Imilab Technology IPC016A IMILAB Home Security Camera Basic User Manual

Shanghai Imilab Technology co.,LTD IMILAB Home Security Camera Basic

User Manual

IMILAB Home Security Camera Basic
User Manual
RESET
MicroSD
RESET
2. Insert the two plastic anchors into the holes on the wall.
Mounting the Security Camera on a Wall
1. Drill two holes on the wall by using the base of the security camera as a
template. It is recommended that you mark the locations of the holes with a
pencil before drilling. The diameter of each hole is approximately 6 mm, and
the depth is approximately 25 mm.
The IMILAB Home Security Camera Basic can be placed on a number of
horizontal surfaces, such as a writing desk, dining table, and coffee table. It
can also be mounted on the wall.
Product Installation Product Instructions
If the indicator light is flashing orange, that means the device is activated
successfully. If you do not see a flashing orange light, please press and
hold the Reset buon to restart the device to enter pairing mode.
Once the IMILAB Home Security Camera Basic is turned on, please do not
aempt to rotate its head by force. If the camera position is incorrect,
adjustments can be made through the app.
Turning the Device On
The IMILAB Home Security Camera Basic will automatically activate once
the power cable is inserted into the Micro-USB charging port.
Quick Setup
Package Contents: IMILAB Home Security Camera Basic, user manual,
wall mounting accessories pack
Read this manual carefully before use, and retain it
for future reference
Product Overview
Status Indicator
Lens
MicroSD Slot
Can be
revealed by
pushing the
lens upward
MIC
Front View Rear View
Loudspeaker
Reset
Buon
Micro-USB
Charging Port
3. Make sure to position the base unit so that the arrow is pointing up.
Secure the base unit in place by tightening the screws into the plastic
anchors.
4. Match the grooves on the boom of the camera unit with the raised
area on the base unit. Press down until the two surfaces are flush, then
turn the camera unit in either direction to lock it in position.
When mounting the security camera on a wall:
please note that the wall must be able to support at least triple
the product's total weight.
Indicator Light
Steady blue on: connected/device status is normal
Flashing blue: network error
Flashing orange rapidly: waiting for connection
Flashing orange slowly: system upgrade in progress
Restore Factory Seings
Press and hold the Reset buon to restore your device to factory seings.
Data stored on the MicroSD card is not erased.
Make sure that the power to the security camera is already disconnected.
Adjust the camera lens upward until the MicroSD slot is revealed, then
insert the MicroSD card into the slot (the side with contact points must
be facing down).
Installing a MicroSD Card
Install Mi Home APP
Scan the QR code or go to App store to download and install Mi Home APP.
This product has been linked to Mi Home, supporting the control by sliding
the screen lock of MIUI system, and the interconnection with other smart
home devices in Mi Home APP.
.Saturday
1.Login in your MI account at MI Home app.(If you not have MI account,
please registration first).
Device Connection
Your Home
Tap to add a device
My devices
4G
4:19
2.Click the quick add buon on home page or top right buon “+” to add
device.
3.Please Click the top right buon “ ” to Scan this QR code on deviece
boom, and you also can search “IMILAB Home Security Camera Basic” at
Search bar to add device.
4:19
Add device
4G
Search
Camera
Video camera
(iOS Device)
Android user can using “ Scanning nearby devices ” to quick add device.
4.Please follow the Setup steps to connect your device.
Enter device name to add
Device nearby Add manually
4G
4:19
Add device
Camera
Video camera
(Android Device)
4G
4:19
Plug device in and follow manual to
operate
IMILAB Home Security Camera Basic
Hold the reset button for about 3s unitel the
notification light turns yellow
Wait until voice prompt
Next
Cancel
Precautions
The suitable operating temperature range for this product is between -10
~ 40 . Please do not use the product in an environment with temperatures
above or below the specified range.
The security camera is a precision electronic product. In order to ensure its
normal operation, please do not install the device in an environment with
high humidity levels or allow water to enter the product.
To improve the product's performance, please do not place the camera
lens facing or next to a reflective surface, such as glass windows/doors
and white walls, which will cause the image to appear overly bright in
areas close to the camera and darker in areas further away, or cause the
camera to produce white images.
Please install the product in areas with Wi-Fi reception, and try to place the
device where the Wi-Fi signal is strong. In addition, please keep the security
