Users Manual
BR-29015
User Manual
(North America)
Rev. 1
Important Safety Instructions
Carefully read all of the instructions provided and save them
for later use. Read all warnings and instructions marked on the
BR-29015.
!
Do not place the BR-29015on an unstable stand or surface as
it may fall resulting in serious damage.
!
The radar antenna should be handled with great care at all
time to avoid damaging the antenna radome. Radome damage
can result in serious performance degradation.
!
The BR-29015 must be operated from a 115Vac 60Hz power
source. Ensure that the supply voltage available at the
installation site meets the input electrical characteristic of the
unit.
!
The BR-29015 power cord is equipped with a three-prong
grounding plug that will only fit into a grounding type power
outlet. This is a safety feature. If you are unable to insert the
plug into the outlet, contact a qualified person to replace the
obsolete outlet. Do not tamper with the grounding prong to
force fit into the outlet.
!
Do not allow any objects to rest on the power cord or place the
BR-29015 where the power cord will be trampled on.
!
If an extension cord is used with the BR-29015, make sure that
the total ampere ratings of the devices plugged into the
extension cord do not exceed the extension cord ampere
rating.
!
Infinition Inc. Rev. 01 1
Do NOT plug in, turn on or attempt to operate an obviously
damaged unit.
!
! No operator serviceable parts inside the BR-29015 radar unit.
Please refer servicing to service qualified personnel.
Infinition Inc. Rev. 01 2
1. General
The BR-29015 radar can be used to measure the radial velocity of any moving object located in
the radar beam coverage. The output of the radar is an analog signal with a frequency and
amplitude proportional to the radial velocity and distance of the moving object.
2. Microwave Safety Warning
Based on limits specified by the Federal Communication Commission (FCC) on
Radio Frequency (RF) emissions in a general population environment,
continued exposure to radiation should be avoided within 10.5 meter in front of
the radar. Radiation levels outside this region fall within regulations of 1
mW/cm2 and are not considered safety hazards. When setting up the antenna,
special care should be taken to avoid situations where the antenna radiates
towards individuals. The antenna should be positioned such that bystanders are
located behind the antenna. During antenna setup, the antenna power cord
should be unplugged to avoid accidental hazardous exposures to radiations.
Always turn the antenna transmitter off during periods of inactivity. Direct
visual contact with the radar when transmitting should be avoided at all times.
!
3. Specifications
Description Specification
Power Requirement 115Vac, 2.0A, 60Hz
Nominal Frequency 10.500 GHz
Nominal Transmitting Power 16.0 W – 1.0 W, selectable
Antenna Gain 29 dBi
Transmitter Stability ±5 ppm
Beamwidth 4° x 4°
Dimension (without yoke) 33” x 18” x 5.00”
Operating Temperature -20degC to 45degC
4. Installation
The BR-29015 is mounted on a yoke. The yoke provides the flexibility for radar alignment in
both azimuth and elevation.
5. Operation
The BR-29015 is powered on 115Vac 60Hz. A power cord is provided for connection in standard
power outlet. The radar is interfaced to a Doppler processor a single four-wire cable equipped
with military connectors. This cable is used to carry out the radar Doppler signal to the
Infinition Inc. Rev. 01 3
processing unit and the antenna transmission control. You should connect your radar cable from
this connector to the appropriate radar input on your processing unit.
The radar head has an override transmitter control switch that can be used to activate the
transmitter locally at the antenna.
In addition, the radar has a transmitter power control switch that can be used to select between
low or high output power levels. At the low setting, the transmitter output power is 1.0 Watt and
at the high setting, the output is 15.0 Watts.
The BR-29015 has three LED indicators, one green for the main power, one red for the
transmitter on/off status and one red for the transmitter output power selection (off for low and on
for high).
Also, the BR-29015 has a provision for connecting a 12 VDC (2 amperes maximum) warning
device. The warning device is automatically enabled when the radar transmitter is switched on.
This safety feature is useful to warn bystanders when the radar is radiating. The warning device is
not mandatory and is therefore not provided as a standard equipment with the radar. Depending
on the environment in which the radar is going to be used, it is the responsibility of the operator
to install such device to provide additional safety for the personnel.
6. Maintenance
The BR-29015 radar does not require much maintenance. Attention should however be paid to a
few points:
- Keep the connectors clean from dirt and moisture to avoid corrosion and bad connections.
