Hospira, Inc. Wireless USB Adapter

Contents

User Manual

Hospira MedNet 802.11 a/b/g Wireless
Upgrade Module
Connectivity Engine (CE)
Configuration Guide
Includes
*Hospira MedNet® Plug ‘n Play Module (List 20677/20791-04-77)
For Use with Plum A+ Infusers (Lists 11971/12391/20679/20792-04)
*Hospira MedNet® Software (List 16033-04)
430-11541-001
430-11541-001 CE Configuration Guide
Change History
Part Number Description of Change
430-11541-001
(Rev. 01/07) Original issue
© Hospira, Inc. All Rights Reserved
This document and the subject matter disclosed herein are proprietary information. Hospira retains all the
exclusive rights of dissemination, reproduction, manufacture and sale. Any party using this document
accepts it in confidence, and agrees not to duplicate it in whole or in part nor disclose it to others without the
written consent of Hospira.
CE Configuration Guide 430-11541-001
Contents
INTRODUCTION TO THE MEDNET WIRELESS MODULE . . . . . . . . . . . . . . . . . . . 5
FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
US FCC (FEDERAL COMMUNICATIONS COMMISSION) STATEMENT . . . . . . . . . . . . . 6
FCC INTERFERENCE STATEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
RADIO FREQUENCY EXPOSURE STATEMENT . . . . . . . . . . . . . . . . . . . . . . . . 6
GUIDANCE ON EMC COMPATIBILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
INSTALLING THE HOSPIRA MEDNET® PLUG ’N PLAY MODULE (LIST 20677-04) . . . . . . 8
CONFIGURATION GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
GENERAL NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SCOPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ASSUMPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SCREENS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
STATUS PROPERTIES SCREEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
ETHERNET PROPERTIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
WIRELESS PROPERTIES - WIRELESS ENABLED . . . . . . . . . . . . . . . . . . . . . . .11
SECURITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
SECURITY - WEP SELECTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
SECURITY - WPA PERSONAL SELECTED . . . . . . . . . . . . . . . . . . . . . . . . . .15
SECURITY - WPA ENTERPRISE SELECTED . . . . . . . . . . . . . . . . . . . . . . . . .15
SECURITY - WPA ENTERPRISE SELECTED - AUTHENTICATION TYPE OPTIONS . . . . . . . .16
CERTIFICATES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
HMSS (HOSPIRA MEDNET® SERVER SUITE) . . . . . . . . . . . . . . . . . . . . . . . .18
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
ADMINISTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
FINISH CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
RESETTING THE ETHERNET IP ADDRESS AND SUBNET MASK . . . . . . . . . . . . . .21
WIRELESS LAN DEVICE SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . .21
Notes
430-11541-001 1 CE Configuration Guide
CE Configuration Guide 5 430-11541-001
Introduction to the Hospira MedNet 802.11 a/b/g
Wireless Module
The Hospira MedNet 802.11 a/b/g Wireless
Upgrade Module is designed as an upgrade
module for Hospira Plum A+ Infusion Systems
(Lists 20792, 20679, 12391 & 11791). The
module contains a Custom Wireless USB
adaptor to provide the IEEE802.11 a/b/g
wireless radio functionality. The wireless USB
adaptor is connected to an integral surface
mount Pifa antenna via a coaxial cable. The
wireless USB adaptor and the antenna are
professionally installed at the manufacturing
facility.
The host units are mobile infusion devices
designed to be employed in the medical care
environment. The wireless functionality afforded
to the host units from the upgrade module
include the ability to download drug library
information for simultaneously operating hosts
without requiring a physical connection and the
time spent visiting the rooms they occupy.
Plum A+ Infusion Systems are meant for patient
bedside and mobile applications in a
pole-mounted configuration as is displayed on
the bottom-right.
