GSM Mobile Phone
I5230
User’s Manual
Contents
1 General Information.......................................................................................................................3
1.1 Introduction.........................................................................................................................3
1.2 Safety ..................................................................................................................................3
1.3 Warning and Notice.............................................................................................................4
1.3.1 Basic Notices................................................................................................................... 4
1.3.2 Notices of Your Phone .....................................................................................................4
1.3.3 Notices of Battery Use..................................................................................................... 5
1.3.4 Notices of Charger Use................................................................................................... 5
1.3.5 Care and Maintenance.................................................................................................... 6
1.3.6 General Notices............................................................................................................... 6
2 Getting Started ...............................................................................................................................7
2.1 Overview and Introduction .................................................................................................7
2.1.1 Product Specification...................................................................................................... 7
2.2 Keypad ................................................................................................................................7
2.3 Battery.................................................................................................................................7
2.4 Network Connections..........................................................................................................8
2.4.1 SIM Card......................................................................................................................... 8
2.4.2 Insert and Remove the SIM Card .................................................................................... 8
2.4.3 Turn Your Phone On or Off ............................................................................................. 8
2.4.4 Phone unlock................................................................................................................... 9
2.4.5 Unlock the SIM Card.......................................................................................................9
2.4.6 Connect to the Network................................................................................................... 9
2.4.7 Make Calls ...................................................................................................................... 9
2.4.8 Make Domestic Calls .................................................................................................... 10
2.4.9 Dial Extension............................................................................................................... 10
2.4.10 International telephone Calls...................................................................................... 10
2.4.11 Dial the Numbers of Phonebook.................................................................................. 10
2.4.12 Emergency Number......................................................................................................11
2.4.13 Answer Calls ................................................................................................................11
2.4.14 Call Records.................................................................................................................11
2
2.4.15 Call Menu.....................................................................................................................11
3 Function Menus............................................................................................................................12
3.1 Use of Function Menus.....................................................................................................12
Scroll Searching and Selection Function ............................................................................... 12
Exit Menus.............................................................................................................................. 12
3.2 Call Center ........................................................................................................................12
3.2.1 Call history.....................................................................................................................12
3.3 Phonebook.........................................................................................................................13
3.4 Messages...........................................................................................................................13
3.4.1 SMS ............................................................................................................................... 13
3.4.1.1 Write Message.............................................................................................14
3.4.1.2 Inbox ...........................................................................................................14
3.4.1.3 Outbox.........................................................................................................14
3.4.1.4 Draft ............................................................................................................14
3.4.1.5 SMS Settings...............................................................................................14
3.4.2 MMS.............................................................................................................................. 15
3.5 Settings..............................................................................................................................16
3.5.1 Dual SIM settings...........................................................................................................16
3.5.2 Phone settings ................................................................................................................16
3.5.3 Network settings.............................................................................................................17
3.5.4 Security settings.............................................................................................................17
3.5.5 Restore factory settings..................................................................................................17
3.6 Services.............................................................................................................................17
3.6.1 STK Service................................................................................................................... 17
3.6.2 WAP............................................................................................................................... 17
3.6.3 Date Account................................................................................................................. 18
3.7Alarm .................................................................................................................................18
3.8 Camera..............................................................................................................................18
3.9 Organizer...........................................................................................................................19
3.9.1 Bluetooth........................................................................................................................19
3.9.2 Calculator.......................................................................................................................19
3.9.3 World clock ....................................................................................................................19
3.9.4 Torchlight.......................................................................................................................19
3.10 Audio player....................................................................................................................19
3.11 Profiles ............................................................................................................................19
3.12 Calendar..........................................................................................................................20
3.13 Multimedia...................................................................................................................20
3.13.1 Phone TV .....................................................................................................................20
3.13.2 Image Viewer ...............................................................................................................20
3.13.3 Video recorder..............................................................................................................20
3.13.4 Video player .................................................................................................................21
3.13.5 Sound Recorder............................................................................................................21
3.13.6 FM radio.......................................................................................................................21
3.14 Fun&Games ....................................................................................................................21
![](/img.php?id=1802463&img=bg3.png)
3
3.14.1 Games...........................................................................................................................21
3.14.1.1 UFO...........................................................................................................................21
3.15 Application......................................................................................................................21
3.15.1 Facebook......................................................................................................................21
3.13.2 Yahoo............................................................................................................................21
3.15.3 Twitter ..........................................................................................................................21
3.15.4 Opera mini....................................................................................................................22
3.16 File manager....................................................................................................................22
4 Input Method................................................................................................................................22
General Outline.......................................................................................................................22
Screen Key values...................................................................................................................22
5 T-flash Card and USB ..................................................................................................................22
5.1 Insert and Remove T-flash Card........................................................................................22
5.2 Use of T-flash Card ...........................................................................................................23
5.3 USB...................................................................................................................................23
6 Troubleshooting ...........................................................................................................................23
1 General Information
1.1 Introduction
We are pleased that you have chosen this color-screen mobile phone. For your safe and
efficient use of the phone, you can read this manual before you use the phone.
The phone is designed for GSM/GPRS network environment. Apart from calling, it also
provides some practical functions, such as associative English input method, card-folder phonebook,
individualized sound and pictures of incoming calls, 64 polyphonic ringtone, SMS, camera & video
recorder, music & media player, voice recorder, clock, alarm clock, calculator, T-flash, STK, keypad
lock, USB, Bluetooth. Moreover, its individualized user interface and functional design can meet your
various requirements.
The phone is designed in accordance with the technical specifications of GSM/GPRS. It also
obtains authentication of domestic and international authorities.
Manufacturers reserve the right to revise this manual without giving advance notice.