- Now and then wipe the radar enclosure and antenna panels with a soft and wet cloth.
- The radar radiating elements are protected by a plastic radome. Special attention should be
paid when handling the radar antenna to avoid damaging the radome as it could result in
performance degradation.
The radar fuses are located inside the radar unit. To replace them, refer the radar system to
qualified personnel.
Warning: No operator serviceable parts inside the radar unit. Please refer
servicing to service qualified personnel
!
Infinition Inc. Rev. 01 4
7. Power Connector Specification
Connector type: Amphenol T3110-000
Pin Description
1 AC Neutral
2 115Vac, 1.0A, 60Hz
3 n/c
4 Protective ground
8. Antenna Connector Specification
Connector type: ITT CANNON MS3124E16-8P
Pin Description
A Not Connected
B Not Connected
C Not Connected
D Remote Make for Antenna Transmitter Control (+ 5 Vdc Output, 1.5kOhm
current limiting resistor)
E Make return
F Doppler Signal + (5 Vpp max.)
G Doppler Signal - (5 Vpp max.)
H Ground
The processor does the remote activation of the transmitter by short circuiting pins D and E.
9. Antenna Warning Device Connector Specification
Connector type: ITT CANNON MS3124E12-3S
Pin Description
A 12 Vdc, 2 amperes maximum (fuse protected)
B Not Connected
C Ground
Infinition Inc. Rev. 01 5
10. Antenna Optional I/O Connector Specification
Connector type: ITT CANNON MS3124E10-6SW
Pin Description
A Not Connected
B Not Connected
C Not Connected
D Not Connected
E Not Connected
F Not Connected
Infinition Inc. Rev. 01 6
LIMITED WARRANTY. Infinition Inc. products are warranted against defects in
materials and workmanship for a limited period of time from the date Infinition Inc. ships
the products to the customer as follows: interface hardware (one (1) year); cables, cable
reels, radar antennas and acoustic sensors (ninety (90) days); and software medium
(ninety (90) days). All software products sold by Infinition Inc. are licensed to the
customer under the terms of the product software license agreement. Replacement
products will be warranted for the longer of, the remainder of the original warranty
period or thirty (30) days. Expenses for shipment of repaired or replacement products to
and from Infinition Inc. shall be the responsibility of the customer. After examining and
testing a returned product, if Infinition Inc. concludes that the product is not defective,
the customer will be notified and the product will be returned to the customer with an
additional charge for shipping, examination and testing. This limited warranty is void if
failure of the products has resulted from accident, abuse, misuse, improper hardware
connection or unauthorized maintenance or repair.
CUSTOMER REMEDIES. The sole obligation of Infinition Inc. (and the customer’s
sole remedy) with respect to this warranty shall be to, as its option, return fees paid or
repair/replace any defective products, provided that Infinition Inc. received a written
notice of such defects during the application of this warranty period.
RETURN/CANCELLATION POLICY. The customer may return unwanted products
within twenty (20) days of the delivery date. A twenty percent (20%) restocking fee shall
be charged to the customer on any returned product. Infinition Inc. reserves the right to
cancel any order if the customer representations to Infinition Inc. are false or misleading.
THE PRODUCTS ARE PROVIDED “AS-IS” WITHOUT WARRANTY OF ANY
KIND, AND NO OTHER WARRANTIES, EITHER EXPRESSED OR IMPLIED
ARE MADE WITH RESPECT TO THE PRODUCTS, INCLUDING BUT NOT
LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. INFINITION INC. DOES NOT
WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS
REGARDING THE USE OF, OR THE RESULTS OF THE USE OF THE
PRODUCTS IN TERMS OF CORRECTNESS, ACCURACY, RELIABILITY, OR
OTHERWISE AND DOES NOT WARRANT THAT THE OPERATION OF THE
PRODUCTS WILL BE ININTERRUPTED OR ERROR FREE.
NO LIABILITY FOR CONSEQUENTIAL DAMAGES. To the maximum extent
permitted by applicable laws, in no event shall Infinition Inc. be liable for any damages,
including, but not limited to, any special, direct, indirect, incidental, exemplary, or
consequential damages, expenses, lost profits, lost savings, business interruption, lost
business information, or any other damages arising out of the use or inability to use the
products, even if Infinition Inc. has been advised of the possibility of such damages.
Infinition Inc. Rev. 01 7