430-11541-001 6 CE Configuration Guide
FCC Information
US FCC (Federal Communications Commission)
Statement
The wireless USB adaptor device in this module complies with part 15C, 15E of the FCC
Rules. Operation is subject to the following two conditions: (1) This device may not cause
interference, and (2) This device must accept any interference, including that may cause
undesired operation of these devices.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15C, 15E of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy. If not installed and used
in accordance with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try and correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the distance between the equipment and the receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Hospira could void the user's authority
to operate the equipment.
Radio Frequency Exposure Statement
The Wireless LAN radio device in the Connectivity Engine peripheral board with this infusion
device has been evaluated and found compliant to the requirements of the following Radio
Frequency exposure standards:
- Federal Communications Commission, OET Bulletin 65 (Edition 97-01), Supplement C
(Edition 01-01), Evaluating Compliance with FCC Guidelines for Human Exposure to
Radio frequency Electromagnetic Fields, July 2001.
- Industry Canada, Evaluation Procedure for Mobile and Portable Radio Transmitters with
respect to Health Canada's Safety Code 6 for Exposure of Humans to Radio Frequency
Fields, Radio Standards Specification RSS-102 Issue 1 (Provisional): September 1999.
The radiated output power of this Wireless LAN device is far below the FCC radio frequency
exposure limits. The Wireless LAN device has been evaluated with zero mm of separation of
human body from the side of the antenna and with 5 mm of separation of human body from
the top of the antenna and found to be compliant with FCC RF exposure limits.
CE Configuration Guide 7 430-11541-001
Guidance on EMC Compatibility
There is a shared responsibility between manufacturers, customers and users to ensure that
Medical Equipment and Systems are designed and operated as intended. Medical electrical
equipment needs special precautions regarding electromagnetic compatibility and needs to
be installed and used according to the electromagnetic compatibility information provided in
this manual.
The device is suitable for use in all establishments, including domestic establishments. If
extended operation during power mains interruption is needed, use battery power.
Always manage the electromagnetic environment.
The guidance included in this manual provides information needed to:
- Determine the device’s suitability for use in the intended environment.
- Manage the electromagnetic environment to permit the device to perform as intended
without disturbing other equipment.
Separate the device from all other electronic equipment. If the device must be used near
other electrical equipment, monitor the equipment to ensure there is no electromagnetic
interference.
Devices should not be used adjacent to or stacked with other equipment. If the device must
be used adjacent to or stacked with other equipment, monitor the devices to verify normal
operation.
USE ONLY components specifically labeled for use with the Plum A+ Infusion System to help
ensure the device operates as intended.
If you suspect external RF sources or other equipment are influencing device operation,
contact the biomedical engineering department for additional guidelines concerning
electromagnetic immunity.
Contact the biomedical engineering department for additional information in the technical
service manual concerning operating devices near RF sources.
This device has been tested with the Hospira Plum A+ Infusion System and found to comply
with the International Standard IEC 60601-1-2 Edition 2, Electromagnetic Compatibility
(EMC) of Medical Electrical Equipment.
430-11541-001 8 CE Configuration Guide
Installing the Hospira MedNet® Plug ’n Play
Module (List 20677-04)
Note: For use with Hospira Plum A+ Infusers with software version 10.3 and higher.
Note: The recommended tool for this procedure is a No. 2 Phillips screwdriver.
CAUTION: Use proper ESD grounding techniques when handling components. Wear an
antistatic wrist strap and use an ESD-protected workstation. Store the PWA in an antistatic
bag before placing it on any surface.
To Replace the Module, proceed as follows:
1. Press [ON/OFF] to power the infuser
OFF.
2. Disconnect the infuser from AC power.
CAUTION: Infuser must be powered
off for at least 2 minutes prior to
removing the module.
3. Carefully place the infuser face down.
4. Using a No. 2 Phillips screwdriver,
remove the two screws from the module
(one in the upper left corner and one in
the lower left corner). Refer to Figure 1.
5. Carefully pull the module away from the
infuser.
