Innostream INNO30 GSM 900/1800/1900 Mobile Phone User Manual i 1000 User s Guide
Innostream Inc. GSM 900/1800/1900 Mobile Phone i 1000 User s Guide
User Manual
INNO 30 User’s Guide INNOSTREAM Confidential
Color Mobile Phone
Tri-band GSM/DCS/PCS
INNO 30 User’s Guide
PAGE : 1 of 93
INNO 30 User’s Guide INNOSTREAM Confidential
Contents
1.BEFORE YOU START
1.1
PHONE LAYOUT AND ICONS
........................................................................................................
1.2
KEYS DESCRIPTION
....................................................................................................................
1.3
QUICK SILENCE MODE
................................................................................................................
1.4
USING THE NAVIGATION KEYS
.....................................................................................................
1.5
USING THE EARPHONE
...............................................................................................................
1.6
DISPLAY IN THE IDLE SCREEN
.....................................................................................................
1.7
USING THE KEYPAD LOCK FEATURE
.............................................................................................
2.GETTING STARTED.................................................................................................................
2.1
HOW TO ATTACH THE BATTERY
..................................................................................................
2.2
HOW TO REMOVE THE BATTERY
..................................................................................................
2.3
HOW TO CHARGE THE BATTERY
..................................................................................................
2.4
HOW TO PLACE THE SIM CARD
....................................................................................................
2.5
HOW TO REMOVE THE SIM CARD
..................................................................................................
2.6
HOW TO SWITCH YOUR PHONE ON AND OFF
..................................................................................
3. SECURITY CODES ...................................................................................................................
3.1
PIN
..........................................................................................................................................
3.2
PUK
..........................................................................................................................................
3.3
PIN
2.........................................................................................................................................
3.4
PUK
2 .......................................................................................................................................
3.5
SIM LOCK CODE
.........................................................................................................................
3.6
LOCK CODE
...............................................................................................................................
3.7
PASSWORD
................................................................................................................................
4. MAKING AND RECEIVING A CALL ........................................................................................
4.1
MAKING A CALL
.........................................................................................................................
4.2
ANSWERING A CALL
...................................................................................................................
4.3
MAKING THE EMERGENCY CALL
..................................................................................................
4.4
MAKING AN INTERNATIONAL CALL
..............................................................................................
4.5
ENTERING A
"
PAUSE
"
CHARACTER IN A DIAL STRING
....................................................................
4.6
NOTIFICATION OF MISSED CALL
...................................................................................................
5. IN-CALL OPTIONS..................................................................................................................
5.1
PUTTING A CALL ON HOLD
/
UNHOLD
............................................................................................
5.2
MAKING A SECOND CALL
............................................................................................................
5.3
SWAPPING BETWEEN ACTIVE CALLS AND HELD CALLS
..................................................................
5.4
ANSWERING A SECOND INCOMING CALL
........................................................................................
5.5
ADJUSTING THE EARPIECE VOLUME
.............................................................................................
5.6
MUTING THE MICROPHONE
.........................................................................................................
5.7
SENDING DTMF
..........................................................................................................................
5.8
STORING A NUMBER ON THE SCRATCHPAD
...................................................................................
5.9
USING THE SMS FUNCTION
5.10
USING THE
LOUDSPEAKER ...................................................................................................
PAGE : 2 of 93
INNO 30 User’s Guide INNOSTREAM Confidential
5.11 MAKING A CONFERENCE CALL ...........................................................................................................
6. PHONEBOOK ...........................................................................................................................
6.1
STORING A PHONE NUMBER WITH A NAME
....................................................................................
6.2
QUICK SEARCHING FOR A NUMBER IN THE PHONEBOOK
.................................................................
6.3
STORING A NUMBER OF THE RECENT CALLS TO THE PHONEBOOK
...................................................
6.4
SPEED LIST
...............................................................................................................................
6.5
USING THE PHONEBOOK OPTIONS
................................................................................................
7. TEXT EDITING ........................................................................................................................
7.1
INPUT MODE
............................................................................................................................
7.2
T9 ABC
INPUT MODE
...............................................................................................................
7.3
MULTI
-
TAP INPUT MODE
...........................................................................................................
7.4
NUMERIC INPUT MODE
..............................................................................................................
7.5
SYMBOLS INPUT MODE
..............................................................................................................
8. THE MENU MAP......................................................................................................................
9. THE MENU FUNCTIONS.........................................................................................................
9.1 MESSAGES
(SMS, MMS, E-mail, Voicemail, Broadcast)
9.2 CALL RECORDS
(Dialled Calls, Received Calls, Missed Calls, Delete Records, Cost & Duration, Data Counter)
9.3 PHONE SETTING
(Own Numbers, Language, Sound Setting, Display Setting, Clock Setting, Call Setting, Connection Profile, Security
Setting, My Menu Setting)
9.4 CAMERA & MEDIA
(Camera, Camcorder, Image File, Audio File, MFlash Folder, Video Folder, File Manager, Memory Status)
9.5 ORGANISER
(Calendar, View Today Report, Alarm, Memo, Template)
9.6 NETWORK SERVICE
(Call Divert, Call Barring, Call Waiting, Caller Identity, Closed User Group, Network Selection)
9.7 GAME & UTILITY
(Games, Java, Biorhythm, Timer, calculator, Voice Memo, Melody Composer, Converter, Lady Schedule)
9.8 INTERNET
(Home, Resume, Bookmarks, Push Messages, Settings, Empty Temp Files, Go To Address, Version Info)
9.9 SIM AT SERVICE
10. VIS
11. DATA AND FAX.....................................................................................................................
12. PHONE AND BATTERY CARE ..............................................................................................
13. TROUBLE SHOOTING ...........................................................................................................
14. GLOSSARY .............................................................................................................................
15. SAFETY INFORMATION........................................................................................................
16. INDEX.....................................................................................................................................
PAGE : 3 of 93
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 4 of 93
1. Before You Start
1.1 Phone Layout and Icons
The following illustration shows the main elements of your phone.
< Icons in the main display screen >
Shows the received signal strength. The larger the number of bars, the better
the signal strength.
Appears when a new text message has been received
Appears when you have messages waiting in voice mail
Appears when vibrator is selected as ring tone type.
Appears when an alarm clock is enabled.
Appears when the phone is out of your home network area and the phone is
registered to the network other than its home service (i.e. when travelling in
other countries with GSM service)
Shows the level of battery status. The more bars you see, the more power
EL Light
External Socket
Camera
Sub
Display
Screen
Antenna
Ear Phone Jac
k
Micro Phone
Soft Key(Right)
Navi
g
ation Ke
y
sSide Key
End Ke
y
Numbers and
Alpha Keys
Send Key
Soft Key(left)
Main display screenMain display screenMain display screenMain display screen
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 5 of 93
battery has left.
Indicates that your phone is on the quick silence mode.
If your phone is in the quick silence mode, all audible key tones are muted
and all audible alerts are changed to vibrator alert.
Appears when a PUSH message has been received
Appears when your phone is registered to a GPRS network.
Appears when there is an active GPRS connection.
< Icons in the sub display screen >
Shows the received signal strength.
Appears when vibrator is selected as ring tone type.
Indicates that your phone is on the quick silence mode.
Appears when an alarm clock is enabled.
Shows the level of battery status.
Appears when your phone is registered to a GPRS network.
Appears when there is an active GPRS connection.
< Event images in the sub display screen >
Appears when an alarm is expired.
Appears when the alarm of scheduler is expired.
Indicates that your phone is under security code checking after power up.
1
Appears when a missed call has occurred.
1
Appears when a new text message has been received
1
Appears when a new MMS message has been received
1
Appears when you have messages waiting in voice mail
1
Appears when a new PUSH message has been received
Indicates that the battery level of your phone is low.
1.2 Keys Description
Key Description
Performs the functions indicated by the text in the bottom line of the display
screen above those keys.
Makes or answers a call.
In the idle mode, launches the recent calls list.(Dialled, Missed and
Received )
In the menu, selects menu function or stores information that you have
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 6 of 93
entered (such as a name) in the phone or SIM memory.
Ends a call.
Also switches the phone ON or OFF when pressed and held.
In the menu, returns to the idle mode or cancels your input.
~
Enters numbers, letters and some special characters.
By pressing and holding [ 1 ] in the idle mode, you can directly listen to the
Voicemail.
~
In the idle mode, enters special dial characters.
Enters ‘ +’ (International Indicator) or ‘ P’ (Pause) when pressed and
held
Whilst you are playing the game, these keys are used for adjusting the game
melody volume.
(on the left side of phone)
During a call, adjust the earpiece volume.
During a game, adjust the game melody volume.
[VOL-UP]
It switches between the quick silence mode and previous profile you have
set on Profiles menu when pressed and held in the idle mode.
[VOL-DOWN]
In the idle mode, displays the today’ s date, day and time for short time.
In the idle mode, launches the Still Shot menu of Camera menu if you press
and hold while the folder is closed.
For more details, please see Still Shot menu in section 9.
In the editing mode, moves the cursor.
In the menu, moves the menu cursor.
In the idle mode, each key has following functionality.
[NAVI-LEFT] : launches the Still Shot menu of Camera menu
[NAVI-RIGHT] : launches the Games menu.
During a call, [NAVI-LEFT] and [NAVI-RIGHT] change the call focus on the
multiple calls state.
[NAVI-UP] : launches the My Menu list, and launch the My Menu Setting
menu if you press and hold [NAVI-UP] key. For more details, please see My
Menu Setting menu in section 9.
[NAVI-DOWN] : launches the Inbox message lists of all kinds of message.
During a call, [NAVI-UP] and [NAVI-DOWN] adjust the earpiece volume.
[NAVI-CENTRE]
In the editing mode, launches the editing mode selection menu.
In the menu, selects the menu on which menu cursor is.
In the idle mode, accesses the WAP site.
1.3 Quick Silence Mode
You can switch the sound/alert mode of your phone by just pressing and holding the [VOLUME-
UP]on the idle screen. icon on the top of the main display screen or icon on the top of the
sub display screen indicates that your phone is under the quick silence mode status.
If your phone is in the quick silence mode, all audible key tones are muted and all audible alerts
are changed to vibrator alert.
You can return to previous profile setting by pressing and holding the [VOLUME-UP] again.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 7 of 93
1.4 Using the Navigation Keys
To use the navigation keys appropriately.
1. [NAVI-LEFT] : Push the left side of the navigation key bar to left direction.
2. [NAVI-RIGHT] : Push the right side of the navigation key bar to right direction.
3. [NAVI-UP] : Push the up side of the navigation key bar to up direction.
4. [NAVI-DOWN] : Push the down side of the navigation key bar to down direction.
5. [NAVI-CENTRE] : Push the navigation key bar down.
1.5 Using the Earphone
If you insert the earphone to the jack on the left side of your phone, you can use it in the same
way as your phone’ s earpiece and microphone.
You can answer or end a call by pressing the hook button on the earphone.
When new waiting call is come whilst you are in a call, you can answer the waiting call by
pressing the hook button on the earphone. (The first call will be held automatically)
You can make the last number dialled call in the idle screen by pressing the hook button on the
earphone. The last number dialled is launched by pressing the hook button, and then the call will
be made by pressing the hook button again.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 8 of 93
1.6 Display Screens in the Idle Mode
< Main Display Screen >
Å Icon Area
Å Network Status or Event Area
Å Broadcast and Digital Time Area
Å Function Key Area
The background image is displayed according to the setting of Wallpaper menu. Please see
Section 9 for details. You can set the background image from Sample Image, Photo Album,
Image File, Mflash Folder or Video Folder menu.
Icon Area:
9 icons such as Signal Level, GPRS, SMS, Vibrator, Alarm, Roaming, Battery Level, PUSH
and Voicemail are displayed indicating the phone status.
If the quick silence mode is enabled, icon will appear in the Vibrator icon’ s place.
If there is an active GPRS connection, icon will appear in the GPRS icon’ s place.
If Travel Charger is inserted, the Battery icon will be scrolled.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 9 of 93
Network Status or Event Area:
Network name registered is displayed. If Network Name Display menu is set to Off, the network
name is not displayed even though your phone is registered to any GSM or GPRS network.
If there is not any GSM or GPRS network near the location you are, No Service is displayed.
If you are in the coverage of a GSM or GPRS network but you are not allowed to be registered
to the network, Emergency Only is displayed.
If an event is occurred, an adequate big event icon is displayed.
! Note: If Network Name Display menu is set to Off, the network name is not displayed even
though your phone is registered to any GSM or GPRS network.
Broadcast and Digital Time Area:
If you set to get the broadcast message from the network, you can see it on this area of the idle
screen. For details of how to activate and deactivate it, please see Broadcast menu in Section 9.
In this case, the User Selectable Area updates the received broadcast messages. If you want to
go back to default screen, press [END].
The digital time is displayed at the right bottom place in this area. If Clock Display menu is set
to Off, the digital time is not displayed.
! Note: The broadcast message service may not be available on all networks.
Function Key Area:
The functions assigned to right soft key and left soft key are displayed.
If you press [VOLUME-DOWN], current date, day and time is displayed at this area for short
time.
< Sub Display Screen >
Å Icon Area
Å Network Status or Event Area
Å Time Area
The background image is displayed according to the setting of Wallpaper menu. Please see
Section 9 for details. You can set the background image from Sample Image, Photo Album or
Image File menu.
Icon Area:
5 soft icons such as Signal Level, GPRS, Vibrator, Alarm, and Battery Level are displayed
indicating the phone status.
If the quick silence mode is enabled, icon will appear in the Vibrator icon’ s place.
If there is an active GPRS connection, icon will appear in the GPRS icon’ s place.
If Traver Charger is inserted, the Battery icon will be scrolled.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 10 of 93
Network Status or Event Area:
Network name registered is displayed. If Network Name Display menu is set to Off, the network
name is not displayed even though your phone is registered to any GSM or GPRS network.
If there is not any GSM or GPRS network near the location you are, No Service is displayed.
If you are in the coverage of a GSM or GPRS network but you are not allowed to be registered
to the network, Emergency Only is displayed.
If an event is occurred, an adequate event image is displayed. For more details, please see
Section 1.1.
If you press [VOLUME-DOWN] on the idle screen, current date and day is displayed on the
area for short time.
Time Area:
Current time is displayed in this area.
2. Getting Started
NOTE :
Please never detach the battery from your mobile whilst your phone is alive. To turn off your
phone, please press and hold down only until you see the power-off animation.
Please use only approved batteries and chargers.
2.1 How to attach the battery
1. Align the bottom of the battery down into the holes in the bottom of the phone.
2. Then sit the battery on the back of the aligned until it clicks into place.
2.2 How to remove the battery
Turn off your phone first.
1. Press up the battery release latch
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 11 of 93
2. Slightly lift the upper place of battery out of back of phone.
2.3 How to charge the battery
The first charging must be for at least 4 hours in order to achieve optimum performance when
you buy this phone. Normally your phone completes to charge the battery in one and half hour.
You can make calls whilst charging your phone.
Your phone turns off by itself if the battery is not able to supply enough power.
The display may not visible for a few seconds in case that full discharged battery is used.
!Note : Do not charge your phone without the battery in place.
Do not detach the battery whilst being charged.
< Charging with the Travel Adaptor>
1. Plug your Travel Adaptor into the external socket at the bottom of your phone.
The percentage of charging will be indicated on the sub display screen.
After complete charging, the percentage of charging disappears.
!Note : Even after complete charging, the phone automatically checks the battery status during
the Travel Adaptor is inserted. Once it detects that the battery level is below full status, it will
automatically recharge the battery.
< Charging with the Battery Charger>
1. Plug your Travel Adaptor into the charger socket at the bottom of the Battery Charger.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 12 of 93
2. Sit your battery into the holder of the Battery Charger properly sliding down.
The LED indicator of the Battery Charger indicate the charging status as follow.
- Green Colour : It indicates idle state or full-charged state.
- Red Colour : It indicates the battery is being charged.
2.4 How to place the SIM card
Ensure your phone is switched off and the charger is detached first before you start the
following steps.
1. Remove the battery.
2. Sit your SIM card into the holder. Beware the direction of the SIM card.
3. Slide the SIM card into the holder.
2.5 How to remove the SIM card
Ensure your phone is switched off and the charger is detached first before you start the
following steps.
1. Remove the battery.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 13 of 93
2. Slide the SIM card by pushing up the back of the card and remove it from the holder.
! Note: About the SIM card
The SIM card is a computer chip containing information about your subscription, security,
phonebook etc.
When you register as a subscriber with GSM or GPRS network operator, you are provided with
the SIM card.
Always handle the SIM card with care and insert with the gold contacts face down.
2.6 How to switch your phone On and Off
Make sure that the battery is attached.
1. Open the folder.
2. a) To switch your phone on, press and hold down [END] until you hear the power-on
melody.
Some SIM card may be protected with PIN.
If Enter PIN is prompted, enter your PIN and then press [Ok soft key].
For more details, please see Security Codes in section 3.
! Note: If your PIN is entered invalidly three times in succession, your SIM card is
blocked . In order to unblock it, see Security Codes in section 3.
If Enter Lock Code is prompted, enter your Lock Code and then press [Ok soft key].
