IPRO TECHNOLOGY IPROV5 GSM Mobile Phone User Manual V5
HONG KONG IPRO TECHNOLOGY CO.,LIMITED GSM Mobile Phone V5
User Manual
1
V5
User Manual
2
Welcome!
PLEASE READ THIS INFORMATION BEFORE
USING THE PHONE TO MAKE A BETTER USE
OF YOUR PHONE. WE ARE NOT
RESPONSIBLE FOR ANY DAMAGE DUE TO
YOUR MISUNDERSTANDING OF THIS
INFORMATION AND MISACTTING.
We are endeavoring to improve our products and
services and we reserve all the rights to revise and
change the description of this product and its
software as well as this user’s manual without
obligation to notify any person of such revisions and
changes.
This user’s manual is for your better use of this
phone not an approval of any accessories. All the
pictures in this manual are for reference only. There
may be slight difference between the appearance of
phone and keys and contents of display used in this
manual and those of your phone. Please refer to
your phone for actuality. Some features introduced
in this manual are network or
subscription-dependent features. Please contact your
service provider
Safety Information
Battery:
Read this information before using your
mobile device otherwise may result in
p
ersonal injury or your device not
complying with local laws.
3
If a conductive material such touches the exposed
terminal, short circuit may occur resulting in
property damage, bodily injury or burn. To avoid
risk of leaking electricity, take care when handling a
charged battery particularly when placing it inside
your pocket, purse or other container with metal
objects.
Keep your mobile device from water:
Keep your mobile device dry.
Use while driving
Always obey the laws and regulations on the use
of mobile devices in the area where you drive. Give
full attention to driving and the road; use hand-free
operation or earpiece if a call is needed.
Aircraft
Mobile device may cause harmful interference so
turn off your mobile device before boarding an
airplane.
Blasting areas
Always obey the related limits and regulations
and do not use your mobile device in blasting areas.
Turn off your mobile device in areas posted “turn
off electronic devices”.
Potentially explosive atmospheres
Turn off your mobile device in the gas station and
areas near fuel and chemical containers. Turn off
your mobile device in areas posted “turn off
electronic devices”.
Medical devices
Turn off your mobile device whenever instructed
to do so by posted signs near some medical
equipment. Mobile device may interfere with
pacemakers, hearing aids and some other medical
4
transplanting equipment. Do not put your mobile
device near pacemakers nor carry in the breast
pocket.
Accessories and battery
Use the accessories, batteries and chargers
approved by manufacturer. Use of batteries not
approved by manufacturer may cause injury.
Emergency calls
Turn on your phone and keep it in service areas,
dial emergency phone numbers and then press send
key to make a call.
When losing your phone
To avoid any economy damage, please inform the
Tele-communication Company or agencies to lock
your SIM card when you lost your phone.
When you inform the telecom company or agencies
to lock your SIM card they need to know the IMEI
No. of your phone, which you can find printed on
the label on the back of your phone when taking off
the battery. Please backup this number for future
need
For safety consideration, you can make preventative
measures such as set PIN Code for your SIM card to
prevent other persons using your SIM card without
your permission.
Keep away from children
Keep the phone, battery and charger away from
children to avoid any personal injury.
Use and Care
To care for this mobile device, keep it away
from:
Any kind of fluid
Keep the device away from water, rain,
5
humidity, sweat or other moisture.
Extreme heat or cold
Avoid the temperature below -10 /14 or ℃℉
above 45 /113 .℃℉
Microwave
Don’t try to dry your phone in a microwave
oven.
Dust and dirt
Don’t expose your phone to dust, dirt, sand,
food or other inappropriate materials.
Cleaning solutions
Use only a dry soft cloth to clean your
phone. Don’t use alcohol or other cleaning
solutions.
Ground
Don’t drop your phone.
6
Chapter 0 - Skills Introduction
0.1 Finger gestures
Tap
When you want to type using the keyboard, select items onscreen such as
application and settings icons, or press onscreen buttons, simply tap them with
your finger.
Press and hold
To open the available options for an item (e.g. contact or link in a web page),
simply press and hold the item.
Swipe or slide
To swipe or slide means to quickly drag your finger vertically or
horizontally across the screen or optical trackball.
Drag
Press and hold your finger with some pressure before you start to drag.
While dragging, do not release your finger until you have reached the target
position.
Flick
Flicking the screen is similar to swiping, except that you need to swipe your
finger in light, quicker strokes. This finger gesture is always in a vertical
direction, such as when flicking the contacts or message list.
Rotate
For most screens, you can automatically change the screen orientation from
portrait to landscape by turning the phone sideways. When entering text, you
can turn the phone sideways to bring up a bigger keyboard. Refer to the
Settings chapter for more details.
Pinch
For some applications, like Photos or the web browser, you can “pinch” the
screen using 2 fingers (for example, thumb and index fingers) to zoom in or
zoom out when viewing a picture or a web page.
0.2 The SIM Card
0.2.1 Installing the SIM card
If you are given a SIM card to install, install it before setting up your
phone.
IMPORTANT: A SIM card is required to use cellular services when
connecting to GSM networks and some CDMA networks. Your phone that has
been activated on a CDMA wireless network may also use a SIM card for
connecting to a GSM network, primarily for international roaming. Your
phone is subject to your wireless service provider’s policies, which may
include restrictions on switching service providers and roaming, even after
conclusion of any required minimum service contract. Contact your wireless
service provider for more details. Availability of cellular capabilities depends
on the wireless network.
