IZZO GOLF C70120 Allsport Watch User Manual
IZZO Golf, Inc. Allsport Watch
User Manual
A. [ POWER ] - HOLD to Power On/O, PRESS
to turn Backlight On/O
B. [ UP ] - Scroll Up
C. [ OK ] - PRESS to
Toggle Screens, Select
Options - HOLD to
access Main Menu.
D. [ DOWN ] - Scroll Down
E. [ BACK ] - PRESS to
return to previous
screen, PRESS to toggle
analog/digital time display
while on time screen.
QUICK START
CHARGING
1. Attach the magnetic pins on the charging
cord to the magnetic charging ports located
on the back of the watch.
2. Make sure the pins are aligned, then insert
the other end of the charging cord into a
USB port or AC adapter (not included).
To view complete user manual visit: www.CallawayDMD.com/product-support
BUTTON DIAGRAM
CHARGING
PINS
CHARGING
PORT
END ROUND
1. When nished with your round, HOLD the [ OK ]
button to return to the Golf Menu.
2. If Scorecard is turned on, use the [ Up/Down ]
buttons to scroll to desired option, then Press
and Release the [ OK ] button to select.
• Save & Exit - Save Scorecard, end round, and
return to Golf Menu.
• Discard & Exit - Discard Scorecard, end
round, and return to Golf Menu.
• Cancel - Select to return to Play Mode.
Note: Saved Scorecards can be viewed by selecting
Score History in the Golf Menu and can be uploaded
then viewed on the free App.
FREE APP
Search for ALLSPORT in the app
store. (Image of app)
Note: Compatibility depends on model
of Smartphone and version of operating
software. Features may vary or could be
limited due to compatibility conicts.
For AppleTM: Compatible with iOS 9.0
or above.
For AndroidTM: Compatible with OS 5.0
or above.
*ANDROID IS A TRADEMARK OF
GOOGLE INC
To return to the Play Mode screen
(distances to green) Press [ OK ] again.
To access the Scorecard, press the
[ OK ] button while on the Hazard
Screen. Press the [Up] or [Down]
buttons to enter your score, then press
[ OK ] again to return to the Play
Mode Screen (distances to green).
Press the [ OK ] button again to
access Shot Distance Mode, & then
travel from where you hit your shot to
your ball. The distance that the shot
traveled will be displayed. To return to
the Play Mode screen (distances to
green), press the [ OK ] button.
Note: Shot Distance Mode can only be used
if turned ON in Settings.
1. HOLD [ POWER ] button until watch powers on.
2. Language - Use the [ UP/DOWN ] buttons to
scroll through the language options then Press
& Release the [ OK ] button to select.
3. Set Time - PRESS [ OK ] button to connect to
the satellites (must be outside) and the watch
will automatically set the correct date and time.
(This could take a few minutes) Press & Release
the [ OK ] button to continue.
4. Gender - Use the [ UP/DOWN ] buttons to toggle
between Male or Female, then Press & Release
the [ OK ] button to select.
5. Age - Use the [ UP/DOWN ] buttons to scroll to
your age then Press & Release the [ OK ] button
to select.
6. Unit - Use the [ UP/DOWN ] buttons to scroll to
the desired unit of measure, then Press & Release
the [ OK ] button to select.
7. Height - Use the [ UP/DOWN ] buttons to scroll
to your height, then Press & Release the [ OK ]
button to select.
8. Weight - Use the [ UP/DOWN ] buttons to scroll
to your weight, then Press & Release the [ OK ]
button to select.
9. The watch will then return to the time screen and
the set up process is complete.
SETUP
GOLF
1. From Time Screen, HOLD [ OK ] button to
access Main Menu.
2. Use the [ Up/Down ] buttons to scroll to Golf, then
Press & Release the [ OK ] button to select and
continue to the Golf Menu.
3. Use the [ Up/Down ] buttons to scroll to Play Golf,
then Press & Release the [ OK ] button to select.
4. Once satellite connection is established, the
nearest golf courses will be listed. Use the
[ UP/DOWN ] buttons to scroll to desired course,
then Press & Release the [ OK ] button to select.
ON THE COURSE
1. Play Mode will now display
the distance to the Front, Center
& Back edge of the green for the
current hole.
2. While in Play Mode, press the [ OK ]
button to access the Hazard Screen.
Note: Scorecard can only be used if turned
ON in Settings.
Note: Watch will automatically switch to the
next hole if Scorecard is turned OFF. If
Scorecard is turned ON, a score must be
entered before the device will advance to
the next hole.
To view complete user manual visit: www.CallawayDMD.com/product-support
2 3 4 5 6 7
1
2
3
4
3.
4.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to
computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