The Lock Code is factory set to 0 0 0 0.
For more details, please see Security Codes in section 3.
After the phone is turned on, the phone searches for a network.
b) To switch your phone off, press and hold down [END] until you see the power-off
animation.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 14 of 93
3. Security Codes
The security codes are used to protect your phone and SIM card from other person’ s use and
control access to security and other options within the menus.
You can change the security codes (except SIM Lock Code, PUK Code, PUK2 Code). For more
details, please see the Security Setting menu in section 9.
3.1 PIN
PIN is Personal Identification Number, used to safeguard your SIM card.
PIN code is composed of at least 4 to 8 digits, and usually provided with your SIM card.
If the PIN code is entered incorrectly more than three times in succession, PIN will be blocked
and your SIM card will automatically lock-up and the Enter PUK screen will be prompted. Once
your SIM card is blocked, you must enter the unblock code (PUK) to use your phone again.
3.2 PUK
PUK is Personal Unblocking Key, used to unblock the blocked SIM card due to incorrectly
entered PIN. PUK code is composed of 8 digits, and usually provided with your SIM card. If the
PUK code is entered incorrectly ten times in succession, PUK will be blocked and your SIM card
will be automatically lock-up and the SIM Blocked message will be displayed. Once you see the
message then you need to contact your network service provider for a new SIM card.
3.3 PIN2
PIN2 is Personal Identification Number 2, used to access specific function of your SIM card, for
example PIN2 code is used to set a Maximum Cost, Price & Unit or a FDN.
PIN2 code is composed of at least 4 to 8 digits, is only available when your SIM card supports
such functions. If the PIN2 code is entered incorrectly three times in succession, PIN2 will be
blocked and the Enter PUK2 screen will be prompted. Therefore those functions cannot be used
until the unblock code (PUK2) is entered.
3.4 PUK2
PUK2 is Personal Unblocking Key 2, used to unblock the blocked PIN2 due to incorrectly
entered PIN2. PUK2 code is composed of 8 digits and it is only used when those functions
mentioned above are available. If the PUK2 code is entered incorrectly ten times in succession,
the PUK2 will be blocked. Therefore those functions can not be used until the unblock
code(PUK2) is entered.
3.5 SIM Lock Code
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 15 of 93
SIM Lock Code is used to safeguard your phone being used by another SIM card. The SIM Lock
Code is composed of 4 digits. The code is a security code entered when you enable the SIM
Lock menu.
3.6 Lock Code
Lock Code is used to prevent your phone from being used by another person. The code is
composed of 4 digits. The code is provided with your phone and is preset from factory to default
setting of ‘ 0 0 0 0’
3.7 Password
Password is used to access call barring service and the code is the network password of four
digits code. In order to get the Password, you should subscribe call barring service on your
network service provider and then request for the Password.
4. Making and Receiving a Call
4.1 Making a call
1. To make a call on your phone, enter the area code and the phone number in the idle screen.
In case you enter a number incorrectly, press the [Clear soft key] once to delete the last digit
that you have entered. To remove all the digits, press and hold the [Clear soft key] down until
they are deleted, or press [END].
2. Press the [SEND].
If the number is identified from the phonebook, the name is displayed.
You can hear the Connect Tone when the call is answered from the called person, if you set it
On. For more details, please see Sound Setting menu in Section 9.
If you want to end the call whilst making a call, press [End soft key] or [END], or close the
folder. The screen will display a brief message and return to the idle.
! Note: The brief message at the call ending may remain long time if the network is busy.
If the earphone is inserted, or if the call is data call, the folder closing does not make
the call end
.
Quick dialling from Phonebook list
1. Press [Phonebook soft key] in the idle screen.
Search the group with [NAVI-LEFT] or [NAVI-RIGHT] to find the group of person you want
the call to belong to.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 16 of 93
2. Locate the cursor with [NAVI-UP] or [NAVI-DOWN] to the name or number you want to
call.
3. Press [SEND].
Quick dialling from Speed List
Press and hold a numeric key ([0], [2] ~[9]) that represents the entry number in the Speed
List. Then the number assigned on the key will be automatically dialled. Please see section 6.4
for more details.
! Note: [1] key is reserved for your Voicemail server number. If you press and hold the key, the
Voicemail server number will be automatically dialed.
For more detailed explanations on setting the Voicemail server number, please see
Voicemail menu in section 9.
Quick dialling from recent calls list
1. Press [SEND] for the recent calls in the idle screen.
2. Search the type of the recent calls with [NAVI-LEFT] or [NAVI-RIGHT].
3. Locate the cursor with [NAVI-UP] or [NAVI-DOWN] to the name or number you want to
call.
4. Press [SEND].
4.2 Answering a call
1. When there is an incoming call, the phone icon on the sub display screen will be displayed,
and the melody will sound or the vibrator will work according to the setting.
If the caller is identified, the caller photograph and caller phone number/name (if stored in the
Phonebook) are displayed and caller group name on the screen is displayed.
The following small fixed icons are available.
: indicates No Group.
: indicates Family group.
: indicates Friends group.
: indicates Colleague group.
: indicates Business group.
: indicates VIP group.
: indicates Group1 (User defined group 1).
: indicates Group2 (User defined group 2).
: indicates Group3 (User defined group 3).
If the caller is not identified by network, No Number or Withheld (if the network suppresses
the number display) is displayed.
2. Press [Answer soft key] or [SEND] or open the folder to answer the incoming call.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 17 of 93
If Any Key Answer menu option is set to On and the folder has been opened, you can press
any key to answer the call except for the [End soft key] or [END].
! Note: If the earphone is inserted, or if the call is data call, the folder opening does not make
the call answer
.
If Folder Answer menu option is set to Off, the folder opening does not make the call
answer.
3. If you want to reject the incoming call when the folder has been closed, press [VOLUME-UP]
or [VOLUME-DOWN].
Press [End soft key] or [END], or close the folder if the folder has been opened.
The call number is saved in the missed calls list.
! Note: If the earphone is inserted, or if the call is data call, the folder closing does not make the
call reject
.
If the folder is closed, [VOLUME-UP] or [VOLUME-DOWN] is used for rejecting the
incoming call regardless of the Any Key Answer menu.
4.3 Making the emergency call
It is possible to call the emergency services if there is a GSM/GPRS network within reach. You
can dial the emergency number even if the handset is locked, or there is no SIM card in your
phone, or your phone cannot be registered with your home network.
1. Enter 112 to call the emergency services.
2. Press [SEND].
! Note: In the situation such as power-on that Enter Lock Code or Enter PIN is prompted, press
simply the [SOS soft key] to call the emergency services.
Some network may not allow the emergency call (112) and may request to insert SIM
card.
The number of 911 may be used for the emergency call number in some network.(PCS)
4.4 Making an international call
1. Press and hold down the [* ] until ‘+’ sign appears to dial an overseas number.
The ‘+’ tells the network that the call is international.
2. Enter the country code, the area code (without the leading zero) and the phone number.
3. Press [SEND].
! Note: Some network may not allow the international call with ‘+’.
4.5 Entering a “Pause” Character in a Dial String
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 18 of 93
A pause character may be entered into a dial string by pressing and holding down [#] until a
‘P’ sign appears.
4.6 Notification of Missed Call
If you are unable to answer an incoming call for a reason or if you reject the call, the Missed
Call notification message is displayed.
You can immediately obtain a list of incoming missed calls (calls not answered) from the idle
screen by pressing the [View soft key].
5. In-Call Options
Your phone provides a number of call control functions that you can use during a call.
To access these call control functions, press the [Option soft key] or right function soft key
during a call.
The following illustrations show the example of the display according to the call state.
icon in the title area of the screen indicates that you are currently on a call.
icon in the title area of the screen indicates that you are in the conference call state. (For
example, 2 active calls or 2 held calls)
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 19 of 93
The boxed digits in middle place of the title area of the screen indicate the number of the
focused call in the multiple calls state. You can focus to next or previous call by pressing
[NAVI-RIGHT] or [NAVI-LEFT].
In the main area of the screen, you can see the number or name (if stored in the phonebook) and
the call state of the focused call. Depending on your subscription, you may see the remaining
cost in the bottom area of the screen.
The time counter in the bottom area of the screen starts when the call starts and indicates how
long you have been on the call.
! Note: All of the call control options are not always displayed through all calls, necessary
options only will be displayed according to the call state.
5.1 Putting a call on hold/unhold
You can put the current call on hold when the call is active state if this service is supported on
the network.
1. Press [Hold soft key], or select the Hold option in the Option menu if muted.
2. To make the held call reactivate, press [Unhold soft key], or select the Unhold option
in the Option menu if muted.
5.2 Making a second call
You can make a second call whilst you are in a call.
1. Enter the second phone number or fetch it up via Phonebook option.
2. Press [SEND]. The first call is automatically put on hold if the second call is made.
< Connecting the first participant with another participant>
If you press [Transfer soft key] whilst the second call is being made, the function allows you to
make two participants connect, and then allows you to leave the conversation by itself.
Thereafter, two participants are connected to each other.
5.3 Swapping between active calls and held calls
You can swap calls whilst there are active calls and held calls on conversation.
Press [Swap soft key], or select the Swap option in the Option menu if muted.
The current active calls are placed on hold and the held calls are reactivated.
5.4 Answering a second incoming call
You will be notified of an incoming call whilst you are in a call. Call waiting tone sounds in the
earpiece, and the display will show that a second call is waiting. This feature, known as Call
Waiting, is only available if the network supports it and if you have set the Call Waiting menu to
Activate.
For details of how to activate and deactivate it, please see Call Waiting menu in Section 9.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 20 of 93
You can answer the second incoming call by pressing [Answer soft key] or [SEND].
The first active call is automatically put on hold, and then the incoming call is active.
If the incoming call is coming whilst you already have active calls and held calls, the following
options are available by pressing [Option soft key] or [SEND].
• End Active Call : makes active calls end and answer the incoming call.
• End Held Call : makes held calls end and answer the incoming call.
You can reject the second incoming call during a call without answering it by pressing [Reject
soft key] or [END].
5.5 Adjusting the earpiece volume
During a call, you can adjust the earpiece volume.
To increase the volume, press [VOLUME-UP] or [NAVI-UP].
To decrease the volume, press [VOLUME-DOWN] or [NAVI-DOWN].
5.6 Muting the microphone
You can mute the microphone during a call by selecting the Mute option so that the other party
cannot hear you.
You can unmute by pressing the [Unmute soft key], and then the other party can hear you
again.
5.7 Sending DTMF
You can turn off the DTMF tone by selecting the DTMF Off option so that the tone is not
transmitted to the remote end during a call.
You can turn on the DTMF tone by selecting the DTMF On option.
The option is automatically reset to the DTMF On when a call is started.
! Note: To communicate with answering machine, you must use with the DTMF On state.
5.8 Storing a number on the scratchpad
You can store a number you entered during a call.
1. Enter a number during a call.
2. Press [Save soft key] to store it to the Phonebook.
If the number entered remains not deleted without saving, the number will be displayed on the
screen after ending the call.
5.9 Using the SMS function
You can read or create SMS messages during a call by selecting the Messages option.
For details of how to use it, please see Short Message menu in Section 9.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 21 of 93
5.10 Using the loudspeaker
You can turn on the loudspeaker by selecting the Loudspeaker On option so that the speech
from the remote end is heard in the loudspeaker.
The option is automatically reset to the Loudspeaker Off when a call is started.
5.11 Making a conference call
The conference call service provides you with the ability to have a simultaneous communication
with up to six persons if this service is supported on the network.
! Note: The Conference Call Service may not be available on all networks.
Setting up a Conference Call
1. Make first call in a normal way.
2. Make second call whilst you’ re already in a call, then the first participant is automatically
put on hold.
3. To join the first participant to the conference call, press [Option soft key] and select the
Join All option. icon in the title area of the screen will be displayed.
All the conference call participants can now hear each other.
4. To add a new participant to the conference call, repeat step 2 and step 3 as required.
You can add incoming callers into conference call by answering the call and pressing [Option
soft key], followed by the Join All option.
Available Options
Please proceed as following sequence to use appropriate option on conference call state.
1. At first, focus on the participant who you want by scrolling through the participants with using
[NAVI-LEFT] or [NAVI-RIGHT].
2. Press [Option soft key].
The following options relevant to conference call are available.
Hold All : puts the conference call (all active calls) on hold.
Private : makes a private call with the focused participant (whose details is currently
displayed on-screen) of the conference call, then puts the other participants on
hold automatically.
Join All : joins all held calls to the conference call.
Transfer : allows you to make two participants connect, then drop your call from the
conversation. Two participants are connected to each other.
It can be available when one participant is on hold and the other participant is
active, or when one participant is on hold and you are making the other call.
End Active Call : makes all active calls end and keep the held call.
! Note: [END] is used for dropping the focused call.
If you close the folder, the conference call is ended.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 22 of 93
6. Phonebook
! Note: If you change with another SIM card, you may lose the information of phonebook data in
the previous SIM card. If you do so, the type of the number, text memo and group type may be
lost. Only the name and telephone number will remain in previous SIM card.
You can store the phone numbers and their corresponding names in the memory of your SIM
card. In addition, you can store up to 800 numbers and names into your phone memory. The SIM
card memory and phone memory is physically separated but they are searched as a single
entity.
You can protect your phonebook information against other persons.
For more details, please see Security Setting menu in Section 9.
The following illustration shows an example of the display of phonebook list.
The small icon on the far left side of each record indicates the group type.
The following small group icons are available.
: indicates No Group.
: indicates Family group.
: indicates Friends group.
: indicates Colleague group.
: indicates Business group.
: indicates VIP group.
: indicates Group1 (User defined group 1).
: indicates Group2 (User defined group 2).
: indicates Group3 (User defined group 3).
The scroll-bar on the right side of the screen indicates current position of the record on which
menu cursor is located.
The small icon on the far left side of the each record indicates the record group type.
You can move to another group by pressing [NAVI-LEFT] or [NAVI-RIGHT] key.
6.1 Storing a phone number with a name
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 23 of 93
1. Enter the number at the idle screen and press [Save soft key].
2. Enter the name of the person or service.
If you want to know more about input mode please see section 7.
Press [Ok soft key] when the name input is completed.
3. You can see the following screen.
With pressing [NAVI-UP] or [NAVI-DOWN], you can move the editing cursor to the item that
you wish to edit or add.
Press the [Edit soft key], and you can edit or add the item.
For each name, you can set the group of the name with adequate group icon explained before.
You can save up to three(3) telephone numbers, one E-mail address and one photograph for
each name. You can link a photograph of Photo Album menu with each name. The photograph
should be taken by your phone camera with size option of 96x64, or 128x160.
For each number, you can set the type of the number with following icons.
: Mobile
: Home
: Office
: Fax
: Pager
After editing, press [Save soft key] to save the record.
The record will be saved into SIM memory or Phone Memory according to the setting of
Place To Save in the Settings option.
6.2 Quick searching for a number in the phonebook
1. Press the [Phonebook soft key] in the idle screen.
The names stored in the phonebook will be listed in alphabetical order.
2. Press the first letter of the name that you want to search for.
To choose a letter on a keypad, the key is pressed the appropriate number of times,
rapidly in succession, once for the first letter, twice for the second letter etc.
! Note: If you found the name, you can dial the number by pressing [SEND].
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 24 of 93
6.3 Storing a number of the recent calls to the phonebook
1. Press [SEND] in the idle screen. Recent Dialled calls list will be displayed.
With pressing [NAVI-LEFT] or [NAVI-RIGHT], you can move the screen cursor to another
call record type screen.
With pressing [NAVI-UP] or [NAVI-DOWN], you can move the list cursor to the recent
number.
2. Press [View soft key] on the name that you wish to store.
3. Press [Paste soft key] and then press [Save soft key].
6.4 Speed List
You can add, edit or delete the Speed Dial Numbers by Speed List option on the Settings option.
To speed dial one of these numbers on the idle screen, press and hold the numeric key ([0], [2]
~[9]) that represents the entry in the speed dial list. The number is automatically dialled without
further input.
!Note : Speed List record will be stored in the SIM memory regardless of Place To Save
settings.
[1] key is reserved for your Voicemail server number. If you press and hold the key, the
Voicemail server number will be automatically dialed.
For more details of setting the Voicemail server number, please see Voicemail menu
in section 9.
Adding a new number to the Speed Dial List
1. Press [Phonebook soft key] in the idle screen.
2. Press [Option soft key] in the phonebook name list screen.
3. Select Settings option.
4. Select Speed List option.
5. Locate the menu cursor to a <Empty> list, and then press [Option soft key].
Select Add option.
6. Press [Ok soft key] after entering the new name and number.
Editing a number in the Speed Dial List
1. Do step 1 to step 4 in the adding sequence.
2. Locate the menu cursor to a list you wish to edit, and then press [Option soft key].
3. Select Edit option.
4. Press [Ok soft key] after editing the name and number.
Deleting a number in the Speed Dial List
1. Do step 1 to step 4 in the adding sequence.
2. Locate the menu cursor to a list you wish to delete, and then press [Option soft key].
3. Select Delete option. The list will be displayed as <Empty>.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 25 of 93
6.5 Using the Phonebook options
If you press [Option soft key] after locating the menu cursor to the name you wish to do an
action, the following options are available.