7
0.2.2 Entering your PIN
If your SIM card is preset with a PIN (personal identification number), you
will be prompted to enter the PIN to proceed. Enter the SIM PIN, and then tap
OK.
Most SIM cards are preset with a PIN (personal identification number) that
is provided by your mobile operator. When prompted, enter the preset PIN,
and then tap Enter. If you enter the wrong PIN three times, the SIM card is
blocked. If this happens, you can unblock it with the PUK (PIN Unblocking
Key) obtained from your mobile operator.
0.3 Lock Screen & Home Screen
The Lock screen can protect your phone against accidental touch to perform
the operation you don’t want. In Lock screen, you can drag the circle ball at
the bottom of the phone screen onto the unlock icon to unlock and into Home
screen.
Tips: Icons at the bottom of the screen gives you quick access to Phone
history and Messages. You can drag the circle ball onto each icon to open
them quickly.
0.3.1 Main Home Screen
The Home screen provides you with a weather clock that shows the time
and weather of your current location.
Tap the respective item to open the associated application. The Home screen
also lets you add the items you want and need on the Home screen. Add items
like application icons, shortcuts, folders, and widgets to give you instant
access to information and applications.
0.3.2 Extended Home screen
The Home screen extends beyond the screen width to provide more space
for adding icons, widgets, and more. There are 9 additional screens apart from
the main Home screen.
0.4 Home Screen Setting
0.4.1 Changing wallpaper
To changing your wallpaper, you can follow the information below:
1. Press and hold the blank place on one main screen, there will be a
selection box.
2. Select wallpaper from Gallery/Live wallpaper/Wallpapers.
3. If you want change wallpaper to a photo, tap Gallery to select a photo that
you have taken using the camera or copied to your storage card. Crop the
photo and then tap Save.
8
4. Tap Wallpaper to choose from preset wallpapers and then tap Set
wallpaper.
0.4.2 Adding a widget to Home screen
A wide selection of widgets is available for you to choose from, such as
Calendar, Music, Photo Album, Friend Stream, and more.
1. Enter the main menu and slide to the right. Slide left and right to seek for
the proper widget.
2. Press and hold the widget to move to the main screen to you want to put
it in.
0.4.3 Adding application icons and other shortcuts on Home screen
Place application icons on your Home screen to open applications quicker.
You can also add shortcuts to settings and specific information such as a
bookmarked webpage, someone’s phone number, a music playlist, route
directions, and many other items, to your Home screen. The shortcuts
available depend on the applications that are installed on your phone.
1. Enter the main menu and slide left and right to seek for the proper widget
and shortcuts.
2. Press and hold on the widget or shortcut to move to the part of the Home
screen where there’s space to add a new shortcut.
3. To add an application icon, tap Program and then select an application.
Tips: To add an application icon on the Home screen, enter All Programs, and
then press and hold an application icon. Without lifting your finger, drag the
icon to an empty area on the Home screen, and then release it.
0.4.4 Adding folders on your Home screen
Use folders to group related applications and other shortcuts to keep your
Home screen tidy and organized. You can also add information folders that
show up-to-date information such as Bluetooth received files, your Facebook
phonebook, and more.
0.4.4.1 Creating a new folder and adding items to it
1. Press and hold an application icon or a shortcut that you want to move to
another icon to create a new folder. The phone then vibrates. Don’t lift your
finger.
2. Simply tap the folder to open it so you can access the applications and
shortcuts inside the folder.
0.4.4.2 Rename a folder
Do the follows you can rename a folder:
Tap the folder to open it, tap at the bottom of the folder. Enter a new folder
name and then tap OK.
0.4.5 Rearranging or removing widgets and icons
Rearrange the widgets and icons on your Home screen to give room for adding
more items to the Home screen. You can also remove widgets and icons that
you don’t frequently use.
9
0.4.5.1 Moving a widget or icon
1. Press and hold the widget or icon you want to move. The phone vibrates
and you’ll see a blue box around the widget or icon. Don’t release your finger.
2. Drag the widget or icon to a new location on the screen. Pause at the left
or right edge of the screen to drag the widget or icon onto another Home
screen panel.
3. When the widget or icon is where you want it, release your finger. If
you’ve released your finger but a message shows that there’s no space to place
the widget or icon, drag it right or left again to another Home screen panel.
0.4.5.2 Removing a widget or icon
1. Press and hold the widget or icon you want to remove. The phone
vibrates and you’ll see a cross on the top of the screen. Don’t release your
finger.
2. Drag the widget or icon to the top of the phone. The Phone button then
changes into the Remove button and turns red.
3. When the widget or icon also turns red, release your finger.
0.5 Checking notifications
Notification icons on the status bar report the arrival of new messages,
calendar events, alarms set and ongoing settings such as when call forwarding
is on or the current call status. You can open the Notifications panel to open the
message, reminder, or event notification and see the mobile operator name.
0.5.1 Opening the Notifications panel
When new notification icons displays in the status bar, press and hold the
status bar, then slide your finger downward to open the Notifications panel.
If you have several notifications, you can scroll down the screen to view more
notifications.
0.5.2 Closing the Notifications panel
Simply move your finger to the bottom of the screen and slide your finger
up.
0.6 Adjusting the ringer volume
Press the VOLUME UP or VOLUME DOWN buttons on the left panel of the
phone to adjust the ringer volume to your desired level. The Ringer volume
window appears on the screen to display the volume levels.
0.7 Connecting your phone to a computer
0.7.1 Charge only
When you connect your phone to computer the default is the charge mode.
