INSTRUCTION MANUAL
VHF FM REPEATER
iFR5200H
iFR6200H
UHF FM REPEATER
This device complies with Part 15 of the FCC
Rules. Operation is subject to the condition that
this device does not cause harmful interference.
i
IMPORTANT
READ THIS INSTRUCTION MANUAL
CAREFULLY before attempting to operate the re-
peater.
SAVE THIS INSTRUCTION MANUAL– This
manual contains important safety and operating in-
structions for the IC-FR5200H/IC-FR6200H vhf/uhf
f m r e p e at e r s .
EXPLICIT DEFINITIONS
WORD DEFINITION
RWARNING! Personal injury, fire hazard or electric
shock may occur.
CAUTION Equipment damage may occur.
NOTE
If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
SUPPLIED ACCESSORIES
The following accessories are supplied.
R WARNING HIGH VOLTAGE! NEVER at-
tach an antenna or internal antenna connector during
transmission. This may result in an electrical shock or
burn.
R WARNING HIGH VOLTAGE! NEVER install
the antenna at any place that person touch the an-
tenna easily during transmission. This may result in an
electrical shock or burn.
R WARNING! NEVER apply AC to the DC power
connector on the repeater rear panel. This could cause
a fire or damage the repeater.
R WARNING! NEVER apply more than 16 V DC
to the DC power connector on the repeater rear panel.
This could cause a fire or damage the repeater.
R WARNING! NEVER reverse the DC power
cable polarity when connecting to a power source. This
could cause a fire or damage the repeater.
CAUTION: NEVER let metal, wire or other objects
touch any internal part or connectors on the rear panel
of the repeater. This may result in an electric shock.
CAUTION: NEVER expose the repeater to rain,
snow or any liquids.
DO NOT operate or place the repeater in areas with
temperatures below –30°C (–22°F) or above +60°C
(+140°F). Be aware that temperatures can exceed
80°C (+176°F), resulting in permanent damage to the
repeater if left there for extended periods.
DO NOT place the repeater in excessively dusty en-
vironments or in direct sunlight.
DO NOT put anything on top of the repeater. This will
obstruct heat dissipation.
BE CAREFUL! The heatsink will become hot when
operating the repeater continuously for long periods.
BE CAREFUL! If a linear amplifier is connected,
set the repeater’s RF output power to less than the
linear amplifier’s maximum input level, otherwise, the
linear amplifier will be damaged.
Use Icom microphones only (optional). Other manu-
facturer’s microphones have different pin assignments,
and may damage the repeater.
Place the repeater in a secure place to avoid inadver-
tent use by children.
For U.S.A. only
CAUTION: Changes or modifications to this re-
peater, not expressly approved by Icom Inc., could
void your authority to operate this repeater under FCC
regulations.
PRECAUTIONS
Handles For handles attachment
For the connector
Spacers Hexagon wrench
Screws
Screws Holder
Connector
Function name stickers*1Rack
KEY SEAL
Used for labelling the program-
mable function keys according
to their assinged functions.
*1
Square fuse
(FGB01 30A)
ii
Icom, Icom Inc. and the Icom logo are registered trademarks
of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other
countries.
All other products or brands are registered trademarks or
trademarks of their respective holders.
FORWARD
Thank you for choosing this Icom repeater. The IC-
FR5200H/IC-FR6200H vhf/uhf f m repeaters are
designed and built with Icom’s state of the art technol-
ogy and craftsmanship. With proper care, this product
should provide you with years of trouble-free opera-
tion.
We want to take a couple of moments of your time to
thank you for making the
IC-FR5200H/IC-FR6200H
your repeater of choice, and hope you agree with
Icom’s philosophy of “technology first.” Many hours
of research and development went into the design of
your
IC-FR5200H/IC-FR6200H
.
D FEATURES
m Built-in 5-Tone, DTMF encoder & decoder
Multiple signaling systems are equipped as stan-
dard. These systems are fully compatible with Icom
F-series radios.
m DTMF remote control capability
You can control the repeater from a remote location
over the air or over a phone line with DTMF.
m D-Sub 25 pin ACC port equipped
You can use the optional equipment via the D-sub
25 pin ACC port equipped on the repeater’s rear
panel.
m Other features
-
Wide frequency coverage
<VHF>
IC-FR5200H: 136 to 174 MHz
<UHF>
IC-FR6200H: 350 to 400 MHz,
400 to 470 MHz,
450 to 512 MHz,
450 to 520 MHz
- PC programmable
- 19 inch rack mount
- Optional Voice Scrambler Unit (UT-109R/
UT-110R) for base operating mode