View : views the details of the selected record.
Search : searches the record you want to find.
Add : adds a new record.
Edit : edits the number, the name, the group, the Email address and the photograph of the
selected record.
Delete : deletes the selected record.
Change Group : changes the group type of the selected record.
Send SMS : send SMS message to the selected record.
Send MMS : send MMS message to the selected record.
Copy To SIM or Copy To Phone : copy selected record to another memory.
Settings : You can set overall phonebook control.
The following options are available.
- Group Setting: set the Ring Melody for each group type and group name.
- Place To Save : set a default saving location.
- Status : identifies the memory use in your SIM card and your phone memory.
- Speed List : adds, edits or deletes the Speed Dial Number.
- Delete All : delete all records in SIM or Phone memory
- Copy All : copy all records to another memory.
7. Text Editing
7.1 Input Mode
The editing situation is as follows.
Editing a message or string in Create Message menu, Template menu, User Define CUG menu,
Add Schedule menu (of the Calendar menu), Memo menu and Editing and input of the name of
Phonebook, name and Address of e-mail setting, Add Bookmarks name (Browser), WAP
Browser, and name of Connection Settings menu(URL Browser editing).
The initial input mode is automatically switched according to the Language Setting menu.
You can select following text input modes by pressing [NAVI-CENTRE] on each editing screen.
T9 Abc
Multi-tap
Numeric
Symbols
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 26 of 93
T9 Language
Template
When editing a name or string in Phonebook name, Bookmarks name (Browser) and WAP
Browser, initial input mode is set to Multi-tap mode and you cannot select Template mode. Also
when editing a name in Connection Settings menu (URL Browser editing), initial input mode is
set to Multi-tap mode and you cannot select T9 Language mode.
If you are in the T9 Abc mode, the [#] key is used to switch the letter entry mode. ( ->
-> )
If you are in the Multi-tap mode, the [#] key is used to switch the letter entry mode. ( ->
)
By pressing and holding [#] key in an input mode, Symbols mode can be also selected
with the exception of the case that you are in the numeric input mode.
By pressing and holding [*] key in an input mode, Numeric mode can be also selected.
By pressing and holding [NAVI-CENTRE] key in an input mode, Multi-tap mode can be also
selected.
7.2 T9 Abc input mode
Using the T9 Abc mode, you can enter words by successively pressing the key corresponding to
each letter in order to get the desired word. Although each key of the numeric keypad
represents several letters, only one key press per letter is required. The T9 Abc mode matches
your keystrokes to its Linguistic Database to determine which word the user intended to spell.
With each keystroke, the Word or Candidate Selection List is updated and the most likely
interpretation of the keystrokes is presented. In cases where more than one interpretation is
possible, T9 Abc mode presents interpretations in order of their frequency of use in the
language. In these case, the icon changes to and the user selects the desired word or
character from the interpretations by using [NAVI-UP] key or [NAVI-DOWN] key.
[Example Screen]
[Key Function Table]
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 27 of 93
[Ok soft key] accepts the string entered on the edit screen, and then turn to next
menu or screen.
[Clear soft key]
Short : clears a character of the string entered on the editing area
or clears a character on the active word(the word remain active).
Long : clears all characters
[NAVI-LEFT] accepts the active word and then moves the cursor to left direction by
a character on the editing area.
[NAVI-RIGHT]
1. accepts the active word and then moves the cursor to right
direction by a character on the editing area.
2. Space
[NAVI-UP]
1. switches the word entered on the editing area to previous similar
word during word editing.
2. moves the cursor to previous line if you are not in a word editing.
[NAVI-DOWN]
1. switches the word entered on the editing area to next similar word
during word editing.
2. moves the cursor to next line if you are not in a word editing.
[NAVI-CENTRE]
Short : launches the character input mode selection menu.
Long : toggles between the Multi-tap input mode and T9 Abc
input mode.
[END] clears all the string entered on the editing area, and then turns back to
previous menu or screen.
[1]
Short: Smart punctuation (You can enter some popular symbol
character using [NAVI-UP] or [NAVI-DOWN])
Long: Number entry.
[2] - [9] Short:Text entry.
Long: Number entry.
[0] Short:Space (It means the previous word entry is accepted)
Long: Number entry.
[*] Long : switches to the Numeric input mode.
[#] Short : switches the letter entry mode. ( -> -> )
Long : switches to the Symbols input mode.
7. 2. 1 Add My Word?
In T9 Abc mode, when a word which matches your key stroke is not in Linguistic Database or
when you do not find a desired word in candidate selection list, the [Ok soft key] changes to the
[SPELL key]. If you push this key, input mode changes to Add My Word? mode and you can
add a word to the Linguistic Database in this mode. If you press Ok soft, you return to T9 Abc
input mode and the word is automatically added to the Linguistic database. You can add email,
web-site address, etc. to the Linguistic Database. You can select added words in candidate list.
In this input mode,
Initial default input mode : Multi-tap mode
Optional input modes : Numeric mode and Symbols mode.
[Example Screen]
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 28 of 93
7. 3 Multi-tap input mode
Multi-Tap input mode provides a method of explicit spelling normally used on devices with a
limited set of mechanical keys. In English, a keypad is automatically switched according to
phone language setting. To choose a letter on a keypad, the key is pressed the appropriate
number of times, rapidly in succession, once for the first letter, twice for the second letter etc.
[Example Screen]
[Key Function Table]
[Ok soft key] accepts the string entered on the editing area, and then turns to next
menu or screen.
[Clear soft key] clears a character of the string entered on the editing area.
[NAVI-LEFT] moves the cursor to left direction by a character on the editing area.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 29 of 93
[NAVI-RIGHT]
1. moves the cursor to right direction by a character on the editing
area.
2. space
[NAVI-UP] moves the cursor to previous line on the editing area.
[NAVI-DOWN] moves the cursor to next line on the editing area.
[NAVI-CENTRE]
Short : launches the character input mode selection menu.
Long : toggles between the T9 Abc input mode and Multi-tap input
mode.
[END] clears all the string entered on the editing area, and then turns back to
previous menu or screen.
[1] – [9] Short : Text entry. (See the Character List Table)
Long : Number entry
[0] Short : Space
Long : Number entry
[*] Short : Text entry. (See the Character List Table)
Long : switches to the Numeric input mode.
[#] Short : switches the letter entry mode. ( -> )
Long : switches to the Symbols input mode.
7. 4 Numeric input mode
This mode uses the standard numeric keypad to allow users to enter numeric information such
as phone numbers, addresses, etc.
[Example Screen]
[Key Function Table]
[Ok soft key] accepts the string entered on the edit screen, and then turns to the
next menu or the screen.
[Clear soft key] clears a digit of the string entered on the editing area.
[NAVI-LEFT] moves the cursor to the left direction by a digit on the editing area.
[NAVI-RIGHT] moves the cursor to the right direction by a digit on the editing area.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 30 of 93
[NAVI-UP] moves the cursor to the beginning of the string.
[NAVI-DOWN] moves the cursor to the end of the string.
[NAVI-CENTRE] launches the character input mode selection menu.
[END] turns back to the previous character input mode.
[0] Short : 0
Long : Space
[1] - [9] Number entry.
[*]
One time of pressing : ‘ *’
Two times of pressing : ‘ +’
Long : turn back to the previous character input mode.
[#] One time of pressing : ‘ .’
Two times of pressing : ‘ #’
7. 5 Symbols input mode
This input mode allows users to enter symbols or formatting characters into text message.
[Example Screen]
[Key Function Table]
[Select soft key] accepts the symbol which cursor indicate , and then turns back to the
previous character input mode.
[Quit soft key] turns back to the previous character input mode.
[NAVI-LEFT] moves the cursor to left.
[NAVI-RIGHT] moves the cursor to right.
[NAVI-UP] moves the cursor to up.
[NAVI-DOWN] moves the cursor to down.
[NAVI-CENTRE] accepts the symbol which cursor indicate , and then turns back to the
previous character input mode.
[SEND] accepts the symbol which cursor indicate , and then turns back to the
previous character input mode.
[END] turns back to the previous character input mode.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 31 of 93
[Available Symbols]
. / : @ , ? ! ‘ - _
( ) ; & % + * # < =
> “ £ $ ¥ € Γ Δ Θ Λ
Ξ Π Σ Φ Ψ Ω ¿ ¡ § ¤
7. 6 T9 Language input mode
This mode allows users to change the T9 language during the editing.
[Example Screen]
7. 7 Template input mode
This mode allows you to select words such as web-site address, e-mail, a sentence word, etc.
which are stored in the template of Organizer menu
[Example Screen]
8. The Menu Map
! Note: Depending on the contents of your SIM card, some menu items may not be visible.
Messages
1.1 SMS
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 32 of 93
Inbox
Outbox
Create Message
SMS Setting ------- Message Center
Validity Period
Delivery Report
Reply Path
Message Protocol
Connection Type
Status
Chat
1.2 MMS
Inbox
Outbox
Create message
Drafts
Sent
MMS Settings ------ Save On Sent
Delivery Report
MMS Profile
MMS Lifetime
MMS Download
Spam Filter
1.3 E-mail
Inbox
Outbox
Create Message
Drafts
Sent
E-mail Setting ----- Connection Profile
E-mail Accounts
Send Option
Size Limit
DNS Address
Status
1.4 Voicemail
Connect Voicemail
Number Setup ---- Home Mailbox
Roam Mailbox
1.5 Broadcast
Read All Messages
Receive Setting
Display On Idle
Subject List ----- Active List
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 33 of 93
User Define List
Language List
Saved Messages
Call Records
2.1 Dialled Calls
2.2 Received Calls
2.3 Missed Calls
2.4 Delete Records
2.5 Cost & Duration
Last Call
All Calls
Maximum Cost
Price & Unit
2.6 Data Counter
Last Data
All Data
Phone Setting
3.1 Own Numbers
3.2 Language
3.3 Sound Setting
Profiles
Key Tone Type
Ring Melody
Message Melody
Rising Volume
Connect Tone
Minute Tone
3.4 Display Setting
Colour Mode
Wallpaper ------ Sample Image----- Main Screen
Sub Screen
Photo Album
Image File
MFlash Folder
Video Folder
LCD contrast----- Main Screen
Sub Screen
Greeting Message
Backlight Time ------ 10 secs
30 secs
1 Min
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 34 of 93
1 Min 30 secs
Clock Display
Network Name Display
EL Light
3.5 Clock Setting
Set Time
Set Date
Time Update
Time Format --- 12 Hour
24 Hour
World Time
3.6 Call Setting
Caller Number
Any Key Answer
Folder Answer
Auto Redial
3.7 Connection Profile
3.8 Security Setting
PIN Access
SIM Lock
Phone Lock
Album Lock
Phonebook Lock
Change Codes
FDN
Factory Reset
3.9 My Menu Setting
Camera & Media
4.1 Camera
Still Shot
Frame Shot
Camera Setting – Self Timer
Shutter Sound
Saving Name
Album Type
Set Default
Photo Album
4.2 Camcorder
Shooting
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 35 of 93
Camcorder Setting - Saving Name
Set Default
Moving Picture
4.3 Image File
4.4 Audio File
Voice Record File
Composed Melody
Downloaded Audio
4.5 MFlash Folder
4.6 Video Folder
4.7 File Manager
4.8 Memory Status
Organiser
5.1 Calendar
5.2 View Today Report
5.3 Alarm
Morning Alarm – Set Time
Alarm Status
Alarm Tone
Repeat Status
Power Up
Snooze
General Alarms
5.4 Memo
5.5 Template
Network Service
6.1 Call Divert
Always
When Not Answered
When Busy
When Not Found
Cancel All
6.2 Call Barring
In Calls
In Calls If Abroad
Out Calls
Foreign Out Calls
Foreign exc. to Home
Cancel All
6.3 Call Waiting
Activate
Cancel
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 36 of 93
Status
6.4 Caller Identity
Show Caller Name
Restrict. Caller ID
Restrict. Your ID
Present. Caller ID
Present. Your ID
6.5 Closed User Group
CUG Select
User Define CUG
6.6 Network Selection
Selection
Preferred List
Game & Utility
7.1 Games
7.2 Java
7.3 Biorhythm
7.4 Timer
Stopwatch
Countdown
7.5 Calculator
7.6 Voice Memo
7.7 Melody Composer
7.8 Converter
7.9 Lady Schedule
Internet
8.1 Home
8.2 Resume
8.3 Bookmarks
8.4 Push Messages
8.5 Settings
Connection Profile
User Preferences
Security Certificate
8.6 Empty Temp Files
8.7 Go To Address
8.8 Version Info
SIM AT Service
! Note : The SIM AT Service menus may be different according to the content of your SIM card.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 37 of 93
9. The Menu Functions
You can enter to menu setting mode by pressing [Menu soft key].
In the menu setting mode, three types of menu are used in your phone.
The digit on the right-top side of the screen indicates the menu number, you can access the
menu by pressing the menu number.
[Select soft key] or [NAVI-CENTER] is used for selecting the menu on which menu cursor is.
The following illustrations show the example of each menu screen.
Icon Menu Choice Menu Choice Menu with Value
Icon Menu
Your phone provide easy-to-understand graphical animation icon menu. You can easily
understand the meaning of each graphical animation icon by the text on the top display line. To
move the cursor, use [Navigation Keys].
Choice Menu
You can see max 7 menu items on the menu selection area.
The text in the title area indicates the name of parent menu item.
The menu cursor is moved by [NAVI-UP] and [NAVI-DOWN].
Choice Menu with Value
You can see max 7 menu items on the menu selection area and see the value window on each
menu below.
The text in the title area indicates the name of parent menu item.
If the menu cursor moves to the item, the setting value of the menu item is displayed on the
value window.
If the menu item does not have any setting value, the value window is not displayed.
The menu cursor is moved by [NAVI-UP] and [NAVI-DOWN].
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 38 of 93
9.1 Messages
9.1.1 SMS
The message can be sent by Fax, E-mail, ERMES, and X400 format, provided that these
services are supported on the network. To send text messages with your phone, you need to set
the Message Service Center Number (obtained from your home network operator) on the
Message Center menu.
If a message has arrived, your phone displays New Message in idle screen and sets icon to
inform you of the arrival.
The arrived message is saved in SIM memory as the first place. If SIM memory is full, it is saved
in phone memory. Your phone has maximum 100 spaces for the SMS records in the phone
memory. If the SIM memory and the Phone memory are both full, SMS Full is indicated, icon
blinks and you cannot receive any more new message. In the case, you need to delete old and
unnecessary messages by using Delete, Delete All option in Inbox or Outbox menu.
You can create the message limit to 1064 alphanumeric characters (462 characters in case of
Chinese character) at one message in Create Message menu.
The long message is saved into maximum 7 records. Also, long received message is saved in
same way.
! Note : The SMS service may not be available on all networks. Some network allows to be sent
only within its own network.
<Inbox>
With this menu, you can view the new text messages or the read messages.
Sender phone numbers or names (if stored in the Phonebook) are displayed on the list.
The small icon on the far left side of the each list indicates following meanings.
: The message is the new unread message.
: The message is the read message.
If you press [Select soft key], you can see the message contents with a sender phone number
and its arrival time by using [NAVI_UP] and [NAVI-DOWN].
If you select [Options soft key], following options are available.
Delete : Allows you to delete the viewed message.
Reply : Allows you to send a reply message to the sender of the viewed message.
Voice Call : Enables you to call the sender of the viewed message.
Extract Number : Enables you to get all numbers(with more than 2 digits) in the message
and sender’s phone number. If you select a number on the list, you can
store the number into phonebook, or can make call with the number.
Forward : Allows you to forward the viewed message to someone else.
Edit : Enables you to edit the viewed message contents.
If you select Save option, the edited message is listed in Outbox menu.
Delete All : Allows you to delete all messages of Inbox menu.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 39 of 93
<Outbox>
With this menu, you can view the saved messages which have been sent or unsent.
Recipient phone numbers or names (if stored in the Phonebook) are displayed on the list.
The small icon on the far left side of the each list indicates following meanings.
: It is the sent message.
: It is the unsent message.
If you select [Options soft key], Delete, Send, Extract Number, Forward, Edit and Delete All
options are available.
With Send option, you can send the saved message unchanged as it is.
<Create Message>
With this menu, you can write a text message of up to 1064 alphanumeric characters (462
characters in case of Chinese character), and then you can save and send the message.
Input a text message and then press the [Ok soft key]. After that, enter the recipient phone
number on the Destination screen. You can input the number directly or get from the phonebook
by pressing the [Phonebook soft key].
If you press the [Ok soft key] on the screen, following options are available.
Send : Sends the text message to the recipient phone number.
The message cannot be saved.
Save : Saves the text message and the recipient phone number.
Save and Send
:
Saves the text message and the recipient phone number, and then sends.
<SMS settings>
- Message Center
With this menu, you can view the Message Center Number List and currently activated the
Message Center Number.
Activate : Activate the selected Message Center Number to use sending a message.
Add : Add the Message Center Number, if the Message Center SIM memory is available.
Edit
:
Edit the Message Center Number and Save it.