Note: When removing the module, note the placement guides the peripheral PWA rests
between.
6. Install the replacement module in the
exact reverse order of removal using the
screws and lock washers included with
the replacement module. Refer to Figure
2.
Note: Verify the module is placed
properly between the guides and fits
correctly into the CPU PWA.
7. Connect the infuser to AC power.
8. To verify successful module
replacement, power ON the infuser and
let the system perform its self-tests. The
screen will display an E453 Malfunction.
9. Power the infuser OFF, and then ON
again.
10. If upgrading from version 12.x, The infuser is ready for operation.
11. If upgrading from version 10.x or 11.x:
a) Enter the serial number.
b) Power the infuser OFF, and then ON again. The infuser is ready for operation.
Figure 1. Remove Screws
Figure 2. Insert Module
CE Configuration Guide 9 430-11541-001
Configuration Guide
General Notes
This document is a general guide for using the CE Configuration Tool.
Note: Please refer to the Installation and Configuration Guide and the User Guide for
proper use, warnings and cautions associated with the Hospira MedNet® Software.
The application software is a web page server that resides in the CE. From the server on which
HMSS resides, access the infuser Status screen by entering:
https://infuserIPaddress:8443
Note: The default IP address for the infuser is 192.168.0.100 and the Netmask is
255.255.0.0
Scope
The scope of this document is to outline the functionality of the CE Configuration web page that
displays in the Microsoft® Internet Explorer Version 6 browser window.
This document does not address the functionality of the browser in which the web page displays,
nor does it address specific topics related to Ethernet, TCP/IP, Internet, or wireless security and
authentication.
Assumptions
The user has a working knowledge of the following terms, features, concepts and facilities:
Operation of Microsoft® Windows
Operation of Microsoft® Internet Explorer Version 6 browser
Basic understanding of Ethernet, IP addresses, MAC Addresses, Subnet Masks, Gateways,
DHCP, DNS, Domains
Basic understanding of HTTP including Basic Authentication, SSL, user IDs, and passwords
Basic understanding of other Ethernet protocols including Telnet, FTP, TCP, UDP
URL formats including protocol and port specifications
Security configuration including WEP, SSID, Access Points, Authentication Types
Introduction
The following is information provided for general use:
A navigation menu is displayed on the left side of the page
The Tab key has no effect on the navigation menu items (i.e., it will not select or highlight
them)
Unless otherwise specified, “alphanumeric characters” include all upper- and lower-case
letters and numbers
In this document, “character” refers to all upper- and lower-case letters, numbers,
punctuation marks, symbols (i.e., 8-bit character codes between 32 and 126 inclusive)
Note: Popup-blockers must be disabled before using this guide.
Note: Wireless client does not support AES Encryption using Nortel's 2330 Access Points.
430-11541-001 10 CE Configuration Guide
Screens
Note: Hovering your mouse over text fields (such as Identity or Password) will activate
a tooltip with admissible characters.
