InnoSenT IPM224F Doppler Radar Module User Manual 110913 IPM 224 F V1 indd

InnoSenT GmbH Doppler Radar Module 110913 IPM 224 F V1 indd

Installation Manual

InnoSenT sets standards – worldwide
Page 1 Version 1.0 USER MANUAL IPM-224_F
CONFIDENTIAL AND PROPRIETARY
The informaon contained in this document shall remain the sole and exclusive property
of InnoSenT GmbH and shall not be disclosed by the recipient to third pares without prior
consent of InnoSenT in wring.
User Manual IPM-224_F
Version 1.0 - 13.09.2011
The IPM-224_F is a K-Band Transceiver with
a split transmit and receive antenna.
This product is compliant to the restricon
of hazardous substances (RoHS - European
Union direcve 2002/95/EG)
Features:
»radar-based moon detector
»the IPM-224_F is designed for the US and Canadian market
»advanced PHEMT-oscillator with low current consumpon
»IF-pre-amplier, bandwidth limited for lowest noise
performance
»compact outline dimensions
Product Family
Applicaons
K-Band Transceiver
Lightning Applicaons
Movement
Velocity
Direcon
Presence
Distance
Angle
Descripon Cercates
InnoSenT GmbH has established and applies
a quality system for: development, produc-
on and sales of radar sensors for industrial
and automove sensors.
and manufactured
in Germany
designed
InnoSenT sets standards – worldwide
Page 2 Version 1.0 USER MANUAL IPM-224_F
Oscillator
transmit frequencies fFCC 24.075 24.175 GHz IPM-224_F
temperature dri (frequency) Δf -1 MHz/°C
output power (EIRP) Pout 6 11 20 dBm @ 25°C
Receiver
IF-output voltage oset 1.0 2.2 4.0 V
IF-amplier bandwidth DC - 10k Hz
gain 20 dB
signal level S29 mV @ InnoSenT test setup
noise level R57 mV @ InnoSenT test setup
S/N rao S/N 6@ InnoSenT test setup
ESD stability 12 kV according to
DIN EN 6100-4-2
Antenna paern
full beam width @ -3dB horizontal 70 ° azimuth
vercal 70 ° elevaon
full beam width @ -10dB horizontal 135 ° azimuth
vercal 135 ° elevaon
side-lobe suppression horizontal 10 dB azimuth
vertical 10 dB elevaon
Power supply
supply voltage VCC 4.75 5.0 5.25 V
supply current ICC 35 40 mA IF-amp included
Environment
operang temperature TOP 0+23 +60 °C
Mechanical Outlines
outline dimensions
height
length
width
6.8
40.0
23.5
mm
Electrical Characteriscs
Parameter Symbol Min. Typ. Max. Units Comment
CONFIDENTIAL AND PROPRIETARY
The informaon contained in this document shall remain the sole and exclusive property
of InnoSenT GmbH and shall not be disclosed by the recipient to third pares without prior
consent of InnoSenT in wring.
InnoSenT sets standards – worldwide
Page 3 Version 1.0 USER MANUAL IPM-224_F
Interface
1not connected
2not connected
3VCC input supply voltage
4 GND input analog ground
5IF1 output signal 1
6not connected
Pin # Descripon In / Out Comment
CONFIDENTIAL AND PROPRIETARY
The informaon contained in this document shall remain the sole and exclusive property
of InnoSenT GmbH and shall not be disclosed by the recipient to third pares without prior
consent of InnoSenT in wring.
Mechanical Outlines
azimuth
3D-View
PIN 1
The sensor provides a 6 pin JST connector (06FMN-BMT-A-TF, SMD, vercal)
InnoSenT sets standards – worldwide
Page 4 Version 1.0 USER MANUAL IPM-224_F
InnoSenT GmbH
Am Rödertor 30
97499 Donnersdorf
GERMANY
Contact Informaon
InnoSenT GmbH | Am Roedertor 30 | 97499 Donnersdorf | Germany
Phone: +49 (0) 9528-9518-0 | Fax: +49 (0) 9528-9518-99 | E-Mail: info@innosent.de
www.innosent.de
Approval
FCC approval
Labeling
This Data Sheet contains the technical specicaons of the described product. Changes of the
specicaon must be in wrien form. All previous versions of this Data Sheet are no longer valid.
The technical specicaons of this Data Sheet are approved by:
The adhesive label on the cover of the sensor provides the following informaon:
FCC/IC-ID
serial number
version (K01 / K02)
last 3digits of the tramsmit frequency
(e.g. 24.125GHz = 125)
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operaon is subject to the following two condions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operaon.
Warning: Changes or modicaons made to this equipment not expressly approved by InnoSenT
GmbH may void the FCC authorizaon to operate this equipment.
Manufacturers of mobile or xed devices incorporang IPM-224_F modules are authorized to use
the FCC Grants and IC Cercates of the IPM-224_F modules for their own nal products according
to the condions referenced in these documents. In this case, the FCC label of the module shall be
visible from the outside, or the host device shall bear a second label stang contains FCC ID: UXS-
IPM224F and contains IC: 6902A-IPM224F.
model number
