IDT Technology SMARTSCALE Weight Scale with BLE User Manual
IDT Technology Limited Weight Scale with BLE
user manual
BLE Body Weight Scale
Model: BW121
User Manual
INTRODUCTION
Congratulations! By purchasing our Oregon Scientific
TM
BLE Body Weight Scale
(BW121), you’ve made the first step toward taking control of your weight. We hope it
could help you easily acquire body weight data and transfer it to your mobile device with
corresponding application through BLE (Bluetooth 4.0 technology). From now on, you
can easily and systematically track your body weight on a daily basis.
Our body weight scale is designed to give you many years of reliable service. Some of
its features include:
User selectable weight measurement in kilograms or pounds.
Patented step-on technology that automatically turns on the scale whenever you
step onto it.
This manual contains important safety and care information, and provides step-
by-step instructions for using this product. To get the greatest benefit from your
purchase, read the manual thoroughly, and keep it in a safe place in case you need to
later refer to it.
WARNING: It is not recommended for persons with implanted medical equipment
such as pacemakers or pregnant women to use the scale.
The scale is intended for home use only, not for hospital diagnosis purposes.
Electronic sensors are sensitive. Be careful not to drop or jar the scale. Place it gently
onto floor surface and store where it will be protected from impact. The scale is an
electronic instrument and should never be submerged in water. Clean with damp cloth
and/or glass cleaner.
Statement of Responsibility
Oregon Scientific assumes no responsibility for any incidental losses (such as the costs
of recording or the loss of income from recording) incurred as a result of faults with this
product.
Oregon Scientific will not be held liable for any bodily injury, death, property damages or
any other claims of whatever nature resulting from the misuse or negligence of this
product, whether intentional or unintentional. Furthermore, Oregon Scientific will not be
responsible for any deviations in the usage of the device from those specified in the user
instructions or any unapproved alterations or repairs of the product.
OVERVIEW
FRONT VIEW
1. LCD display
2. Scale platform
REAR VIEW
LCD DISPLAY
1. Low battery indicator
2. kg: Kilogram
3. lb: Pound
GETTING STARTED
FOR THE FIRST TIME
Unpacking the scale, make sure to keep all the packing materials in a safe place, in case
you need to later transport or return it for servicing.
INSTALL BATTERIES
To insert/replace the batteries:
1. Insert 3 (AAA) alkaline batteries provided
before first use, matching the polarity (+/-).
3. Rubber mat
4. Battery compartment with cover
5. UNIT: Weight unit button
2. Align the cover flat against the battery compartment, and then slide it upwards until it
clicks into place to lock the cover.
Low battery indicator
Please replace the battery when the screen displays .
Please use the batteries we provided at the first time. In the future:
1. Do not use rechargeable batteries. It is recommended that you use alkaline batteries
or consumer grade lithium batteries with this product for longer usage.
2. Reversing the battery polarity may damage the product.
3. Different types of batteries have different characteristics and should not be mixed.
Do not pair old and new batteries together – this can shorten the life of new batteries
and cause old batteries to leak harmful chemicals that can corrode the battery
compartment and cause a rash on your skin. If the batteries leak, wipe the battery
compartment with a clean cloth and wash your hands with warm soapy water after
handling.
4. Remove the batteries if the scale will be in storage for an extended period of time.
5. Do not attempt to open the scale or to remove any components. Servicing should be
done by qualified technicians only.
SELECT WEIGHING UNIT
Toggle UNIT button at the rear of the scale to select your desired weighing unit, kg or lb.
Unit Description Geographic application
Conversion
kg Metric kilogram Global 1 kg = 2.20 lb
lb Imperial pound United States 1 lb = 0.45 kg
SELECT A LOCATION FOR THE SCALE
Set the scale on floor. Surface must be level for accurate operation and safety.
Please avoid thick carpeting.
IMPORTANT INFORMATION
CONCERNING WEIGHT MANAGEMENT
Your scale is the best tool for monitoring weight. While not the only measure of weight
loss, scales is the most popular method used to gauge weight-loss success. A scale
measures the sum of your total body weight, which includes bone, muscle, fat and water.
Body weight fluctuates during the day, and from day to day, depending on a
variety of factors.
Salt and carbohydrate intake can affect the body’s water retention.
A large meal adds weight and can cause water retention.
Dehydration from exercise, illness, or low fluid intake can result in weight loss.
Muscle is also a factor. Heavy-duty resistance training can build muscle, which can
affect weight.
The menstrual cycle can cause temporary weight gains and losses.
Here are 5 rules for effectively monitoring your weight – weigh yourself:
Once a week, on the same day of the week
At the same time of day
In the same place
Wearing the same clothes
Using the same scale
To keep track of your weight, record only one number for the week. This will give you a
clear picture of any trend your weight is following.
For Maintaining Weight
Fluctuations in day-to-day weight tend to be smaller when weight is stable, so a more
frequent weight-in pattern is helpful. To maintain a stable weight:
Weigh yourself more often than once a week.