Delete : Delete the Message Center Number. If the selected Message Center Number is the
Base Area, this menu cannot be displayed.
The number can be obtained from your home network service provider.
- Validity Period
This menu allows you to set the length of time period that your message will be stored at the
Message Service Center in the network whilst attempts are made to deliver them to the
recipient. Available options are One Hour, Two Hours, Six Hours, One Day, Two Days, One
Week, Four Weeks and Six Months.
- Delivery Report
You can set whether network sends the delivery report message to your phone or not. The
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 40 of 93
delivery report message means that the sent message has arrived to the recipient properly.
- Reply Path
With this menu, you can select which Message Service Center will route your reply message.
If you select Own Center, the cost of the reply message is charged to your bill and you can
receive the reply message regardless of the recipient’s SMS service subscription.
Own Center : When the recipient sends reply message to you, your own Message Service
Center that has set on the Message Center menu is used.
Remote Center : When the recipient sends reply message to you, his Message Service
Center(Remote Message Service Center) is used.
- Message Protocol
With this menu, you can use a network messaging service which offers you the facility of
converting your text messages into alternative formats (Text, Fax, Voicemail, ERMES, Paging,
X.400 or Internet).
! Note : All formats may not be available on all networks.
- Connection Type
You can select which connection will be used for sending or receiving SMS
CS Only : Only Circuit Switch Connection will be used.
CS Preferred : If Circuit Switch connection and GPRS connection are possible, Circuit Switch
connection will be used at first. If failed, GPRS connection will be used.
GPRS Only : Only GPRS Connection will be used.
GPRS Preferred : If Circuit Switch connection and GPRS connection are possible, GPRS
connection will be used at first. If failed, Circuit Switch connection will be used.
- Status
You can identify the memory use for SMS message in your SIM card and your phone memory.
<Chat>
This chat service allows you to do chatting with standard SMS. During the chat session, you can
see all received and sent chat message on screen. Chat messages are not saved on SIM card.
9.1.2 MMS
A multimedia message can contain text, images, and/or sound clips.
To send Multimedia messages with your phone, you need to set the Message Service Center
Number and the connection profile on the Message Center menu and Connection Profile menu.
For more details about these information, please contact your network service provider.
If multimedia message has arrived your phone displays New Multimedia Message in idle screen
to inform you of the arrival. Messages are stored within the local filing system. When storing
messages within the filing system, the maximum number and size of stored messages is entirely
dependent upon available local filing system storage space.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 41 of 93
! Note : The MMS service may not be available on all networks. For more details, please contact
your network service provider.
<Inbox>
With this menu, you can view the new multimedia messages or the read messages.
Sender phone numbers or names (if stored in the Phonebook) are displayed on the list.
The small icon on the far left side of the each list indicates following meanings.
: The message informs you new message has arrived. However it is not downloaded
yet.
: The message is the downloaded and unread message.
: The message is the downloaded and read message.
If you select [Option soft key], following options are available.
Read : Reads the message. If the message is deferred/left on the message server, this
option downloads it before anything else.
If Multimedia message has multiple pages, it displays like a slideshow. You can stop
slide show by pressing [NAVI-CENTER]or [Option soft key]. You also see each
page by pressing [NAVI-LEFT] or [NAVI-RIGHT].
: During multiple page message playing, this icon is displayed on center of
soft key area. You can stop playing.
: During multiple page message stopped, this icon is displayed on center of
soft key area. You can play the message.
: Sound file is attached but Sound is not playing because of User Setting.
Delete : Allows you to delete the viewed or list selected message.
Edit : Enables you to edit the viewed or list selected message contents.
Forward : Allows the message to be forwarded to someone else.
Details : Enables you to see the message contents details.
Delete All : Allows you to delete all message in Inbox.
<Outbox>
With this menu, you can view a list of any messages waiting to be sent or failed to send.
Recipient phone numbers or names (if stored in the Phonebook) are displayed on the list.
If you press [Option soft key], the options are available the same as Inbox.
<Create Message>
The user is presented with a screen showing the first page in a blank MMS message. The screen
displays the page with following information above the message.
− The presence of any sounds or attachments on the current page.
− The size of the whole MMS message in bytes or kilobytes.
− The current page number/total number of pages.
If you press [Option soft key], following options are available.
Add Recipient : Proceeds to the subject/address stage of the message creation.
You can insert multiple recipients each of To, Cc, Bcc fields from Phonebook or edit the
address. In multiple recipients, character‘ ;’ must be input between each recipient.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 42 of 93
Insert : Adds a photo, picture, sound, text, subject and attachment to the current page.
In one page, you can insert one image(photo or picture), one sound, one text and one
attachment. If you try to change each object, select this menu and change it another item. An
icon at the top of the screen will indicate the presence of a subject , sound , attachment .
! Note : RTX file which is made in Melody Composer and MFR file which is made in Voice Memo
are not recognized as sound file.
Delete : Deletes an object from the current page. The user will be prompted for which object to
delete. It will list all objects contained on the current page.
Preview : Previews the current MMS message.
Object Properties : Displays a list of objects on the current page and allows each object to get a
property. After selecting an object, the user will be presented with the following property
options for the given object.
Displayed After : The time at which the object is played relative to the start of the current
page.
Displayed For : The length of time for which the object is displayed. Maximum implies the
object is played until the end of the current page.
Page : Manipulates page in the MMS message. The following options are available.
Add Page : Adds an additional page after the current page and makes it the active page.
Delete Page : Deletes the current page. It is available only if there is at least one other page.
Previous Page : Moves to the previous page. It is available only if there is a page before the
current page.
Next Page : Moves to the next page. It is available only if there is a page after the current
page.
Page Properties : Allows current page to get a property.
Page Layout : Selects the image and text position. When Image At Top is selected,
image is displayed on the top position and text is on bottom position. When Text At
Top is selected, text is displayed on top position.
Displayed For : Selects a displaying period of current page.
<Drafts>
With this menu, you can view a list of any draft messages that have been created in the Create
Message and saved, but are not ready to be sent.
Recipient phone numbers or names (if stored in the Phonebook) are displayed on the list.
If you press [Option soft key], the options are available the same as Inbox.
<Sent>
With this menu, you can view a list of MMS messages that have been sent.
Recipient phone numbers or names (if stored in the Phonebook) are displayed on the list.
If you press [Option soft key], the options are available the same as Inbox.
<MMS Settings>
The following options are available.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 43 of 93
Save On Sent : Configures whether to save a copy of all sent messages in the “ Sent” folder.
Delivery Report : Configures whether network sends the delivery report message to your phone
or not. The delivery report message means that the sent MMS message has arrived to the
recipient properly.
MMS Profile : Configures which MMS profile is used to connect over when sending or receiving
MMS message. MMS Profile is composed of Message Center and Connection Profile.
These information can be obtained from your home network service provider.
If you want to add or edit Connection Profile, go to the Connection Profile menu of Phone
Setting menu.
MMS Lifetime : Allows you to set the length of time period that your MMS message will be
stored at the Message Service Center in the network whilst attempts are made to deliver them
to the recipient. Available options are 1 Hour, 6 Hours, 12 Hours, 1 Day, 3 Days, 1 Week and
Maximum.
MMS Download : Configures whether new MMS messages are downloaded as soon as they are
available or only when the user has confirmed they wish to receive them.
Automatic : Downloads new messages immediately and notify the user when they are fully
downloaded.
On Read : Notifys the user when a new message is available. And allows the user to
decide whether to download the message or not.
Spam Filter : Spam emails are defined as MMS messages where the message class is set to
“ Advertisement” .
Off : All MMS messages are accepted.
Defer Download : Spam messages are not downloaded automatically.
Reject Spam : The Spam messages are rejected with no user notification.
9.1.3 E-mail
You can use your phone to send and receive E-mail.
! Note : Before using E-mail, please set up your E-mail Accounts and Connection Profile in E-
mail Setting menu. Connection Profile information can be obtained from your home network
service provider.
! Note : The Email service may not be available on all networks. For more details, please
contact your network service provider.
<Inbox>
With this menu, you can view all E-mail messages that have been received from each of your
E-mail Accounts.
At First you enter this menu, you can see your E-mail Accounts list if you had set your
accounts in E-mail Setting menu.
If you press [Option soft key], the following options are available.
Open : Opens current selected E-mail Account.
Connect to Server : Receives new E-mail message from current selected E-mail Account.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 44 of 93
Create Message : Creates new E-mail message using current selected E-mail Account.
View Detail : Enables you to see the details of current E-mail Account.
If you select Open option on the selected E-mail account list, you can see your E-mail message
list from the E-mail Account.
The small icon on the far left side of each list indicates following meanings.
: The message is the new unread E-mail message.
: The message is the read E-mail message.
If you press [Option soft key]on the E-mail message of list, following options are available.
Open : Views current selected E-mail message.
Delete : Deletes current selected E-mail message.
Reply : Sends reply E-mail message to sender of current selected E-mail message.
Forward : Forwards current selected E-mail message to another persons.
Save Attachment : Saves attachment of current selected E-mail message. Maximum size of
attachment is 45 Kbyes.
View Detail : Enables you to see the details of current selected E-mail.
Default Encoding
: enables you to select character encoding type.
If you select Open option on the selected E-mail message, you can see the message contents
with a sender E-mail address and its arrival time.
If you press [Option soft key] on the message contents, same options like above are also
available.
<Outbox>
With this menu, you can view the saved E-mail message that has been unsent.
Subject of each E-mail message are displayed on the list.
If you press [Option soft key]on the selected E-mail message, Delete, Send, Edit and View
Detail options are available.
With Send option, you can send the saved E-mail message unchanged as it is.
<Create Message>
With this menu, you can write an E-mail message, and then you can save and send it.
Input the E-mail message contents and subject and then press [Ok soft key]. After that, enter
the recipient E-mail address. You can input the E-mail address directly from the Phonebook by
pressing the [P.book soft key].
If you press [Ok soft key] after completing the recipient E-mail address, following options are
available.
Send : Sends the E-mail message to the recipient E-mail address. The E-mail will not be
saved.
Save : Saves the E-mail message and the recipient E-mail address.
Save and Send
:
Saves the E-mail message and the recipient E-mail address, and then
sends.
<Drafts>
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 45 of 93
With this menu, you can view a list of any draft E-mail messages that have been created in the
Create Message and saved, but have no subject or no recipient.
Subject or front side of each E-mail message is displayed on the list.
If you press [Option soft key], Delete, Send , Edit and View Detail options are available.
<Sent>
With this menu, you can view a list of E-mail messages that have been sent.
Subjects are displayed on the list.
If you press [Option soft key], Delete, Send, Edit and View Detail options are available.
With Send option, you can send the saved E-mail message unchanged as it is.
! Note : The attachment size of sending E-mail message cannot exceed 45 Kbytes and the
maximum size of sending E-mail message is 100 Kbytes.
<E-mail Setting>
The following options are available.
Connection Profile
With this menu, you can configure which Connection Profile is used to connect over when
sending or receiving E-mail message.
The information can be obtained from your home network service provider.
If you want to add or edit Connection Profile, go to the Connection Profile menu of Phone
Setting menu.
E-mail Accounts
With this menu, you can view E-mail Accounts list and add new E-mail Account. The following
options are available.
Set Default : Sets the selected E-mail Account as default account to use sending a E-mail
message.
Edit
:
Edits the selected E-mail Account. With this option, you can set up Incoming Server,
Outgoing Server ,My E-mail Address and My Name.
You can select Incoming Server Server type between POP3 and IMAP.
The Username and Password are generally the login information related to the
Incoming Server, but those may be also necessary for the Outgoing Server depending
on network service provider.
Outgoing Server information can be obtained from your home network service
provider. If you want to use your own Outgoing Server, you have to check that your
E-mail account can support POP3(or IMAP) and SMTP.
My E-mail Address is used for the default E-mail address to send E-mail message.
To send E-mail message, you must set your E-mail address in this menu.
My Name is used to insert your name in sending E-mail message.(Optional)
Rename : Renames the selected E-mail Account name.
Delete : Deletes the selected E-mail Account.
Send Option
This menu allows you to set the send option when sending your new E-mail message. Available
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 46 of 93
options are Next Connection, Immediately and None.
Size Limit
You can set size Limit of receiving E-mail message. Maximum size of receiving E-mail message
is 99 Kbytes.
DNS Address
You can set DNS for connection. This DNS is used when Network doesn’ t offer DNS
automatically. If you have select Manual in Get DNS Address menu, Primary DNS and
Secondary DNS are applied.
Status
You can identify the memory use of E-mail messages in your phone memory.
9.1.4 Voicemail
Your phone is capable of dealing with voicemail if this service is supported on the network. If
the voicemail has arrived, your phone displays New Voicemail in the idle screen and sets to
inform you of the arrival.
By selecting the Connect Voicemail, you can then listen to the voicemail.
Your phone automatically dials to the configured number that has stored in Number Setup menu.
! Note : The voicemail service may not be available on all networks. For more details, please
contact your network service provider.
By pressing and holding down [ 1 ] in the idle screen, you can directly listen to the Voicemail.
< Connect Voicemail>
With this menu, you can listen to the voicemails you have received.
<Number Setup>
With this menu, voice mailbox numbers can be stored.
- Home Mailbox
The voicemail number is to dial when you are on the home network to listen to the voicemail.
- Roam Mailbox
The voicemail number is to dial when you are on the other network to listen to the voicemail.
9.1.5 Broadcast
This network service allows you to receive the broadcasted text messages on various topics
such as weather, traffic, local district code, local hospitals, taxis or pharmacy in the area where
you are. You can even receive the message to be in a particular language. (For example, when
you are abroad) by using Language List option. For more information about topics, please
contact your service provider.
! Note : This service may not be available on all networks.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 47 of 93
<Read All Messages>
With this menu, you can read all the broadcasted text messages and save the messages
you desire by pressing the [Save soft key].
In title area of the screen, the name of the message subject item is displayed.
The contents of the message subject are updated whenever new contents are received.
If the message subject is not sent from the area you are, No Message is displayed.
You can read the message through by pressing [NAVI-DOWN].
To move to next message subject item, press [NAVI-RIGHT].
<Receive Setting>
This menu allows you to enable or disable the reception of the broadcasted text messages.
All : Enables to receive all broadcasted text messages regardless of the setting of
Subject List and Language List.
Active List : Enables to receive all broadcasted text messages depending on the setting of
Subject List and Language List.
Disable : Disables to receive the broadcasted text messages.
<Display On Idle>
This menu allows you to enable or disable to view new broadcasted text messages
in the idle screen.
On : New broadcasted text messages are displayed in the idle screen.
Off : New broadcasted text messages are not displayed in the idle screen.
<Subject List>
This menu allows you to select the subject items of the broadcasted text message.
Each item is identified by three digits index. Following table shows the default subject items
your phone has. If the default subject items list does not have the item you want or if the index
or name of a default subject item is different from that of the network service provider, you can
add or edit in User Define List menu.
Index Subject Name
000
010
020
022
024
030
032
034
040
050
052
054
056
057
Index
Flashes
Hospitals
Doctors
Pharmacy
Far Traffic
Local Traffic
Taxis
Weather
District
Network Info.
Operator
National Help
Intl. Help
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 48 of 93
058
059
National Care
Intl. Care
!Note : For more information about the available subjects, please contact your network service
provider.
- Active List
All items list you selected are displayed. You can add and delete the list by using Add and
Delete option. The number of items in the list depends on your SIM card.
- User Define List
You can add, edit and delete the subject item you want. You can define up to five items. After
that, you need to add the defined subject in the Active List in order to enable the subject.
<Language List>
You can select your preferred languages of the broadcasted message by using Insert and Delete
options.
The number of languages you can select depends on your SIM card.
<Saved Messages>
You can read saved messages and send these messages by using SMS. If you press [Option soft
key], the following options will be available. (It may differ according to situation)
- Open : enables you to view selected message.
- Delete : enables you to delete selected message.
- Delete All : enables you to delete all saved message.
- Send : enables you to send selected message by using SMS.
9.2 Call Records
Within this menu, you can identify all call records that you have dialled, received or missed.
9.2.1 Dialled Calls
This menu lets you view the last 20 dialled calls.
In the dialled calls list, you can view the details of the record by pressing the [Option soft key]
then selecting View option. In the view screen you can make a call to the number by pressing
[SEND], or can paste the number to the idle screen by pressing [Paste soft key] and then can
save the record to the phonebook by pressing the [Save soft key].
You can delete a record in a view screen by pressing [Delete soft key].
9.2.2 Received Calls
This menu lets you view the last 20 received calls.
In the received calls list, you can view the details of the record by pressing the [Option soft
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 49 of 93
key] then selecting View option. In the view screen you can make a call to the number by
pressing [SEND], or can paste the number to the idle screen by pressing [Paste soft key] and
then can save the record to the phonebook by the pressing the [Save soft key].
You can delete a record in a view screen by pressing [Delete soft key].
9.2.3 Missed Calls
This menu lets you view the last 20 missed calls.
In the missed calls list, you can view the details of the record by pressing the [Option soft key]
then selecting View option. In the view screen you can make a call to the number by pressing
[SEND], or can paste the number to the idle screen by pressing [Paste soft key] and then can
save the record to the phonebook by pressing the [Save soft key].