1.2 Safety
If your phone has been lost or stolen, contact telecommunication department or its agencies so
as to forbid the use of your phone and SIM card. Your prompt action can prevent others from
personator calls which will result in your pecuniary loss.
When you contact telecommunication department or its agencies, they will require IMEI code.
The IMEI code is printed on the label of the phone back and you can see it when you remove the
battery. You should copy the code and keep it properly for future need.
In order to avoid the misuse of your phone, you shall take the following measures:
Set PIN code of your SIM card and alter it before others have known it.
Do not put your phone in the visible places before you leave the car. You’d better keep
4
it with you or lock it in the boot.
Set Call Barring.
1.3 Warning and Notice
For your safe and proper use of the phone, read these guidelines before you use the phone.
1.3.1 Basic Notices
Do use the batteries and chargers approved by the manufacturer. The disapproved products
may cause battery leakage, overheating, burst or fire.
Do not strike, shake or sling your phone. It can prevent damage or fire.
Do not place your phone, battery or charger in microwave oven or high-voltage equipment;
otherwise it may cause accidents, such as circuit damage or fire.
Do not use your phone in the place where there is inflammable and explosive gas; otherwise
it may cause your phone failure or fire.
Do not put your phone in the place of high temperature, high humidity or the place where
there is a lot of dust; otherwise it may cause your phone failure.
Keep your phone out of the reach of children. It can prevent children from playing your
phone as a toy and the subsequent body injury.
Do not place your phone at the unsmooth or unstable table; otherwise your phone may fall
from the table and get damage.
1.3.2 Notices of Your Phone
Turn off your phone in any facility where using mobile phone is forbidden. These facilities
may include airplanes and hospitals. The phone can influence the regular operation of electronic
devices and medical devices. Therefore, any use of the phone must be in accordance with applicable
regulations of the facility. Your phone is of automatic turn-on function. You should check the setting of
clock alarm in order to ensure your phone will not be automatically turned on while the airplane is
flying.
Do not use your phone in the place of poor signal or near the electronic devices of high
definition. The interference of radio wave may cause electronic devices’ misoperation or other
problems, especially to audiphones, pacemakers and other medical electronic devices, fire detectors,
automatic doors and other automatic control devices. You can consult the manufacturer or seller of the
medical device about the influence of the phone on the pacemaker or other medical devices.
Do not press the LCD strongly or strike other things with your phone; otherwise it can cause
damage to LCD or leakage of LCD liquid. If LCD liquid accidentally gets into your eye, you may
become blind. At this very moment, do not knead your eye. You should immediately wash your eye
with water and then go to hospital.
Do not dismantle or refit your phone; otherwise it will cause damage to your phone, leakage
of electricity and circuit failure.
In few situations, your phone may have bad influence on electronic devices in some car. Do
not use your phone so as not to lose security.
Do not press the keys with sharp things, such as needle or nib; otherwise it may cause
damage to your phone or misoperation.
Do not use your phone if its antenna is damaged; otherwise it may cause injury to the person.
5
Do not put your phone too near magnetic objects, such as the magnetic card; otherwise the
radiation wave of the phone may eliminate the information stored in floppy disk, debit card and credit
card
Do put the small metal objects such as thumbtack far away from the earphone because the
loudspeaker is magnetic while it is working and it can attract these small metal objects. It may cause
injury to the person or damage to the phone.
Keep your phone dry. If water or other liquid gets into the phone, it may cause overheating,
leakage of electricity or failure of your phone.
1.3.3 Notices of Battery Use
Do not cast the battery into the fire; otherwise it can cause fire or burst.
Do not install the battery strongly; otherwise it can cause leakage of electrolyte, overheating,
burst or fire.
Do not short-circuit the battery with metal objects, such as electrical wiring or needle. Do not
put the battery together with metal objects such as necklace; otherwise it may result in leakage of
electrolyte, overheating, burst or fire.
Do not weld the positive (+) and negative (-) of the battery; otherwise it may result in leakage
of electrolyte, overheating, burst or fire.
If battery electrolyte accidentally gets into your eye, you may become blind. At this very
moment, do not kneading your eye. You should immediately wash your eye with water and then go to
hospital.
Do not dismantle or refit the battery; otherwise it can cause leakage of electrolyte,
overheating, burst or fire.
Do not use or put your phone near the fire or in the place where is of high temperature;
otherwise it can cause leakage of electrolyte, overheating, burst or fire.
If the battery is calefactive, color-changing or transformative while is it is charging, using or
preserve, do stop using it and change a new battery.
If battery electrolyte contacts skin or clothes, it may burn the skin. Do wash the skin with
water immediately and go to hospital if necessary.
If electrolyte leaks out of the battery or send out strange smell, put the battery far away from
the fire immediately in order to avoid fire or burst.
Keep the battery dry; otherwise it can cause overheating, smoking or erosion of the battery.
Do not use or put the battery in the places of sunlit or high temperature; otherwise it can
cause leakage of electrolyte or overheating. Moreover, it can reduce the capacity and lifetime of the
battery.
Do not charge the battery continuously over 24 hours.
1.3.4 Notices of Charger Use
You can use Charger or connect it to PC for your phone with dateline.
Do use alternating current of 220V. Using other voltage can cause leakage of electricity, fire
or damage to your phone and the charger.
Do not short-circuit the charger; otherwise it can cause electric shock, smoking or damage to
the charger.
6
Do use the charger while the power line is damaged; otherwise it can cause fire or electric
shock.
Do wipe the socket and remove the dust in time
Do not place the container filled with water near the charger; otherwise it can cause
overheating, leakage of electricity and failure if water spills out.
If the charger accidentally contacts water or other liquid, you should immediately unplug the
charger so as to avoid overheating, fire, electric shock or failure of the charger.
