Identec Solutions ILR-ID2NA i-D2 NA Tag, Industrial & Personnel User Manual Part 15 with 38 dB rejection
Identec Solutions, Inc. i-D2 NA Tag, Industrial & Personnel Part 15 with 38 dB rejection
Users Manual
Rhein Tech Laboratories, Inc. Client Identec Solutions, Inc.
360 Herndon Parkway Model i-D2 NA
Suite 1400 Report No 2003025
Herndon, VA 20170 Standards FCC 15.249/IC RSS-210
http://www.rheintech.com Date March 10, 2003
Page 23 of 32
APPENDIX H: MANUAL
Please see the following pages.
Document # 7000-0001, Rev. A - 2 –
Disclaimer and Limitation of Liability
IDENTEC SOLUTIONS, Inc. and its affiliates, subsidiaries, officers, directors,
employees and agents provide the information contained in this Manual on an “as-is”
basis and do not make any express or implied warranties or representations with
respect to such information including, without limitation, warranties as to non-
infringement, reliability, fitness for a particular purpose, usefulness, completeness,
accuracy or currentness. IDENTEC SOLUTIONS, Inc. shall not in any circumstances be
liable to any person for any special, incidental, indirect or consequential damages,
including without limitation, damages resulting from use of or reliance on information
presented herein, or loss of profits or revenues or costs of replacement goods, even if
informed in advance of the possibility of such damages.
Trademarks
“IDENTEC SOLUTIONS”, “Intelligent Long Range”, “ILR” and the stylized “i” are
registered trademarks and “i-Q”, “i-D”, “i-CARD”, “i-PORT”, “i-LINKS”, “Solutions. It’s
in our name.” are trademarks of IDENTEC SOLUTIONS, Inc. and/or IDENTEC
SOLUTIONS AG.
Copyright Notice
Copyright © 2003 IDENTEC SOLUTIONS, Inc. All rights reserved.
No part of this document may be reproduced or transmitted in any form by any
means, photographic, electronic, mechanical or otherwise, or used in any information
storage and retrieval system, without the prior written permission of IDENTEC
SOLUTIONS, Inc.
Document # 7000-0001, Rev. A - 3 –
Radio Frequency Compliance Statement
IDENTEC SOLUTIONS, Inc. is the responsible party for the compliance of the following device:
MODEL: i-D2
TYPE: IL/NA, IL/NA-H
PL/NA, PL/NA-H
FCC ID: O2E-ILR-ID2NA
CANADA: 3538(A)-ID2NA
The user(s) of these products are cautioned to only use accessories and peripherals approved, in
advance, by IDENTEC SOLUTIONS, Inc. The use of accessories and peripherals, other than those
approved by IDENTEC SOLUTIONS, Inc., or unauthorized changes to approved products, may void
the compliance of these products and may result in the loss of the user(s) authority to operate the
equipment.
Operation is subject to the following conditions: (1) these devices may not cause harmful
interference, and (2) these devices must accept any interference, including interference that may
cause undesired operation of the device.
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communication.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his/her own expense.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Industry Canada Compliance
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Document # 7000-0001, Rev. A - 4 –
Table of Contents
1.0 INTRODUCTION........................................................................................................................................5
1.1 FUNDAMENTALS .........................................................................................................................................5
1.2 SYSTEM OVERVIEW ....................................................................................................................................5
1.3 OPERATIONAL DESCRIPTION.......................................................................................................................5
1.4 FEATURES ...................................................................................................................................................6
2.0 CONFIGURATION.....................................................................................................................................7
3.0 MOUNTING THE TAG..............................................................................................................................7
3.1 INDUSTRIAL TAG ........................................................................................................................................7
3.2 PERSONNEL TAG .........................................................................................................................................7
4.0 TECHNICAL SPECIFICATIONS.............................................................................................................8
5.0 TECHNICAL CONTACTS:.......................................................................................................................9
Document # 7000-0001, Rev. A - 5 –
1.0 Introduction
1.1 Fundamentals
IDENTEC SOLUTIONS’ ILR® (Intelligent Long Range®) technology is the next generation of
long range RFID (Radio Frequency Identification). The objective is wireless and automated
data collection over large distances.
1.2 System Overview
IDENTEC SOLUTIONS’ ILR-System consists of four main components:
• Active tags (also called transponders) with internal power supply, which are used to
identify goods or to store data and histories
• Interrogator (i-PORT; fixed-mounted) and handheld devices (mobile), which exchange
information with the tags and host computer systems
• Antennas for definition of read zone
• A central computer system as basis for control and monitoring
This manual only describes the operations of the i-D2 active tag.
1.3 Operational Description
The i-D2 tag is a high performance active RFID tag suitable for a wide variety of
applications. The tag response to an activation telegram from the interrogator is to
transmit its unique identification number. It is available in either a personnel or industrial
style housing, and in two receive sensitivity modes, low or high.