Status Properties Screen
Screen Function
Status Current status of the CE
Ethernet Properties Ethernet properties settings
Wireless Properties Wireless properties settings
Wireless Security
Properties Wireless security properties settings
Certificates Wireless certificates properties settings
HMSS Properties Hospira MedNet® Server Suite properties
Service Properties Service settings
Administration Administration settings
Finish Configuration Confirmation and results
Configuration Results Configuration results
Field/Button Content/Action
Device Status Device Name: value entered on HMSS Screen
Device Type: Device Type connected to
CE App Version: CE version string
CE System Version: CE system string
Ethernet If Ethernet interface is active: IP Address, Subnet Mask, MAC
Address
If WLAN interface is active: (Interface is down)
Wireless LAN WLAN Interface is Active: IP Address, Subnet Mask, MAC
Address, WEP Enabled, Access Point, SSID, Current Channel,
Signal Quality Level, Noise Level, Frequency Band, Transmit
Power, Power Save
WLAN Interface is not active: (Interface is down)
HMSS HMSS Host/ URL or IP Address
Status: Connected, "Not responding", "(Status is not available)”
Pump Status: Connected, "Not responding", "(Status is not available)"
Refresh Updates all Status sections with current values
Next Displays the Ethernet Properties screen
CE Configuration Guide 11 430-11541-001
Ethernet Properties
Wireless Properties - Wireless Enabled
Field/Button Content/Action
MAC Address (Not configurable, READ ONLY)
Device MAC address
Default: factory default MAC address
Use DHCP Unchecked: Displays IP Address, Subnet Mask, Gateway fields,
DNS1, DNS2, and Domain
Checked: Hides IP Address, Subnet Mask, Gateway fields,
DNS1, DNS2, and Domain
Default: unchecked
IP Address (available when
DHCP is unchecked) IP Address of the device
Default: 192.168.0.100
Subnet Mask (available
when DHCP is unchecked) Subnet Mask of the device
Default: 255.255.0.0
Gateway (available when
DHCP is unchecked) Gateway Host Name or IP Address
Default: Blank
DNS1 (available when
DHCP is unchecked) Primary DNS IP Address
Default: Blank
DNS2 (available when
DHCP is unchecked) -
Optional field
Secondary DNS IP Address
Default: Blank
Domain (available when
DHCP is unchecked) Domain name
Alphanumeric 1-255 characters and the following 3 characters:
Period (.), hyphen (-), underscore (_)
Default: Blank
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Field/Button Content/Action
Wireless Enabled Checked: Enables Wireless Capability and displays the rest of the
fields and checkboxes on the screen
Unchecked: Disables Wireless Capability and hides the rest of
the fields and checkboxes on the screen
Default: Checked
430-11541-001 12 CE Configuration Guide
Use DHCP Unchecked: Displays IP Address, Subnet Mask, Gateway fields,
DNS1, DNS2 and Domain
Checked: Hides IP Address, Subnet Mask, Gateway fields,
DNS1, DNS2 and Domain
Default: unchecked
IP Address (DHCP is
unchecked) IP Address of the device
Default: 192.168.0.100
Subnet Mask (DHCP is
unchecked) Subnet Mask of the device
Default: 255.255.0.0
Renew Lease on Wireless
AP Association Unchecked: Disables DHCP lease renewal on wireless AP
change
Checked: Enables DHCP lease renewal on wireless AP change
Default: unchecked
Gateway (DHCP is
unchecked) Gateway Host Name or IP Address
Default: Blank
DNS1 (DHCP is
unchecked)- Optional field Primary DNS IP Address
Default: Blank
DNS2 (DHCP is
unchecked)- Optional field Secondary DNS IP Address
Default: Blank
Domain (DHCP is
unchecked) Domain name
Alphanumeric 1-255 characters and the following 3 characters:
Period (.), hyphen (-), underscore (_)
Default: Blank
SSID Alphanumeric, space, and the following characters:
~ ! @ # % ^ & * ( ) _ { } | : < > ` - = ; ' , . /
2-32characters
Additionally, the following three characters cannot be the first
character: ! # ;
Frequency 802.11b (2.4GHz)
802.11b/802.11g (2.4GHz)
802.11g (2.4GHz)
802.11a (5GHz)
Auto
Default: Auto (The "Auto" option is comprised of 802.11a, 802.11b
and 802.11g.)
Note: Selecting Auto prompts a sequential search and may be
slower
802.11B Preamble
(Available only when 802.11b/
802.11g is selected)
Long
Short
Default: Long
Field/Button Content/Action
CE Configuration Guide 13 430-11541-001
Security
Important: Security settings, such as identify, password, etc. should conform to
your infrastructure.
Power Save Continuous Access Mode
Maximum Power Save
Default: Maximum Power Save
Transmit Power 100% (maximum), 75%, 50%, 25%, 12%, 6%, 4%, 2%, 1%
(lowest)
Default: 100%
Note: 100%=50 mW; 50%=25 mW; 25%=12.5 mW; Minimum=1
mW
Country List of countries
Default: United States
Note: Selecting a country from the drop-down list, adjusts
automatically the frequency and channels.
