz
56 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
50/60
50/60
50/60
50/60
DVI(HDCP)
Under 28W
Less then 0.5W
1 : ForAudio Model Only.
2
531.36mm(H) x 298.89mm(V) (24 inch)
0.276mm(H) x 0.276mm(V)
1920 x 1080@60Hz
170º/170º(H/V)
16.7M
< 28W (Typ.)
1Wx2
AC:100V-240V 50/60Hz, 2.0A
DVI-I, AUDIO *1
50
24 Wide
*1
10 11
< 0.5W
USB ,*2
2 : ForU S B Model Only.
12
FCC compliance
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
ㆍReorient or relocate the receiving antenna.
ㆍIncrease the separation between the equipment and receiver.
ㆍConnect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
ㆍConsult the dealer or an experienced radio/TV technician for help.
Change or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate the equipment under FCC rules.