You can delete a record in a view screen by pressing [Delete soft key].
9.2.4 Delete Records
This menu lets you delete the record of the recent calls. Following options are available.
All Calls : deletes the record of all recent calls.
Dialled : deletes the record of the dialled calls.
Received : deletes the record of the received calls.
Missed : deletes the record of the missed calls.
9.2.5 Cost & Duration
You can view the cost and duration of the last call, or all calls. Costs are shown only if your
network operator supports this service.
The following options are available.
Last Call : allows you to check or reset the cost and the duration of the last call.
All Calls : allows you to check or reset the cost and the duration of all calls.
If you press the [Reset soft key], you may have to enter your PIN2 according
to SIM card contents.
Maximum Cost : allows you to check or change the maximum limit for the cost of calls.
If you press the [Change soft key], you must enter your PIN2. The value that
multiplied the entry by the value set at Price & Unit option is displayed.
Price & Unit : allows you to set the cost of one unit and currency code. This price per unit
is applied when calculating the cost of calls. If you press the [Change soft key],
you must enter your PIN2.
! Note: Not all SIM cards support this feature. The number of items in these lists depends on
the contents of your SIM card.
9.2.6 Data Counter
You can view the size of the sent data, the received data and total data transferred in the Last
Data session or All Data sessions.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 50 of 93
The following options are available.
Last Data : allows you to check or reset the data size used in the last session.
All Data : allows you to check or reset the data size used in the all sessions.
9.3 Phone Setting
9.3.1 Own Numbers
This menu displays your phone numbers. You can view, add, edit, and delete the numbers,
stored in your SIM card.
9.3.2 Language
You can select in which language the display text is shown.
If you select Automatic, the display text is automatically displayed according to the country of
your SIM card.
This setting also determines which text input mode is selected when you write a text message.
For details, please see section 7.
9.3.3 Sound Setting
With this menu, you can customize various audible settings.
! Note : To switch on the silence mode, press and hold [VOLUME-UP] on the left side of phone
in the idle screen. To switch off the mode, press and hold down [VOLUME-UP] again.
If your phone is in the silence mode, all audile key tones and melodies are prohibited and all
alerts are changed to the vibrator regardless of the setting in this menu.
<Profiles>
This menu allows you to activate and change the settings of the selected profile according to
your wish.
The audio profile menu allows you to access a group of pre-defined settings. A profile is a
group of audio settings that are set to suit a wide variety of events and environments (e.g.
meetings, movies, etc). There are seven types of profiles; Normal, Meeting, Outdoor, Car, Silent
VIP and Headset profiles.
The table below shows the default settings of each profile.
Normal Meeting Outdoor Car Silent VIP Headset
Ring Type Melody Vibrator Melody +
Vibrator Melody Light Melody +
Vibrator Melody
Ring
Volume Level 7 Level 0 Level 7 Level 7 Level 0 Level 7 Level 4
SMS Alert Melody Vibrator Melody Melody Off Melody Melody
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 51 of 93
Type
SMS Alert
Volume Level 5 Level 0 Level 7 Level 7 Level 0 Level 7 Level 3
Key Tone
Volume Level 5 Level 0 Level 7 Level 5 Level 0 Level 5 Level 3
Speaker
Volume Level 6 Level 5 Level 7 Level 7 Level 6 Level 7 Level 6
Game
Volume Level 5 Level 0 Level 7 Level 5 Level 0 Level 5 Level 4
- Ring Type
This menu allows you to select how to be informed of any incoming call.
Following types are available.
Melody : Your phone rings using the ringing melody selected at menu option of Ring Melody
option.
Vibrator : Your phone rings using the vibrator.
Light : Your phone rings using the backlight illuminated on the sub display screen, rather
than the normal ringing tone or vibrator.
Melody + Vibrator : Your phone rings using both melody and vibrator simultaneously.
- Ring Volume
This option allows you to adjust the ringing volume to one of eight levels.
Use [NAVI-UP] and [NAVI-DOWN], and then press [Select soft key].
- SMS Alert Type
This menu allows you to select how to be informed of new incoming SMS message.
Following types are available.
Melody : Your phone alerts using the SMS alert sound selected at menu option of
SMS Melody option.
Vibrator: Your phone alerts using the vibrator.
Off : Your phone does not alert with sound or vibrator.
- SMS Alert Volume
This option allows you to adjust the SMS alert volume to one of eight levels.
Use [NAVI-UP] and [NAVI-DOWN], and then press [Select soft key].
- Key Tone Volume
This option allows you to adjust the key volume to one of eight levels when you press a key.
Use [NAVI-UP] and [NAVI-DOWN], and then press [Select soft key].
- Speaker Volume
This option allows you to adjust the speaker or earpiece volume to one of eight levels when you
are in active call state.
Use [NAVI-UP] and [NAVI-DOWN], and then press [Select soft key].
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 52 of 93
- Game Volume
This option allows you to adjust the game volume to one of eight levels when you play a game.
Use [NAVI-UP] and [NAVI-DOWN], and then press [Select soft key].
<Key Tone Type>
This option allows you to select the tone that the keypad generates when you press a key on the
idle screen.
Following types are available.
Tone : When a key is pressed, your phone makes a different sound(DTMF Tone) for
different keys.
Beep : When a numeric key is pressed, your phone makes same sound for different keys.
Voice : When a numeric key is pressed, your phone makes voice for each numeric keys.
Waterdrop : When a key is pressed, your phone makes water drop sound.
Off : When a key is pressed, your phone makes no sound.
<Ring Melody>
This menu allows you to select which melody is used for any incoming call.
You can select the melody that you prefer among various melodies.
You can select melody from the following category :
Bell : The list of various sounds.
Melody : The list of classical music.
Music Bell : The list of original sound music.
Voice Record File : The list of files recorded in Voice Memo menu.
Composed Melody : The list of composed melody files downloaded from user or edited in
Melody Composer menu.
Downloaded Audio : The list of audio files downloaded via MMS message, E-mail message
or WAP service.
<Message Melody>
This menu allows you to select how to be informed of any SMS, MMS, Voicemail delivery.
You can select the melody that you prefer among various melodies.
<Rising Volume>
With this menu set to On, the alert volume for incoming call and alarm tones are to be increased
gradually.
<Connect Tone>
With this menu set to On, your phone beeps at connecting to a network when making a call.
! Note : This function may not be possible on all networks.
<Minute Tone>
With this menu set to On, your phone beeps 10 seconds before every one minute during a call to
remind you of how long the call has been in progress.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 53 of 93
9.3.4 Display Setting
<Colour Mode>
You can select your favourite colour mode that makes your phone get different feeling of the
colour.
<Wallpaper>
You can apply image from Sample Image, Photo Album, Image File, MFlash Folder or Video
Folder to main or sub wallpaper.
<LCD Contrast>
This menu allows you to adjust the contrast of the main or sub Display screen.
<Greeting Message>
This menu allows you to edit a greeting message that is briefly displayed when the phone is
switched on.
<Backlight Time>
You can select a backlighting time of the main display screen.
The following options are available.
10 secs : The backlight comes on for 10 seconds.
30 secs : The backlight comes on for 30 seconds.
1 Min: The backlight comes on for 1 minute.
1 Min 30 secs : The backlight comes on for 1 minute 30 seconds.
<Clock Display>
You can select whether digital clock is displayed on idle screen or not.
The following options are available.
On : Enable clock display on main and sub wallpaper
Off : Disable clock display on main and sub wallpaper
<Network Name Display>
You can select whether network name is displayed on idle screen or not.
The following options are available.
On : Enable network name display on main and sub wallpaper.
Off : Disable network name display on main and sub wallpaper.
<EL Light>
You can select whether external light is displayed or not.
The following options are available.
On : Enable the external light.
Off : Disable the external light.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 54 of 93
9.3.5 Clock Setting
<Set Time>
This menu allows you to change the time displayed in the idle screen.
You can use numeric key ([0]~[9]) to change time value and use [NAVI-LEFT] or [NAVI-
RIGHT] to change the setting place. If you have selected 12 Hour time format, you can change
am/pm value by pressing [NAVI-UP] or [NAVI-DOWN].
<Set Date>
This menu allows you to change the date displayed in the idle screen.
You can use numeric key ([0]~[9]) to change date value and use [NAVI-LEFT] or [NAVI-
RIGHT] to change setting place.
<Time Update>
This menu allows you to change time update option. If you select automatic, the time in your
phone is set by network.
! Note 1. This option only takes effect using GPRS SIM card.
2. For the automatic update setting to take effect, the phone needs to be restarted.
3. If you have changed time/date in Set Time or Set Date menu, automatic update will
be disabled.
<Time Format>
This menu allows you to change time format between 12 Hour and 24 Hour.
<World Time>
This menu allows you to identify what time it is in various cities around the world.
You can easily set your local time in another country by pressing [Set Local soft key].
9.3.6 Call Setting
<Caller Number>
This menu prevents your phone number from being displayed on the phone of the person being
called.
The following options are available.
Default : The default setting provided by the network is used.
Hide Number : Your phone number is not displayed on the called person's phone.
!Note : In some network, when you make a call with hiding the telephone number, the network
does not allow to make the call.
Send Number : Your phone number is displayed on the called person’s phone each time you
make a call.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 55 of 93
<Any Key Answer>
With this menu, you can answer an incoming call by pressing any key except the [End soft key]
or [END].
On: You can press any key except the [End soft key] and the [END] to answer an incoming
call.
Off: You can only press the [Answer soft key] and the [SEND] to answer an incoming call.
<Folder Answer>
With this menu, you can answer an incoming call with just [SEND] regardless of the folder
opening.
On: You can answer the incoming call by the folder opening.
Off: You can answer the incoming call by only [SEND] regardless of the folder opening.
<Auto Redial>
With this menu, your phone makes up to five attempts to redial a phone number after an
unsuccessful call.
The following options are available.
On: The number entered is redialled automatically.
Off: The number entered is not redialled.
! Note: The number of retrial may be variable according to the cause of the unsuccessful call.
If you press any key or close the folder cover, or if an incoming call or SMS is arrived,
the redialling mode is stopped.
9.3.7 Connection Profile
In order to use WAP browser, MMS and E-mail, you should set up the Connection Profile to
connect to the Internet.
You can edit or rename each Connection Profile in list.
In order to edit each profile, please see Connection Profile of Settings menu in Internet menu.
And you can activate profile you want to use to connect to the Internet, but the activated profile
is actually used for WAP connection.
If you want to use different profile for MMS connection and E-mail connection, you can activate
the profile in MMS Settings menu and E-mail Setting menu.
9.3.8 Security Setting
To access this menu, you must first enter the Lock Code.
The feature enables you to protect the use of your phone. Various codes and passwords are
used to protect your phone. They are described in the section 3.
! Note : The Lock Code is factory set to 0 0 0 0.
<PIN Access>
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 56 of 93
With this menu set to Enable, your phone asks to enter the PIN each time the phone is switched
on. If Disable, doesn't ask to enter the PIN.
<SIM Lock>
With this menu set to Enable, your phone asks to enter the SIM Lock Code when a different SIM
card is inserted. If Disable, your phone doesn't ask to enter the SIM Lock Code.
<Phone Lock>
With this menu set to On, your phone will be locked. The display asks you to enter the Lock
Code each time the phone is switched on.
<Album Lock>
With this menu set to On, your Album will be locked. The display asks you to enter the Lock
Code each time you enter the Album.
<Phonebook Lock>
With this menu set to On, your phonebook will be locked. The display asks you to enter the
Lock Code each time you enter the phonebook.
<Change Codes>
You can change all security codes in this menu.
- Lock Code
You can change your current Lock Code to new one in this menu.
- PIN Code
You can change your current PIN to a new one in this menu.
- PIN2 Code
You can change your current PIN2 to a new one in this menu.
- Password
You can change your network password in this menu. You need a password to activate network
call barring. The network password is supplied by your network service provider and is not the
same as the PIN for your SIM card.
<FDN>
To change the setting of this menu, you must first enter the PIN2.
With this menu set to Enable, FDN mode is enabled and you can only make a call with the
numbers that are stored in the FDN list.
You can find, add, edit or delete the FDN numbers list by pressing [Phonebook soft key] in the
idle screen after enabling the FDN mode.
If Disable, FDN mode is disabled and you can make a call in normal way.
<Factory Reset>
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 57 of 93
This menu enables you to restore the default value of the phone setting value.
9.3.9 My Menu Setting
This menu allows you to set the My Menu. My Menu is user’ s collection of favorite menus.
You can use more fast and easily registering menus that use often to My Menu. You can select
shortcuts of maximum 10 favorite menus among 30 shortcuts to check in checkbox. For checking and
canceling use [NAVI-CENTRE].
In the idle screen, if you press [NAVI-UP] the My Menu menu is launched and if you press and
hold [NAVI-UP] the My Menu Setting menu is launched.
[Default setting] [Change setting] [My Menu]
9.4 Camera & Media
9.4.1 Camera
You can take pictures with the phone’s built-in camera, view them on your phone screen and
send them to your friends via a MMS message or via E-mail message.
If there is not enough memory to save a new photo, you need to free some by deleting old
pictures or other files in Image File or File Manager menu.
<Still Shot>
This menu allows you to take pictures and adjust its settings.
You can capture the image on the screen by pressing [NAVI-CENTRE] and decide whether to
save or cancel it.
The picture is automatically or manually named according to setting of Saving Name menu.
If you press [Setup soft key] and move to the icon by pressing [NAVI-LEFT] or [NAVI-
RIGHT], you can adjust the following settings by pressing [NAVI-UP] or [NAVI-DOWN].
: You can choose resolution. Resolution refers to the number of pixels in a picture.
Higher resolution use more memory per picture.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 58 of 93
There are 5 kinds of resolutions : 96x64, 128x160, 320x240,640x480.
: You can change the zoom.
: You can change the brightness.
: You can have effect on picture colour.
There are 7 kinds of effects.
: You can select single shot or multi shot.
There are 2 kinds of multi shot. : 3, 6.
If you select multi shot, you can take pictures continuously up to 6 images by pressing
[NAVI-CENTRE] one time.
! Note : When Resolution is 640x480, Multi shot is limited to 3.
When the folder is closed
In the idle mode, launches the Still Shot menu if you press [VOL-DOWN] and hold while the
folder is closed. You can take pictures by yourself, use the sub display screen on the front of
the phone.
When your image is centered in the sub display screen, take a picture by pressing [VOL-UP].
If you want to exit this menu, press [VOL-DOWN] and hold.
<Frame Shot>
This menu allows you to compound the picture and the background image.
You can capture a compounded image by pressing [NAVI-CENTRE] and decide whether to save
or cancel it.
If you press [Setup soft key] and move to the icon by pressing [NAVI-LEFT] or [NAVI-
RIGHT], you can adjust the following settings by pressing [NAVI-UP] or [NAVI-DOWN].
: You can change the zoom.
: You can change the brightness.
: You can have effect on picture colour.
There are 7 kinds of effects.
: You can change the background image.
There are 10 kinds of background image.
! Note : Resolution is fixed on 128x128.
<Camera Setting>
This menu allows you to adjust additional functions.
Self Timer : Enables you to take a picture with 5 seconds delay.
Shutter Sound : Enables you to select the shutter sound.
Saving Name : Enables you to select whether a picture is named automatically or manually.
Album Type : Enables you to select between Thumbnail and List in Photo Album menu.
If you select Thumbnail, Pictures are shown through small thumbnail
pictures.
If you sele ct List, Pictures are listed by the names of pictures.
Shot menu. Set Default : Enables you to reset the settings changed in Still Shot or Frame
<Photo Album>
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 59 of 93
This menu allows you to view, organize, delete and send pictures stored in your phone.
or to a picture to view on the list of small thumbnail pictures by pressing
2.
-LEFT] or [NAVI-RIGHT] take you to the
you select [Options soft key], following options are available.
Viewing pictures
1.Move menu curs
[NAVI-UP] or [NAVI-DOWN] or [NAVI-LEFT] or [NAVI-RIGHT].
Press [NAVI-CENTRE] to launch main viewer.
3. When you are viewing a picture, pressing [NAVI
next or previous picture.
If
Info : allows you to view the name of a picture, size, date and time.
View : allows you to view selected picture.
Set Wallpaper : allows you to set to wallpaper.
Photo Decoration : allows you to compound the picture and the background image or the
stamp image. First press [Setup soft key] and move through the setting
icons by pressing [NAVI-LEFT] or [NAVI-RIGHT], you can adjust the
following settings by pressing [NAVI-UP] or [NAVI-DOWN].
: You can choose the background image.
: You can choose the stamp icon image.
: You can change the distance of stamp icon moving.
: Yo P] or [NAVI-DOWN] or u can move the stamp icon image by pressing [NAVI-U
[NAVI-LEFT] or [NAVI-RIGHT].
: You can save the decorated photo as jpeg file by pressing [NAVI-CENTRE].
!Note
s via E-mail.
: the saved resolution of decorated photo fixed on 128x128.
Send As E-mail : allows you to send selected picture to your friend
Send As MMS : allows you to send selected picture to your friends via MMS.
