IZZO GOLF 3159860000 Speed Radar User Manual IZZO ok
IZZO Golf Speed Radar IZZO ok
user manual
IZZO Speed Pro Instruction Manual
Technical Specifications:
- Swing Speed Mode: 40 to 150 mph
- Ball Speed Mode: 40 to 150 mph
- Distance Range (Ball Speed mode): Approximately 40 ft.
- Battery type: 5pcs AA batteries (batteries not included)
- Operating Time: Without Voice up to 50 working hours, With Voice up to 30 working
hours
- Operating Temperature Range: 32 – 104F / 0 – 40C
Battery Installation:
The Speed Pro operates on 5 AA batteries. To install, please open the cover on the back
of the Speed Pro. After that insert all batteries per layout shown, put the cover back on.
(Note: The Speed Pro turns off automatically when it does not measure any speed for 5
minutes). When battery power is low, the LED screen will show "Lo" and repeat every 30
seconds until you replace the batteries.
How to use:
1. Push ON/OFF button on the back to turn on the Speed Pro
2. Push KPH/MPH button to choose which measurement you prefer. The LED light will
indicate which one you chose.
3. Push VOICE button to have speaker announce the readings (A1 will appear on the
LED). Push again to switch off (A0 will appear on the LED).
4. Push B.S/S.S. button to choose which speed mode you want. When LED screen
shows BS, it is in "Ball Speed Mode". When LED screen shows SS, it is in "Swing Speed
Mode".
5. Push REC button to see the last 10 recorded speeds.
Positioning the Speed Pro:
- For “Ball Speed” place the Speed Pro on the ground approx. 1.5 – 2 ft. behind Hitting
Net.
Important: A large or solid hitting target made interfere with the Speed Pro’s speed
detection, we recommend you either raise the target or remove it while using your Speed
Pro.
- For “Swing Speed” place the Speed Pro on the ground 1 ft. away from the ball you are
hitting, make sure the Speed Pro’s LED screen is facing towards you.
What’s more important, Ball Speed or Swing Speed?
Actually the combination of both of these will allow you to add distance to your shots. But
probably the best way to increase distance is to develop a consistent Ball Speed. The
Ball Speed measures how solid your contact is, you can have a high Swing Speed but
you won’t get the maximum distance if you don’t make solid contact. Use the following as
a reference point for your practice, the Ball Speed of a well struck, solid shot should be
approx 1.4 times your Swing Speed (100mph Swing Speed = 140mph Ball Speed). With
this in mind we recommend you first determine your optimal Swing Speed first then you
can determine what your optimum Ball Speed is. We have also included a reference card
that will give you the approximate Driver distance in relation to Swing Speed.
FCC statement:
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this is equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference b one or more of the following
measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Consult the dealer or an experienced radio / TV technician for help
FCC Caution:
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This device and its antenna(s) must not be co-located or operation in conjunction with any
other antenna or transmitter.
For further information, contact: customer service: (800) 536 7900 or sales@izzo.com
For any questions or warranty issues please contact IZZO Golf at:
www.izzo.com