Use the “5-pound rule” – research shows that people who keep weight within a 5-pound
range are more likely to maintain a healthy body weight over the long term.
TAKE MEASUREMENT
Please remove and discard the display film strip from the LCD screen.
1. Step on the scale to start to measure.
2. Stand still while the measurement is being taken.
3. The scale flashes and then stops with a beep to remind the
reading is complete.
4. If animated - - - - - (dash mode) displays on the screen, it
means the scale is searching for your mobile device for
connection.
OR
If a name is displayed on the screen, that means the
connection is successful, you can read the measurement in
your application (see details for Scale’s Application).
5. The reading disappears from the screen after 5 seconds.
If ERR displays, the scale is unstable while measuring your weight or the weight
on the scale exceeds the scale’s capacity. Make sure to remain still and place the scale
on a flat surface.
If you step on the Scale but leave it before a final reading, the scale will turn off in
15 seconds.
The Scale is a precise meausring instrument that is most accurate when
weighing a stationary object. To ensure the most accurate readings, always try to stand
on the same area of the scale platform and DO NOT MOVE.
IDT APPLICATION
Download the IDT application from your mobile device. It is available in Apple App Store
(iOS version). For details, please see the HELP information in the application.
SPECIFICATIONS
Dimensions 315 x 315 x 25.7 mm
(L x W x H) (12.4 x 12.4 x 1.0 inches)
Weight 1.8kg (3.97 lbs) without battery
Battery 3 x AAA 1.5V alkaline batteries
Weight Measurement
Weight units Kilogram (kg) / pounds (lb) / stone pounds (st-lb)
Maximum Weighing
Capacity
180kg (397.8lb)
Weight display resolution
0.1 kg / 0.2 lb
Operating Environment
Operation temperature 0℃ to 45℃ (32°F to 113°F)
Storage temperature -5℃ to 60℃ (-4°F to 140°F)
ADDITIONAL RESOURCES
Visit our website (www.oregonscientific.com) to learn more about your Body Weight
Scale and other Oregon Scientific TM products such as digital cameras, telephones,
hand-held organizers, alarm clocks, and weather stations. The website also includes
contact information for our customer service department, in case you need to reach us.
Help us protect the environment. Recycle the packaging, batteries, and products after
you no longer need them.
PRECAUTIONS
To ensure you use your product correctly and safely, read these warnings and the entire
user manual before using the product:
• Use a soft, slightly moistened cloth. Do not use abrasive or corrosive cleaning agents, as
these may cause damage. Use lukewarm water and mild soap to clean the watch
thoroughly after each training session. Never use the product in hot water or store it
when wet.
• Do not subject the product to excessive force, shock, dust, temperature changes, or
humidity. Never expose the product to direct sunlight for extended periods. Such
treatment may result in malfunction.
• Do not bend or stretch the transmitter part of the chest belt.
• Do not tamper with the internal components. Doing so will terminate the product
warranty and may cause damage. The main unit contains no user-serviceable parts.
• Do not scratch hard objects against the LCD display as this may cause damage.
• Take precautions when handling all battery types.
• Remove the batteries whenever you are planning to store the product for a long period
of time.
• When replacing batteries, use new batteries as specified in this user manual.
• The product is a precision instrument. Never attempt to take this device apart. Contact
the retailer or our customer service department if the product requires servicing.
• Do not touch the exposed electronic circuitry, as there is a danger of electric shock.
• Check all major functions if the device has not been used for a long time. Maintain
regular internal testing and cleaning of your device. Have your watch serviced by an
approved service center annually.
• When disposing of this product, ensure it is collected separately for special treatment
and not as normal household waste.
• Due to printing limitations, the displays shown in this manual may differ from the actual
display.
• The contents of this manual may not be reproduced without the permission of the
manufacturer.
The technical specifications for this product and the contents of the user manual
are subject to change without notice.
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn more about Oregon Scientific
products.
For any enquiry, please contact our Customer Services at info@oregonscientific.com.
EU-DECLARATION OF CONFORMITY
Hereby, Oregon Scientific, declares that this BLE Body Weight Scale (model: BW121) is
in compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC. A copy of the signed and dated Declaration of Conformity is available on
request via our Oregon Scientific Customer Service.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio / TV technician for help.
DECLARATION OF CONFORMITY
The following information is not to be used as contact for support or sales. Please visit our
website at www.oregonscientific.com for all enquiries.
We
Name: Oregon Scientific, Inc.
Address: 19861 SW 95th Ave.,Tualatin,
Oregon 97062 USA
Telephone No.: 1-800-853-8883
declare that the product
Product No.: BW121
Product Name: BLE Body Weight Scale
Manufacturer: IDT Technology Limited
Address: Block C, 9/F, Kaiser Estate,
Phase 1,41 Man Yue St., Hung Hom, Kowloon,
Hong Kong
is in conformity with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: 1) This device may not cause harmful interference. 2) This device must accept
any interference received, including interference that may cause undesired operation.