0.7.2 Disk drive
10
Disk drive mode is available only when you have installed a microSD card
on your phone.
When your phone is connected to the computer, open the notification panel
(see 0.6.1 Opening the Notification panel) and tap USB connected to open
USB Mass Storage page, tap Turn on USB storage.
Select this mode when you want to use your storage card as a USB thumb
drive, and copy files between your phone’s storage card and your computer.
When Disk Drive mode is enabled while your phone is connected to the
computer, you will not be able to run applications that use the storage card,
such as Music or Photos.
0.7.3 Copying files to and from the storage card
1. Connect the phone to your computer using the supplied USB cable.
2. Turn on USB storage.
3. On your computer, the connected phone is recognized as a removable
disk. Navigate to this removable disk and open it.
4. Do one of the following:
Copy the files from the computer to the phone’s storage card’s root folder.
Copy the files from the phone’s storage card to a folder in your computer or
computer desktop.
5. After copying the files, unmount the removable disk (that is, the
connected phone) as required by your computer’s operating system to safely
remove your phone.
0.7.4 Disconnect the phone from the computer.
If you want to keep the phone connected to the computer but don’t want the
phone access the storage card, open the Notifications panel, tap Turn off USB
storage.
Chapter 1 - Phone
1.1 Phone calls
1.1.1 Making a call
There are several convenient methods to make a call from your phone.
1.1.1.1 Calling using the Dialer
You can tap phone button at the bottom of the screen to enter the dialer
screen. In Dialer, when you input some number, you have two ways to select
make a call.
1. Directly press call on the keyboard, and then choose which SIM card you
want to use.
2. You can slide to the right to choose the number in your call history.
Note: If you only one SIM card inserted, you can’t use another SIM card to
make a call. When one SIM card is a call, another is temporarily unavailable.
1.1.1.2 Calling a phone number in a text message
While viewing a text message, you can place a call to a number that is in the
body of the message.
11
1. Tap the message with the phone number.
2. On the Select action screen, tap the number you want to call.
3. The dialer screen then opens, with the phone number automatically filled
in and ready to be dialed. To place the call, press call and select SIM 1 or SIM
2 by yourself.
1.1.1.3 Calling a phone number in contacts
Enter contacts list and select a contacts. In the contact information details
screen, tap call button behind the number you want to call.
1.1.1.4 Making an Emergency Call
On the Phone screen, dial the international emergency number for your
locale (for example, 911), and then tap Call.
If your phone is locked with a passcode, you may still be able to make an
emergency call: On the Enter Passcode screen, tap Emergency Call, then enter
the emergency number and tap the red button.
1.1.2 Answering or Rejecting a Call
When you receive a phone call from a contact, the Incoming call screen
appears and displays the caller ID icon, name, and phone number of the calling
party. When you receive a phone call from someone who is not stored in
Contacts, only the default caller ID icon and phone number appear on the
Incoming call screen.
1.1.2.1 Answering an incoming call
Slide across the screen to answer incoming call.
1.1.2.2 Rejecting an incoming call
Slide the end call to reject.
1.1.2.3 Muting the ringing sound
To mute the ring without rejecting the call, press the VOLUME UP /
VOLUME DOWN button or Power button. You can also mute the ring with
press Menu and then tap Mute.
1.1.3 Using In-call Options
When a call is in progress, you can go through the operation of key options.
Tap the available buttons to put a call on hold, dial another contact for a phone
conference, mute the phone microphone, and more.
Note: When the phone is dialing, only the End call and Speaker on buttons
are available.
1.1.3.1 Muting the microphone during a call
Tap Mute to switch between turning the microphone on or off. When the
microphone is turned off, the Mute icon appears in the status bar.
1.1.3.2 Putting a call on hold
Tap Hold to put the call on hold. When you put a call on hold, the hold call
icon appears in the status bar. Then tap Unhold to resume the call.
1.1.3.3 Turning the speakerphone on or off
When you are on a call, tap Speaker to toggle between turning the
speakerphone on or off. The speakerphone icon appears in the status bar when
the speakerphone is on.
Warning! To avoid damage to your hearing, do not hold your phone against
12
your ear when the loudspeaker is turned on.
1.1.4 Ending a call
Do one of the following to end the call:
• Tap End call.
• If you are using the provided wired headset, press and hold the button to
end the call.
1.2 Using Call Log
When you miss a call, the missed call icon appears in the title bar. Use
the Call log tab of the Contacts screen to check who the caller was or view all
your dialed numbers and received calls.
1.2.1 Using the Call log tab
Enter the dial number and slide to the right to the call log.
At the Call log tab, you can do one of the following:
1. Tap the name or number in the list to have a call.
2. Tap a name or number in the list to display the options menu where you
can select to view the contact information (if the number is stored in your
contacts list), edit number before call, send text message, or remove from call
log.
1.3 Adjusting Phone Settings
You can adjust the phone settings of your phone such as your voice mail
number, or enable additional call services from your wireless service provider.
To open the dial pad, press MENU, and then tap Settings > Call settings,
meanwhile you must select SIM1 or SIM2.
Options Description
Fixed Dialing
Numbers
Restrict outgoing calls to a fixed set of numbers. To enable
this feature you must know your SIM card’s PIN 2 code.
Voicemail Specify another voicemail number aside from the voice
mail number on your SIM card.
Call forwarding
Select how you want your phone to handle busy,
unanswered, and unreachable.
You can also set the call forwarding option for all
incoming calls.
