Users Manual
![](/img.php?id=1863877&img=bg1.png)
1
VENUS L
User’s Manual
2
TABLE OF CONTENT
1 BASIC INFORMATION....................6
1.1 BRIEF INTRODUCTION........................................... 6
2 BEFORE USE.....................................7
2.1 NAME AND EXPLANATION OF EACH PART............. 7
2.1.1 Appearance Sketch Map ........................... 7
2.1.2 Description of the Standby Pictures.......... 7
2.2 INSTALL SIM CARD AND MEMORY CARD............. 9
2.2.1 SIM Card................................................... 9
2.2.2 Inserting and Taking out SIM Card ........ 10
2.2.3 Memory Card .......................................... 10
2.3 BATTERY ............................................................ 11
2.3.1 Install the Battery.................................... 11
2.3.2 Charging.................................................. 12
2.4 SECURITY PASSWORD ......................................... 13
3 QUICK USER GUIDE.....................14
3.1 FEATURE FUNCTIONS.......................................... 14
3
3.2 DIAL A CALL....................................................... 16
3.3 REJECT A CALL ................................................... 16
3.4 RECEIVE A CALL................................................. 16
3.5 END A CALL........................................................ 16
3.6 EMERGENCY SERVICES ....................................... 17
3.7 EXTENSION SPEED DIAL ..................................... 17
3.8 DIALED CALLS/MISSED CALLS/RECEIVED
CALLS/REJECTED CALLS .............................................. 17
3.9 CALL FORWARD.................................................. 17
3.10 CALL WAITING ................................................... 18
3.11 CALL BARRING................................................... 18
3.12 POWER OFF THE PHONE ...................................... 18
3.13 T-FLASH CARD ................................................... 19
4 FUNCTION MENU..........................19
4.1 PHONEBOOK .................................................. 19
4.1.1 New ......................................................... 20
4.1.2 Search...................................................... 20
4.1.3 SMS......................................................... 20
4.1.4 Call.......................................................... 20
4.1.5 Delete ...................................................... 20
4.1.6 Mark........................................................ 21
4
4.1.7 Copy........................................................ 21
4.1.8 Others...................................................... 21
4.2 MESSAGES.......................................................... 22
4.2.1 Write Message ........................................ 22
4.2.2 Inbox ....................................................... 23
4.2.3 Outbox..................................................... 24
4.2.4 Drafts....................................................... 24
4.2.5 Sentbox ................................................... 24
4.2.6 Templates................................................ 25
4.2.7 Voice mail server .................................... 25
4.2.8 Settings.................................................... 26
4.2.9 Message capacity .................................... 27
4.3 CALL CENTER................................................ 28
4.3.1 Dialed calls.............................................. 28
4.3.2 Received calls ......................................... 29
4.3.3 Missed calls............................................. 29
4.3.4 Rejected calls .......................................... 29
4.3.5 Call settings............................................. 29
4.4 SETTINGS............................................................ 34
4.4.1 DUAL-SIM Settings…………………....36
4.4.1 Phone settings ......................................... 35
4.4.2 Security settings ...................................... 36
4.4.3 Restore factory settings. ..................... 38
5
4.5 PROFILES ............................................................ 38
4.6 MULTIMEDIA ...................................................... 40
4.6.1 Mobile TV………………………..……..42
4.6.1 Camera .................................................... 41
4.6.2 Image viewer........................................... 43
4.6.4 Video recorder………….………………45
4.6.4 Video Player............................................ 44
4.6.3 Audio Player ........................................... 45
4.6.5 FM Radio ................................................ 46
4.7 ORGANIZER......................................................... 47
4.7.1 Alarm ...................................................... 47
4.7.4 Calculator .............................................. 47
4.8 FILE MANAGEMENT..................................... 48
4.9 INTERNET ....................................................... 49
4.9.1 STK……………….………………….…51
4.9.2 WAP........................................................ 49
4.9.3 Connections............................................. 50
4.10 TIME AND DATE .................................................. 50
4.11 CALENDAR ......................................................... 50
4.12 EXTRA ................................................................ 51
4.12.1 Bluetooth................................................. 51
4.12.2 Facebook ................................................. 52
6
5 TEXT INPUT....................................52
6 CARE AND MAINTENANCE........52
1 Basic Information
1.1 Brief Introduction
Thanks for selecting VENUS L color screen GSM digital
mobile phone. Through reading the manual, you can fully know
how to use VENUS L mobile phone, appreciate its complete
function and simple operating method.