Do not dismantle or refit the charger; otherwise it can cause electric shock, fire, damage to
the charger or injury to the person.
Do not use the charger in the place of high humidity, such as bathroom; otherwise it can
cause electric shock, fire or damage to the charger.
Do not touch the charger, power line and socket with wet hand; otherwise you can get an
electric shock.
Do not put heavy things on the power line or refit the wire; otherwise it can cause electric
shock or fire.
Do unplug the charger before you clean and maintain it.
Do Hold the charger if you unplug it. Do not pull the power line. It may damage the wire and
cause electric shock or fire.
1.3.5 Care and Maintenance
Your phone, battery and charger are not waterproof. Therefore, do not use them in the place
of high humidity, such as bathroom. They should also avoid shower.
Do clean your phone, battery and charger with the soft and dry cloth.
Do not wipe your phone with alcohol, diluents or benzene.
Do wipe the socket regularly. The dirty socket can result in bad contact, unsteady power and
no recharge.
1.3.6 General Notices
The Phone
Your phone must be used in the places where the temperature is below 40°C and above 5°C
and the humidity is below 85% and above 35%.
Do stay way from telephone, television, and radio and office automatic instrument while you
are using the mobile phone. It can prevent the interference of your phone and the abovementioned
instruments.
The Battery
Do put the battery in the ventilated place and keep it away from the sunlit place.
The battery is of limited lifetime and frequent charging can reduce its capacity. If the battery
cannot be charge, change a new approved battery.
Do not dispose of the battery as household waste. The battery must be disposed of in
accordance with the regulations.
The Charger
Do not charge the battery in the following places: the sunlit place, the place where the
temperature is below 40°C and above 5°C, the place of humility, dust or severe shake and the place
![](/img.php?id=1802463&img=bg7.png)
7
near the television, radio or other electrical appliances.
2 Getting Started
2.1 Overview and Introduction
2.1.1 Product Specification
Phone
Model
Dimension
Weight
Battery
Model
Nominal Voltage 3.7V
Limiting Voltage 4.2V
Rated Capacity
Standby Time
Talk Time
Model
Input
2.2 Keypad
“Press some key” hereof indicates that press the key and then relax it; “Press and hold some
key” hereof indicates that press and hold the key for two or more seconds.
2.3 Battery
The initial state of battery charge of about 50% the electricity. The first three complete charge
please run out of power after the full use of this battery easy to achieve the best use of state.
Install and Remove the Battery
You should follow these steps to remove the battery: Open the battery back; Remove the ①②
battery from back-end mobile phones.
You should follow these steps to install the battery: Insert the front①-end of the battery into the
phone; Put the rear cover back.②
Charge the Battery
Plug in the charger.
Insert the connector plug into the connector port on the bottom of your phone.
Then the Battery Level icon displays in top right corner of the screen will flicker regularly. If
your phone is power off, a charge indicator will display in the screen and indicates that the battery is
charging. If the battery is too low the charge indicator will display in the screen for a moment.
When the icon is full and does not flicker, it indicates that the battery is completely charged.
8
If your phone is power off, the system will display “charging complete”. The charging process usually
spend 3-4 hours. In the process of charging your phone、battery and charger will become hot that it is a
normal phenomenon.
Notice:
The phone must be charged with the approved charger in the ventilated places where
temperature is below 40°C and above 5°C.The use of any other disapproved battery may
invalidate any warranty, and may be dangerous.
When your phone is automatically turned off or indicates the power will be exhausted, you
should charge the battery in time. If the battery is not exhausted, the charging time will be
shorter than the normal time.
The data of suspended time and talk time is provided by manufacturer is based on the ideal
working environment. But actual working time depends on the network environment, working
environment and usage method.
Do check if the battery has been well installed before charging. Do not remove the battery
while charging.
Remove the connection between charger and batter after the battery is completely charged.
If you do not remove the connection between charger and batter, the battery will be charged
in 5-8 hours. We suggest that you don’t do it, because it can shorten battery lifetime.
2.4 Network Connections
2.4.1 SIM Card
You must insert an effective SIM card into your phone before you use the phone. SIM card into
your digital GSM network key.
All the information of network connection and the initial call record is stored in the metal area
of SIM card. It also stores your phonebook and SMS. SIM card can be removed from your phone and
used in any mobile phone of GSM network. (The new phone will automatically read the SIM card)
In order to avoid the SIM card information will be lost, you should put SIM card far away from
the place of electricity or magnetism and do not touch the metal area of SIM card. Once SIM card is
damaged, you cannot logging in GSM network.
Caution: Do turn off your phone before you remove SIM card. Do not insert or remove SIM
card when the phone is power on; otherwise SIM card can be damaged.
2.4.2 Insert and Remove the SIM Card
SIM card is usually placed in a card. You should take it out carefully before you insert it into your
phone.
Turn off your phone and remove the battery or external power.
Insert SIM card into the card slot as shown below
When you want to remove SIM card, turn off your phone and remove the battery. Then you
can take out SIM card.
2.4.3 Turn Your Phone On or Off
Press and hold Power Key to turn on your phone. Do the same thing to turn off your phone.
If you have not installed SIM card, your phone will request you to insert SIM card. The phone
9
check if the card can be used after the card has been installed. Then the screen will display the
following indications sequentially.
Input SIM1(2) PIN: was set up SIM password..
Input Phone lock code: was set up cell phone password.
Searching: phone will search until found a suitable network connection.
2.4.4 Phone unlock
In order to prevent the illegal use your mobile phone can be set up password-protected. Elected to
user this feature, you must enter a password so you can unlock the phone when you turn on phone
every time, and send or receive calls. You can remove passwords (see 3.5.4 of the “Security setting”).In
this case, the phone cannot prevent the illegal use of.