Call barring Choose barring outing or barring incoming, You need
apply this function from your network operators .
Additional call
settings
Enable or disable operator services such as caller ID and
call waiting.
1.4 Turning the Phone Function On and Off
You can do the follows to enabling or disabling Airplane mode:
13
1. Press HOME> MENU, then tap System Settings >more.>
Wireless&networks, Select the Airplane mode check box to enable or disable
Airplane mode. When enabled, the Airplane mode icon displays in the
status bar.
2. Long press Power and then tap Airplane mode.
3. At the top of Notification number, you can tap the Airplane mode
shortcut to turn on or turn off the Airplane mode.
Tips: When you disable Airplane Mode, the phone function is turned back on
and the previous state of Bluetooth and Wi-Fi is restored.
Chapter 2 - Contacts
2.1 About Contacts
In Contacts, you can easily manage your communications with contacts via
phone, messaging, and email. If you are synchronizing contacts with your
Google account, with your PC tools, any contacts stored in those accounts are
displayed in contacts.
2.2 Contacts List
2.2.1 Add a new contact
1. On the contacts list screen, press the button, then tap Create contact.
2. Enter the contact information in the fields provided.
3. Scroll to the bottom of the screen and tap Save.
2.2.2 To search for a contact
You can press button to enter search, there is a search bar on the top of
contacts list screen, enter the first few letters of the first or last name of the
contact you are searching, matching contacts are displayed.
Tips: If the list of matching contacts is long, you can view more results by
tapping to hide the on screen keyboard.
2.2.3 Delete contact
On the contacts list screen, press Menu, and then tap Delete contact. On the
Delete screen, you can operate Multiple choice, or Mark all.
Warning: This operation will delete contact, please be careful.
2.2.4 Display options
The function help you to display customize options, including default and
Gmail account display option.
Tips: After synchronizing contacts with your Google account, add the contact
14
to the phone, you must select “All Other Contacts” item in Gmail account
display option, the contacts will displayed in the list.
2.2.5 Import/Export
Start the phone will automatically import SIM1 and SIM2 card contacts;
you can cancel it in “Display options”.
1. On the contacts list screen, press MENU, and then tap Import/Export.
2. You can select copy contacts from following items: Phone, SIM1 card,
SIM2 card and SD card, then tap Next.
3. Select copy contact to you want and tap Next, then select the contact(s)
you want and tap Copy.
2.2.6 Edit contact
On the contacts list screen, tap a contact for details and then tap Menu-Edit.
2.2.7 Set default number
If the contacts contain more than one number item, you can set any to
default number. On the contacts details screen, press and hold the number not
default, then tap Make default number.
2.2.8 Groups
You can create different groups, add saved in the phone contacts to the group,
and set personalized items. Press to create new group. Long press a
group you created you can operate the Groups by the pop-up items.
Chapter 3 - Messaging
3.1 Using Message
Message lets you compose and send text (SMS) and multimedia messages
(MMS) to other mobile phones.
3.1.1 Creating and sending SMS and MMS messages
You can compose text (SMS) messages of up to 160 characters. If you
continue to type after the limit is reached, your message will be delivered as
one, but count as more than one message. These are called concatenated
messages.
Multimedia messages, also known as MMS, can contain text and a picture, a
recorded voice, an audio or video file, a picture slideshow.
15
3.1.2 To create and send a text message
1. On the All Messages screen, tap create the compose screen opens.
2. Enter the phone number (the message recipient) in the To field. As you
enter the phone number, matching contacts will appear on the screen. Tap a
recipient or continue entering the recipient’s phone number.
Note: Only show the saved to contact mobile phone number.
3. Tap the text box that contains the text “Type message”, and then start
composing your message.
Note: As you compose your message, a counter will appear in the top right
corner of the text box to tell you how many characters right now. Once you go
over 160- character, a new message is created but automatically joined into
one when received.
4. When done, tap Send to send the text message.
Note: To receive delivery reports and know when a text message is received,
in the All threads screen, press MENU and then tap Settings. In the SMS
settings section, select the Delivery reports check box.
3.1.3 To create and send a multimedia (MMS) message
1. On the All threads screen, tap create to open the Compose screen.
2. Enter the mobile phone number or email address of your message
recipients in the To field. As you enter the phone number or email address,
matching contacts will appear on the screen. Tap a recipient or continue
entering the recipient’s phone number or email address.
3. Tap the text box that contains the text “Type text message”, and then start
composing your message.
4. Press “+” and then tap Attach.
5. On the Attach window, select from the following file attachments:
Pictures Open the Albums application. Select a picture to attach it to your
message.
Videos Open the Albums application. Select a video to attach it to your
message.
Audio Open the Select music track screen. Tap an audio file to select, and
then tap OK to attach the file into your message. The music file plays back
when you tap it.
Capture picture. Open the Camera application. Take a picture of your
subject, and then tap Done to attach it to your message.
Capture video. Open the Camcorder application. Shoot a video, and then
tap Done to attach it to your message.
Record audio Open Voice Recorder. Tap the button to start recording your
message, and then tap the button to stop.
Slideshow Open the Edit slideshow screen. Tap Add slide to create a new
slide. Tap the created slide (for example, Slide 1), tap Insert picture, and then
select the picture you want to add to the slide. You can also navigate to the
text box and enter a caption for the picture. When finished, tap Done to attach
the slideshow to your message.
Tips: When editing multiple slides, tap to edit the next slide or tap
16
to return to the previous slide.
