IDEMIA Identity and Security France YPSIDE4 YPSID TOKEN User Manual 130429 YpsID E4

SAFRAN MORPHO YPSID TOKEN 130429 YpsID E4

Contents

User Manual

RESTRICTED MORPHO
ypsID E4
This document and the information therein are the property of Morpho, They must not be copied or communicated to a third party without the prior written authorization of Morpho.
User Manual
RESTRICTED MORPHO
YPSID E4 PRESENTATION
Dual interface token:
USB
and contactless
Mobile and contactless payment
E-banking / E-commerce
Based on a 2 chipsets architecture.
1 /
This document and the information therein are the property of Morpho, They must not be copied or communicated to a third party without the prior written authorization of Morpho.
Based on a 2 chipsets architecture.
The main chipset is a certified dual interface smart card chipset.
The front chipset called the Bridge Module (BM) provides:
the USB device interface to communicate with the host (typically a PC or a MAC) ,
an ISO master interface to connect the second chipset, the Crypto Module.
CONFIDENTIAL / Secure R&D
RESTRICTED MORPHO
MOBILE INTERNET (CONTACTLESS)
Mobile internet (on Smartphone, tablet, etc.)
Online authentication (PKI based)
Online signature (PKI based)
All transactions steps are strengthen:
Authentication
Confidentiality
Signature
2 /
This document and the information therein are the property of Morpho, They must not be copied or communicated to a third party without the prior written authorization of Morpho.
Signature
In this use case, the user has to
follow the instruction displayed
by the phone application.
CONFIDENTIAL / Secure R&D
RESTRICTED MORPHO
CONTACTLESS PAYMENT
Mobile and contactless payment
MC and Visa Mobile
MC PayPass and Visa PayWave
When the user wants to realize a transaction, he just has to present the
token to the RFID payment terminal.
3 /
This document and the information therein are the property of Morpho, They must not be copied or communicated to a third party without the prior written authorization of Morpho.
CONFIDENTIAL / Secure R&D
RESTRICTED MORPHO
HOME E-BANKING (USB)
Home E-banking / E-commerce through USB interface
Online authentication (PKI based)
Online signature (PKI based)
All transactions steps are strengthen:
Authentication
Confidentiality
Signature
4 /
This document and the information therein are the property of Morpho, They must not be copied or communicated to a third party without the prior written authorization of Morpho.
Signature
The user just has to follow
the instruction displayed by
the website interface (PIN
writing…)
CONFIDENTIAL / Secure R&D
FCC NOTE：
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF exposure guidelines, this equipment should be
installed and operated with a minimum distance of 20cm between the radiator and your
body.