Enter the password phone, right soft key can clear input error. For example, if the phone
password is set to 1122, you must enter “1122”.
If you forget your phone password, you must contact your local retailer or authorized service
center, in order to unlock your phone password.
2.4.5 Unlock the SIM Card
In order to prevent the illegal use, SIM card PIN1 (personal identification number) code
encryption protection. Elected to user this feature, you must enter PIN 1 code to unlock SIM card when
you turn on phone every time, and send or receive calls. You can remove the S protection IM card (See
3.5.4 Security setup). In this case, the SIM card cannot prevent the illegal use of.
By hanging up the phone key to open.
Enter PIN 1 code and then select Confirm. right soft key can clear input error. For example, if
the PIN 1 code is set to “1234”, you should enter “1234”.
If three consecutive input error, your SIM card will be locked Network. Phone will be asked
whether the PUK 1 code. If you do not know PUK 1 code, do not enter on its own, SIM card should be
paid to deal with network operators(See 3.5.4Security setup)
Notice: The network operator suppliers for you SIM card to set a standard of PIN1(4 to 8),
You as soon as change to your private password(See 3.5.4Security setup)
2.4.6 Connect to the Network
If SIM card is success in unlock, phone will automatically search for an effective network. Once
contacted, the network provider’s name will appear on the screen.
Notice: If the screen displays “EMERGENCY”, means that you don’t in network service’s
coverage area. But you can still send an emergency call according to the signal strength.
2.4.7 Make Calls
When the network provider’s logo appears on the screen, you can call or answer the phone. The
icon be displayed in the top left corner of screen is the network signal strength.
The barrier can influence call quality. Therefore, you can mobile in small area so that effectively
call quality.
10
2.4.8 Make Domestic Calls
Press Number Keys to enter the phone number and then press dial-up button to begin to call. If
you want to change the number, press Right Soft Key to delete the number. The screen will show
animation while dial-up call. After answer each other, the screen will show call state. If you have set
extra tone , you will hear ring tone.( network support)
Press Power/End Key to hang up the call.
Dialing Code Phone Number Dial-up button
2.4.9 Dial Extension
Some fixed-line extensions cannot dial directly, you need to dial the switchboard, dial extension.
If you insert “P” between the switchboard number and the extension number while entering the phone
numbers, the phone will automatic dial-up extension. Press and hold “ * ” Key to input “ P ”.
Dialing Code fixed-line telephone number P extension number Dial-up button
For example, if you have a number 8880000 to use a dial-up voice-mail system, mail for the
6666 and 8888 for the password, well , you can dial in the following manner:
8880000 P 6666 P 8888
The first part of number is dial-up voice-mail system.
After telephone response, send 6666 to choice voice-mail.
Before number 8888 is sent out the second “P” will have a 5 seconds delay.
2.4.10 International telephone Calls
When you want to make international call, you may keep pressing “*” key till the screen
displays international long-distance telephone prefix symbol "+". his allows you to dial a number from
any country even unknowing prefix number (e.g. which in china is “86”)
With prefix number inputted,input your desired district number and complete phone number.
The country code in accordance with usual practice. For example, district number of Germany is 49,
that of UK is 44,and of Sweden is 46, etc.
For example: to dial hotline for service, you should dial:
+86 21 114
+ County Code Phone Number Dial-up button
2.4.11 Dial the Numbers of Phonebook
Every call you dialed or received can be saved and listed in your phone. The recent dialed and
received calls are on the top of the list. Every dialed call, received call or missed call is listed in dialed
calls group, received calls group or missed calls group respectively. You can view all the call records.
When the groups are full, the old records will be automatically deleted. You should follow these steps
to view the list.
Press Call Key to view Call history
All the numbers in the list can be directly dialed by pressing Call Key.
You can select ok to view detailed information of the chosen number. Enter Options and select
11
Save to Phonebook to save the chosen number in your phonebook.
2.4.12 Emergency Number
If you are in network service’s coverage area (check the upper left corner of the screen mobile
phone network signal strength), you can make an emergency number. If your network provider fails to
provide roaming service on such location, the screen will display “EMERGENCY” and you can only
make an emergency numbers. If you are in the network coverage area, you can call emergency numbers
without SIM car.
2.4.13 Answer Calls
If you set “press any key to answer a call”, then pressing any key will answer a call(but don’t press
the “right soft key” and “end key” ), Otherwise, you have to press Call Key or Left Soft Key to
answer call. If the headset has been inserted, you can press the headset button to answer the call. If it's
not convenient for you press button, can be set to auto answer. Then your phone, if the headset has been
inserted, in the ringing tone or vibration after 5 seconds, telephone automatically connect
2.4.14 Call Records
Your phone can record the latest call record and the total call duration (See 3.2 Call Center).
2.4.15 Call Menu
Select H-Free to activate Hands-Free function or Options to enter Options Menu. The
operation is the same as that of function menu. Such call menu can only be seen during a call,and call
waiting, call holding, and multi-parties conference need network support, please contact your network
service provider.
Select Options Menu to perform the following operations.
Hold/Retrieve single call:
Hold a current call or resume a held call.
End single call:
End a current call.
New Call:
Call new call(s).
Phonebook:
Allow you to search a number in your phone book.
Message Center:
Edit and send a message.
Mute:
Not to send (send) local voice.
DTMF:
Press “left soft key” to activate or deactivate dual
![](/img.php?id=1802463&img=bgc.png)
12
3 Function Menus
3.1 Use of Function Menus
Scroll Searching and Selection Function
Press the left soft key to enter Function Menus in idle mode.
In all the main menu or submenu level, the left soft key to choose functions.