While editing the slideshow, press MENU to let you preview the slideshow,
add music or video to a slide, remove a slide, and more.
6. When you are finished composing the multimedia message, tap Send.
3.1.4 To save a message as a draft
While composing a text or multimedia message, press BACK to
automatically save your message as a draft. To resume composing the message,
tap the message in the All thread screen. Continue editing the message, and
then tap Send to send it.
Note: Only the message have a valid recipients will be saved as a draft.
3.1.5 Receiving text and multimedia messages
Depending on your notification settings, the phone will play a ring tone,
vibrate, or display the message briefly in the status bar when you receive a
new text or multimedia message.
3.1.6 To open and read a text message
Press HOME, then press and hold the status bar, slide it down to open the
Notifications panel. Tap the new message to open and read it. On the All
threads screen, tap the text message or message thread to open and read it. To
return to the All threads screen from a text message thread, press MENU and
then tap More -> All threads.
Notes • To view the details of a particular message, in the message threads,
press and hold the message to open the options menu, and then tap View
thread.
• If a message contains a link to a web page, tap the link to let you open the
link in Browser or add the URL as a bookmark.
• If a message contains a phone number, tap the message to open Dialer so you
can call the number.
3.1.7 To open and view a multimedia message
1. On the All threads screen, tap a multimedia message or message thread to
open it.
2. Tap the Play button at the top of a multimedia message to view it.
Tips: You can save the file attachment on the multimedia message to the SD
card. To save, press and hold the file and then tap Copy attached to SD card
on the options menu.
Notes: When Auto-retrieve in MMS settings is disabled, only the message
subject is downloaded. To download the entire message, tap the Download
button at the right side of the message. Once the message has downloaded, tap
the Play button to view the message.
• If you are concerned about the size of your data downloads, check the
17
multimedia message size before you download it.
3.2 Using Email
3.2.1 Adding a POP3/IMAP email account
If the account type you want to set up is not in the phone database, you will
be asked to enter more details. It is recommended that you get all pertinent
information for the email account such as incoming/outgoing server settings
before you proceed.
3.2.2 Composing and sending emails
1. On the email account Inbox, tap Compose.
2. Enter the message recipient’s email address in the To field. As you enter
information, matching contacts will appear on the screen. Tap the recipient or
continue entering the email address. If you are sending the email to several
recipients, separate the email addresses with a comma.
3. Enter the subject, and then compose your message. Tap Send.
Note: Tap Save as draft to save the message as a draft, tap Discard will not
save.
3.2.3 Viewing
On the email account Inbox, tap the email you want to view. If the email
added attachment, you can view all the attachment after download.
3.2.4 Managing emails
1. Press and hold one email, on the popup options screen, you can select
Delete / Move to folder / Mark as read (unread).
2. On the email account Inbox screen, press Refresh, you can receive new
email in time.
3. On the email account Inbox screen, press Accounts, enter to all accounts
screen
3.2.5 Editing email account settings
1. On the email account Inbox screen, press Menu -> Accounts.
2. Press and hold the account, on the popup option, select Account
Settings.
Account settings Change the email account settings such as General settings,
Notification settings and server settings.
General settings Set the account name, your name, Signature, email check
frequency, default email account.
Notification settings Set the email notification, select ringtone and vibrate.
Server settings Set incoming settings, outing settings.
18
3. Press BACK to save your changes.
3.2.6 Deleting an email account
1. On the email account Inbox screen, press Menu -> Accounts.
2. On the accounts list screen, press and hold the account, on the popup
option, select Remove Account.
Chapter 4 - Camera and Multimedia
4.1 Photos
All pictures or videos that you capture on your phone are stored on the
storage card. Photos lets you view photos and videos on Phone, in your:
1. Camera Roll album—shots you took with the built-in camera, or save
from an email, text message, or webpage.
2. Photo Stream Album.
3. Photo Library and other albums synced from your computer.
Share: Send a photo or video in an Email, Messaging, Gmail, Bluetooth,
Picasa. Delete: remove the selected photos. Menu: view Details, set as
Contact icon or Wall paper, Crop photo, Rotate Left or Right.
4.2 Camera
The built-in camera lets you take both still photos and videos. Phone include
a front camera for Face Time and self-portraits (in addition to the main camera
on the back), and an LED flash.
Tips: All pictures or videos that you capture on your phone are stored on the
storage card.
4.2.1 Taking photos
When you open Camera, the preview screen orientation will depend on how
you are holding the phone.
1.Aim your object with the screen.
2.Touch the “shutter” button on the screen.
3.After taking，photos will save to the camera’s galley folder with the name
of taking time.
4.You can view the photos by touching the preview box button.
5.Camera settings
You can touch the button of “set” in the interface of camera to do
the settings
4.2.2 Shooting videos
When you open Camera, the preview screen orientation will depend on how
you are holding the phone.
1.Aim your object with the screen.
19
2.Touch the “shutter” button on the screen.
3.After taking，videos will save to the camera’s galley folder with the name
of taking time.
4.You can view the videos by touching the preview box button.
5.Video camera settings
You can touch the button of “set” in the interface of camera to do
the settings
4.2.3 Closing Camera
On the Camera screen, press HOME or BACK.
4.3 Music
All songs that you capture on your phone are stored on the storage card.
Copying music into the storage card .As follows:
1. Set the phone’s storage card as a USB drive.
2. On the computer, navigate to the USB drive and open it.
3. Create a folder on the root folder of the storage card (for example,
Music).
4. Copy the music into the folder you have created.
5. After copying music, Unmount or eject the drive as required by your
Computer’s operating system to safely remove the phone.
