Innovation First RADO1 VEX Elementary 900 MHz Radio User Manual
Innovation First, Inc. VEX Elementary 900 MHz Radio
User Manual
VEX 228-2621 900 MHz VEX Radio Module User Guide
03/15/2013 Rev NC www.VEXrobotics.com Page 1
VEX Robotics, Inc.
228-2621 VEX 900 MHz Radio Module
User Guide
VEX 228 -2 6 21 900 MHz VEX Radio Module User Guide
03/15/2013 Rev NC www.VEXrobotics.com Page 2
Table of Contents
1. Overview ................................................................................................................................. 2
2. Operation ................................................................................................................................. 2
3. FCC / Industry Canada Compliance Information ................................................................... 2
1. Overview
This document describes how to use the 228-2621 900 MHz VEX Radio Module.
2. Operation
Start with the 228-2530 VEX Controller or 228-2540 VEX Robot Brain turned off. Connect the
Radio Module to the VEX Controller or Robot Brain by sliding it in to the radio socket. Power
will be applied to the Radio Module when the host device is turned on. Radio Module
operation is based on commands from the host.
3. FCC / Industry Canada Compliance Information
FCC Compliance Statement (United States):
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Note: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Industry Canada Compliance Statement
This device complies with Industry Canada licence-exempt RSS Standards. Operation is subject to the following
two conditions: 1) this device may not cause interference, and
2) this device must accept any interference, including interference that may cause undesired operation of the
device.
Conformité aux normes d'Industrie Canada
Cet appareil est conforme aux normes RSS exemptes de licence d'Industrie Canada. Son utilisation doit répondre
aux deux conditions suivantes :(1) cet appareil ne doit pas générer d'interférences et (2) il doit supporter toutes les
interférences, y compris les interférences susceptibles de provoquer des dysfonctionnements.
Appendix A: Document Version History
Date Code Changes
2013-03-15 Rev NC. Initial document release.