Exit Menus
Generally, you can press Right Soft Key to exit from some menu item. Press Power/End Key to
return to idle mode.
3.2 Call Center
3.2.1 Call history
3.2.1.1 Missed Calls: Select OK to view the list of missed calls.
3.2.1.2 Dialed Calls: Select OK to view the list of dialed calls.
3.2.1.3 Received Calls: Select OK to view the list of received calls.
Select OK to view the information of the chosen entry, such as date, duration, number and dial
times. Select Options to perform following operations on the chosen entry.
Delete: Delete this record.
Save: Save this number to the SIM card or mobile phone.
Call: Dial this number.
Send Text message: send message to this number
Send MMS: send MMS to this number
Edit : Edit this number and dial this number.
Add to blacklist: Add this number to blacklist
3.2.1.4 Deleted call logs :Deleted the current call logs or deleted all call logs
Missed Calls
Dialed Calls
Received Calls
Delete All
3.2.2 Call settings
3.2.2.1 Call settings
Call waiting: To open or close the call waiting feature. Select status inquiry to check the
current status of call waiting.
Call Divert:
Divert All Voice Calls:With this option on, any incoming call will be forwarded to the
number you set.
Divert If Unreachable:With this option on, the incoming call will, when you are
unreachable, be forwarded to the number you set.
Divert If No Answer:With this option on, the incoming call will, when there is no reply, be
forwarded to the number you set。
Divert If Busy:With this option on, the incoming call will, when you are on the phone with
13
other person, be forwarded to the number you set.
Divert All Date Calls:The incoming call will, if it is data call, be forwarded
Cancel All Diverts:Cancel all call forward.
Call barring:
Outgoing Calls:Bar any outgoing call or international call or international exclusive of
national call.
Incoming Calls:Bar any incoming or roaming call.
Cancel All:Cancel all barred call settings(password required) to allow normal calls.
Change Barring password:Change password.
This function requires support from your network operator.
Line switching: Switch to line 1 or 2 lines for use.
3.2.2.2 Advance settings
Auto redial: with this option on, this phone will automatically redial if any call fails.
IP dial: you can IP dialing after turn on this function
Call time reminder: to set the call time reminder.
Blacklist: Put the mode on/off, set some numbers you don't want to touch
3.3 Phonebook
Phonebook allows you to store some important people‘s name, phone number, etc. From the main
menu to select the phonebook or press right soft key in idle mode. Your phone can store 150 phone
numbers.
In the phonebook menu, Press OK to perform following operations.
Quick Search: Into the contact list interface, Input first letter inquiry
Search Contact: Input the name you want to call
Add Number: To add a new directory to telephone book.
Copy All: To choose from phone to the SIM card or SIM card to the phone to copy all
records of SIM cards and phones.
Delete : Delete Choose from the phone / SIM 1 / SIM 2
Caller Groups: The groups like friends or family、VIP etc.
Extra Numbers: Owner number, you can edit owner number of SIM1/SIM2.
Settings: Include Preferred Storage and Memory Status, Select priority storage location.
Phone or SIM 1/SIM 2;SIM card 1/SIM card 2 and phone phonebook store information.
Caller Picture : Set you liked pictures to your contacts / new contacts / caller groups
Caller Ringtone: Set you liked ringtones to your contacts /new contacts /caller groups
3.4 Messages
If your network support message service and you have applied to network service providers for
this business, you can arbitrarily send and receive English message and multimedia information by the
message service center.
3.4.1 SMS
When you receive a new message, your phone will vibrate (if vibrator is activated) or ring (if
ringing mode is activated); meanwhile your phone show animation. If you do not read it at once, the
14
message will be stored in SIM card or phone, the new message icon appears in the screen.
Enter Inbox to read the new message.
3.4.1.1 Write Message
Select write message and write a new message (See 4. Input Method)
SIM1 Done : End write message ,chose SIM1
SIM2 Done : End write message ,chose SIM2
Advanced: insert phonebook number or name
Input Method: Change the input method when editing message.
3.4.1.2 Inbox
Enter Inbox you can view SIM 1/SIM 2 Message. The screen will show the number or names
when you view Message in the inbox. You can use Navigation Key to select message. Select OK to
view the chosen message.
According to the options do the following:
Reply: Send a SMS to current Message sender.
Delete: Delete the current message.
Edit:Edit the current message
Delete All: Delete all messages in Inbox
Use Number: call or save the number in your received messages
3.4.1.3 Outbox
Enter Outbox you can view the message has not been sent successfully. You select OK to view
the chosen message. Select Options to perform following operations on the chosen message.
Send: Send the current message
Edit: Edit the current message
Delete: Delete the current message.
Delete All: Delete all the messages in Outbox.
Use Number: call or save the number in current messages
3.4.1.4 Draft
Enter Draft box you can view the message you have been saved successfully. You select OK to
view the chosen message. Select Options to perform following operations on the chosen message.
Send: Send the current message
Edit: Edit the current message
Delete: Delete the current message.
Delete All: Delete all the messages in Draftbox
Use Number: call or save the number in current messages
3.4.1.5 SMS Settings
You have to make some necessary settings before you use the message function. Enter Messaging
Settings and perform the following settings.
Profile Settings: Choose an appropriate mode for phone text message. Enter different modes
to set responding names of files, message center number, message expiration and format of massage to
be sent.
15
Voice Mail Server: You receive voice mail will be stored in the network. If you want listen
to the message, you must call the voice mail number.
Common Settings: perform On/Off settings for Delivery report and replay path.
Memory Status: Browse storing conditions of messages stored in SIM card or in the phone.
Preferred Storage: Save the message to your phone memory or SIM card.