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Field/Button Content/Action
Security Disabled
WEP
WPA Personal
WPA Enterprise
When WEP is selected, displays Authentication Type, Key Length,
WEP Keys 0 - 3, and Default Key fields
When WPA Personal is selected, displays Encryption Protocol
and Shared Key field
When WPA Enterprise is selected, displays Authentication Type
and Validate Server Cert objects and fields
Default: Disabled
Field/Button Content/Action
430-11541-001 14 CE Configuration Guide
Security - WEP Selected
Note: If the information is entered incorrectly, an error message will pop-up indicating
what fields needs changing and display the parameters.
Field/Button Content/Action
Security Disabled
WEP (Static only)
WPA Personal
WPA Enterprise
When WEP is selected, displays Authentication Type, Key Length,
WEP Keys 0 - 3, and Default Key fields
When WPA Personal is selected, displays Shared Key field
When WPA Enterprise is selected, displays Authentication Type
and Validate Server Cert objects and fields
Default: Disabled
Authentication Type (WEP
selected) Open
Shared
Default: Open
Key Length WEP 40 (40 + 24/10 hex digits)
WEP 104 (104 + 24/26 hex digits)
WEP Key 0
(Required field if this WEP
key number is selected in
the "Default Key" field)
10 or 26 hex digits
Default: Blank
WEP Key 1
(Required field if this WEP
key number is selected in
the "Default Key" field)
10 or 26 hex digits
Default: Blank
WEP Key 2
(Required field if this WEP
key number is selected in
the "Default Key" field)
10 or 26 hex digits
Default: Blank
WEP Key 3
(Required field if this WEP
key number is selected in
the "Default Key" field)
10 or 26 hex digits
Default: Blank
Default Key 0, 1, 2, 3
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
CE Configuration Guide 15 430-11541-001
Security - WPA Personal Selected
Security - WPA Enterprise Selected
Note: WPA Enterprise requires an authentication server. We support Free Radius and
Cisco ACS.
Field/Button Content/Action
Security Disabled
WEP
WPA Personal
WPA Enterprise
When WPA Personal is selected, displays Shared Key field
Default: Disabled
Encryption Protocol WPA2-CCMP/AES (requires appropriate hardware for access
points)
WPA1-TKIP
Default: WPA2-CCMP/AES
Shared Key 64 (hex) character shared key value or an 8 - 63 ASCII character
pass-phrase
Note: An invalid entry will prompt an error message and display
the field requirements
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Field/Button Content/Action
Security Disabled
WEP
WPA Personal
WPA Enterprise
When WPA Enterprise is selected, displays Authentication Type
and Validate Server Cert objects and fields
Default: Disabled
Encryption Protocol WPA2-CCMP/AES (requires appropriate hardware for access
points)
WPA1-TKIP
Default: WPA2-CCMP/AES
430-11541-001 16 CE Configuration Guide
Note: No format checking is performed at the time a file is uploaded.
Security - WPA Enterprise Selected - Authentication Type options
Authentication Type
(see table below for fields
available according to
settings)
EAP-TLS (Default setting)
EAP-TTLS (FreeRadius only)
EAP-PEAP
EAP-FAST (Cisco ACS only)
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Authentication Type: Field/Content
EAP-TLS (Default) Identity
Validate Server Cert
Note: Placing a checkmark in the box next to Validate Server
Cert: enables the server certificate validation. If checked, a Client
Certificate and an appropriate CA Certificate should be uploaded
on the Certificates page
EAP-TTLS Protocol:
• EAP-MSCHAPv2
• EAP-MD5
•PAP
• CHAP
• MSCHAP
• MSCHAPv2
Identity
Password
Confirm Password
Anonymous identity (Optional)
Validate Server Cert (Optional)
Note: Placing a checkmark in the box next to Validate Server
Cert: enables the server certificate validation. If checked, an
appropriate CA Certificate should be uploaded on the Certificates
page
Field/Button Content/Action
CE Configuration Guide 17 430-11541-001
The software shall support the following file type for WPA Authentication:
FAST PAC File - FAST Protected Access Credential (PAC) file
Note: Two settings are recommended when using EAP-FAST:
1. The AP setting "activity timeout" under the "association" options for "unknown (non-cisco)"
devices. Set to 220 seconds.