6. Disconnect the phone from the computer.
Tips: You can also create and use folders to organize your music inside the
Music folder you have created.
4.3.1 Play songs
1. Artists：Displayed with artists’ name；hold one，you can play, add to a
playlist, delete, search.
2. Albums：Displayed with albums’ name；hold one，you can play, add to
a playlist, delete, search.
3. Songs：Displayed with songs’ name；hold one，you can play, add to a
playlist, delete, search, set as phone ringtone.
4. Playlists’；hold one，you can play, edit.
Tips: Random party broadcast from play lists is random choice part of the
song to play, "all random play" is random play album or list of all the songs.
Chapter 5 - Google apps
5.1 Signing In to Your Google Account
Signing in to your Google Account lets you synchronize Gmail/Google Mail,
Calendar, and Contacts between your phone and the web. You also need to
sign into a Google Account to use Google Apps such as Google Talk™ and
Android Market. When you turn on the phone for the first time, you are given
the option to sign in to your Google Account.
20
1. In the Setup accounts screen, tap Google account > Yes > Next.
2. Tap Sign in. Enter your user name and password, and then tap Sign in.
After signing in, all emails, contacts, and calendar events on your Google
Account will automatically synchronize with your phone.
Note: Tap Create if you do not have a Google Account yet.
Retrieving your Google Account password
If you forgot your Google Account password, you can retrieve it by doing
the following:
1. On your computer, open your browser and go to
http://google.com/accounts.
2. On the right side of the page, click I cannot access my account.
3. In the Please select your issue section, select I forgot my password.
4. Click Reset your password now, and then follow the procedure on how to
recover your password.
5.2 Using Gmail/Google Mail
Gmail/Google Mail is Google’s web-based email service. Gmail/Google
Mail is configured when you first set up your phone. Depending on your
synchronization settings, Gmail/Google Mail on your phone is automatically
synchronized with your Gmail/Google Mail account on the web.
5.2.1 To open Gmail/Google Mail
The Inbox conversations list (here in after referred to as Inbox) is your
default Gmail/Google Mail view. All your received emails are delivered to
your Inbox.
5.2.2 To refresh Gmail/Google Mail
Press Refresh to send or receive new emails and to synchronize your emails
with your Gmail/Google Mail account on the web.
5.2.3 Creating and sending emails
5.2.3.1 To create and send an email
1. In the Inbox, press MENU and then tap Compose.
2. Enter the message recipient’s email address in the To field. If you are
sending the email to several recipients, separate the email addresses with a
comma. You can add as many message recipients as you want.
Note: If you want to send a carbon copy (Cc) or a blind carbon copy (Bcc) of
the email to other recipients, press MENU and then tap Add Cc/Bcc.
3. Enter the email subject, and then compose your email.
Tips: If you want to add a picture attachment, press Attach. Select the picture
you want to attach, and then tap OK.
4. After composing your email, tap Send.
Note: While composing the message, tap Save as draft or press the BACK
21
button to save it as a draft. To view your draft email messages, in the Inbox,
press MENU and then tap View labels > Drafts.
5.2.3.2 To view your sent messages
In the Inbox, press MENU and then tap View labels > Sent.
Chapter 6 - Settings
6.1 SIM management
You can choose to use the SIM1 or SIM2, or both of them. If you insert one
SIM card, just the one would be choice.
6.1.1 SIM Information
Tap check box to choose enable or disable a SIM card, or tap a SIM card to
change its information.
6.1.2 Default SIM
You could choose which the default SIM card is when you have a voice call,
video card, sending a message or connection.
6.1.3 General settings
You could change roaming settings or associate contacts with a specific
SIM.
6.2 Wi-Fi
Wi-Fi provides wireless Internet access over distances of up to 100 feet (100
meters). To use Wi-Fi on your phone, you need access to a wireless access
point or “hotspot”.
Note: The availability and range of the Wi-Fi signal depends on the number,
infrastructure, and other objects through which the signal passes.
6.2.1 Turning Wi-Fi on and connecting to a wireless network
1. Tap Settings > Wireless controls.
2. Select the Wi-Fi check box to turn Wi-Fi on. The phone will scan for
available wireless networks.
3. Tap Wi-Fi settings. The network names and security settings (Open
network or Secured with WEP) of detected Wi-Fi networks are displayed in
the Wi-Fi networks section.
4. Tap a Wi-Fi network to connect. If you selected an open network, you
will be automatically connected to the network. If you selected a network that
is secured with WEP, enter the key and then tap Connect.
6.2.2 Checking the wireless network status
You can check the current wireless connection status from the following:
22
• Status bar
When your phone is connected to a wireless network, the Wi-Fi icon
appears in the status bar and tells you the approximate signal strength (number
of bands that light up). If Network notification in Wi-Fi settings is enabled,
this icon appears in the status bar whenever the phone detects an available
wireless network within range.
• Wi-Fi networks
On the Wireless controls screen, tap Wi-Fi settings, then tap the wireless
network that the phone is currently connected to. A message box will be
displayed showing the Wi-Fi network name, status, speed, signal strength, and
more.
Note: If you want to remove the wireless network settings on your phone, tap
Forget on this window. You need to enter the settings again if you want to
connect to this wireless network.
6.2.3 To connect to another Wi-Fi network
On the Wireless controls screen, tap Wi-Fi settings. Detected Wi-Fi
networks are displayed in the Wi-Fi networks section.