Cut : allows you to move selected picture to another folder.
Delete : allows you to delete selected picture.
Rename : allows you to change the name of selected picture.
.4.2 Camcorder 9
You can record moving pictures with the phone’s built-in camera, view them on your phone
Shooting>
screen and send them to your friends in a Multimedia message or via E-mail.
<
This menu allows you to record moving pictures and adjust its settings.
pped and you can
ve to the icon by pressing [NAVI-LEFT] or [NAVI-
You can start recording a moving picture by pressing [NAVI-CENTRE].
If you press [NAVI-CENTRE] or Cache memory is filled, recording is sto
decide whether to save or cancel it.
If you press [Setup soft key] and mo
RIGHT], you can adjust the following settings by pressing [NAVI-UP] or [NAVI-DOWN].
: You can change the zoom.
: You can change the brightness.
lour. : You can have effect on picture co
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 60 of 93
There are 7 kinds of effects.
: You can change recording quality.
memory per moving picture.
! Note
<Camc der Setting>
Higher recording quality use more
: Resolution is fixed on 128x104.
or
This menu allows you to adjust additional functions.
moving picture is named automatically Saving Name : Enables you to select whether a
or manually.
Set Default : Enables you to reset the settings changed in Shooting menu.
Moving Picture> <
This menu allows you to view, organize, delete moving pictures stored in your phone.
name of a moving picture to view on the list by pressing [NAVI-UP]
2. RE] to launch main viewer.
you to next or previous moving picture.
you select [Options soft key], following options are available.
Viewing Moving Pictures
1.Move menu cursor to the
or [NAVI-DOWN].
Press [NAVI-CENT
3. Pressing [NAVI-LEFT] or [NAVI-RIGHT] takes
4. Press [NAVI-CENTRE] to play moving picture.
If
Info : allows you to view the name of a picture, size, date and time.
Play : allows you to play selected moving picture.
Send As E-mail : allows you to send selected moving picture to your friends via E-mail.
Send As MMS : allows you to send selected moving picture to your friends via MMS.
Cut : allows you to move selected moving picture to another folder.
Delete : allows you to delete selected moving picture.
Rename : allows you to change the name of selected moving picture.
.4.3 Image File
9
This menu allows you to view, organize, delete and send the image via MMS message, E-mail
.4.4 Audio File
message or WAP service.
9
With this menu, you can play, organize, delete and send audio files via MMS message, E-mail
message or WAP service. Audio files can also be set to Ring Melody.
<Voice Record File>
- Display the list of files recorded in Voice Memo menu.
<Composed Melody>
mposed melody files downloaded from user or edited in Melody - Display the list of co
Composer menu.
<D> ownloaded Audio
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 61 of 93
- Display the list of audio files downloaded via MMS message, E-mail message or WAP service.
.4.5 MFlash Folder
9
This menu allows you to access flash images(VIS).
.4.6 Video Folder
9
This menu allows you to access video images(MSF).
.4.7 File Manager
9
This menu allows you to organize and delete files stored in your phone.
of folders.
sub-folders too.
fter the menu cursor move to the file you want, you can execute default action about the file
If you enter this menu, several folders may be seen. There are two kinds
One is possible to access, and the other that is system folder is inaccessible.
If you select the accessible folder, you can look at file names list of inside and
A
by pressing [NAVI-CENTRE] key, or you can process several work for the relevant file by
pressing [Option soft key].
Following basic options are available.
ion will be available. For example, View in case of image According to the file type, adequate opt
file and Play in case of sound file.
Info : Shows you the information (size, type, etc..) of relevant file.
Cut : Moves this file to other folder. After selecting Cut, move to other folder you want and
then select <Paste Here>.
Delete : Deletes this file.
Rename : Renames this file to other name.
View : Views this file if file type is jpg, gif, bmp, wbmp, png.
9.4.8 Memory Status
This menu allows you to check free space and usage status of file memory space and delete all
der will pop up.
files in each folder. (Except MMS, E-mail, Java and System folder)
If you enter this menu, several folders will be seen.
If you select a folder, a detailed information of the fol
If you want to delete all files the folder, press [Clear soft key].
! Note : Files cannot be selectively deleted. All files in a folder will be deleted at once.
9.5 Organiser
9.5.1 Calendar
With this menu, you can use calendar function and scheduler function.
Further, the lunar date If you enter this menu, the date cursor is on today’ s date.
corresponding to today is also displayed on top-right side.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 62 of 93
If the date on the cursor has schedule list, then adequate icons of the schedule are displayed on
the calendar as follows.
) day decrement or increment.
he scheduler function helps you keep track of reminder, calls, meetings, birthdays, travels or
r the schedule.
bottom-right side.
You can use key on
[NAVI-LEFT] or [NAVI-RIGHT] : One(1
[NAVI-UP] or [NAVI-DOWN] : Seven(7) days decrement or increment.
[*] or [#] : One(1) month decrement or increment.
T
wedding that you need to know. Your phone sounds adequate melody alarm when the set
date/time for the schedule is reached.
You can add up to 100 schedule list.
Six(6) schedule types are available fo
: It indicates Reminder schedule.
: It indicates Meeting schedule.
: It indicates Birthday schedule.
: It indicates Call schedule.
: It indicates Travel schedule.
: It indicates Wedding schedule.
ollowing scheduler options are available.
ew the schedule list of the date.
F
View Today : enables you to vi
View All : enables you to view all schedule lists.
Add Schedule : enables you to add schedule.
View Biorhythm : enables you to view your biorhythm of the date.
Delete All : enables you to delete all schedule lists.
View Status : enables you to view the status of schedule lists.
Go To : enables you to go to specific date on the calendar.
You can select the date you want to go to by using following menus.
Date – move to specific date.
After – move to the day after currently selected date in calendar.
B. efore - move to the day before currently selected date in calendar
.5.2 View Today Report 9
This menu enables you to review current time, date, and information about today schedule.
.5.3 Alarm
9
<Morning Alarm>
you to set the morning alarm This menu enables
- Set Time : sets the time for the alarm.
- Alarm Status : enables you to decide whether the alarm is enable or disable.
- Alarm Tone : selects the alarm tone melody.
- Repeat Status : enables you to decide which day of the week the alarm alerts.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 63 of 93
- Power Up : enables you to decide whether the alarm alerts or not whilst your phone is
powered off.
- Snooze: enables you to set the snooze option. If you set this option, the morning alarm repeats
alerting according to this option.
<General Alarms>
This menu enables you to set the general alarms
- Set Time : sets the time for the alarm.
- Alarm Status : enables you to decide whether the alarm is enable or disable.
- Alarm Tone : selects the alarm tone melody.
- Enter Message : enters message for the alarm.
- Repeat Status : enables you to decide whether the alarm alerts every day or not.
9.5.4 Memo
If you press [Option soft key], the following options can be available. (It is different according
to situation)
This menu enables you to write memo.
memo. - Open : enables you to view selected
- Delete : enables you to delete selected memo
- Edit : enables you to edit selected memo.
- Add : enables you to add new memo.
- Mark : enables you to mark selected memo as done.
- Unmark : enables you to unmark selected memo as not done.
- Default Encoding
: enables you to select character encoding type.
Note!: Memo is saved in “ a:/APP/USER” directory in mobile local file system .
.5.5 Template
9
This function allows you to make template, and later you can send message with this.
you press [New soft key], you can create new template.
If
If you press [Option soft key], the following options will be available.
- Create Message : enables you to make message with selected item.
- Edit : enables you to edit the template
- Delete : enables you to delete the template.
9.6 Network Service
These features are network services.
ovider to check their availability and subscribe to the Please contact your network service pr
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 64 of 93
feature if you wish.
9.6.1 Call Divert
This network service enables incoming calls to be rerouted to another number you specify.
liday.
uld be forwarded to.
For example, you may wish to divert your business calls to a colleague whilst you are on ho
Call diverting can be set up in the following ways.
You must enter a number that the incoming call sho
- Always : All incoming calls are diverted.
- When Not Answered: Incoming call is diverted if you do not answer the call.
You can change the unanswered delay time.
! Note: A network may impose a constant time for the unanswered delay time.
- When Busy : Incoming call is diverted if you are already in another call.
- When Not Found : Incoming call is diverted if you are not in an area connectable.
- Cancel All : All call divert settings are deactivated. Calls can be normal.
Additionally, you can specify individual diverting options for each of the following services.
Speech
Data Sync
Fax
ollowing options for each service are available:
selected.
F
Activate : activates the call diverting service
Cancel : cancels the call diverting service selected
Status : displays the current status of the call diverting service selected.
Note: After the action of the call diverting service selected is sent to the network, the network
.6.2 Call Barring
!
acknowledgement is displayed.
9
This network service allows you to restrict your calls.
e following types of call. You can request your network service provider to bar th
To use Activate and Cancel options, you must enter your network Password.
Please contact service provider for the Password.
- In Calls : All incoming calls are barred.
- In Calls If Abroad : All Incoming calls are barred when abroad.
- Out Calls : All outgoing calls cannot be made.
- Foreign Out Calls : Any outgoing international calls cannot be made.
- Foreign exc.to Home : When abroad, outgoing call can be made only to numbers within the
current country and to your home country that is the country where your home
- Cancel All: Al tivated. Calls can be made and received normally.
network provider is located.
l call barring settings are deac
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 65 of 93
Additionally, you can specify individual barring options for each of the following services:
Speech
Data Sync
Fax
ollowing options for each service are available.
lected.
F
Activate: activates the call barring service se
Cancel : cancels the call barring service selected.
Status : displays the current status of the call barring service selected.
Note: After the action of the call barring service selected is sent to the network, the network
.6.3 Call Waiting
!
acknowledgement is displayed.
9
This network service enables you to know when there is a second call waiting whilst you are in
g service.
a call, if network service provider supports this feature.
The following options are available.
Activate: activates the call waitin
Cancel : cancels the call waiting service.
Status : displays the current status of the call waiting service.
.6.4 Caller Identity
9
This feature lets you view the following line identification settings status of the network.
our - Show Caller Name : The caller's name information(even if the name has not saved in y
Phonebook) is displayed on your phone when you receive a call.
Your name information is displayed on the called person’s phone when you make a
call.
trict. Caller ID : The caller's phone number is not displayed on your phone when you - Res
receive a call.
- Restrict ur phone number does not appear on the called person on your phone . Your ID : Yo
when you make a call.
. Caller ID : The caller- Present 's phone number is displayed on your phone when you receive
a call.
. Your I- Present D : Your phone number is displayed on the called person's phone when you
make a call.
.6.5 Closed User Group
9
This network service allows the restriction of calls to and from a selected user group.
mployee and
You may be a member of up to 10 user groups. For details on creating a user group and
activating and using this service, please contact your network service provider.
This function can, for example, be used when a company lends SIM cards to its e
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 66 of 93
wants to restrict the outgoing calls to members of a working team.
<CUG select>
You can select CUG you want.
d from User Define CUG menu, the CUG group will be used. If you select a CUG group define
Default : This menu of CUG allows you to use the closed user group with network service
provider agreed.
This menu of CUGNot CUG : does not allow you to use this feature.
User Define CUG> <
The list of current CUG you defined appears. You can add, edit, delete or delete all CUG list.
The list will be listed up into the CUG Select menu list.
9.6.6 Network Selection
The Network Selection feature enables you to select whether the network registered on roaming
Selection>
(outside your home network area) is searched automatically or manually, and enables you to set
up a preferred network list to be used when selecting a network automatically.
<
If you select Automatic, your phone will be connected to the first available network in the order
of your home network and then your preferred network list that are available on roaming.
If you select Manual, your phone will scan for the available network and display all available
networks list in your area.
The small icon on the far right side of the each list indicates following meanings.
: The network is an available network to connect to.
: The network is not an available network to connect to.
You c
isplays the screen
Note: If you select the unavailable network manually, your phone cannot get the network
an select the network you wish to connect to from this networks list.
If your phone loses the network signal of the selected network operator, it d
of the manual selection.
!
service. You have to change the network selection mode to Automatic or select the
available network manually.
Preferred List> <
This menu allows you to list your preferred networks to be used when roaming. This function is
available when the network selection mode is Automatic.
Your phone connects to the networks in order of appearance in this networks list, if the
st by pressing [Option soft key]. When adding the
networks are available in your area.
You can add or delete the networks li
networks list, first select the region of the country which the network is in by using the
navigation key. Then select the submenu once more and add the network operator you w
preferred list.
ish to
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 67 of 93
9.7 Game & Utility
9.7.1 Games
When you select this menu, you can see embedded games and downloaded games.
You can change the game volume in Game Volume menu on the Edit Profile menu.
You can also change the game volume whilst enjoying the game, by pressing [*] or [VOL-
he embedded games are as follows.
Savanah Adventure>
DOWN] to decrease the volume, [#] or [VOL-UP] to increase the volume.
T
<
Rules of the game
an enemy he looses energy. The longer he is in physical contact with the
e enemy from above, the enemy dies (except Piranha
laying the game
rts you see this screen.
When Fillip touches
enemy, the more energy he looses. If he runs out of energy, he looses a life. Fillip has three
lives, and if all are lost the game ends.
However, if Fillip jumps and then hits th
fish, which Fillip cannot kill).
P
When the game sta
The top line displays your current score, your health (measured in %), the number of airplane
rogress to the right. Fillip does not loose energy from falling
ontrols
onfiguration is as follows:
Fillip to the left.
.
n you save your score.
parts you have collected so far and the total number of airplane items you must collect before
you can proceed to the next level.
All levels begin at the far left and p
from great heights.
C
The key c
[NAVI-UP] or [2] : moves
[NAVI-DOWN] or [8] : moves Fillip to the right
[NAVI-RIGHT] or [6] : makes Fillip jump.
[NAVI-CENTRE] or [5] : selects a letter whe
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 68 of 93
nemies and objects
ribes the enemies and objects you will encounter when playing:
collect all airplane parts on a level before he can continue to the next level. That is,
ote that there is a time
annot
Airplane parts: Engine, propeller and wing.
E
The following list desc
-Objects
Fillip must
collect 3 parts on level 1, 2 parts on level 2 and 3 parts on level 3.
Collect as many coins as you can in order to maximize your score. N
bonus for each level, i.e. the faster you complete a level, the bigger bonus you get.
Collect eggs to score extra points and gain health points. Note that Fillip’ s health c
exceed 100%.
Airplane parts: Glass and exhaust pipe.
Airplane parts: Chassis and wheel.
Coin: Collect these to score more points.
Egg: Collect these to get health points.
-Enemies
s Fillip encounters in the jungle are unfriendly to say the least. The longer
el
and lands on top of an animal, it
Enemy: Spider.
The animal
Fillip is in physical contact with an enemy, the more energy he looses. If his energy lev
reaches 0%, Fillip dies. If he dies 3 times, the game is over.
Fortunately, Fillip is not completely defenseless. If he jumps
dies.
Enemy: Snake.
Enemy: Mosquito.
Enemy: Piranha fish.
inishing the game
lect all airplane parts on all levels you can watch an end-sequence with
f
quare, the letter
When
F
If you manage to col
Fillip taking off in his plane. The sequence can be interrupted at any time by pressing a key. I
you have scored enough points to enter the high score list you will be prompted for your name.
To search for a letter, use [NAVI-UP] or [2] for the left direction and [NAVI-DOWN] or [8]
for the right direction. A letter focused appears in the flashing square.
If you press [NAVI-CENTRE] or [5] to select the letter in the flashing s
appears on the dotted line. You can delete one or more letters by selecting the ◀ symbol.
you are done, finish by selecting the V symbol.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 69 of 93
<Space Fighters>
Rules of the game
Equipped with guns and missiles your objective is to kill as many enemies as possible, whilst at
the same time avoiding being hit. If you do get hit you will loose one life. Initially you start with
3 lives but if you last long enough you will eventually be rewarded with additional lives and
more powerful weapons.
Playing the game
When the game starts you see this screen.
The top line displays your current score, and the bottom line displays the number of lives you
have left.
If you manage to stay alive long enough you will be rewarded with extra lives and power-ups.
The power-ups increase the number of missiles you fire.
Controls
[NAVI-LEFT] or [4] : moves the fighter craft to the left.
[NAVI-RIGHT] or [6] : moves the fighter craft to the right.
[NAVI-UP] or [2] : moves the fighter craft to the up.
[NAVI-DOWN] or [8] : moves the fighter craft to the down.
[SOFT1] or [1] : f
ire guns.
[SOFT2] or [3] : f
ire missiles.
Enemies
The enemies you encounter will fly in formation and try to hit you using their homing missiles.
The farther you venture into the game, the more aggressive enemies.
Finishing the game
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 70 of 93
The game has 3 different levels and each level is divided into stages.
The farther you venture into the game the more resistance you will encounter.
Every level you finish, you can see “ Level Completed” .
<Trapped>
Rules of the game
In this game you play the part of Sprintus Maximus, a Roman Legionary famed for his athletic
ability. You must guide Sprintus as he makes his way through 20 treacherous mazes, avoiding
the ‘ Marbles of the gods’ – huge rolling boulders that will mercilessly follow you through the
mazes, trying to trap you at every junction.
