uTrust 47X0F – User Manual
Version: 1.0 Page 1 of 4
User manual
For
uTrust 47X0F
Version 1.0
Author Robert
Version 1.0
Date 31-October-2014
uTrust 47X0F – User Manual
Version: 1.0 Page 2 of 4
Document History
Version Date Description of Change Author
1.0 31-October-14 Initial version Robert
uTrust 47X0F – User Manual
Version: 1.0 Page 3 of 4
Table of Contents
1Scope of the document ..................................................................................................... 4
2About uTrust 47x0 reader ................................................................................................. 4
3Driver Installation in Windows ........................................................................................... 4
4Communication with Card ................................................................................................. 4
uTrust 47X0F – User Manual
Version: 1.0 Page 4 of 4
1 Scope of the document
The user manual specifies the basic application of the reader by the customer.
2 About uTrust 47x0 reader
uTrust 47x0 is a USB based dual interface reader capable of reading ISO7816 Contact smart
cards and ISO14443 Contactless cards. The reader has a bicolor LED for status indication and
connects to a host PC via USB2.0 Full speed interface. The reader comes in 2 flavors,
uTrust 4700F - Dual Interface reader
uTrust 4710F - Contactless+SAM reader
3 Driver Installation in Windows
Follow the sequence of steps to install the driver,
Plug in the reader to a Windows PC
The PC prompts for a driver
Select Microsoft CCID driver and install the driver
The device enumerates with Identive VID and PID strings
4 Communication with Card
Follow the sequence of steps to communicate with the contact card,
Plug in the reader to a Windows PC and load the driver
Insert the contact card into the card reader slot of the reader
Check the status indication of the LED changing from a steady GREEN glow to a
blinking GREEN LED status
Follow the sequence of steps to communicate with the contactless card,
Plug in the reader to a Windows PC and load the driver
Place a contactless card on top of the reader
Check the status indication of the LED changing from a steady GREEN glow to a
steady AMBER LED status
If both Contact and Contactless cards are in the field the status indication of the LED
changes from a steady GREEN glow to a blinking AMBER LED status
