Identiv >
Users Manual
SCL 010/SC R331CL -NTTCom – USB Contact less reader OEM
Manual
SCM Microsystems (India)
Contents
1.0 Product Sp ecification ....................................................................................................... .........3
1.1 Overview................................................................................................................................... 3
1.2 Product Features ...................................................................................................................... 3
1.3 OS Support...............................................................................................................................3
2.0 Hardware Specification ...................................................................................................... .......3
2.1 Adapter Power..........................................................................................................................3
2.2 Clock Frequency.......................................................................................................................3
3.0 Software Specifications..................................................................................................... ........4
3.1 Operating System ..................................................................................................................... 4
3.2 PICC Parameters...................................................................................................................... 4
3.3 USB Parameters.......................................................................................................................4
4.0 Software Modules............................................................................................................. .......... 5
4.1 Firmware................................................................................................................................... 5
4.2 USB Drivers..............................................................................................................................5
4.3 Utilities ...................................................................................................................................... 5
5.0 Regulatory Compliance ....................................................................................................... ......6
5.1 Safety Regulations.................................................................................................................... 6
5.2 EMC Regulations...................................................................................................................... 6
OEM Manual – SCL010/ SCR331CL -NTTCom Confidential Page 2 of 7
SCM Microsystems (India)
1.0 Product Specification
1.1 Overview
The SCL010/ SCR331CL -NTTCom is based on the SCM Microsystems’ STC3 Micro Controller.
The SCL010/ SCR331CL -NTTCom is the industry’s first to offer on-board flash. This enables future
firmware and application enhancements that guarantee against obsolescence.
The SCL010/ SCR331CL -NTTCom offers the best price/performance in the market.
1.2 Product Features
PC/SC 2.0 compliant drivers
Type A – CL , Type B – CL , Mifare, Felica
ISO14443 Compliant
USB CCID like Host interface handled by SCM vendor drivers
USB2.0 compliant full speed device
High bus-powered through USB
Device firmware upgradeable in the field through USB
WHQL compliant drivers for WINXP platform,VISTA,WIN 2003 Server
One single color LED indicating contactless activity
1.3 OS Support
The following OS is supported by SCL010/SCR331CL-NTTCom:
Windows XP (including all service packs)
Windows 2000 (including all service packs)
Windows 2003 Server
Vista
2.0 Hardware Specification
2.1 Adapter Power
High Bus Powered (>100mA and <500mA) (draws power from the USB bus), for USB
operation.
2.2 Clock Frequency
STC3 chip internally running @24 MHz for USB operation, derived from an external
12 MHz crystal
ICC clock @4MHz
Contactless reader's Transmitter antenna and receiver circuit works @13.56MHz
using PN512 chip
OEM Manual – SCL010/ SCR331CL-NTTCom Confidential Page 3 of 7
(32-bit and 64-bit for above all OSs)
Windows 2008 Server
SCM Microsystems (India)
3.0 Software Specifications
3.1 Operating System
Generic device firmware
Vendor drivers for WIN98SE, WINME , WIN2000, WINXP, Windows Server 2003,Windows vista,
3.2 PICC Parameters
Some important PICC parameters, supported contact-less card types, maximum operable PICC
frequencies, operating voltages etc., are detailed in the tables below.
ICC Parameters Value/Description
Type A memory card PICC Supported
Type A T=CL PICC Supported
Type B memory card PICC Supported (Through SCM Specific APDUs)
Type B T=CL PICC Supported
ISO-14443 compliant Yes
PC/SC compliant Yes ( Contactless cards simulated as T=1 cards)
WHQL compliant Yes ( Windows 2000, Windows XP, Windows Server
2003,Windows Server2008)
PICC operating frequency 13.56MHz
Maximum supported card baud-rate 424Kbps
OEM Manual – SCL010/ SCR331CL -NTTCom Confidential Page 4 of 7
3.3 USB Parameters
USB Parameters Value/Description
USB Specification USB 2.0 FS Device
USB Speed Full Speed Device (12Mbit/s)
Device Class Vendor
Felica Supported
Windows Server2008.,
SCM Microsystems (India)
4.0 Software Modules
4.1 Firmware
Device firmware that supports USB interface is provided.
On USB, the firmware implements CONTACT-LESS interface.
4.2 USB Drivers
The driver gets loaded and it handles CONTACT-LESS operations.
The reader is seen at the host level as below.
4.3 Utilities
4.3.1 Installation
SCM provides Install Shield Installer for Windows to install the product. The SCM drivers as well as
the utilities can be installed with the help of this installer.
4.3.2 DFU Utility
DFU utilities/drivers for dynamic Device Firmware Upgrade (DFU) are shipped with the device for
USB interface. DFU utilities/drivers are capable of performing a DFU under the following operating
systems.
OEM Manual – SCL010/ SCR331CL -NTTCom Confidential Page 5 of 7
'SCR331CL-NTTCom' - for SCR331CL-NTTCom
'SCL010' - for SCL010
Operating System Support
WIN2000 Yes
WINXP Yes
WIN2003 Server Yes
Vista Yes
SCM Microsystems (India)
5.0 Regulatory Compliance
This section describes the product's compliance with U.S. and international safety and
electromagnetic compatibility (EMC) regulations.
5.1 Safety Regulations
Below Table the safety regulations the product complies with when correctly installed in a compatible
host system.
Regulation Title
UL 60950 US Safety of Information Technology Equipment
EN 60950:2000 The Standard for Safety of Information Technology
Equipment including Electrical Business Equipment.
(European Union)
5.2 EMC Regulations
Regulation Title
FCC (Class B) Title 47 of the Code of Federal Regulations, Parts 2
and 15, Subpart C,Radio Frequency Devices. (USA)
VCCI:1997 Class
B ITE
Radio Law Japan
5.2.1 FCC Compliance Statement (USA)
Product Type: Contactless smart card reader.
Product Name: SCL010/ SCR331CL -NTTCom
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 Sub part C of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
OEM Manual – SCL010/ SCR331CL -NTTCom Confidential Page 6 of 7
SCM Microsystems (India)
OEM Manual – SCL010/ SCR331CL -NTTCom Confidential Page 7 of 7
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to a different electrical branch circuit from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to the equipment not expressly approved by SCM could void the user’s
authority to operate the equipment.
5.3 Product Ecology Statements
The following information is provided to address worldwide product ecology concerns and regulations.
5.3.1
5.3.2
Disposal Considerations
This product contains the following materials that may be regulated upon disposal: lead solder on the
printed wiring board assembly.
Recycling Considerations
SCM encourages its customers to recycle its products and their components (e.g., batteries, circuit
boards, plastic enclosures, etc.) whenever possible. In the U.S., a list of recyclers in your area can be
found at: http://www.eiae.org/
In the absence of a viable recycling option, products and their components must be disposed of in
accordance with all applicable local environmental regulations.
5.4 Product Certification Markings
Below Table lists the product certification markings.
Description Marking
UL file number for SCL010/
SCR331CL-NTTCom XXXXXXXXX
FCC ID for intentional radiator Class B
equipment.
FCC ID MBPSCL 010 - 4400
VCCI Declaration of Conformity logo
mark for Class B equipment.
Radio Law Japan RF certification