VENUS L color screen mobile phone is designed aiming at
GSM network environment; the phone is Two Card Two Standby,
but you can not call another SIM card when one SIM card is under
phone call. Besides basic call functions, VENUS L also provides
many kinds of practical functions, such as name card holder, scene
mode, message, audio and video player, camera and video, game,
Bluetooth, alarm clock, calculator,, STK, time and date, auto
![](/img.php?id=1863877&img=bg7.png)
7
power-on and shut-down and etc. so that convenient for your work
and leisure activities. In addition, VENUS L adopts personalized
human-computer interface design, its complete function can meet
your different requirements.
VENUS L color screen mobile phone accords with GSM
criterion, has obtained the certification of competent authority.
The company reserves the rights to revise the contents of the
manual without prior notice.
2 Before Use
2.1 Name and Explanation of Each Part
2.1.1 Appearance Sketch Map
The picture is only for your reference.
2.1.2 Description of the Standby Pictures
Network signal strength
The more the stripe is, the stronger the signal is.
![](/img.php?id=1863877&img=bg8.png)
8
When SIM card 1s inserted in card slot 1, standby
screen will show the icon.
Network signal strength
The more the stripe is, the stronger the signal is.
When SIM card 1s inserted in card slot 2, standby
screen will show the icon.
Battery strength
The full the fill is, the more electric quantity is.
Standby screen will show the icon.
Silent mode
When scene mode is set as mute mode, standby
screen will show the icon.
Meeting mode
When scene mode is set as Vibration mode
, standby screen will show the icon.
Indoor mode
When scene mode is set as indoor mode, standby
screen will show the icon.
Outdoor mode
When scene mode is set as outdoor mode, standby
screen will show the icon.
9
2.2 Install SIM Card and Memory Card
2.2.1 SIM Card
Before using the phone, you must insert valid SIM
(Subscriber Identity Module) card in the phone. SIM card 1s
provided by network supplier.
All the information related to network connection are
recorded in the chip of SIM card, also the names, telephone
numbers and SMS that storing in the name card holder of SIM card.
You can take out SIM card from your phone, and use it in any
GSM mobile phone (new mobile phone can read SIM card
automatically).
In order to avoid losing or damaging the information saves in
SIM card, please don’t touch the metal contact surface, and place
SIM card in the place that away from electricity and magnetic
force. Once SIM card is damaged, you can’t use the phone
normally.
Prompt: Please make sure to power off the phone before taking
out SIM card. It is absolutely forbidden to insert or take
out SIM card with external power supply; otherwise it
may damage SIM card and the phone.
10
2.2.2 Inserting and Taking out SIM Card
Metal contact surface of SIM card is easily scratched. You
must take out SIM card carefully before the assembly.
Power off the phone, remove the rear cover, battery or other
external power supply.
Make the end of SIM card without cutting angle inside and
aim at the card slot of the phone and metal surface of SIM
card face downward, then insert SIM card to the card slot of
the phone, the other SIM card is also inserted in this way.
When taking out SIM card, directly pull it outward and then
can take out SIM card.
Prompt: Without special explanation inserting two SIM cards
are defaulted in the manual. If you just insert one
SIM card, maybe some options of the menu will not
be shown.
2.2.3 Memory Card
Aim at the T card slot and push the T card gently, and the card
will be inserted correctly.
Prompt: If the memory card is failed, please check whether it
is correctly placed and good contact of metal point.
11
2.3 Battery
2.3.1 Install the Battery
Take off the rear cover, of the mobile.
Make one end of battery with metal surface aim at the battery
connector.
Then gently press the battery downward using the finger, and
then press the other end to install the battery.
Prompt: Please operate correctly to avoid damaging the
battery connector.
Do not place the battery in fire ; follow local laws and
ordinances in Disposing used battery.
Check the model number of the charger before using it to
charge the mobile.
Only use approved battery , charger and accessories applicable
to the specific mobile model . Using other types of battery ,
charger and accessories may violate the certification or
warranty terms of the accessories may violate the certification
or warranty terms of the equipment and may result in danger .
Return waste and used batteries to the supplier or specified
recovery site .
CAUTION!
12
Risk of explosion if battery is replaced by an incorrect type .
Dispose of used batteries according to the instructions .
2.3.2 Charging
Insert the charger on the charging interface at the side end of
the phone.
After inserting the charging plug, battery strength icon stripe
at the top right corner of the screen is scrolling, which means that
the charging is processing; when the stripe is full of the whole icon
and stop scrolling, which means that the battery charging is
completed; when the charging is completed, please pull out the
plug.
When electric quantity is not enough, warning message will
be sent; and electric quantity shows empty. When electric quantity
is too low, the phone will power off automatically. Please don’t
make the battery in the status of not enough electric quantity for a
long time; otherwise it may damage the battery quality and service
life. Please don’t charge the battery for a long time.
Prompt: In order to ensure normal operation of the phone,
please make sure to use the designated charger.