2. The ACS setting "AP EAP request timeout (seconds)" under the "system configuration",
and "global authentication" options. Set to 180 seconds (from a default of 20 seconds).
Certificates
This category is optional and will depend upon your network configuration.
EAP-PEAP Peap Inner Protocol:
• EAP-MSCHAPv2
• EAP-MD5
Identity
Password
Confirm Password
Validate Server Cert (Optional)
Note: Placing a checkmark in the box next to Validate Server
Cert: enables the server certificate validation. If checked, an
appropriate CA Certificate should be uploaded on the Certificates
page
EAP-FAST Identity
Password
Confirm Password
Anonymous identity (Optional)
PAC File (Selecting Upload accesses the pop-up Browse
feature)
Important: Verify the ACS server’s system configuration has the
AP EAP request timeout set at 180 and the AP Activity
Timeout “unknown (non-cisco)” default is set at 220
(seconds)
Field/Button Content/Action
Client Certificate Default Hospira Certificate
User Specified Certificate
Default: Hospira Certificate
Client Certificate (User
Specified Certificate
selected)
Private Key File (upload/browse feature)
Password
Confirm Password
Certificate File (upload/browse feature)
Note: A “Success” message appears once the file is loaded and
the file information displays. If the transfer fails, NO error message
will display to notify the user that the upload has failed.
Authentication Type: Field/Content
430-11541-001 18 CE Configuration Guide
The software shall support the following file types for WPA authentication:
CA Certificate - PEM, DER
Client Certificate - PEM, DER
Private Key File - PEM, DER, PFX
HMSS (Hospira MedNet® Server Suite)
CA Certificates Active Certificates
Add Certificate (upload/browse feature)
Note: The software shall allow up to three CA Certificates to be active at
one time
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Field/Button Content/Action
HMSS HostIP Address Server IP address or hostname
Format: alphanumeric and the following (3) characters: Period (.),
hyphen (-), underscore (_). The first character must be an
alpha-character and the last character may not be a hyphen (-)
character. A valid IP address is of the form "xxx.xxx.xxx.xxx"
where xxx is a number between 0 and 255.
HMSS SSL Enabled Checked: Enables SSL mode during HMSS communications
Unchecked: Disables SSL mode during HMSS communications
Default: unchecked
Important: The appropriate port needs to be opened for outbound
traffic. Port 8443 or 8080 for device to HMSS and Port
80 or 443 for HMSS to device
Device Name Device unique ID
1-255 characters or less
Note: We recommend using 15 characters or less. Using more
than 15 characters may affect HMSS report layouts
Default: device00 (must be renamed - cannot be saved as
device00)
Device Type (READ ONLY) Hospira Plum A+ or
Hospira Plum A+(CE) or
Hospira PCA or
Hospira Symbiq
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Field/Button Content/Action
CE Configuration Guide 19 430-11541-001
Service
Telnet and FTP are enabled by default.
Note: We recommend turning off both Telnet and FTP before putting the pump into
production and disabling HTTP access to the device (Port 8008).
Note: Web configuration access to the device using HTTPs (SSL) is always enabled.
