INTELLIGENT SYSTEMS FULLW001 WLAN Module User Manual FULLW001 x
INTELLIGENT SYSTEMS Co.,Ltd. WLAN Module FULLW001 x
Manual
FULLW001
User manual
The “J27H023.01 WLAN MODULE” made by HON
HAI Precision Ind. Co., Ltd. is embedded.
2015 INTELLIGENT SYSTEMS CO.,LTD.
Released: January 30 2015
2
Introduction
The J27H023.01 802.11b/g module provides wireless modem functionality utilizing direct sequence
spread
spectrum and OFDM/CCK
technology.
1.1 WLAN Features
Operating Frequency 2412 ~ 2483.5 MHz ISM
band
Modulation Schemes 802.11b (DSSS): DBPSK, DQPSK, CCK
802.11g (OFDM): BPSK, QPSK, 16QAM, 64QAM
Channel Numbers IEEE 802.11 g
compliant:
1 ~ 11 channels for United
States
1 ~ 13 channels for Europe,
Japan
IEEE 802.11 b
compliant:
1 ~ 13 channels for United States, Europe and
Japan
WLAN Data Rate 802.11g: Up to 54 Mbps with auto fallback to 48, 36, 24, 18,
12,
9 and 6
Mbps.
802.11b: Up to 11 Mbps with auto fallback to 5.5, 2 and
1Mbps.
Media Access Protocol CSMA/CA with
ACK
Output Power 8.02.11g: 15.06dBm (Conducted)
8.02.11b: 9.18dBm (Conducted)
Antenna Type Single antenna connector for off board
antenna
Operating Voltage 1.8 VDC and 3.3
VDC
Operating Systems Windows
98/Me/2000/XP
3
1.2 FCC Notice
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in
a residential installation. This equipment generates uses and can radiate radio frequency energy and, if
not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment
off and on, the user is encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)
This device may not cause harmful interference, and (2) this device must accept any interference
received,
including interference that may cause undesired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance
could void the user's authority to operate this
equipment.
4
IMPORTANT
NOTE:
FCC Radiation Exposure
Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
This transmitter must not be co-located or operating in conjunction with any other antenna
or
transmitter.
FOXCONN declared that J27H023.01 is limited in CH1~11 from 2412 to 2462 MHz (802.11g) by
specified
firmware
controlled in
USA.
This device is intended only for OEM integrators under the following
conditions:
The antenna must be installed such that 20 cm is maintained between the antenna and users,
and
The transmitter module may not be co-located with any other transmitter or
antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the
OEM
integrator is still responsible for testing their end-product for any additional compliance
requirements
required
with this module installed (for example, digital device emissions, PC peripheral requirements,
etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain
laptop
configurations
or co-location with another transmitter), then the FCC authorization is no longer considered
valid
and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will
be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate
FCC
authorization.
End Product
Labelling
This transmitter module is authorized only for use in device where the antenna may be installed such
that
20 cm may be maintained between the antenna and users. The final end product must be labelled in
a
visible area with the following: “Contains FCC ID: SRX-FULLW001
”.
Manual Information That Must be
Included
The OEM integrator has to be aware not to provide information to the end user regarding how to install
or
remove this RF module in the user manual of the end product which integrates this
module.
The users manual for OEM integrators must include the following information in a prominent
location
“IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for
this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not
be
co-located or operating in conjunction with any other antenna or
transmitter.
1.3 Canada Notice
Industry Canada
Statement
This radio transmitter (IC: 5567A–FULLW001) has been approved by Industry Canada to operate with the
antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list,
having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this
device.
Antenna type: 1/2 lambda type
Gain: 2.14 dBi
Impedance: 50 ohms
Le présent émetteur radio (IC: 5567A–FULLW001) a été approuvé par Industrie Canada pour fonctionner avec
les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne non inclus
dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour
5
l'exploitation de l'émetteur.
Type d'antenne: Type 1/2 lambda
Gain: 2.14 dBi
Impédance: 50 ohms).
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement
End Product
Labelling
This transmitter module is authorized only for use in device where the antenna may be installed such
that
20 cm may be maintained between the antenna and users. The final end product must be labelled in
a
visible area with the following: “Contains IC: 5567A-FULLW001
”.