13
2.4 Security Password
PIN
PIN (Personal Identification Number) is used to prevent your
SIM card from being used illegally. PIN is usually provided with
SIM card together. If you input wrong PIN for continuous three
times, please input PUK to unlock it. Please contact with network
operations company for more details.
PIN 2
You need to input PIN2 when entering some functions (such
as call charge); if you input wrong PIN2 for continuous three times,
you need to input PUK2 to unlock it. Please contact with network
operations company for more details.
PUK
When changing the locked PIN, you need to input PUK
(Personal Unlock Key). PUK is provided with SIM card together.
If it is not provided, please contact with your service provider. If
you input wrong PUK for continuous ten times, the SIM card can’t
be used again. Please contact with your service provider to buy
new card. You can’t change PUK. If you lose the code, please
contact with your service provider.
PUK2
When changing the locked PIN2, you need to input PUK2. If
you input wrong PUK2 for continuous ten times, you can’t use the
14
functions that need PIN2. Please contact with your service provider
to buy new card. You can’t change PUK 2. If you lose the code,
please contact with your service provider.
3 Quick User Guide
3.1 Feature Functions
The phone has not only the basic functions of mobile phone,
but also support rich, practical and rapid feature functions, can be
briefly introduced as follows:
Contacts: Each name card holder record stored in the phone
can be related with several telephone numbers at most, the
phone can store 100 records at most; can send SMS in the
name card holder; you can copy name card holder record
between SIM card and the phone.
Profiles: Custom the ringtone (include ringtone settings,
volume adjustment, incoming call prompt, message prompt,
alarm clock prompt, key-press tone, low voltage warning
tone, power-on and power-off tone) according to different
events or environment.
Call log: The phone will automatically store the information
15
of call log for you to check; support to call the telephone
number in the call log; support to save the telephone number
in the call log to name card holder and set as rejected call;
support the function of sending SMS and etc. to the telephone
numbers in the call log.
Message: The phone supports storing SMS and 50 pieces at
most. The phone supports the storing status of SMS in SIM
card and the phone.
Multimedia: Your phone provides all kinds of entertainment
services including player, camera, FM radio and other
functions.
Camera: The phone supports camera and video function. You
can customize the camera and video, and switch between
prepositive and postpositive video captures through menu
option.
Organizer: The phone supports various practical functions.
Supports alarm clock, calendar, calculator and other
functions.
Settings: You can customize the phone according to the needs,
include phone settings, display settings, call settings, security
settings and other functions.
Input method: The phone supports various input modes,
which is convenient for you to input English, letters, numbers,
16
symbols, and etc.
3.2 Dial a Call
In standby mode, press numerical keys to input phone
number to dial phone number. When you finish inputting phone
number, press the dial key to make a call. If you're making a long
distance call, add the area code preceding the telephone number.
3.3 Reject a Call
You can press End key to reject an incoming call.
3.4 Receive a Call
When an incoming call arrives, the phone will give out the
corresponding prompt (such as vibration, ringtone, and etc.); if
network support, the phone screen will show the name and
telephone number of the caller; at this time, you can press Dial key
to receive an incoming call.
3.5 End a Call
After finishing a call, you can press End key to end a call.
17
3.6 Emergency Services
You can directly dial an emergency service call without SIM
card.
Different network uses different emergency numbers, please
consult your network operations company for more details.
3.7 Extension Speed Dial
After inputting telephone number, if you want to input branch
number, please press and hold “*”, input your extension number
after the display screen shows “P”. After getting through the call, it
will directly dial the extension.
3.8 Dialed Calls/Missed Calls/Received
Calls/Rejected Calls
You can enter call log to check the relevant details of dialed
calls, missed calls, received calls and rejected calls.
Prompt: The record of incoming call from blacklist number
will be saved in Rejected Calls.
3.9 Call Forward
After call forward function is started, according to different
forward conditions settings (Call Forward Unconditionally,
18
Forward Busy, Forward No Answer, Forward Can Not Reach), you
can select to switch the incoming call to voice inbox or other
telephone numbers.
3.10 Call Waiting
After call waiting function is started, when you are calling,
the other call can be put through.
3.11 Call Barring
After call barring function is started, according to different
restricted conditions settings (all the dialed calls, all the incoming
calls, incoming calls when roaming, dialed international calls,
outgoing international calls when roaming), you can restrict the
call under the corresponding conditions (need to apply to network
operator for business).
3.12 Power off the Phone
In the standby mode, press and hold End key to power off
the phone.
19
3.13 T-flash Card
Insert the T-Flash card into phone from the background.
This will expand the Flash memory of the phone.
Tap Multimedia menu, you can browse MP3, MP4, picture, video,
photograph etc.
4 Function Menu
4.1 Phonebook
This function could help you browse the name card holder,
store, edit and delete the names and phone numbers in the phone
and SIM card. To facilitate the management of the records, this
phone sets the group function, collecting the similar items into a
group. The storage capacity of the SIM card varies and the
maximum storage capacity of this phone is 100.
