User Manual
Samsung W1000
Stand with Quick Connect - DVW110
Quick Connect Sensor - DVW220/230
Custom Charge Head - DVW440
1
2
Remove the watch band from the
watch body.
3
Align the sensor with the watch body
as shown. Make sure that the tape
on the sensor ts between the sensor
and the watch body.
4b
Use the pin removal tool to
disengage the watch pin.
2
Band Sensor Installation:
Select the watch band with the
buckle.
1
Use the tool or a ngernail to depress
the other pin and insert that side into
the watch body.
6
With the sensor held in place against
the watch body, reinsert the side of the
watch band without the pin into the
watch body.
5
Inspect the sensor to make sure
that the tape on the sensor is intact
and that the switch is in the down
position.
4a
!
Use the pin removal tool to
disengage the pin on the other band.
9
Pull the tape from the sensor to
activate the alarm
8
Gently tug the watch band to make
sure it is secured.
7Remove the watch band from the
watch body.
10
11 Orient the band clip so that the at
side of the clip will sit along the top
side of the band.
Flat Side
Slide the clip over the band from the side
with the pin.
Use the pin removal tool to push in
the other side of the pin and pivot the
band into place.
12 Stand Installation:
Use the provided alcohol wipe to
clean the surface where the stand will
be placed. Allow it to dry completely.
13
CONTENTS: One pad saturated in 75%
Isopropyl Alcohol
DIRECTIONS: Apply topically as
needed to cleanse surface mounting area.
FOR EXTERNAL USE ONLY
KEEP OUT OF REACH OF
CHILDREN
KEEP AWAY FROM EYES
AND FIRE
Peel the liner from the adhesive on
the bottom of the stand.
14
Place the stand in the desired
location and apply pressure for at
least 10 seconds.
15 Charger Installation:
Peel the backing from the circular
adhesive.
16 Place the adhesive on the end of the
stand’s arm. Apply pressure for at
least 10 seconds.
17 Orient the charger with the cable
facing towards the stem and place
onto the adhesive. Apply pressure for
at least 10 seconds.
18
Remove the cable cover from the
stem and route the charger cable into
the channel as shown. Replace the
cable cover to its original position to
hold the cable in place.
19
1
2
Pull the quick connect adapter from
the unit.
21
Snap the cover onto the charger.
20
Peel the liner from the adhesive.
To connect the sensor head, pull
back the barrel on the recoiler cable.
22
Insert the sensor end into the barrel
on the recoiler cable.
23
Twist the barrel over the sensor
connection to secure.
Note: The internal threads are
reversed, be sure that the threads are
fully engaged when tightening.
24 Place the watch and sensor onto the
charger.
25
Plug the charger cable into the power
supply. Plug the power supply into an
outlet. Make sure that the watch is
receiving power.
26
Pull the battery tab to alarm the unit.
27