3.4.2 MMS
When you receive a new MMS, your phone will vibrate (if vibrator is activated) or ring (if
ringing mode is activated); meanwhile your phone show animation. If you do not read it at once, the
message will be stored in SIM card or phone, the new message icon appears in the screen.
Enter Inbox to read the new MMS
3.4.2.1 New MMS:
New MMS: Write a new MMS. You have to enter receiver, copy, bcc, subject and text.
3.4.2.2 Inbox
Inbox: You can view the received MMS.
View: View the MMS.
Reply : Sender of current MMS sending a MMS.
Reply All: Send a MMS to current MMS sender and all receivers.
Forward: Forward current MMS to other people.
Delete: Delete the current MMS
Delete All: Delete all the MMS in Inbox.
Properties: View the information of the chosen MMS.
3.4.2.3 Sent
Sent box:You can view the MMS you have been sent .
View: View the chosen MMS.
Forward: Send the chosen MMS to other people.
Edit Message: Edit the current MMS.
Delete: Delete the current MMS.
Delete All: Delete all the MMS in Sent box
Properties: View the information of the chosen MMS.
3.4.2.4 Outbox
Outbox: Display list of MMS under sending or those failed to be sent out.
View: View the chosen MMS.
Forward: Send the chosen MMS to other people.
Edit Message: Edit the current MMS.
Resend: Resend the current MMS
Delete: Delete the current MMS.
Delete All: Delete all the MMS in Out box.
Properties: View the information of the chosen MMS.
3.4.2.5 Draft
Drafts: MMS not send out at once can be stored here. A MMS after being sent out will be
transferred to Sent Items.
View: View the current MMS.
Edit Message: Edit the chosen MMS.
16
Delete: Delete the current MMS.
Delete All: Delete all the MMS in draft box.
Properties: View the information of the chosen MMS.
3.4.2.6 Message Settings
MMS Settings: Where relevant parameters of sending and receiving concerning multimedia can
be set.
Server Profile: Select the proper server.
Compose: Set editor
Send: Set send. For example: Send report、send time、priority, etc.
Retrieve: Set Retrieve. For example: roaming Network、Web、allowed to send report, etc.
Memory Status: Browse memory space of MMS
3.4.2.7 About Us
MMS Client :Version:1.0 Build:5
3.5 Settings
3.5.1 Dual SIM settings
SIM 1 open: Only open SIM 1
SIM 2 open: Only open SIM 2
3.5.2 Phone settings
Time and Date
Set Home City: choose a city for the time settings of the phone. Choose City through the
UP and DOWN keys.
Set Time/Date: set the current time and date. Choose to open or close the daylight-saving
time through left and right keys.
Set Format: set the display format of time and date. Set the formats of the time and date
through left and right keys.
Schedule Power On/Off
You can set four different time intervals to edit and define the automatic switch on/off of the
phone.
Language
Your phone can support languages: English,etc.
Preferred Input Methods
You can preset the word-entering methods for text.
Display
Wallpaper: Select interface standby wallpaper
Screen Saver: The main standby screen interface selection screen image or animation, and
set the wait time
Power On Display: Choose the opening animation.
Power Off Display: Choose the closing animation.
Show date and time: Choose to open or close the idle interface shows the current time.
Greeting Text: you can set the greeting words when it powered on. Choose <close> to
un-display.
17
Speed dial: The number keys can be set directly by dialin.
Flight mode: When you choose this mode, your phones GSM/GPRS module will be
stopped using
Charging Complete: you can set ring for charging completed
3.5.3 Network settings
Network selection: Select of manual or automatic network selection
Preferences : The first choice
Band selection: Research the network which belong SIM card.
3.5.4 Security settings
SIM lock
You may set for your phone security options in this menu to avoid unauthorized use of phone
of SIM card, and PIN code may serve the purpose.
If currently the PIN code is disenabled, select Enable to actuate PIN code protection, and the
PIN code will be demanded in the next power-on, if this code is currently enabled, select
Disenable to cancel PIN code , or Change PIN number to set a new one, please follow the prompt
to input old PIN code, new and repeat new.
Notice: Upon three incorrect inputs of PIN code in a row , the SIM card will be locked
up, by then, you need to input PUK code to unlock the SIM card, both codes might have
been provided along with the SIM card to you, if not, please contact your network operator.
The PIN code default is normally 1234, please change it into your own code.
Phone Lock
Phone lock is provided to prevent your phone from unauthorized use. Select Phone lock to
enable the protection by phone password which will be demanded in the next power-on, press the
selection again to disenable the protection.
Notice: The password default of phone lock is1234, please change it into your own password.
Auto Keypad Lock
Set idle time of keyboard, when set as desired, if the phone is not used in the specified time,
the keyboard will be automatically locked up.
Change Password
Change password including Phone lock and private lock codes.
3.5.5 Restore factory settings.
The password default of phone lock is 1122.
3.6 Services
3.6.1 STK Service
STK service, such as M-zone and GoTone, is provided by network service provider. If it is not
supported by SIM card and network service provider, you cannot use this function. For more
information please contact with the network provider.
3.6.2 WAP
Your phone supports services subject to WAP. You can access the services provided by network
18
service operator. You can acquire the information about news, weather forecast, flight, etc.
Notice: GPRS service needs the support of network. You can enjoy it in the coverage areas
of GPRS network.
Homepage: Access the Home page. Home page is your preset website of WAP. If you do not
set the Home Page, your phone will access the default website.
Bookmarks: View the bookmarks. You can select one of them to access the website.
Recent Visits: the option will record the web addresses you viewed before.
Input URL:This function for the input you want to connect the web site
Settings: Some settings of surfing the Internet
1.Active Profile: Select profile for right
2.Options: Setting parameters of visit website
3. Clear cache: Delete the cache.
4.Clear cookies: Clear personal data.