On the standby interface, press right soft key to enter the
interface of the name card holder. When the record of the name
card holder is not empty, press left soft key for the following
operation:
Prompt: Take the records in SIM card 1 for example.
20
4.1.1 New
Create new name card holder records to SIM card or the
mobile phone.
4.1.2 Search
Search the record stored in the phone or the SIM cards.
4.1.3 SMS
Send SMS message to this record.
4.1.4 Call
Dial this record directly or by means of IP call.
4.1.5 Delete
Delete this record.
21
4.1.6 Mark
Choose one record or all records, and cancel what you choose
are also allowed.
4.1.7 Copy
Copy the record to SIM cards or memory card.
4.1.8 Others
――Caller ID: You can view or edit the number of this
phone.
――Memory status: You could enquire the capacity of SIM1,
SIM2 and the phone.
――Single /Double line display: You can set the display
mode of record list as one line or two lines.
22
4.2 Messages
4.2.1 Write Message
You could write new message by using this function. When
you input the message to be sent, press left soft key to send, to
insert the templates, to add contact person information and symbol,
and to save, etc.
--Send: Enter the interface of input number, you can dial the
phone number directly, or press left soft key to
enter the name card holder and choose the number
to send.
--Insert template: Enter the templates interface and you could
insert the template to the message.
--Add contact info: Enter the Name card holder interface and
you could insert the name card holder
information to the message.
--Add phiz: Enter the symbol interface and add the symbols to
the message.
--Save: Save this message to the drafts.
23
4.2.2 Inbox
Store the SMS message you’ve received. The SMS message
could be differentiated by different icons. The icons before the
message list means whether this message is SMS message and
which is stored in SIM1, SIM2 or the phone.
Choose one SMS press left soft key, then you will do several
operations, for example, reply the SMS, delete, dial and mark.
Press OK key directly you can read this SMS.
――Reply: You could choose to reply the addresser by SMS.
――Delete: Delete this message.
――Call: Call the addresser.
--Lock/unlock: Lock the message or unlock it.
――Mark: Choose this message or all messages in the inbox,
or only choose the messages saved in SIM 1, SIM 2, SIM1storage
SMS or SIM2 storage SMS
――Sort: Sort the messages in the inbox by time, contact
person, theme or message type.
――Delete repeated numbers: Delete all the messages of the
same number.
24
4.2.3 Outbox
Store the SMS you’ve sent in failure. The SMS could be
differentiated by different icons. The two icons before the message
list means whether this message is SMS, and it is stored in SIM1,
SIM2 or the phone.
Choose one SMS and press left soft key, you could send,
delete, lock, mark, sort, and so on.
4.2.4 Drafts
Store the SMS you’ve edited. The SMS could be
differentiated by different icons. The two icons before the message
list means whether this message is SMS, and it is stored in SIM1,
SIM2 or the phone.
Choose one SMS press left soft key, you could delete, edit,
lock, mark, sort, and so on.
4.2.5 Sentbox
Store the SMS you’ve sent successfully. The SMS could be
differentiated by different icons. The two icons before the message
25
list means whether this message is SMS, and it is stored in SIM1,
SIM2 or the phone.
Choose one SMS and press left soft key, you could delete,
forward, lock, mark, sort, and so on.
4.2.6 Templates
You could edit or delete the templates.
4.2.7 Voice mail server
This phone supports the function of the voice mail. You could
choose either SIM1, SIM2. When you receive the calls from others,
they could give you a message in your voice mailbox. When you
phone receives the message notice, you could listen to the
messages. Under the voice mail interface you can edit and set the
number of line 1, line 2, fax or data.
Prompt: The realization of the voice mail requires the support
of the network operator and you may firstly apply for
this service. For more information and the number of
the voice mail, please inquire about your local network
operator.
26
4.2.8 Settings
SMS Settings
There are seven options: SIM 1 service center, SIM2 service center,
service center validity period, status report, save sent message,
prior storage medium.
--SIM1 msg center: Display the SMS service center number
in SIM1.
--SIM2 msg center: Display the SMS service center number
in SIM2.
--Massage validity period: You could set the validity period of
the message for 1 hour, 6 hours, 24 hours,
72 hours, 1 week and the maximum value.
Prompt: This time is related with the services of the network
operator.
--Status report: May choose to start up or shut down the
delivery report. After switching this
function as on, when the receiver gets
the message or doesn’t get for some
reason, the SMS service center will
give you a delivery report, so you will
27
know whether your message sent
successfully or not conveniently.
--Save sent messages: There are three options: “prompt”,
“Save”, “Not save”.
Prompt: Before sending the message,
you will be suggested to choose “Send
and Save” or “Send only”.