The tag has a low current ASK receiver in the UHF band for a data rate up to 38.4 Kbps.
The PLL stabilized ASK transmitter has a data rate up to 115.2 Kbps.
The operation range is 6 meters (20 feet) in open air, with a typical operation life of six
years.
Document # 7000-0001, Rev. A - 6 –
1.4 Features
Features Benefits
Low cost Tracks large quantities of assets economically using high-
speed active technology.
2000-tag simultaneous
identification Provides high-speed data collection to facilitate warehousing
and inventory-based applications.
Wireless triangulation Allows fast, precise location of assets in a warehouse or an
inventory yard.
64-byte data memory Stores process information onto the tag to provide real-time
tracking and tracing.
100-tags/sec.
identification rate Provides reliable identification of fast moving objects.
6-meter read/write
range Allows identification, tracking and tracing of personnel and
assets without human intervention.
LED (option) Provides visual identification of an addressed tag (pick-to-
light).
6-year battery life time
Delivers long time maintenance-free operation, without
battery replacement.
Credit card-style
packaging Offers thin, lightweight, versatile packaging in two styles
suitable for personnel or asset tracking.
On-demand
communication Eliminates RF flooding by using application-driven read/write
operations.
UHF operating
frequencies Operates interchangeably on standard North American and
European ISM band frequencies so the same infrastructure
can be used for global transport.
Non-line-of-sight data
transmission Allows tags to be buried while transmitting for improved
tracking/locating efficiency.
Document # 7000-0001, Rev. A - 7 –
2.0 Configuration
The i-D2 tag requires no special configuration. Options are configured at the factory. It is
controlled by commands from the ILR Interrogation device.
3.0 Mounting the Tag.
3.1 Industrial Tag
The industrial tag is designed with two mounting holes so it can be firmly mounted onto
virtually any surface. It can be mounted using various methods dependent on the
particular application.
Among the common types of mounting are:
• Screws
• Rivets
• Double sided tape
Note: Mounting hardware is not supplied with the tag.
3.2 Personnel Tag
The personnel tag is designed with only one mounting hole so a chain or clip device (not
supplied) worn by an individual can be used to hold the tag.
Document # 7000-0001, Rev. A - 8 –
4.0 Technical Specifications
Performance
Read rate Up to 100 tags/s (Identification Code only)
Up to 35 tags/s @ 128 bit data reading
Max. response time < 10 ms (single tag)
Multiple tag handling Up to 2,000 tags in the read zone
Communication
Read/write range to i-PORTIII Up to 6 m (20 ft) (free air)
Operating frequency 868 MHz (EC) or 915 MHz (NA) ISM band
Data rate (download to tag) 38.4 kbits/s
Data rate (upload to reader) 115.2 kbits/s
Maximum transmission power 0.75 mW ERP
Certification EN 300 220 (EC), FCC Part 15 (US)
Industry Canada
Electrical
Power source Lithium battery (not replaceable)
Expected battery life > 6 Years @ 600 times 64 bit readings/day
Battery monitoring Yes
Optional features LED
Data
Data retention >10 years without power
Write cycles 100,000 writes to a tag
Memory size 64 bytes (56 byte user definable)
Identification code 48 bit fixed ID (one in one trillion)
Environmental
Operating temperature –20°C to +70°C (–4ºF to +158ºF)
Shock 50 G; 3 times DIN IEC 68-2-27
1-meter multiple drops to concrete
Vibration 3 G; 20 sine wave cycles; 5 Hz to 150 Hz,
DIN IEC 6
5 G; noise 5 Hz to 1000 Hz; 30 minutes
DIN IEC 68-2-64
Package rating
Personnel tag IP52 — Protected against dust and direct
sprays of water up to 15 degrees from vertical.
Industrial tag IP52 — Protected against dust and direct
sprays of water up to 15 degrees
Physical
Dimensions personnel tag 87 mm x 50 mm x 7 mm
(3.94 in. x 1.97 in. x 0.27 in.)
Dimensions industrial tag 100 mm x 50 mm x 7 mm
(3.44 in. x 1.97 in. x 0.27 in.)
Case material Plastic (Luran® S)
Mass of industrial tag 27 grams (0.95 ounces)
Mass of personnel tag 24 grams (0.84 ounces)
Document # 7000-0001, Rev. A - 9 –
5.0 Technical contacts:
In North America:
IDENTEC SOLUTIONS Inc.
#102 – 1860 Dayton Street
Kelowna, BC
Canada
V1Y 7W6
Tel: (250) 860
-6567
Fax: (250) 860-6541
In Europe:
IDENTEC SOLUTIONS AG
Millennium Park 2
A-6890 Lustenau
Austria
Tel: +43 (0)5577 87387
-0
Fax: +43 (0)5577 87387-15