5.Select SIM: Select SIM 1 or SIM 2
About Us: WAP Browser :Version:1.0 Build:5
3.6.3 Date Account
Select one account and enter it.
1. Account Name: the name of the account
2. APN: Enter APN.
3. User Name: the name of dial-up server
4. Password: the password of dial-up server
5. Auth. Type:Select the identified manner of encryption.
3.7Alarm
Under the alarm setting option menu you can set alarm on or off, alarm time, ring setting and
lingering time, press left or right key to select the ring type as Daily, weekly, Monthly or Yearly; with
self-definition option on, you can set your alarm by pressing the left and right keys to go off in any day
from Mon to Sun.
3.8 Camera
You mobile phone has camera function.
Select Options to perform following operations.
Photos: Enter Album.
Camera Settings: Setting the parameters.
Image Settings: Setting Image size and quality.
Cont. shot: you can choose 1shot,3shot etc.
Delay timer: Setting the delay time while taking pictures.
Storage: Save the files to your phone memory or T-flash card.
Restore default: All the settings to their default values.
19
3.9 Organizer
3.9.1 Bluetooth
◆ Power: Activate Bluetooth.
◆ Inquiry Audio Device: Inquiry Bluetooth headset. (See Bluetooth headset user’s
manual.)
◆ My Device: You can read list of all linked Bluetooth.
◆ Active Device: You can see the linking Bluetooth.
◆ Settings: Set Bluetooth.
◆ About: Service List.
3.9.2 Calculator
Enter Calculator and it can do some simple calculation. Enter the calculated number through
keypad .Press Right Soft Key to cancel the result or exit from Calculator. Press Left Soft Key to output
the result.
3.9.3 World clock
Enter World clock ,you can know the all of the world's time.
3.9.4 Torchlight
Standby interface, long press OK key, you can turn on or off flashlight feature.
3.10 Audio player
Your phone has music player function which supports the following file formats: MIDI, WAV,
MP3, AMR etc. Inserting the memory card , connecting the phone and computer with USB and
copying the AVI format to memory card menu list to enter MP3 Music Player interface;. The
functions of each key are as follows:
Play:Play current song.
Details:View the details of the song.
Add To Ringtones: Add current song to ring bank of situation modes.
Refresh List:Update play list.
Settings:
Pre. Play List: Select from phone or memory card with left/right key.
List Auto Gen: Automatically produce play list.
Repeat:Activate the feature to repeat song playing. Select repeating songs with
left/right keys.
Shuffle:Activate the feature to repeat song playing randomly. Open/close the feature
with left/right key.
Bluetooth settings: When you connect audio device , your phone will automatically
activate Bluetooth Mode
3.11 Profiles
Your phone provides 7 kinds of phone mode for you to select or edit. They are General、
Meeting 、Outdoor、Indoor 、Silent 、Headset and Bluetooth
20
General
Enter Normal Mode and select Activate or Customize.
Activate: Activate Normal Mode.
Customize: Edit the settings of Normal Mode. The editable settings include Tone settings, volume,
Alert type, Ring type, Extra tone, Answer mode, LCD backlight.
Meeting
The operations are the same as Normal Mode.
Outdoor
The operations are the same as Normal Mode.
Indoor
The operations are the same as Normal Mode.
Silent
The operations are the same as Normal Mode.
Headset
When you insert headset, your phone will automatically activate Headset Mode.
Bluetooth
When you connect audio device , your phone will automatically activate Bluetooth Mode.
3.12 Calendar
Enter submenu of tool box, select calendar and press “OK” to display the calendar. Press
Up, Down, Left, Right keys to set date, and press “Options” to enter submenu before proceeding
with the following operations:
View all tasks: Look up all tasks routing.
View tasks: Look up the current routing.
Jump To Date:Set the current date of the schedule as the specified date.
3.13 Multimedia
3.13.1 Phone TV
The mobile phone with TV function, can search for and watch television programs in
different regions.
3.13.2 Image Viewer
Photos can be related to the operation, such as: view、browse style、send、rename, etc.
3.13.3 Video recorder
Your phone has video recording function. Select animation recorder icon and press <ok> to enter
animation recorder interface. In animation recording interface, press the Central Key to start
recording. Press the key once again to pause; Press Right Soft Key to stop recording. Meanwhile,
in animation recording interface, regulate exposure compensation and foci by direction keys. Press
<Options> to enter submenus and perform the following operations:
CamCorder Settings: Settings for animation recorder.
Restore default: All the settings to their default values.
21
3.13.4 Video player
Your phone has Video playing function which supports 3GP formats. Inserting the
memory card , connecting the phone and computer with USB and copying the AVI format to
memory card menu list to enter video player; Select an animation to enter Video playing interface
where you can play, transmit, rename, delete, delete all, ordering and store animation.
3.13.5 Sound Recorder
Press “OK” to enter the submenu to choose the audio record. To choose any record,
press “Options” to enter the submenu to do the following operations: Record, Play, Append,
Rename, Delete, Delete all, Setting, and forward
Record: Create a new record.
Play: Play the record.
Append: Add a new voice to the chosen record.
Rename: Rename the current record.
Delete: Delete the current record.
Delete all : Delete all records.
Settings: Set the format of the voice file.
Forward: send to Bluetooth or Use as user profiles
3.13.6 FM radio
Press“OK”to enter FM radio player interface, you select right soft key can exit FM. If you
select left soft key, it will show below menu:
Channel list: Save search channels, and can be edited.
Manual input: Manually enter the frequency.
Auto search: Auto search channels and auto save channel list.
Settings: The opening or closing of the radio loudspeaker and background play.