Save: Save automatically your sent
message.
Not save: Not to save automatically
your sent message.
--Preferred storage: You could choose the preferential storage
position at SIM card or phone.
Broadcast message
――Broadcast launch: Choose to start up/shut down the
broadcasting.
――Channel settings: Set the channel to receive the area
message.
――Languages: Set different languages.
4.2.9 Message capacity
You could view the capacity of SMS.
28
4.3 Call Center
Display your recent call log.
4.3.1 Dialed calls
Display the list of your recent dialed numbers.
On the interface of Dialed, choose one record, then press left
soft key “Option” to enter the Option interface and you could go
on the following operations.
Details: Display the information of dial calls (Number, Date,
Time, Duration, From, Style, and SIM Name)
Call: Recall the number.
Edit: Edit the number.
Save: Save the number to Phone/SIM1/SIM2
Send SMS: You could send message to this number.
Add to the existed contact: Add this number to the existing
record of the name card holder.
Add to blacklist: Add this number to the blacklist.
Delete: Delete this record.
Delete all: Delete all the records in the Dialed list.
29
4.3.2 Received calls
Display the list of your recent answered numbers. The operation is
the same as the Dialed.
4.3.3 Missed calls
Display the list of your recent missed numbers. The operation is
the same as the Dialed.
4.3.4 Rejected calls
Display the incoming call records in the blacklist. The operation is
the same as the Dialed.
4.3.5 Call settings
Network selection
This function can let you select the network manually or
automatically when the phone is in the roaming state. You can use
30
this function only after you have made an effective roaming.
Select SIM1/SIM2 and then access:
-Auto Select: Press the left key and Ok, the mobile phone will
search various networks. This operation will let your phone
register the most suitable network.
-Manual Select: Press the left soft key and Ok, the mobile phone
will search various networks. You can select the suitable network
from the listed networks.
Call divert: When “call divert” function is started up,
you can transfer the incoming call to voice inbox or
other phone number according to the scheduled
“ call divert” conditions.
――Call forwarding unconditional: All incoming calls
will be transferred to voice inbox or
other phone number according to
the setup.
――Call forwarding on busy: When your number is
busy, the incoming calls will be
transferred to voice inbox or other
phone number according to the
setup.
――Call forwarding on no reply: When there are
31
missed calls in your phone, they
will be transferred to voice inbox or
other phone number according to
the setup.
――Divert If Unreachable: When your phone is power
off or out of the service area, the
incoming calls will be transferred to
voice inbox or other phone number
according to the setup.
――Cancel All Diverts: You can delete all settings of
call divert.
Call barred: All outgoing calls, incoming calls,
roaming incoming calls, international outgoing calls,
roaming international outgoing calls are available.
――All outgoing calls: Activate/Deactivate/Check
Status
――All incoming calls: Activate/Deactivate/Check
Status
――Incoming calls when roaming:
Activate/Deactivate/Check Status
―― ISD calling: Activate/Deactivate/Check Status
――Dial when INTL roaming:
32
Activate/Deactivate/Check Status
――Cancel all barring : Cancel all restrictions on the
call.
――Change Password: You can consult your network
operator about the call
barring password.
Prompt: The above-mentioned function will have to need
network support. To use the function, please contact
your network service provider.
Call waiting: You can start up or shut down the
function. When it is started up, even when you are
making a call, you can also receive another income
call.
Hide ID: This function must be supported by
network.
Select SIM1/SIM2
-Hide ID
-Display own ID
-Display ID by Network
33
Select line: There are two lines can be selected:
line 1 and line 2. But the function just for the phone
which has one SIM card and two numbers. If your
phone is not the type like that, please just select line
1, because if you choose line 2, dialing will be
limited.
Select SIM1/SIM2
—Line 1
—Line 2
Flight mode: You can start up the function
directly or choose when power on. It is used on
flight. When flight mode is working all the functions
connect with network, such as SMS, dialing back,
WAP network, will be unavailable, to avoid
interfering the signal of the flight you take.
—Activate
—Select When Power On
Others:
――IP shortcut key: In this function, you can set IP call to
enter the number.
――50 secs warning
34
——Vibration when connected: Activated/Off
――Answer/Reject mode: SMS reply after reject/ anykey
answer
――Auto redial: Activate/ Deactivate
For a general setting,such as:SIM1 ,SIM2,SIM3,SIM4 call
setting(including Call ID ,Call waiting, Call divert, Call
barring),Auto redial, IP Dial, Call time display, Call time
reminder,Auto quick end.
4.4 Settings
You can customize the settings, such as time and date,
language, call settings etc.