Tips: To manually scan for available Wi-Fi networks, on the Wi-Fi settings
screen, press MENU and then tap Scan.
Tap another Wi-Fi network to connect to it.
Note: If the wireless network you want to connect to is not in the list of
detected networks, scroll down the screen, then tap Add Wi-Fi network.
Enter the wireless network settings, then tap Save.
6.3 Bluetooth
Bluetooth on your phone operates in three different modes:
• On. Bluetooth is turned on. Your phone can detect other
Bluetooth-enabled devices, but not vice versa.
• Discoverable. Bluetooth is turned on, and all other Bluetooth-enabled
devices can detect your phone.
• Off. Bluetooth is turned off. In this mode, you can neither send nor receive
information using Bluetooth.
Notes: By default, Bluetooth is turned off. If you turn it on, then turn off your
phone, Bluetooth also turns off. When you turn on your phone again, you
should turn on Bluetooth again.
Tips: Turn off Bluetooth when not in use to conserve battery power, or in
places where using a wireless device is prohibited, such as on board an aircraft
and in hospitals.
Turning on Bluetooth and making the phone discoverable
1. Tap Bluetooth Settings.
2. Select the Bluetooth check box to turn on Bluetooth. When on, the
Bluetooth icon appears in the status bar.
3. Tap Bluetooth settings, then tap Discoverable to chose how long the
phone discoverable to other Bluetooth devices that are within range, never, in
2 minutes or forever.
23
6.4 Data usage
This is for your use of the GPRS traffic monitoring; you can also set their
own needs.
6.5 More
6.5.1 VPN Settings
From your phone, you can add, set up, and manage virtual private networks
(VPNs) that allow you to connect and access resources inside a secured local
network, such as your corporate network.
6.5.1.1 Preparing your phone for VPN connection
Depending on the type of VPN you are using at work, you may be required
to enter your login credentials and/or install security certificates before you
can connect to your company’s local network. You can get this information
from your network administrator. Also, your phone must first establish a
Wi-Fi or data connection before you can initiate a VPN connection.
6.5.1.2 Setting up secure credential storage
If your network administrator instructs you to download and install security
certificates, you must first set up the phone’s secure credential storage.
1. Press HOME > MENU, tap Settings > Security, and then tap Set
password.
2. Enter a new password (at least 8 characters without any spaces) for the
credential storage, scroll down and confirm the password, and then tap OK.
3. Select the Use secure credentials check box.
You can then download and install the certificates needed to access your
local network, your network administrator can tell you how to do this.
6.5.1.3 Adding a VPN connection
1. Press HOME > MENU, and then tap Settings > Wireless & networks >
VPN settings.
2. Tap Add VPN, and then tap the type of VPN you want to add.
3. Tap the VPN settings and set them up according to the security details
you have obtained from your network administrator.
4. When finished, press MENU, and then tap Save.
The VPN is then added to the VPNs section of the VPN settings screen.
6.2.5.4 Connecting to a VPN
1. Press HOME > MENU, and then tap Settings > Wireless & networks >
VPN settings.
2. In the VPNs section, tap the VPN that you want to connect to.
3. When prompted, enter your log in credentials, and then tap Connect.
When you are connected, the VPN connected icon appears in the
notification area of the title bar.
4. Open the web browser to access resources such as intranet sites on your
corporate network.
6.5.1.5 Disconnecting from a VPN
1. Press and hold the title bar, and then slide down your finger to open the
24
Notifications panel.
2. Tap the VPN connection to return to the VPN settings screen, and then
tap the VPN connection to disconnect from it.
When your phone has disconnected from the VPN, the VPN disconnected
icon is displayed in the notification area of the title bar.
6.5.2 Tethering&portable hotspot
You can turn your phone into a portable Wi-Fi hotspot, to share your
phone’s internet connection with one or more computers or other devices.
1. Open the Settings application.
2. Touch Wireless & networks > Tethering & portable hotspot.
3. Check Portable Wi-Fi hotspot.
Notes: • When your phone is serving as a Wi-Fi hotspot, you can’t use your
phone’s applications to access the internet via its Wi-Fi connection.
• You configure the hotspot with the Wi-Fi hotspot settings.
• For more information, visit http://www.android.com/tether#Wi-Fi.
6.5.3 Mobile Networks
You can set mobile networks related options such as Data usage, Network
Mode, Access Point Names and Network operators in Mobile Networks.
6.6 Audio profiles
There are four modes to choose from, including General, Silent, Meeting,
Outdoor. You could tap for set specific.
6.7 Display
You can select the screen brightness and standby time to their own needs
and place is in need if they had to switch screens.
6.8 Storage
SD card and the phone which you can view and use the total capacity, and
can be inserted on the installation and format the SD card.
6.9 Battery
Show your battery capacity and how much remaining and how long it is
used.
6.10 Apps
Here you can choose to install non-market applications and view the
application procedure and has been downloaded
6.11 Location access
1. When checked use wireless networks, the mobile network /Wi-Fi to
determine the location.
2. Use of GPS satellites to determine your location.
25
6.12 Security
In accordance with the options to lock screen with a pattern, PIN, or
password.
6.13 Language & input
Set the phone language, personal dictionary and input method and so on.
6.14 Backup & reset
Its main application is loaded back up, if reinstall an application, restore
backed up settings or other data.
Note: When you tap Factory data reset, all data on phone would be erases, so
please do not try to restore factory settings.
6.15 Accounts
You can add corporate and Google account to synchronize.