3.14 Fun&Games
3.14.1 Games
3.14.1.1 UFO
Control the fighter to shoot UFOS and prevent being attacked by them.
3.15 Application
3.15.1 Facebook
Facebook is a social network service website.The operations like Twitter
3.13.2 Yahoo
Yahoo is the first to provide a Internet and navigation services web site.The operations like
3.15.3 Twitter
Twitter is foreign social network and micro blogging service website. It allows users to
their latest dynamic and idea to send text messages to mobile and form of personalized website
![](/img.php?id=1802463&img=bg16.png)
22
3.15.4 Opera mini
Opera Mini is a Norwegian Opera Software ASA made, used in mobile phone use on free web
browser, you can by this visit the world wide web and WAP site. The operations like Twitter
3.16 File manager
Save user documents, into the Folder Options
Open: View the contents.
New Folder: Create new folder..
Format: Format the folder
4 Input Method
General Outline
This mobile phone provides many input methods. Character entry functions permitted by this
mobile phone are:
- Inputting and editing of short messages
- Inputting and editing of names in the phonebook
- Looking up the phone entry by name
- - ……
Screen Key values
The keyboard values are as follows:
Generally the Left soft Key indicates confirmation; the right soft key is to return or eliminate.
Navigation keys (up/down and left/right keys): Generally used to move the cursor or candidate
characters for inputting.
a/t key: to switch between different input methods.
5 T-flash Card and USB
You can purchase a compatible T-flash card and use it as extra storage space to save the memory
on your phone.
5.1 Insert and Remove T-flash Card
The card slot is on the right-upper of the battery. Insert the card in the slot and ensure that the
contact area on the card is facing up. Press the card to release it from the slot. Do not pull the card
directly; otherwise the card slot and T-flash card can be permanently damaged.
![](/img.php?id=1802463&img=bg17.png)
23
Notice: Your phone supports plug and play. However, you’d better turn off your phone to
insert or remove T-flash card when your phone is on. It can ensure the normal usage of the
information. Generally speaking, you’d better not insert or remove T-flash card.
5.2 Use of T-flash Card
T-flash, which is one kind of phone storages, is set as the default storage. You do not make any
setting and use it directly.
When you first insert T-flash card, you have to set it as the default storage of Music Player,
Video Player, Camera etc. Then you can use it to store or read the information.
When you phone is connected to the computer with USB line, you can copy the data between
your phone and the computer. Your T-flash is used as USB flash drives.
(MP3 is discovered by Audio player just when it is saved in My Music folder;
Video is discovered by Video player just when it is saved in Videos folder;
Picture is discovered by Album just when it is saved in Photos folder.)
5.3 USB
You can connect the USB to phone or PC with dateline.
USB portable drive
Power off: You can copy the data between your phone and the computer.
6 Troubleshooting
If your phone does not work normally, read the following problems and solutions for reference. If
you still can't solve the problems, consult the seller or service centre.
Problems Reasons Solutions
Use the phone in bad reception
areas such as near the high
buildings or in the basement
where radio wave can not be
transmitted effectively.
Try to avoid it.
Use the phone in busy-line period. Try to avoid it.
Bad reception
It has something to do with the
distance of the base stations built
by the network service provider.
Request the network service
provider to provide the map of
service areas.
Bad trunk line of network Echo or noise
The line of some area is bad.
Hang up the phone and redial the
number or change the line.
Standby time is related to the
setting of network.
Turn off the phone temporarily in the
areas of poor signal.
Standby time
o
mes short.
The battery needs to be changed. Change for a new battery.
![](/img.php?id=1802463&img=bg18.png)
24
In the poor signal areas, the phone
has to consume more power to
search the base station. It shortens
the standby time.
Move to the areas of good signal or
turn off the phone temporarily.
The phone can
be turned on.
The battery is out of power. Check the battery level or charge the
battery.
SIM card is damaged. Contact your network service
provider.
SIM card is not well inserted. Ensure SIM card is well inserted.
SIM Card Error
There is filth on the metal area of
SIM card.
Wipe the metal area with a clean
cloth.
SIM card is invalid. Contact your network service
provider.
Out of GSM service areas Consult the network service provider
about the service areas.
The phone can
connect to
w
ork.
Poor signal Move to the areas of good signal.
Call Barring is activated. Inactivate Call Barring. The phone can
make calls. Fixed Dial is activated. Inactivate Fixed Dial.
Incorrect PIN
d
e
Enter an incorrect PIN code 3 times
in a row
Contact your network service
provider.
The battery or charger is damaged. Change for a new battery or charger.
The temperature of charging
environment is below -10°C or
above 55°C.
Change the charging environment.
The phone can
be charged.
Bad contact Check the connection of the
connector.
New entries can
be added to the
nebook.
The phonebook is full. Delete some entries of the
phonebook.
Some functions
not be set.
The network service provider does
not provide this service or you do
not apply for this service.
Contact your network service
provider.
FCC Caution
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
25
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
SAR tests are conducted using standard operating positions accepted by the FCC with the phone
transmitting at its highest certified power level in all tested frequency bands, although the SAR is
determined at the highest certified power level, the actual SAR level of the phone while operating
can be well below the maximum value, in general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a new model phone is a available for sale to the public, it must be tested and certified to the
FCC that it does not exceed the exposure limit established by the FCC, Tests for each phone are
performed in positions and locations (e.g. at the ear and worn on the body)as required by the FCC.
For body worn operation, this model phone has been tested and meets the FCC RF exposure
guidelines when used with an accessory designated for this product or when used with an
accessory that
Contains no metal and that positions the handset a minimum of 1.5 cm from the body.
Non-compliance with the above restrictions may result in violation of RF exposure guidelines.