4.4.1 Dual-SIM Settings
――Standby mode: Only SIM1 enable/ Only SIM2 enable/
Dual SIM dual standby
――Reply by original SIM: Call/SMS Reply by original
SIM
――Set SIM name: You can set any name you like as the
name of SIM card slot.
35
4.4.2 Phone settings
Select Language: You can select phone language.
Display:
z Wallpaper settings: You can set as default wallpaper
image as well as more other wallpaper images.
z Contrast: On the screen backlight interface you can set
different lightness of your phone by pressing the left/right
direction key.
z Backlight:
――Always on
――30secs
――20secs
――15secs
――10secs
――5secs
z Keypad backlight time:
――20secs
――10secs
――5secs
――night mode
――Off
36
z Animation effect:
――Power on display
――Power off display
Auto Power on/off: You can set the time and repeat mode of
power-on and power-off.
Power management: You can view the electric quantity of
your battery.
4.4.3 Security settings
――PIN
You can start up, shut down or modify PIN code.
Correct PIN code shall be input when you unlock or
shut down PIN code. If PIN code verification is
started up, each time when you switch on your
phone, you will have to input PIN code. If you input
mistaken PIN codes three times in a row, SIM card
will be locked. You will have to get PUK1 code to
unlock it. Please contact network operator to get
PUK1 code when necessary.
The default PIN code is 1234.
――PIN2
37
You can review PIN2 code. For details, please
contact network operator.
――Privacy
You can review privacy protection password. Besides,
you can also set passwords for some menus, in this
way, you will have to input password each time
when you desire to open the menus. The default
password of privacy protection mode is 1234.
――Auto Keypad lock
-Off
-5 secs
-15 secs
-30 secs
-1 min
-5 mins
――Lock screen by end-key
-Activated
-Off
――Power-on password
You can start up or shut down “phone password” or
revise it. When “phone password” is started up, you
will have to input “password” each time when you
use the phone. The default phone password is 1234.
38
4.4.4 Restore factory settings: You can restore part of
the phone settings as factory settings. The
default code of restoring factory settings is: 1234.
4.5 Profiles
You could set different scene modes.
——Normal
——Silent
——Metting
——Indoor
——Outdoor
You could active, customize or rename.
Ring Settings
――SIM1 call ring: You could set the ringtone of SIM1 into
fixed tone or more tones.
――SIM2 call ring: You could set the ringtone of SIM2 into
fixed tone or more tones.
――SIM1 MSG ring: You could set the message tone when
39
the SIM1 receives the message.
――SIM2 MSG ring: You could set the message tone when
the SIM2 receives the message.
Adjust Volume
――Caller ringtone: You could set the ringtone volume when
there is an incoming call.
――message ringtone: You could set the ringtone volume
when there is an incoming message.
――Call volume: You could set the volume when you are
calling.
――Alarm & calendar ringtone: You could set the volume of
the alarm clock when it rings.
――Power ringtone: You could set the volume when power
on or power off.
Call Alert
You could set the incoming call alert for the SIM1 and
SIM2 and there are five options for you to choose: ringtone,
vibrate, Silent, vibrate then ring, ring and vibrate.
Message Alert
You could set the incoming message alert for the SIM1
and SIM2 and there are four options for you to choose:
ringtone, vibrate, silent, ring and vibrate.
Alarm & calendar remind
40
You could set the alarm clock alerts into ringtone, vibrate,
silent, ring and vibrate.
Key Tone
You could set the keypad tone into silent, ringtone 1 and
ringtone 2.
Battery Low alert
You could set to start or close the low voltage alarms.
After starting this function, when the electric quantity of the
battery is low, the low voltage alarm will ring.
Power ring tone
You could set the tones when starting up and shutting
down the phone.
4.6 Multimedia
4.6.1 Mobiel TV
You can watch TV freely. Enter the TV interface first time,
search the channel automatically, and change previous or next
channel by pressing the left and right direction keys
On the interface of the TV playing, press left soft key you
could enter the options menu and do operations as follows:
--Location: Select your area in the area list
--Dissolve noise: Setup the dissolve noise on or off.
41
--Search: Auto search the channel in your area.
4.6.2 Camera
The device is equipped with a webcam with high pixels. You
can take photo at any time and save the photo in the device or
SIM card. The photo can be used as wallpaper of your device or
you can send it to your friends through Bluetooth.
You can view the photo on screen and press camera key to get
a picture. On the photo preview interface (screen rotate), press
up/down direction key to adjust focus; press left/right direction
key to adjust menu settings; press OK key to get the picture;
――Mode :You can change the DC or DV mode
Size: You can set the photo image size.
――Night mode: You can set up the image modes as
normal and night.
――Brightness: Six levels of brightness are available.
――Contrast: Six levels of contrast are available.
――Exposure bias: Six level of exposure compensation are
available.
――White balance: You can set as automatic white
42
balance, incandescent lamp, fluorescent
lamp, daylight and cloud.
