USERS MANUAL
CHILDMINDER
Instructions
King Ring Unit
1. See back of Key Ring Unit.
2. Remove battery compartment cover and insert two (2) alkaline or lithium AAA
batteries in the battery compartment of Key Ring Unit
3. Replace Battery compartment cover
4. Key Ring Unit is now ready for operation
Smart Clip (active child safety seat shoulder harness clip)
1. See back of Smart Clip Part A
2. Remove battery compartment cover and insert two (2) AAA alkaline or lithium
batteries in the battery compartment of Smart Clip Part A
3. Replace battery compartment cover
Operation
1. Arming / Activation of ChildMinder
1. Insert Smart Clip Part B to Smart Clip Part A
2. Smart Clip Part A will began to beep and its surface red light are now flashing
3. Press and release the test button on the Key Ring Unit. The Key ring unit will
beep once and the Smart Clip Part A will stop beeping
4. The green lights on Smart Clip Part A and the green light on the Key ring Unit are
now flashing indicating that ChildMinder is now activated (armed).
2. Alarm Engaged
1.Upon the proximity of Key ring Unit becoming greater than 30 meters from the
activated Smart Clips’ part A&B, the Key ring Unit will began to beep (alarm).
2. The Key Ring Unit will continuously beep until the Smart Clip has been either
deactivated (see below) or the Key Ring Unit is return to proximity of less than 30 meters
of the Smart Clip.
3. Deactivation of Child Minder
1. Press and hold down the Release button on Smart Clip Part B while gently
pulling outward on both Parts A & B
2. Separate parts A from Part B,
3. Allow 4 seconds.
4. The Key Ring Unit will beep 3 times then the Smart Clip will beep 3 times.
ChildMinder is now deactivated (disarmed).
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH
MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
