1. Hardware
1) Bluetooth Core : BC3_Audio FLASH
2) Memory: Int. 6MB FLASH
3) Ant.: Chip Antenna
4) Mic: SDM (Special Directional MIC), Sensitivity : -47dB, CosmoSound Technology
5) Switch (3 Button, 1 Slide) : MFB (Multi Function Button) Tact SW
Volume +, Volume – Tact SW
MIC Gain (High or Low) – Slide SW
6) Regulator: Integrated Switch-mode Regulator (output : 1.8V)
Integrated Linear Regulator (output: 1.8V)
7) Charger: Integrated Battery Charger
(Programmable Current (25~100mA), DC 4.5V~6.5V Input Range)
8) Battery: Size : 4.0(T) X 12(W) X 35(L) (120mAh)
9) Mini USB Port: DC_IN(5V), SPI, UART
2. Bluetooth Profile & Stack
1) Bluetooth Stack V 1.2
2) Hands-Free Profile V 1.5
3) Headset Profile V 1.1
3. Specification
1) Bluetooth
Sensitivity: -84dBm Max0.1% BER
Output Power: Typically 2dBm (Class2)
2) Power Consumption
Standby: 1mA
Active Call: About 20mA
4. Features
1) Talk Time : Up to 6 Hours
2) Standby Time : 120 Hours
3) Charging Time : About 2 Hours
4) Range : 10 meters
5) Battery Type : Lithium-polymer
6) Version : Bluetooth v2.0
5. Operating Process
1) Power On/Off
- Power ON
Press Talk button for 2 seconds, Blue LED will blink 3 times when it’s Power Off.
- Power OFF
Press Talk button for 6 seconds. Red LED will blink 4 times indicate Power Off.
2) Reset Device List
In order to set Primary AG (Audio Gateway), you should delete address memorized in the
headset.
Press Talk button and Vol(-) button at the same time for 2 seconds and more, then Red and
Blue LED will blink 2 times.
3) Multi-Point Pairing
Sound Port II has an ability to pair with 2 Audio Gateway or the BT Cell phone at the same
time. When you have another incoming call while you are on the phone, you will hear an
incoming call signal through the headset. Then the call you've had will be disconnected and
the new caller will be connected.
It’s possible to have Two Profile (HFP/HSP) connection simultaneously. (Multi-Point Connect
function)
To initiate the device pairing, it’s required to reset the other AG pairing information
memorized on the headset.
Please refers to 2) Reset Device List for the reset method.
Press “Vol(+) button” and “Vol(-)button” at the same time for 2 seconds when it’s Power On,
it goes pairing mode.
Red LED and Blue LED will blink alternately.
When linking the device supporting HFP first, RED LED and BLUE LED blink for three
times which is a pairing mode signal.
Then press VOL (+) and VOL(-) simultaneously again for 2 seconds and more, then
the previous connection with AG will be end.
Connect 2nd AG supporting HSP and choose Soundport II from Bluetooth list of AG and
press a connection button, then the connection with two devices is completed.
When linking the device supporting HFP first, RED LED and BLUE LED blink for three
times which is a pairing mode signal.
Then press VOL (+) and VOL(-) simultaneously again for 2 seconds and more, then
the previous connection with AG will be end.
Connect 2nd AG supporting HSP and choose Soundport II from Bluetooth list of AG and
press a connection button, then the connection with two devices is completed.
HFP will be primary AG and HSP will be secondary AG.
* Attention facts when pairing with two Mobile phones:
It's unable to pair SoundPort II with a same profile at the same time.
One should be HFP and the other should be HSP. Also if you registered a new AG, press
Talk button and Vol (-) button at the same time for 2 seconds and more in order to delete the
pairing information. In this case, the AG with HFP profile should be the primary AG and HSP
should be secondary.
<Available Multi-Point Pairing setting up with Sound Port II>
BT Phone A BT Phone B SoundPort II
HFP HSP OK
HSP HFP OK
HFP HFP Not support
HSP HSP Not support
4. Sending and receiving a call
In order to make a call, press the talk button on the headset, then the call will connect
at the primary device.
If you push the talk button shortly, the last number will be redialed and if you press the
talk button for 2 seconds and more, the voice dial will be operated.
(Voice dial function will be supported depends on the kinds of Mobile phones)
To receive a call, push the talk button shortly and if you want to reject the call, press
the talk button for 2 seconds and more.
If you have another call while you are having a call on the primary device, you will hear
the melody from the secondary device. If you push the talk button shortly, the
connection at the primary AG will be discontinued and the push the talk button shortly
again, the call from secondary AG will be connected.
After complete the call, press the talk button, then you can make another call from
Primary AG again.
5. Charging
- Connect the power cable to Mini USB port.
- Red LED will be turned on during charging, then it will be turned off after full charge.
6. Button Operation
* VOL (+/-) Button
1) Press “Vol (+) button” and “Vol (-)button” at the same time for 2 seconds, it goes pairing
mode.
2) Press the Vol (+) button shortly, volume lever will increase by one step.
Press the Vol (+) button longer, volume level will increase continuously.
3) Press the Vol (-) button shortly, volume level will decrease by one step.
Press the Vol (-) button longer, volume level will decrease continuously.
* Talk Button
1) Press Talk button for 2 seconds when it’s Power Off, it will be turned on.
2) Press Talk button for 6 seconds when it’s Power On, it will be turned off.
3) Press the Talk button shortly to receive a call.
4) Press the Talk button for 2 seconds and more to reject a call.
5) It will be disconnected when you push the Talk button shortly during the phone.
6) If you press the talk button for 2 seconds and more while you are on the phone, phone
mode will work on the Mobile phone from Headset.
* MIC Gain Select Switch
1) Switch UP: High Gain
2) Switch down: Low Gain
6. SoundPort II LED Status
LED COLOR RED (1) BLUE (2)
Status
Event
ON
(ms)
OFF
(ms)
Repeat
(ms)
Flash
Num.
Repeat
Num.
ON
(ms)
OFF
(ms)
Repeat
(ms)
Flash
Num.
Repeat
Num.
Power On · · · · · 100 100 0 4 0
Connectable · · · · · 100 100 4000 1 0
Connectable/Discoverable · · · · · · · · · ·
Connected · · · · · 100 100 3000 3 0
Active Call · · · · · 100 100 3000 4 0
Power Off 100 100 0 4 0 · · · · ·
Low Battery 100 100 5000 1 0 · · · · ·
Reset Device List · · · · · · · · · ·
Pairing Successful · · · · · · · · · ·
LED COLOR ALT (3) BOTH (4)
Status
Event
ON
(ms)
OFF
(ms)
Repeat
(ms)
Flash
Num.
Repeat
Num.
ON
(ms)
OFF
(ms)
Repeat
(ms)
Flash
Num.
Repeat
Num.
Power On · · · · · · · · · ·
Connectable · · · · · · · · · ·
Connectable/Discoverable 100 100 100 2 0 · · · · ·
Connected · · · · · · · · · ·
Active Call · · · · · · · · · ·
Power Off · · · · · · · · · ·
Low Battery · · · · · · · · · ·
Reset Device List · · · · · 100 100 0 2 0
Pairing Successful · · · · · 100 100 0 3 0
FCC compliance Information
This device complies with part 15 of FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received.
Including interference that may cause undesired operation.
Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device,
Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio Frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver- Connect the equipment into an outlet
on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Cautions
Modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