Jealous of Sprintus’ athletic prowess, the gods have cast the stars that make up the 12 zodiac
constellations out of the heavens and scattered them through the mazes.
Playing the game
When you start the game, select “ Start” by pressing [NAVI-CENTRE] or [5]
The game has two playing modes, ‘ Arcade’ and ‘ Puzzle’ .
You have to be very quick in ‘ Arcade’ as the boulders won’ t wait for you to start moving
before they start hunting you down. Puzzle mode is much more of a strategy based game, you
have to plan your path through the maze junction by junction, making sure you know where the
boulders are going to be at every turn.
To complete a maze, you must find the exit, which will be steps down to the next level.
In the game the bottom line displays the time left, the level, and the score you got.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 71 of 93
Keep an eye on your time, if it runs too low you won’ t be able to continue to the next level.
When you complete a level, if you think you can do it faster, select retry as your time is carried
forward to the next level and remaining time is awarded as a bonus
You don’ t have to collect all the stars, but if you miss just one star, you will loose your chance
to become a god. When you collect all the starts in a level, you restore one zodiac sign.
Controls
The key configuration is as follows:
[NAVI-LEFT] or [4] : makes Sprintus move to the left.
[NAVI-RIGHT] or [6] : makes Sprintus move to the right.
[NAVI-UP] or [2] : makes Sprintus move up
[NAVI-DOWN] or [8] : makes Sprintus move down
[NAVI-CENTRE] or [5] : selects
Finishing the game
If Sprintus make it through all 20 mazes he will escape with his life and return to Rome
unharmed. However, if he manages to collect all 100 stars, he will be awarded the greatest prize
available to mortal men, to join the gods as an equal on Mt. Olympus.
9.7.2 Java
When you enter this menu, you will see a list of Midlets ( Java Application running on the mobile
phone) installed on the mobile phone. If you want to install a Midlet, you can download one by
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 72 of 93
using WAP browser.
If you have more than one Midlet installed in your mobile phone, and when you press [Option
soft key], you will see the following menu.
- Launch : enables you to start the selected Midlet.
- About : shows you the detail information of the selected Midlet.
- Delete : enables you to delete the selected Midlet.
- Download : start a WAP browswer and opens a WAP page which is defined by the user in
Download Setting menu, or current Home.
- Download Setting : enables you to define a WAP page to open, when you press Download.
If there is no Midlet installed, you will see List Empty message, only two options ( Download,
Download Setting ) will be shown.
9.7.3 Biorhythm
When you enter this menu, Set Birthday will be prompted if you have not input before.
Three sine waves about your birthday are displayed on the biorhythm screen.
The blue colour of wave indicates your physical rhythm this month.
The red colour of wave indicates your emotional rhythm this month.
The green colour of wave indicates your intellectual rhythm this month.
The vertical line indicates today.
If you enter the birthday of other person by pressing [Birthday soft key], you can see his
biorhythm.
9.7.4 Timer
<Stopwatch>
The stopwatch can check nine(9) lap time and save one record.(One record is composed of
nine(9) lap times) When the stopwatch is not running, you can start or restart and reset the
stopwatch. In running state, you have two choices (stop and save lap time). If you press [Lap
Time soft key], the total time does not stop but present lap time stop and new lap time
immediately starts. Also you can save present record or load previous record. Whether the
stopwatch is running or not, you can directly check lap time by pressing numeric key ([0]~[9]).
In screen first big number is total time, and small two lines show you lap time with lap time
order.
[Key Function Table]
[Start soft key] starts or restarts the stopwatch
[Stop soft key] stops the stopwatch
[Reset soft key] resets and delete present record
[Lap Time soft key] saves the lap time or reset the stopwatch (when pressed and held)
[NAVI-LEFT] checks saved lap times backward (previous lap time)
[NAVI-RIGHT] checks saved lap times forward (next lap time)
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 73 of 93
[NAVI-UP] saves present record in not running state
[NAVI-DOWN] loads saved record in not running state
[0]~[9] directs check saved lap time directly
[END] ends the stopwatch and then turns back to the previous menu
! Note: The stopwatch is not turned off when you answer an incoming call or the phone is
sounding an alarm. But if you don’t save record and press [END], record will be lost.
<Countdown>
You can check countdown timer by using this menu.
Enter : enables you to enter countdown main screen. You can set time and start the timer.
Countdown Tone : enables you to select countdown expiry tone.
Auto Repeat : enables you to decide whether the countdown timer restarts automatically or not.
! Note: The countdown is not turned off when you answer an incoming call or the phone is
sounding an alarm.
9.7.5 Calculator
Your phone has built-in engineering calculator, which can perform basic arithmetic operation
and scientific function.
Some of its features include:
- Normal and scientific output
(addition, subtraction, division and multiplication)
- Support for all standard mathematical functions
(sin, cos, tan, asin, acos, atan, sinh, cosh, tanh, exp, log, log10 and sqrt)
- More than 15 built-in variables for memories labelled A to Q.
The following icon illustrates key functions.
Press the [Answer soft key] to display the result of an arithmetic operation.
Press the [Clear soft key] once to erase a figure to the left of the cursor.
Use the [*] key to enter the decimal part of a number or special symbols such as ., (, ), ^, e, !,
<, > and =.
Use the [#] key to see helpful information for calculation.
Use the [NAVI-CENTRE] to enter Option menu for function and memory.
9.7.6 Voice Memo
This function allows you to record voice memo and set it as the ring tone.
After recording, you can play recorded voice memo and save to “ *.mfr” file.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 74 of 93
You can launch Option menu by pressing [NAVI-CENTRE].
After the recoded voice memo is saved to a file, you can set as ring tone by selecting Set As…
option.
9.7.7 Melody Composer
This function allows you to compose your own melodies to be used as the ring tone.
Four octaves are available. A maximum of 200 notes can be entered. You can adjust the length
of a note and add a rest, as required.
You can compose melodies.
1. When you access the menu, the musical paper is displayed.
2. Compose your melody using the following keys.
[1] C (Do), the first note in the musical scale
[2] D (Re)
[3] E (Mi)
[4] F (Fa)
[5] G (Sol)
[6] A (La)
[7] B (Si)
[8] C (Do), 3 octave
[9] moves a note up or down one octave
[0] Rest
[*]
decreases the length of a note or a rest
[#]
increases the length of a note or a rest
[NAVI-UP]
moves a note a tone up
(For example, the note A changes to A#, B, C, C#, and so on in
the scale each time you press the [NAVI-UP] key)
[NAVI-DOWN]
moves a note a tone down
(For example, the note C# changes to C, B, A#, A, and so on in
the scale each time you press the [NAVI-DOWN] key)
[NAVI-LEFT] moves the note cursor to the previous note
[NAVI-RIGHT] moves the note cursor to the next note
[Clear soft key] clears the note in the note cursor
[Option soft key]
or [SEND] launches Option menu
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 75 of 93
[NAVI-CENTRE] Listens to currently focused note
[END] turns back to previous menu or screen
If you press [Option soft key], [SEND], the following options are
Available. The options are visible depending on situation.
Play : Listens to your melody
New : Create new melody
Save : Saves your melody to file
Set As : Set the melody to ring melody
Melody Files : Launch the melody file manager
Clear All : Clears all musical paper
3. When you are satisfied with your melody, you can save the melody to a file through Save
menu.
4. In Melody Files menu, you can see the list of melody files. You can hear melody directly
through the [NAVI-CENTRE]. If you press [Option soft key], following options are available.
Edit : Edits selected melody file in musical paper
Play : Listens to selected melody file
Set As… : Sets the selected melody to ring melody
Delete : Deletes selected melody file
Rename : Renames selected melody file
9.7.8 Converter
Converter enables you to convert measures such as
Length
from one unit (
Meters
) to another
(
Miles
). There are several different units of Area, Computer, Length and so on..
The first row ( ) means the unit type you wish to convert.
The second row ( ) means the unit from which you want to convert
The third row ( ) means amount you want to convert
The fourth row ( ) means the unit to which you want to convert
The fifth row ( ) means the result amount. It changes automatically.
If you want to change the type and unit, scroll ([NAVI-UP] or [NAVI-DOWN]) to each field
and press [NAVI-LEFT] or [NAVI-RIGHT].
It is possible everywhere to input the amount.
9.7.9 Lady Schedule
This menu helps you check woman’ s menstrual cycle.
To enter this menu, you must enter your lock code.
9.7.9.1
Lady Calendar
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 76 of 93
Lady Calendar enables you to view woman’ s menstrual cycle.
At first you must add the first day of the menstrual period.
Depending on the situation dates can be added or deleted by pressing [ Option soft key ].
If a date is selected and is the first day of menstrual period, the option is Delete.
If a date is not selected or is not the first day of menstrual period, the option is Add.
It is possible to store up to 6 dates. If you add more, the earliest day will be deleted.
If you add the first day, you can view information on your menstrual cycle.
The information is displayed on the calendar by Image.
: the first day of the menstrual period
: the first day of expected menstrual period
: the expected ovulation days.
9.7.9.2 View My Cycle
This menu enables you to view information on your menstrual cycle. (such as average cycle,
first day of menstrual period)
9.7.9.3 Set My Cycle
You can set a typical menstrual cycle days by pressing [NAVI-UP] or [NAVA-DOWN].
9.7.9.4 Reset My Cycle
This menu enables you to delete data on your menstrual cycle.
9.8 Internet
WAP is a standard specifically created for mobile communications devices and gives fast and
easy access to the Internet information and services. Now you can find a lot of useful
information by using the micro browser in your mobile phone, instead of using your computer.
There are WAP service available that you will be able to access, such as reservation services,
news, sports and weather, games ad banking, etc.
The ways in which you can go to a WAP page are as follows:
- Selecting Home menu.
- Selecting address list in Bookmarks menu
- Entering its address either in the Go to address menu or in the WAP browser
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 77 of 93
Press the navigation key[NAVI-CENTRE] to connect directly to Internet services in the idle
screen.
Browser
In the WAP browser, you can see the connection status icon.
The available icons are as follows.
: Appears when the data call is currently being connected.
: Appears when your phone is registered to a GPRS network.
: Appears when there is an active GPRS connection.
: Appears when connection is in the Secure Mode.
You can highlight the specific hyperlink with a cursor that is indicated as an underline each and
view the content by selecting the highlighted hyperlink. You may choose these items by
pressing the [NAVI-CENTRE], [SEND] and [Select soft key] in the screen.
If you press [Option soft key] on the browser, you can use the following available options.
The options depend on the contents of the WAP site.
Home : connects to the homepage you defined in the profile
Refresh : reloads the current page
Select : follows the highlighted hyperlink
Back : navigates back one page in the history list
Add Bookmark : adds a new list to the bookmarks for the Web page you are viewing
Bookmarks : presents the list and allows you to go to the Web page you want.
Go to Address : allows you to enter a URL to browse to
Show Address : show current URL.
Full Screen : display full screen mode.
Normal Screen : display normal screen mode.
Set As Homepage : current URL is set as default homepage.
Exit : exits the browser at any time, then the idle screen will be displayed.
The following keys are available for use when browsing:
[NAVI-UP] : moves the screen upwards.
[NAVI-DOWN] : moves the screen downwards.
[NAVI-LEFT] : moves the screen to the left (if the horizontal scroll bar is available).
[NAVI-RIGHT] : moves the screen to the right (if the horizontal scroll bar is available).
[NAVI-CENTRE] or [SEND]: selects an item (if it is a selectable item).
[END] : exits the browser.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 78 of 93
Note!: Although the call is not in active state, if you ask the browser to do an action (by
selecting an option menu or by pressing the [Back soft key] ), it automatically makes a call and
tries to reconnect to the WAP site.
9.8.1 Home
Once a connection profile has been set up, you can connect to the home page you defined.
9.8.2 Resume
You can access the WAP site that you accessed before. If you have not accessed any site, your
phone is connected to the home page.
9.8.3 Bookmarks
You can access the list of bookmark sets in this menu.
The following four options are available by pressing [Option soft key].
Add Bookmark : creates a new bookmark name/URL.
Go To : launches the WAP browser and loads the page bookmarked.
Edit : allows you to alter the name/URL of the bookmark.
Delete : deletes the current bookmark.
9.8.4 Push Messages
You can receive push messages sent by your service provider. The push message is a kind of
notification from network, for example, stock news, weather news, headline news or E-mail.
If a push message has arrived, your phone displays New PUSH Message in the idle screen and
sets icon to inform you of the arrival. If you select [View soft key], you can view the
received push messages on the list.
The small icon on the far right side of each list indicates following meanings.
: indicates that you have not accessed Internet site related to the PUSH message of the
list.
: indicates that you have accessed Internet site related to the PUSH message of the list.
If you select [Option soft key], following options are available.
Info : Allows you to view the received push message.
If you press [Select soft key] in the viewer, you can connect to Internet to view more
information.
Load : Allows you to go to the site linked with the received push message.
Delete : Allows you to delete the received push message
Delete All : Allows you to delete all of the received push messages.
9.8.5 Settings
<Connection Profile>
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 79 of 93
A WAP profile consists of a group of network settings. After setting them up, you simply switch
between the different WAP profiles, without having to re-enter the settings every time you want
to change your network connection.
At first, select a profile you want to set up. And then you will be asked if you want to activate,
edit, rename or delete the profile with options.
- Activate
This option activates the chosen setting as a current WAP setting to be used for the WAP
connection.
- Edit
This option edits the WAP setting values to connect to Internet.
! Note : The setting value varies according to the WAP service provider. So please contact your
network service provider for the values before using WAP services.
If you select Edit, the following options are available.
Homepage : Enter the address of the WAP page that you want to use as your home page
for the WAP profile.
Connection Type : Select type of internet connection.
Temporary is a non-confirmed (connectionless) service.
Continuous is a confirmed delivery mechanism but generates more network traffic.
Connection Options : The options are None or Secure and depend on the gateway you are
using.
Bearer : You must select the bearer service provided by your WAP gateway which will be
either GSM Data or GPRS.
You will see different menu items as bearer to which you selected.
1. Data Service Settings include:
The service settings below are only available when GSM Data has been selected as a
bearer service.
IP Address
You must enter the IP address of the WAP gateway you want to use to access WAP pages.
Dial Number
You need to enter the telephone number to dial to access your WAP gateway.
Data Call Type
You need to select the type of data call to make, that is: Analogue or ISDN (digital).
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 80 of 93
Data Call Speed
This is the speed of your data connection and should be provided by your network.
Server Login
This is your user identity (Username and Password) for your dial-up server
Timeout
You need to select one of three timeout periods, after which browser will report a failure
to send a data (for example, because the WAP gateway is not responding)
Note!: You need a subscription that supports data transmission.
2. GPRS Service Settings include:
The service settings below are only available when GPRS has been selected as a bearer
service. GPRS (General Packet Radio Service) allows fast and efficient access where you
can always be online.
Access Point Name
The address of external data network you want to connect to, either an IP address or a text
Sting.
IP Address
You must enter the IP address of the WAP gateway you want to use to access WAP pages.
Server Login
This is your user identity (Username and Password) for your WAP gateway.
Note!: You need a subscription that supports GPRS.
- Rename
This option changes the name of the chosen profile.
<User Preferences>
- Cache Mode
For Always Check, the cache is always checked every time the browser opens a WAP site.
This should be set for normal operation.
For Never Check, the cache is never checked when connecting to the Internet.
- Push Security
This options are used for filtering the received push messages.
Accept All : You can receive all push messages.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 81 of 93
Trusted Only : You can receive only authenticated or trusted push messages.
Accept None : You can not receive any push message.
- Display Images
This allows you to select whether images on WAP cards are displayed or not.
<Security Certificate>
This lists the trusted root certificates that are stored on the handset for secure-mode
connections. Security certificate are used by some WAP services for security purpose, for
example, server certificates, banking services or other authority certificates. You can download
the certificate from a WAP page if the WAP service supports the use of authority certificates.
After the download, you can save or delete it. If you save the certificate, it is added to the
security certificate list on the phone.
! Note : If you delete the security certificate on the phone, you cannot use some WAP service
with secure mode connection.
9.8.6 Empty Temp Files
When opening a WAP page, if the WAP page which has been stored in the cache, the browser
automatically use the stored data in the cache. This menu enables you to flush the cache.
Empty Cache : This allows you to delete Cache Data information piled such as image or text.
Empty Cookies : This allows you to delete Cookie Data information piled such as user
information.
Empty Passwords : This allows you to delete a Password information piled.
9.8.7 Go To Address
This menu enables you to directly enter a URL address and open it.
Before using this menu, please check the activated profile have been correctly set.
9.8.8 Version Info
This menu allows you to view the version of the WAP browser.
9.9 SIM AT Service
SIM Card provides several value added menu service other than your handset does.
This menu service will display and work on the menu of your phone only when your SIM card
supports it. Therefore, this menu may not be shown depending on your SIM card.
The contents and terms of the menu function lists will depend on your network service provider.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 82 of 93
Please contact your network service provider (a network operator or the service provider) in
regards with availability of any services related to your SIM card, application information and
the costs.
! Note: Please be aware that you may probably be charged due to activated SMS or call when
you use those menu services.
The text of the SIM AT menus may be different from your phone language setting because the
text directly comes from your SIM card.
