Infrared Resources IRPWLUS 915 Mhz Wireless IR repeater system User Manual A 1369S Manualx
Infrared Resources ,LLC 915 Mhz Wireless IR repeater system A 1369S Manualx
Users Manual
915MHzWirelessIRRepeaterSystemUserGuide
FEATURES:
1. Connect wired IR Repeater devices wirelessly.
2. Easy to control all home entertainment in this system over 200 meters.
3. No extra wire need.
SPECIFICATIONS
IR:
1. Compatible with all Universal full band carrier frequency infrared
Remote
2. Better IR receive sensitivity(distance),over 7 meter
RF:
1. Long range transmission over 200 meter (open space)
2. 915MHz RF technology to ignore current 433MHz RF-interference
3. FSK modulation:
Better signal sensitivity than ASK modulation
Better Anti RF-interference than ASK modulation
Better
noise suppression
4. Digital technology with frequency hopping technology to minimizes RF-interference
5. Digital encrypted function ensures safety and reliability
Power:5VDC/500mA
915MHzWirelessIRRepeaterSystemUserGuide
915MHzWirelessIRRepeaterSystemUserGuide
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from thatto
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device and its antenna(s) must not be co-located or operating in
conjunction with any other antenna or transmitter.
