InBody INLAB3 Activity Tracker User Manual 1

InBody Co., Ltd. Activity Tracker 1

Manual

Instructions
1. Product Components
1 2
InLab3
Charging Dock
Micro USB Cable
Instructions
2. Charging
Once you open your package, charge your InLab Wristband
with the cable and dock provided. It takes roughly 60
minutes to fully charge.
2. Charging
!
Keep the charge port clean in order to prevent rust.
Warning
Track your activity with InLab3 on your wrist
! Note
Please paste the charging cradle on the product according
to directions. If the direction is not correct, the charging
cradle is not attached to the product.
1. Product Components
Wristband can be replaced by a band of several materials.
(metal, leather and so on)
* Visit www.store.inbody.com to buy the band.
3 4
Table of Contents
1. Product Components ………………………………………………………1
2. Charging……………………………………………………………………………3
3. Installing the InBody App......…………………………………………….5
4. Powering Up….…………………………………………………………………..7
5. Syncing InBody Band with InBody App..………………………….9
6. InBody Band Modes …………………...…………………………………..11
7. Data Management…………….……………………………………………...13
8. General Precautions……..…….…………………………………………….15
9. Usage Warnings…….………………………………………………………17
10. Others………………………………..……………………………………………19
Install the InBody App on your smartphone as instructed, and connect the
product to the app over Bluetooth.
1) InLab3: InLab3: After fully charging, tapping the screen twice, and then turn
the power on.
2) InBody App: On the InBody App, go to Settings > Devices and select the
InBody Band to bring up the setup screen.
3) InBody App: Tap the Settings button on the InBody App. In the Bluetooth
registration request window, tap the “OK” button and proceed as instructed
on the app.
4) InLab3: When the connection is established, the time will sync with your
smartphone.
You can turn on the display by double-
tapping InLab3.
6
7 8
5. Syncing InBody Band with InBody App
4. Powering Up 4. Powering Up
! Note
• Display will turn off after 5 seconds of inactivity.
If your InLab3 does not turn on, charge your InLab3 as
instructed on page 2 until fully charged. Try turning on your
InLab3 again.
6. InBody Band Modes
If you tap the screen twice, the current time and
achievement will appear in sequence as shown in the picture
below.
11
3. Installing the InBody App
! Note
• This product is compatible with Android 4.3(Jellybean)
with BLE or newer and iPhone 4S or newer.
! Note
• If the battery is low, the red light will blink on the screen.
Hour: Light on Minute: Light blink
Current time 1:25 Achievement
50 %
6. InBody Band Modes
5
3. Installing the InBody App
Connect this product with the InBody App to transfer
and monitor your data conveniently on your
smartphone.
1) Search “InBody” in the Google Play Store or the
Apple App Store.
2) Download the app.
3) Load the app and follow the instructions on-screen
to sync this product with your phone.
12
5. Syncing InBody Band with InBody App
! Note
• You may experience difficulties linking your InLab3 if
there are other InLab3 present.
• The time on your InLab3 will automatically sync with your
smartphone.
9 10
9. Usage Warnings 9. Usage Warnings
• This product is water-resistant.
• Do not swim with the InLab3 on or use it in water.
• Do not place the InLab3 in salt water/chemicals.
Preferred operating temperature: 10 ℃ ~ 40 ℃
The InLab3 failures, of which water labels are discolored due to the
user’s negligence, are not subject to warranty.
• Excessively bending the InLab3 may cause damage to the product.
• Do not drop/shock the InLab3. Such impact may result in damage.
Use a lint-free cloth to gently wipe the external surface of the
equipment about once every week. Be careful not
to scratch the LCD screen.
The InLab3 is classified as Class B electromagnetic radio equipment
and can be used anywhere.
• Do not use the InLab3 if you have life-sustaining medical implants as
the radio waves emitted by the InLab3 may interfere with the
implants.
• Specifications and instructions may change without prior notice.
8. General Precautions
Keep out of reach of children. The InLab3 can be a choking
hazard.
• Do not cover the InLab3 with any fabrics while it is
charging. Doing so may cause a fire.
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
• Please use InLab3 properly as instructed in this manual.
17
19
14
7. Data Management
! Note
• InLab3 starts counting steps after the 7th step.
• The time on the InLab3 syncs with your phone’s time once
the InLab3 is connected to the InBody app.
8. General Precautions
Please read these safety warnings carefully to ensure your
personal safety and to prevent property damage.
Do not disassemble or modify the equipment, including internal parts, without
written consent from the manufacturer. This may cause electric shock or injury,
product malfunction, inaccurate results, and will void the manufacturer’s warranty.
• Do not place the InLab3 near a bathtub, sink, sauna, pool, or stream room.
Exposure of the InLab3 to excessive moisture could result
information/failure/explosion.
• Keep the charge port from contacting necklaces, keys, coins or any metals.
15 16
18
7. Data Management
Your data automatically uploads to your smartphone when you sync
the InLab3 with the InBody App.
! Note
• Sync occurs when the InLab3 and your smartphone are within 2
meters.
Range may vary depending on environment.
• The InLab3 resets daily at midnight. Data will be stored for 7 days if
not uploaded to smartphone.
13
Disposal of old Electrical & Electronic Equipment
(Application in the European Union and other
European countries with separate collection
system.) This symbol indicates that this product
shall not be treated as household waste. Instead,
it shall be handed over to the applicable
collection point for the recycling of electrical and
electronic equipment.
By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise be
caused by inappropriate waste handling of this product. For
more detailed information about recycling this product,
please refer to local governing ordinances and recycling
plans.
20
10. Others 10. Others
InBody
Customer Service: (323)932-6503
Website : www.inbodyusa.com
Data Displayed Time, Activity Goal Tracking, Battery Life
Data Storage 7 days
Battery Life Approx. 5 days
Battery Capacity 32 mAH
Recharging Time Approx. 1 hour
Charging Connector Micro USB, Charging Dock
Dimensions 68 mm (W) x 101.3 mm (L) x 11 mm (H),
Thickness: 9.6 mm
Weight 12.8 g
Color Black, Blue, Pink, S-Grey, Ivory, Red, Brown,
Light Blue
Communication Method Bluetooth 4.0 Low Energy (BLE)
Input Power Operating Voltage : 3.7 VDC,
Charge Voltage : 5.0 VDC
Operation Environment (10 ~ 40) ºC, (30 ~ 75) %R.H., (70 ~ 106) kPa
Expected Service Life 3 years (Depending on the battery charge cycles)
Frequency Used 2 402 MHz ~ 2 480 MHz
No. of Channels 40
Wattage 1 mW and below
10. Others 10. Others * Specifications may change without prior notice.
FCC Information
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note : This equipment may generate or use radio frequency energy.
Change or modification to this equipment may cause harmful
interface unless the modifications are expressly approved in the
instruction manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and
23
24
10. Others 10. Others
21
22
can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
! Caution
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
25
26
10. Others 10. Others
FCC ID : F6OINLAB3