――Delay: You can set up the timer as: Forbidden, 3S and
10S.
――Effect: The special effect can be classified into:
normal, black and white, red, green, blue,
yellow, canvas and negative.
――Flashlight: You can select “on” or “off”.
In camera preview interface press left soft key you can
enter options menu as follows:
――Gallery: Enter into image browser list.
――Settings:
―Quality: There are three options in photo image
quality: Advanced, Common and Low.
The default mode will be “Common”.
―Banding: You can set as 50Hz or 60Hz.
―Shutter sound: You can set up the sound of shutter as:
Active or Off.
―Auto save: You can select “Active” or “Off”.
―Display parameters: You can select “Active” or “off”.
Prompt: Observe photographing related local laws and
regulations. Do not use the function in illegal way.
43
4.6.3 Image viewer
Enter the images list interface, press left soft key, you could
go on the following operations.
--Change folder: change the images folder.
--Send: send this file to Bluetooth.
--Slide play: view this file as full screen.
--Delete: delete this image.
--Set image as wallpaper: set this image as wallpaper
--Rename: rename the file
--Mark: choose the image or all of the images.
--Details: to show the images details.
--Slide settings: to setup the slide about effect and slide
delay time.
4.6.4 Video recorder
The device is equipped with a video capture so that you can
chat with your friends through it. A driver is needed to be
installed when the video capture function is used. The details can
be found in driver installation guide.
――Size: You can set the photo image size.
44
――Brightness: Six levels of brightness are available.
――Contrast: Six levels of contrast are available.
――Effect: The special effect can be classified into:
normal, black and white, red, green, blue,
yellow, canvas and negative.
In camera preview interface press left soft key you can
enter options menu as follows:
――Settings:
―Banding: You can set as 50Hz or 60Hz.
4.6.5 Video Player
This phone supports the video format of 3GP and MP4.
Enter the video play list interface, press left soft key, you
could go on the following operations.
--Play list: to show the video files.
-- Fullscreen play
-- Order play: You can set as open or close.
--Video application: You can set the video file as power
on animation or power off animation
--File attribute: to show the video file details.
45
4.6.6 Audio Player
This phone could play the MP3 stored in the phone memory
and support the background play.
Press the left soft key or "OK" key to enter and use the Navigation
keys to operate the MP3 player.
Press” +” key and” –“ key to adjust volume. Press left soft key to
access Options:
On the audio player interface, move cursor to the shortcut
keys on the screen, you could rapidly operate the MP3 functions.
Under the MP3 list interface, press left soft key, then you can
do operations as follows:
--Music list: Display all the MP3 or the play list you’ve
saved.
--Music mark: Mark the selected MP3 to play.
--Add: Add the selected MP3 to the list.
--Play mode: Selected the play mode repeat or shuffle.
--Settings: Set the music setting display.
--Exit: Return to previous menu.
Prompt:
In the main interface of “Play MP3’ press hang-up key
to return, the background broadcasting status will remain
46
and the standby interface will display the name of the
music played in circulation.
4.6.7 FM Radio
You can listen to Fm radio freely. Enter the radio interface,
search the frequency automatically by pressing the up and down
direction keys, and change previous or next channel by pressing
the left and right direction keys。
On the interface of the Radio playing, press left soft key you
could enter the options menu and do operations as follows:
--Auto search and save: Search frequency available
automatically and save it to broadcasting station list.
-- Channel list: You can view all the broadcasting stations
you saved.
--Save: Save the frequency you searched to the list.
--Manual search: Search the broadcasting station by input
frequency manually.
--Open/Close speaker: You can start up loudspeaker to
make the sound louder.
--Background play: When the function is on, you can do
other operations while listening to the radio.
--Help
47
Prompt: Please connect with the earphone before you listen to
the radio, for the device is equal to radio antenna. When the
battery of your cell is insufficient, you may not enter the TV or
Radio channel.
4.7 Organizer
4.7.1 Alarm
You can edit alarm, time, ring and repeated ring mode.
In “ alarm edit” mode, you can scroll up or down direction
key, when the cursor goes to the desired option, press “OK”, then
you can select desired settings.
The alarm clock feature sounds an alert or makes a vibration
alert at a time you specify.
-Alarm1
-Alarm2
-Alarm3
4.7.2 Calculator
The function will make your device a calculator with which
you can carry out simple math calculation.
48
Write by stylus to enter the numbers. Use following
direction keys to calculate:
Up, down, left, right key: +、-、×、/
OK key: Show the calculation result.
* Key: Decimal point
4.8 File manager
You can check the specific content and service condition of
the phone memory via this function. Meanwhile, you can format
memory, too.
