User Manual
Bluetooth Fabric Chest belt SZ999
The SZ999 water resistant chest belt is equipped with the latest low energy Bluetooth 4.0 Sports
System to achieve reliable transmission linkage with other devices that is with the logo .
WEARING THE CHEST BELT
Chest belt
The chest belt counts your heartbeat and transmits this data to the watch.
1. Align the heart rate detector unit with the snap buttons on the
belt strap. Secure by snapping into place.
2. Unfasten the belt strap.
3. Wet the conductive pads on the underside of the chest belt with
a few drops of water or conductive gel to ensure solid contact.
4. Position the heart rate detector unit below your chest, while
making sure logo is the right way up. Wrap the strap around
your chest and fasten into place.
To ensure an accurate heart rate signal, adjust the strap until the belt
sits snugly below your pectoral muscles.
TIPS
• The position of the chest belt affects its performance.
• Avoid areas with dense chest hair.
• In dry, cold climates, it may take several minutes for the chest belt to function steadily. This
is normal and should improve with several minutes of exercise.
TRANSMISSION SIGNAL
The SZ999 chest belt can be paired with your watch or sports accessory to provide heart rate
readings. Locate your chest belt with the device as close as you can to help achieve pairing. The
heart rate chest belt has a maximum transmission range of about 100 centimeters (40 inches).
To search for heart rate signal, refer to watch instructions.
NOTE While pairing, make sure to stay away from other devices and move the device to pair
close to the watch.
NOTE For SZ999 chest belt, pairing is only considered successful when the heart rate signal
(such as an icon ) is found on the screen of your device.
TROUBLESHOOTING
In the event that you experience a weak signal or your signal is disrupted by interference in the
environment, follow the instructions below to identify and resolve the situation.
1. The signal is weak - the device may only show “0”:
• Shorten the distance between the heart rate chest belt and device.
• Re-adjust the position of the heart rate chest belt.
• Check the conductive pads are moist enough to ensure solid contact.
• Check the batteries. If they are low or exhausted, the transmission range may be
shortened.
• Force a signal search on the device.
2. The gym equipment does not seem to work with your chest belt.
• Most gym equipment is compatible with analog transmission. This chest belt does
not transmit an analog signal, it only uses the low energy Bluetooth 4.0 technology.
3. Signal is jammed or there is interference from another person’s heart rate monitor:
• There is too much interference in the environment for your heart rate monitor to
function. Move to an area where the watch can register your heart rate reading
and/or force another signal search.
WARNING Signal interference in the environment can be caused by electromagnetic
disturbances. These may occur near high voltage power lines, traffic lights, overhead lines of
electric railways, electric bus lines or trams, televisions, car motors, bike computers, some motor
driven exercise equipment, cellular phones or when you walk through electric security gates.
Under interference, the heart rate reading may become unstable and inaccurate.
REPLACE BATTERY
Please replace battery promptly as it may affect the accuracy of the readings.
To replace the chest belt battery:
1. Detach the heart rate detector unit from the belt strap.
2. Use a coin to open the battery compartment lid by turning it anticlockwise to open.
3. Remove the old battery and insert a new CR2032, 3V lithium battery. Make sure to place
the battery in the compartment following the polarity +/-.
4. Secure the lid by turning the coin clockwise.
IMPORTANT Remember to set the profiles after every battery replacement or reset.
CARE INSTRUCTIONS
The belt strap can be hand washed. Remember to detach the heart rate detector unit!
• Do not wrap the detector unit in a wet towel nor with other wet materials.
• Do not place or wash the heart rate detector unit under running water, instead clean it with a
wet cloth.
• Properly dry the detector unit immediately after use.
• Do not store the chest belt in a hot (about 50°C) and humid (about 90%) environment.
• Do not place the conductive rubber face down on a metal table or surface.
• Do not bleach, dry clean, tumble dry or iron the belt strap.
WATER RESISTANCE
The SZ999 is water-resistant up to 10 meters (32.8 feet). Not recommended to use for swimming.
RAIN
SPLASHES
ETC
SHOWERING
(WARM /
COOL
WATER
ONLY)
LIGHT
SWIMMING /
SHALLOW
WATER
SHALLOW
DIVING /
SURFING /
WATER
SPORTS
SNORKELING
/ DEEP
WATER
DIVING
10M / 32.8 FT
OK
NO
NO
NO
NO
NOTE Ensure the battery compartment is secured and intact before exposing to excessive water.
SPECIFICATIONS
Heart rate detector dimension
(L x W x H)
66.1 x 38 x12.5 mm
(2.6 x 1.5 x 0.49 inches)
Power
1 x CR2032 3V lithium battery
Operating temperature
5˚C to 40˚C (41˚F to 104˚F)
Storage temperature
-20˚C to 60˚C (-4˚F to 140˚F)
PRECAUTIONS
To ensure you use your product correctly and safely, read these warnings and the entire user
manual before using the product:
• Use a soft, slightly moistened cloth. Do not use abrasive or corrosive cleaning agents, as
these may cause damage. Use luke warm water and mild soap to clean the watch and chest
belt thoroughly after each training session. Never use the products in hot water or store them
when wet.
• Do not bend or stretch the transmitter part of the chest belt.
• Do not subject the product to excessive force, shock, dust, temperature changes, or humidity.
Never expose the product to direct sunlight for extended periods. Such treatment may result
in malfunction. Do not tamper with the internal components. Doing so will terminate the
product warranty and may cause damage. The main unit contains no user-serviceable parts.
• Take precautions when handling all battery types.
• Remove the batteries whenever you are planning to store the product for a long period of
time.
• When replacing batteries, use new batteries as specified in this user manual.
• The product is a precision instrument. Never attempt to take this device apart. Contact the
retailer or our customer service department if the product requires servicing.
• Do not touch the exposed electronic circuitry, as there is a danger of electric shock.
• Check all major functions if the device has not been used for a long time. Maintain regular
internal testing and cleaning of your device. Have your watch serviced by an approved
service center annually.
• When disposing of this product, ensure it is collected separately for special treatment and not
as normal household waste.
• Due to printing limitations, the displays shown in this manual may differ from the actual
display.
• The contents of this manual may not be reproduced without the permission of the
manufacturer.
NOTE The technical specifications for this product and the contents of the user manual are
subject to change without notice.
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn more about Oregon Scientific products.
For any enquiry, please contact our Customer Services at info@oregonscientific.com.
FCC / IC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired operation.
WARNING Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio / TV technician for help.
DECLARATION OF CONFORMITY
The following information is not to be used as contact for support or sales. Please visit our
website at www.oregonscientific.com for all enquiries.
We
Name: Oregon Scientific, Inc.
Address: 19861 SW 95th Ave.,Tualatin,
Oregon 97062 USA
Telephone No.: 1-800-853-8883
declare that the product
Product No.: SZ999
Product Name: Bluetooth Chest belt
Manufacturer: IDT Technology Limited
Address: Block C, 9/F, Kaiser Estate,
Phase 1,41 Man Yue St.,
Hung Hom, Kowloon,
Hong Kong
is in conformity with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: 1) This device may not cause harmful interference. 2) This device must accept any
interference received, including interference that may cause undesired operation.