When you first enter your Gmail, Google Latitude, Google Talk, an Market,
will be prompted to add a Google account, Google account let you back up
your phone's information (such as: contacts, etc.) to Google's servers in order
to avoid loss of information when replacement of the phone, your information
will be restored to the new phone. You can also add a new account in
"Settings-> Account & sync -> Add Account ". You can add multiple accounts;
a cell phone with an account can also be associated to multiple mobile phones.
6.16 Date & time
You can change the phone time and date or time zone in this option.
6.17 Schedule power on/off
Here you can set anytime you want to power on/off your mobile phone.
6.18 Accessibility
Here are some accessibility for you to better use your mobile phone, such as
Large text, Power button ends call, Auto-rotate screen, Speak passwords.
6.19 About phone
Here you can view the phone status and the use of mobile phone batteries
and IMEI number, Bluetooth address, Wi-Fi address
Chapter 7 - Other Applications
7.1 Clock
You can use Clock to set alarms.
26
7.1.1 Setting the local date, time zone, and time
By default, your phone automatically uses the network-provided date, time
zone, and time. You can set the date, time zone, and time manually.
Tips: You can also press HOME > MENU, and then tap System Settings >
Date & time.
7.1.2 Setting alarms
1. Tap one of the default alarms on the screen.
2. In the Set alarm screen, set the alarm time by sliding your finger up or
down on the numbers and AM/PM.
3. Enter the alarm Description, set the Alarm sound and Repeat, and select
the Vibrate checkbox if you want the phone to also vibrate when the alarm
goes off.
Note: Scroll up the screen to see all the Alarm options.
4. Tap Done.
Note: If you need to set more than an alarm, you can add more alarms by
tapping Add alarm or press and hold the alarm, and tap Delete alarm.
7.2 Sound Recorder
Voice Memos lets you use Phone as a portable recording device using the
built-in microphone, Phone or Bluetooth headset mic, or supported external
microphone. Recordings using the built-in microphone are mono, but you can
record stereo using an external stereo microphone.
Recording your voice
1. Press HOME, then tap “Apps”, and then tap Sound Recorder.
2. Hold the device’s microphone near your mouth.
3. Tap to start recording a voice clip. Tap to stop
recording.
4. Enter a name for the voice clip and then tap Save.
5. Tap to play back the voice recording.
7.3 FM Radio
7.3.1 Open Radio
When you listen to the radio, please inset the headset and tap FM Radio.
7.3.2 Selectable channel
Tap the icon or , you can fine-tune on the radio or course.
7.3.3 options
1. Search: Search all the channels.
2. Speaker: You can start up loudspeaker to make the sound louder.
3. Record FM: You can record your favorite music or program.
27
7.4 Calendar
Calendar makes it easy to stay on schedule. You can view individual
calendars, or several calendars
at once. You can view your events by day, by month, or in a list. You can
search the titles, invitees,
locations, and notes of events. If you enter birthdays for your contacts, you can
view those
birthdays in Calendar.
Day: To display the day of calendar in days.
Week: To display the day of calendar in weeks.
Month: To display the day of calendar in months.
Daily: Display the calendar in the certain period of time within the region.
Today: "Day", "Week", "month", under the circumstances of the agenda click
Today, a variety of display format selection box will jump to the "today".
More: Create a new event, view the currently selected calendar, setting.
7.5 Calculator
Tap numbers and functions in Calculator just as you would with a standard
calculator. When you tap the add, subtract, multiply, or divide button, a code
appears around the button to let you know the operation to be carried out.
7.6 Browser
7.6.1 Open browser
Browser is used for internet surfing. Press “HOME”, then tap “Apps”,find
Browser.
7.6.2 Basic operations
7.6.2.1 New window
1. Touch the address bar, tap in the words you are interested in, then tap
“Go”.
2. When you are tap in the words in history, it will show up automatically.
7.6.2.2 Bookmarks/ History
Press menu key to find the “bookmark/ History”, you can add your favorite
websites. By bookmarks you can go to your website rapidly.
The browser will record the websites you have visited. By history, you can
find the websites you want. Also you can delete all the history.
§ 15.19 Labelling requirements.
28
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
29
the user is encouraged to try to correct the interference by one or more
of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate (SAR) information:
This Automotive Diagnosis Computer meets the government's
requirements for exposure to radio waves. The guidelines are based on
standards that were developed by independent scientific organizations
through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the
safety of all persons regardless of age or health.
FCC RF Exposure Information and Statement The SAR limit of USA
(FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: V5
(FCC ID: PQ4IPROV5) has also been tested against this SAR limit. The
highest SAR value reported under this standard during product
certification for use at the ear is 0.36W/kg and when properly worn on
the body is 1.31W/kg. This device was tested for typical body-worn
30
operations with the back of the handset kept 1.5cm from the body. To
maintain compliance with FCC RF exposure requirements, use
accessories that maintain a 1.5cm separation distance between the user's
body and the back of the handset. The use of belt clips, holsters and
similar accessories should not contain metallic components in its
assembly. The use of accessories that do not satisfy these requirements
may not comply with FCC RF exposure requirements, and should be
avoided.
Body-worn Operation
This device was tested for typical body-worn operations. To comply
with RF exposure requirements, a minimum separation distance of 1.5
cm must be maintained between the user’s body and the handset,
including the antenna. Third-party belt-clips, holsters, and similar
accessories used by this device should not contain any metallic
components. Body-worn accessories that do not meet these requirements
may not comply with RF exposure requirements and should be avoided.
Use only the supplied or an approved antenna.