Choose one folder and press left soft key, then you can
operate as follows:
1. New folder: Create a new folder.
2. Delete: Delete the folder.
3. Details: Check details of the folder, name,
date, size, position and so on.
4. Edit: Re-name or copy the folder.
5. Search: Search the file in the folder.
6. Sort: To sort according to name, date, size
and type.
7. Mark: Mark one or all the folders in phone
memory.
8. More:you can check the memory capacity ,or
format MemoryCard.
49
Prompt: There is no own memory capacity in the phone.
4.9 Services
4.9.1 STK
This function is provided by network supplier, such
as mobile monternet, M-zone, global and some other
brand increment service. This function isn’t available if it
is beyond SIM card and network supplier’s support. So
please contact network supplier to get more.
4.9.2 WAP
Your mobile phone support the service based on
wireless application protocol(WAP).You can access all the
service supported by your network supplier.
Note: GPRS service is available after being open and
in the range covered by network.
¾ About Us:Into view the current mobile phone supports
50
WAP version.
4.9.3 Connections
Network account
You can view/select network count which you want to use.
GPRS settings
You can select connect when needed, always connect.
4.10 Time and date
You can set up the date and time on the phone as well as their
display mode.
4.11 Calendar
You can use this feature to view the year, date and solar term
easily. Use up/down/left/right direction key to navigator other date.
――Go to Date: Enter the Solar calendar and it can go to the
date you want to check.
――Weekly
51
4.12 Extra
4.12.1 Bluetooth
Open/Close Bluetooth
You can choose to “open” or “close” Bluetooth.
Bluetooth visibility
You can choose “show phone” or “hidden” Bluetooth. If the
Bluetooth is hidden, others cannot search your phone.
Paired device
You can search different Bluetooth equipments and find
compatible ones (as long as the PIN codes of two Bluetooth
equipments are identical with each other, the match will be
successful. The PIN code of Bluetooth earphone is different due to
different type, and you can find the code in operating manual of the
Bluetooth earphone.).
My Bluetooth name
You can change the name of the phone.
Bluetooth file storage
Help
You can view the operating instruction of Bluetooth.
52
4.12.2 Facebook
You can go to the Facebook website.
5 Text Input
The device provides several text input modes so that you can
write text or input data in your “contacts”, edit “contacts” record,
search English names and write SMS .
In “text input” mode, if you want to change the input way,
you can press “ alt” key. The selected input way will appear on the
top left of the screen.
6 Care and Maintenance
Maintenance of battery
·Your device is powered by a rechargeable battery. It is necessary
to have the battery charged when it is going to wear out. The full
performance of a new battery is achieved only when it is fully
53
wore out.
·Unplug the charger from the electrical plug and the device when
not in use. Do not leave fully a charged battery connected to a
charger over a week, since overcharging may shorten its lifetime.
·Temperature tends to affect the limit of battery to be charged.
Therefore, it is necessary for the battery to be cooled or warmed
before it is charged. If the temperature of batter exceeds 40ºC ,the
battery cannot be charged.
·Use the battery only for its intended purpose and avoid
short-circuiting. Accidental short-circuiting can occur when a
metallic object causes direct connection of the positive (+) and
negative (-) terminals of the battery.
·Do not use damaged battery.
·Leave the battery in hot or cold places will reduce the capacity
and lifetime of the battery. A device with a hot or cold battery may
not work temporarily, even when the battery is fully charged.
·Do not dispose of batteries in a fire as they may explode. Dispose
of batteries according to local regulations.
Care of maintenance of your device
The suggestions below will help you protect your warranty
coverage.
·Keep the device and accessories out of the reach of small children.
·Keep the device dry. All types of liquids or moisture will corrode
54
electronic circuits.
· Do not store the device in hot areas. High temperatures can
shorten the life of electronic devices and warp or melt certain
plastics.
·Do not attempt to open the device other than as instructed in this
guide. Non-professional handling may damage the device.
·Do not use harsh chemicals or strong detergents to clean the
device.
·Use only the supplied or an approved replacement attachments,
for the unauthorized ones could invalidate the warranty of
maintenance.
FCC Caution
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
55
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
SAR tests are conducted using standard operating positions
56
accepted by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands, although the
SAR is determined at the highest certified power level, the actual
SAR level of the phone while operating can be well below the
maximum value, in general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a new model phone is a available for sale to the public, it
must be tested and certified to the FCC that it does not exceed the
exposure limit established by the FCC, Tests for each phone are
performed in positions and locations (e.g. at the ear and worn on
the body)as required by the FCC.
For body worn operation, this model phone has been tested and
meets the FCC RF exposure guidelines when used with an
accessory designated for this product or when used with an
accessory that
Contains no metal and that positions the handset a minimum of 1.5
cm from the body.
Non-compliance with the above restrictions may result in violation
of RF exposure guidelines.