10. VIS (Vector Image Service)
VIS solution is all-in-one wireless multimedia package which provides complete mobile
multimedia solutions from raster & vector graphic, sound to video streaming.
VIS can be described as a Flash™ + Video streaming in wireless environment.
Flash™ and Video streaming is very popular service in wired Internet but have not been realized
in wireless Internet, especially in mobile environment. However now, you can enjoy the fantastic
functionality of the VIS with your phone.
10.1 MFlash Folder and VIDEO Folder
In your mobile file system, Mflash folder is used for VIS file storage and VIDEO folder is used
for MSF file storage.
MFlash Folder and VIDEO Folder can be accessed by Wallpaper menu, Camera & Media menu
and File Manager menu.
10.2 VIS Player
You can play VIS file with [NAVI-CENTRE] or with Play option in the file list.
If the VIS file has an audio content, you can hear the sound and you can change audio volume
with [VOLUME-UP] and [VOLUME-DOWN].
You can stop playing with right soft key and terminate VIS player with [END].
If VIS file playing is completed or stopped, function option appear on the soft key area.
10.3 MSF Player
You can play MSF file with [NAVI-CENTER] or with Play option in the file list.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 83 of 93
If the MSF file has an audio content, you can hear the sound and you can change audio volume
with [VOLUME-UP] and [VOLUME-DOWN].
During the MSF playing, you can stop or pause playing with using function icons which is
focused by navigation keys and you can terminate MSF player with right soft key or [END].
Also you can mute the sound using mute function icon during MSF playing.
10.4 VIS Wallpaper Function
You can set VIS file and MSF file to Wallpaper using Set Wallpaper function in the Option menu
on the file list. After this file is set to wallpaper, the sound doesn’ t play in the idle screen by
default but you can hear the sound and you can change audio volume with [VOLUME-UP] and
[VOLUME-DOWN].
If the VIS file or MSF file has an interactive content, icon appears on icon area of the
idle screen. If you press and hold [#] key for more than 2 seconds, your phone is entered into
the interactive mode and you can use interactive features. During the interactive mode is
enabled, icon appears on icon area of the idle screen. You can quickly escape the
interactive mode with [END].
11. Data and Fax
You can transfer data or fax to other devices via a data cable that is connected to PC. The data
cable is used to connect your phone to the PC’ s serial port.
To send and receive E-mail and faxes, connect to computer and access the Internet, you need
the appropriate data/fax communication software installed on your computer.
Also, you have to subscribe the data service when you subscribe a network service provider.
This service varies depending on the network, so contact service provider before you start
using the service.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 84 of 93
!Note : The data cable is optional part, so you need to purchase that from your phone dealer in
order to enjoy the data/fax world.
Modem configuration setting on the PC
Your phone has an integral modem. You need to install a standard modem in your PC’ s
operating system.
- Standard modem with 19200 bit/s (115200 initialisation speed)
- Fax Class 1 modem, max 9600 bit/s
For using fax service, you need to check the fax application program on the PC as below.
- Modem initialisation: AT+IFC=1,1
- Flow Control : Software Flow Control
- 115200 initialization speed and Fax Class 1 modem
How to use the data service.
1. Connect the data cable between the PC’ s serial port and your phone’ s external socket.
2. Execute a dial-up Modem software on the PC.
You need to set the Modem configuration on the PC before you use.
3. Execute appropriate data/fax program such as Internet browser on the PC.
! Note : Some data service provider releases a integrated data/fax software including the dial-up
modem software.
Using the travel adapter during the data service
The data cable has a socket for the travel adapter. You can charge your phone whilst you are
enjoying the data/fax world.
To do it, connect the plug of the travel adaptor to the socket of the data cable as following
illustration.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 85 of 93
12. Phone and Battery Care
- Keep in mind that a new battery’ s full performance is achieved only after two or three times
of complete charging and discharging cycles!
- The battery can be charged and discharged hundreds of times but it will eventually wear out.
When the operating time (talk-time and stand-by time) is noticeably shorter than normal, The
symptom means the time to buy a new battery.
- Do not attempt to open the casing on your phone or its battery.
- Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications or attachments could damage the phone and may violate regulations governing
use of mobile phones or FCC regulations.
- Always keep SIM card out of children’ s reach.
- Use your phone battery only for its intended purpose, and never use any charger or battery
which is damaged or worn out.
- Never allow the battery terminals to short circuit, as this can cause damage to the battery or
connecting object. (a short circuit can occur if a metallic object such as a coin, clip or pen
causes direct connection between the + and – terminals of the battery)
Therefore, always take adequate precautions when carrying a spare battery in a purse or
pocket.
- Battery must be recycled or disposed properly, and must not be disposed of in municipal
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 86 of 93
waste. Never dispose batteries in a fire.
- When you unplug your phone from its charger, grasp and pull the plug, not the power cord.
- For good operation times, discharge a Li-ion battery from time to time by leaving your phone
switched on until it turns itself off.
- Do not drop, knock or shake it.
- Do not use harsh chemicals, cleaning solvents, or strong detergents to clean it. Wipe it with a
soft cloth slightly dampened in a mild soap-and-water solution.
13. Troubleshooting
If you meet a trouble on your phone operation, please check the followings.
These checks enable you to save time and expense due to the unnecessary after-service.
1. When Enter PIN appears at the power-up.
The PIN check is currently enabled.
You must enter the PIN supplied together with your SIM card. You can disable the PIN check if
you want, please see Security Setting menu in section 9.
2. When Enter PUK appears at the power-up.
PIN has been entered invalidly three times in succession and your SIM card has been blocked.
In order to unblock it, you must enter the PUK supplied together with your SIM card.
3. When Insert SIM screen appears at the power-up.
Please check that your SIM card is inserted properly.
4. When Enter Lock Code appears at the power-up.
Your phone is phone locked.
You must enter the Lock Code supplied together with your phone.
5. When No Service appears.
You probably are in the area out of the coverage of a GSM/ GPRS network.
6. When Emergency Only appears even though a number of the signal bar are indicated.
You probably are in the area out of the coverage of your home GSM/ GPRS network.
You probably are in the coverage of another GSM/ GPRS network but you are not allowed to be
registered to the network.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 87 of 93
7. If any tone is not generated when you press a keypad.
You need to check the quick silence mode setting. If you can find icon on the top of the main
display screen it is the quick silence mode. By pressing and holding [VOL-UP] on the idle
screen, you can switch it off.
You need to check the Key Tone Type of Sound Setting menu.
You need to check Key Tone Volume of the profile option that you have set on Profiles menu.
8. If an audible alert is not made when a call is received.
You need to check the quick silence mode setting. If you can find icon on top of the main
display screen it is the quick silence mode. By pressing and holing [VOL-UP] on the idle screen,
you can switch it off.
You need to check Ring Type and Ring Volume of the profile option that you have set on
Profiles menu.
9. If an audible alert is not made when an alarm is expired.
You need to check the quick silence mode setting. If you can find icon on top of the main
display screen it is quick silence mode. By pressing and holing [VOL-UP] on the idle screen,
you can switch it off.
10. If an outgoing call is not made.
You have probably set an outgoing calls barring option. You need to check Call Barring menu.
Otherwise, you have probably set to Hide Number in Caller Number menu of Call Setting menu.
In some network, when you make a call with hiding the telephone number, the network does not
allow to make the call.
11. If an incoming call is not made.
You have probably set an incoming calls barring option. You need to check Call Barring menu.
12. If an outgoing SMS message is not sent.
You need to check the Message Center option in SMS Setting menu.
13. If all audible key tones are muted and all audible alerts are changed to vibrator alert.
You need to check the quick silence mode setting. If you can find icon on top of the main
display screen it is the quick silence mode. By pressing and holing [VOL-UP] on the idle screen,
you can switch it off.
14. If some audible action is not prompted on a menu of Sound Setting menu.
You need to check the quick silence mode setting. If you can find icon on top of the main
display screen it is the quick silence mode. By pressing and holing [VOL-UP] on the idle screen,
you can switch it off.
15. If nothing is displayed in the
Network Status or Event Area of the Sub Display Screen.
You need to check the Network Name Display menu of the Display Setting menu. If you have
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 88 of 93
set to Off, nothing is displayed.
16. If a telephone number that has over 20 digits is not saved and Number Too Long is
displayed when you try to save the number.
You need to check Place To Save option of Settings option in Phonebook.
If you have set to SIM Memory, maximum 20 digits can be saved in to SIM card.
If you change to Phone Memory, you can save maximum 40 digits into phone memory.
For more details, please see Phonebook menu in section 6
17. If a file such as audio file, image file, photo album file, MMS and Email are not saved into
phone memory any more.
With Memory Status menu in Camera & Media menu, you need to check how much memory size
is occupied for each application.
After that, please go to the appropriate application menu and delete some application file you
don’ t need any more.
18. If Service Not Available is continuously displayed when you try to send MMS or download
MMS.
You need to check MMS profile in MMS Settings menu.
You can know the exact MMS setting value by Network Service Provider.
19. If the image on the screen is blurred when you try to take a picture.
You need to check that the protection film is detached or the lens is clean.
To remove fingerprints or other stains wipe the lens with soft cloth.
20. If Pictures are blurred when you try to view images in Photo Album menu.
It is possible that the phone was shook during shot or lighting was poor.
If you enable self-timer in Self Timer menu, you can prevent the phone from being shook.
14. Glossary
Cell Broadcast
This network service allows you to receive the broadcasted text messages on various topics
such as weather, traffic, local district code, local hospitals, taxis or pharmacy in the area where
you are.
CUG (Closed User Group)
This network service allows the restriction of calls to and from a selected user group.
DTMF (Dial Tone Multi Frequency)
Codes sent as tone signals. Used for telephone banking, for accessing an answering machine,
etc.
GPRS (General Packet Radio Service)
New packet service that allows information to be sent and received across a mobile network.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 89 of 93
The GPRS promises data rates from 56 up to 114 Kbps and continuous packet connection to the
Internet for mobile phone and computer users. It is based on existing GSM such as circuit-
switched cellular phone connections and complements that.
International Indicator
‘+’ sign automatically adds the correct international code in front of a telephone number
when dialling out of a country.
Network Service Operator
To be able to use your phone, you need a subscription to a network. You get this subscription
from a network operator, together with a SIM card that you need to use with your phone.
PIN (Personal Identification Number)
The code is to establish authorization for access to certain functions or information in your SIM
card. The PIN code comes with your subscription. It may be a four to eight digit number and can
be changed as required.
PIN2 (Personal Identification Number 2)
The code is an authorization code to access certain special field in your SIM card. The PIN2
code does not come with your subscription in some country.
PUK (Personal Unblocking Key Code)
Used to unlock a blocked SIM card. This comes with your subscription
Roaming
Use of your phone when you are outside your subscription network area.
SIM (Subscriber Identity Module)
It contains subscriber details, security information and memory for a personal directory of
numbers.
SMS (Short Message Service)
Messages to be sent and received via the network service operator’ s message centre to your
mobile phone. To use this service, it must be supported from your network.
WAP (Wireless Application Protocol)
A standard specifically created for mobile communications devices and gives fast and easy
access to Internet information and services.
15. Safety Information
For the efficient and safe operation of your phone, observe these guidelines.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 90 of 93
Everyday Use of your phone
For normal operating position, hold your phone as you would any other telephone, with the
antenna pointed up and over your shoulder.
Do not touch the antenna unnecessarily when your phone is in use, as this will affect call quality
and may cause the phone to operate at a higher power level than otherwise needed.
As with any other radio transmitting equipment, you are advised that for the satisfactory
operation of your phone and for your own safety, you should use your phone only in the normal
operating position.
Using your phone in a vehicle
Safety comes first, and is the ultimate responsibility of the driver. Please:
i) Give full attention to driving – driving safely is your first responsibility.
ii) Use Hands-free Kit, if available.
iii) If you have those kits make sure it is done pre-programmed numbers where possible,
and keeping calls brief and to a minimum.
iv) If you don’ t have a Hands-free Kit, pull off the road and park your vehicle before making
or answering a call in driving conditions so require.
Non-ionizing radiation (exposure to Radio Frequency Signals)
Your phone is a low power radio transmitter and receiver. When it is on, it receives and also
sends the radio frequency(RF) signals. Most modern electronic equipment is shielded from RF
signals. However, certain electronic equipment may not be shielded against the RF signals from
your mobile phone. RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Consult your vehicle manufacturer and the manufacturer of
any equipment that has been added to the vehicle.
Pacemakers
The Health industry Manufacturers Association recommends that a minimum separation of six
inches be maintained between a mobile phone and pacemakers to avoid potential interference
with the pacemaker. Users with pacemakers:
i) Always keep your phone at least 20 cm (6inches) from your pacemakers when the phone
is switched on.
ii) Do not carry your phone in your breast pocket.
iii) Use the ear opposite the pacemakers to minimize the potential for interference.
iv) Switch off your phone immediately if you suspect that interference is being caused.
Hearing aids
Some mobile phones, including your mobile phone, may interfere with certain hearing aids. In the
event of such interference you may consult the hearing manufacturer to discuss alternatives.
Other medical devices
If you use any other medical devices, please consult a physician or the manufacturer of the
medical devices to determine if they are adequately shielded from external RF energy. Your
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 91 of 93
physician may be able to assist you in obtaining this information. Always check the regulations
of the healthcare facilities, which generally request that all mobiles are switched off on entry.
Operating Environment
Remember to follow any special regulations in force in any area, and always turn off your phone
wherever it is forbidden to use it, or when it may cause interference or danger.
Aircraft Safety
FCC regulations prohibit using your phone whilst in the air. Switch off your phone before
boarding an aircraft.
Explosive Atmospheres and materials
Turn your phone off and do not remove the battery when in any area with a potential explosive
atmospheres and obey all signs and instructions. You must observe restrictions on the use of
radio equipment in fuel depots; below deck on boats; fuel or chemical transfer or storage
facilities; areas where the air contains chemicals or particles, such as grain, dust, or metal
powders; areas with signs about explosive atmospheres or where blasting operations are in
progress; any other areas where you would normally be advised to turn off your vehicle engines.
For Vehicle Equipped with an Air Bag
Al air bag inflates with great force. Do not place objects, including both installed or portable
wireless equipment, in the area over the air bag or in the air bag development area. If in-vehicle
wireless equipment is improperly installed and the air bag inflates, serious injury could result.
Battery charging
Do not charge the phone without the battery in place.
Please use only approved batteries and chargers.
Specific Absorption Rate Data
This Model Phone Meets the Government’ s Requirements for Exposure to Radio Waves.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio frequency(RF) energy set by the Federal
Communications Commission(FCC) of the U.S. Government.
These limits are part of comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that were developed by
independent scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, of SAR.
The SAR limit set by the FCC is 1.6W/kg.* Tests for SAR are conducted using standard
operating positions specified by the FCC with the phone transmitting at its highest certified
power level in all tested frequency bands. Although SAR is determined at the highest certified
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 92 of 93
power level, the actual SAR level of th phone while operating can be well below the maximum
value. Because the phone is designed to operate at multiple power levels to use only the power
required to reach the network, in general, the closer you are to a wireless base station antenna,
the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified to the
FCC that it does not exceed the limit established by the government-adopted requirement for
safe exposure. The tests are performed in positions and locations(e.g., at the ear and worn on
the body) as required by the FCC for each model. The highest SAR value for this model phone
when tested for use at the ear is 0.628W/kg and when worn on the body, as described in the
user’ s manual, is 0.408W/kg. (Body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements.) While there may be differences
between SAR levels of various phones and at various positions, they all meet the government
requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this
model phone is on file with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID RJAINNO30.
Additional information on Specific Absorption Rates(SAR) can be found on the Cellular
INNO 30 User’ s Guide INNOSTREAM Confidential
Telecommunications Industry Association(CTIA) website at http://www.wow-com.com.
In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 W/kg
averaged over one gram of tissue. The standard incorporates a substantial margin of safety to
give additional protection for the public and to account for any variations in measurements.
FCC RF Exposure Information
Read this information carefully before using your phone
WARNING! In August 1996 the Federal Communications Commission (FCC) of the United States with
its action in Report and Order FCC 96-326 adopted an updated safety standards for human exposure to
radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are
consistent with the safety standards previously set by both U.S. and international standards parties. The
design of this phone complies with the FCC guidelines ad these international standards.
CAUTION! Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or
attachments could impair call quality, damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a
minor burn may result. Please contact your local dealer for replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operation with the back of the phone kept 1.5 centimeters
from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 1.5
centimeters must be maintained between the user’s body and the back of the phone, including the
antenna, whether extended or retracted. All belt-clips, holsters and similar accessories used by this device
must not contain any metallic components. Body-worn accessories that do not meet these requirements
may not comply with FCC RF exposure limits and should be avoided.
INNO 30 User’s Guide INNOSTREAM Confidential
PAGE : 93 of 93
Note : For more information about FCC RF exposure, please visit the FCC website at www.fcc.gov
16. Index
! Note : The contents of user’ s guide is subject to change for technical improvement without
notice. The availability of some services in this user’ s guide may differ from your phone
depending on your network operator or SIM card you are using.
