TRANSMITTER – E1201C ANSLUTA
USER INSTRUCTION
A. Features
1. Easy and simple to use.
2. Blinking blue LED indicates signal transmission status.
B. Diagram & Descriptions
i
ii
No.
Description
Function
i
indicator
The indicator blinks to indicate signal transmission status.
ii 1 OFF,1 ON Switch on and off the appliances connected to channel 1 receiver E1201
C. Operation
1. Configure
Press the“ON/OFF Learning Code ”button on the receiver until the LED “Indicator” blinks. Then press
any one of the four “OFF” buttons until the red LED “Indicator” goes off. The receiver is trained to
respond to the corresponding channel.
2. Control
Press the “ON” or “OFF” button to switch on or off the appliance connected to the receiver trained to the
corresponding channel.
.
D. Specifications
1. Battery : 2X AAA
2. Frequency : 433.92 MHz
3. Distance : 20 meters max. (in the open air)
E. Holder
IKEA of Sweden, AB
Manufactory: Everflourish Electrical Co., Ltd.
Adress:Renjiu Village, Wuxiang Town, Yinzhou Ningbo 315111 P.R. China
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé
pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de
brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente
(p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication
satisfaisante.