camera away from metal structures, microwave ovens, or other locations
where signal strength may be impacted.
Manufactured: Shanghai Imilab Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room908,No.1,Lane399,Shengxia Rd., China Pilot Free Trade Zone,
Shanghai, China
For further information, please go to www.imilab.com.
Through the IMILAB Home Security Camera Basic control interface in the Mi
Home app, you can set your security camera as a shared device under the
General Seings menu, and invite your friends to view the camera remotely.
Your friends will be required to download the Mi Home app and log in with
his/her Xiaomi account.
IMILAB Home Security Camera Basic
Share with Mi Account
Manage Sharing
Rename
Security Seings
Network Information
Shared Remote Viewing
Launch the Mi Home app and select a IMILAB Home Security Camera Basic
that is already connected to monitor the surroundings in real-time. The
camera's control interface allows you to adjust the sharpness of the image,
as well as to change the device's vertical and horizontal viewing angles.
Additional features such as screen capture or record and remote
communications can also be performed.
Real-Time Monitoring
Note:
The diagram is for reference only. Actual displays will vary based on different
versions of the Mi Home platform and your smartphone model.
Note:
The diagram is for reference only. Actual displays will vary based on different
versions of the Mi Home platform and your smartphone model.
Automatic MonitoringPlayback
Infrared night vision mode sample
2018 3 2 20:51:05
With the incorporation of eight infrared illuminators, the security camera is
able to view up to a distance of 9 m and capture crystal clear images in the
dark.
IMILAB Home Security Camera Basic's playback feature is only available aer
installing a compatible MicroSD card. Once a MicroSD card has been
installed and the security camera is turned on, videos will be recorded
automatically. Aer entering the user interface of the Playback feature,
simply slide the bar on the timeline to select the time period you wish to
view.
Supporting Infrared and Image-intensified Night Vision
Monitoring Review Call Photo Album Shortcut
IMILAB Home Security Camera Basic
108KB S 108KB S
Automatic monitoring can be configured through the IMILAB Home
Security Camera Basic control interface in the Mi Home app.
Available options include 24-hour, daytime, and nighime monitoring.
You can also create your own schedule and set the desired camera angle.
This product is able to detect movements within its field of view. Once
movements are detected, a video is recorded and you will receive a
notification.
HD
105KB S
HD
Note:
The diagram is for reference only. Actual displays will vary based on different
versions of the Mi Home platform and your smartphone model.
Note:
The diagram is for reference only. Actual displays will vary based on different
versions of the Mi Home platform and your smartphone model.
Device Sharing
Location Management
Check for Firmware Updates
Delete Device
Add Desktop Shortcut
Feedback
IMILAB Home Security Camera Basic
Monitoring Review Call Photo Album Shortcut
Monitoring Review Call Photo Album Shortcut
IMILAB Home Security Camera Basic
General Seings Sharing with Mi Home ……
FCC Statement
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and canradiate radio
frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interferenceto radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
FCC ID: 2APA9-IPC016A
– Consult the dealer or an experienced radio/TV technician for help.
FCC 20cm Statement: This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20cm between the
radiator & your body. This transmier must not be co-located or operating in
conjunction with any other antenna or transmier.
For pluggable equipment, the socket-outlet (power adaptor) shall be installed
near the equipment and shall be easily accessible.
Adaptor Statements
WEEE Disposal and Recycling Information
Correct Disposal of this product. This marking indicates that product
should not be disposal with other household wastes through out the
EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse sustainable reuse of material resources. To return your
used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for
environment safe recycling.
Hereby, Shanghai Imilab Technology Co., Ltd. declares that the radio
equipment type IMI Home Security Camera Basic is in compliance with
Directive 2014/53/EU.
Specifications
Name: IMILAB Home Security Camera Basic
Model: CMSXJ16A
Lens Angle: 110°
Net Weight: 182 g
Video Encoding: H.265
Power Input: 5 V 2 A
Operating Temperature: -10 ~ 40
Expandable Memory: MicroSD card (up to 64 GB)
Compatible With: Android 4.4, iOS 9.0 or later
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz
Resolution: 1920 x 1080
Focal Length: F3.2
Item Dimensions: 108 x 76 x 76 mm