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Field/Button Content/Action
Telnet Enabled Checked: The CE Telnet service on port 23 is enabled
Unchecked: The CE Telnet service is disabled
FTP Enabled Checked: The CE FTP service on port 21 is enabled
Unchecked: The CE FTP service is disabled
Non-Secure Configuration
Access (HTTP) Enabled Checked: The non-secure HTTP access to the web configuration
pages is enabled on port 8008
Unchecked: HTTP access to the web is disabled
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Field/Button Content/Action
430-11541-001 20 CE Configuration Guide
Administration
Note: Do not use double-quotes (") in the PSK password field.
Finish Configuration
Note: You may want to verify some or all of the previous screens to ensure the information
is entered correctly. It may take up to 5 minutes to activate the changes.
The Configuration Successful screen displays. If a configuration error occurred, you will be
prompted to use the menu to return to a page of your choice.
Close the browser and remove the Ethernet cable if you wish to test the infuser on wireless mode.
The CE will reboot in 1 - 5 minutes.
Field/Button Content/Action
Web User Web log in username. Format: ASCII, 1-31 characters. Colon (:) is
not allowed
Default: admin
Web Password Web password. Format: ASCII, 1-20 characters
Default: admin
Note: By default the password field is blank but for each character
entered a dot is displayed.
Confirm Password Confirms the password entered displaying as a dot for each
character
Note: An error message displays if the confirmed password does
not match the web password
Previous Displays the previous screen
Reset Allows you to reconfigure the current page only
Finish Displays the Finish Configuration screen and should only be
clicked when all the variables have been entered
Next Displays the following screen
Field/Button Content/Action
Previous Displays the previous screen
Finish Commits the configuration changes to the device
CE Configuration Guide 21 430-11541-001
Resetting the Ethernet IP Address and Subnet
Mask
If the CE has been misconfigured and you cannot communicate with it
using WebConfig, the Reset Button can be used to reset the Ethernet IP
Address and Subnet Mask to the original settings (192.168.0.100)
1. Press and hold the reset button for at least 20 seconds at CE
bootup. This will reset the IP and Subnet mask to known values
so WebConfig can be used.
2. Use WebConfig as needed.
Wireless Lan Device Specifications
Standards: IEEE802.11a/b/g
Transmit Power: 802.11 b/g: 17 dBm
802.11 a: 16 dBm
Antenna: Integral surface mount antenna
430-11541-001-END CE Configuration Guide
For technical assistance, product return authorization, and to order parts, accessories, or manuals within the United
States, contact Hospira Technical Support Operations.
1-800-241-4002
For additional services and technical training courses, visit the website at www.hospira.com.
For technical assistance and services outside the United States, contact the local Hospira sales office.
CAUTION: Federal (USA) law restricts this infuser to sale by or on the order of a physician or other licensed
practitioner.
Plum A+ and LifeCare PCA are registered trademarks of Hospira, Inc. Symbiq is a trademark of Hospira, Inc. Microsoft
and Windows are not trademarks nor registered trademarks of Hospira, Inc.
This document and the subject matter disclosed herein are proprietary information. Hospira retains all the exclusive rights
of dissemination, reproduction, manufacture, and sale. Any party using this document accepts it in confidence, and
agrees not to duplicate it in whole or in part nor disclose it to others without the written consent of Hospira.
DUT INFORMATION
Contains FCC ID: STJ-80411396001
Contains IC No: 5627A-80411396001
Certifications: FCC Part 15.247, 15.407
IC RSS-210, RSS-102
Device Name: Hospira MedNet 802.11 a/b/g Wireless Upgrade Module
Note: For use with Hospira Plum A+ Infusion system
List Numbers Covered: 20791-04-77, 20677-04-77
Note: Above two device model numbers are based on the same assembly. Device Model
20791-04-XX is meant for use in models 20792-04-XX and 20679-04-XX of PlumA+ Infusion
System and device model 20677-04-XX is meant for use in models 12391-04-XX and 11971-04-XX
Plum A+ Infusion Systems.
© Hospira, Inc.
Complies with limits for Class B digital device established
by FCC Rules, Part 15
Attention, consult accompanying documents.
C
C
F

Navigation menu
