1 Overview
Novatel T2000 (Home Phone Connect) works over the Verizon 4G LTE Broadband
wireless network, and uses your existing home phone number and handsets.
GET CONNECTED IN MINUTES
Just plug in, connect your phone and make calls. Connecting your phone is a snap.
You can do it yourself—no professional installation required. Set up this small, sleek,
portable device in the kitchen, your office, the bedroom, and even take it with you
when you travel.
KEEP YOUR PHONE…LOSE THE LANDLINE
Enjoy clear local and long distance telephone service with caller ID, call forwarding,
call waiting, call holding, three-way calling, TTY-TTD, and E911. Plug in your corded
or cordless phone. Use your own home phone number or set up a new one.
SEE SIGNAL STRENGTH, ALERT AND MORE ON THE TOUCH-KEY
NAVIGATION SCREEN
The T2000 with Voice’s user friendly touch-key navigation screen puts the
information you need right at your fingertips. See voice and data signal strength,
number of new voice mails, Alert status, backup battery life, and more directly on the
device.
MAINTAIN YOUR ABILITY TO MAKE CALLS DURING POWER OUTAGES
The T2000 with Voice’s backup battery provides 3 hours talk time and 33 hours
standby.
2 Features
LTE Bands: B2,B4,B13
GPS Support (E911 Support)
VoLTE Compliant, HD Voice.
2RJ-11Phone Jacks
1 RJ-31 Security Ports
1 SMA Port for External LTE antenna
DECT 6.0 Support
TTY Support
FAX Support
Callwaiting, callforwarding, three-waycalling
SupportforCallerID
FOTA
Nano SIM
NOVATEL WIRELESS, INC. T2000 User Manual
Rev.: R1.0
2
3 ProductIntroduction
3.1 LED Behavior
Blink rate = 1 sec on, 1 sec off
State LED
Operation Use Cases Note
Normal
State Solid Blue Default Screen Use TTY text icon. Never show
battery icon in status bar, only in
Home screen.
Add roaming icon to status bar,
normal sequence (check)
Solid Blue Incoming/Outgoing call
(including 911) Phone icon should be present
on the left side.
911 should be the same except
the call number.
Solid Blue Incoming/Outgoing Fax
Solid Blue Call Waiting
Solid Blue Conference Call
Solid Blue Software Update in progress
Software Update completed
Notification
State Blinking Blue Voice Mail Available
Blinking Blue
Call Forwarding Enabled Call forwarding icon should be
activated when the user set up
call forwarding from the phone
connected to New Zealand.
Call forwarding icon should be
cleared when either the user
disable up call forwarding from
the phone connected to New
Zealand or if there is an
incoming call to New Zealand
Blinking Blue Battery Powered Case Turn ON when switch to battery
for 10 sec.
Low battery – LED blink RED
Blinking Blue Missed Call Case
Error State Blinking Red No Service Case
Blinking Red SIM Error Case
Blinking Red SIM Locked Case
Blinking Red Low Battery Low = 10% or less
3.2 Button Behavior
Power Button
State Button Press Notes
Device OFF Startup No timer, no delay, just press and
release
Device ON Shutdown No timer, no delay, just press and
release
Menu Button
State Button Press Notes
Device OFF No effect
NOVATEL WIRELESS, INC. T2000 User Manual
Rev.: R1.0
3
Device ON
Screen ON Short Press – Change sub-screen
Long Press – Jump to Home
screen
Long press = 3 seconds
Device ON
Screen OFF Short Press – turn screen on
Long Press – turn screen on Home screen displayed – do not
remember last sub-screen.
Long press = 3 seconds
Reset Button
State Button Press Notes
Device OFF No effect
Device ON Reset to factory defaults Press & hold 3 secs (need pin)
NOVATEL WIRELESS, INC. T2000 User Manual
Rev.: R1.0
4
3.3 Screen On/Off Behavior
T1 = 30 seconds
T2 = 5 seconds
Screen On/Off Behavior
Power State Screen On/Off Notes
AC/Battery Startup On, Timeout (T1) If user does nothing, transition to Idle state.
AC/Battery Idle Off
AC/Battery Incoming call On, Timeout (T1) Answered => Call in progress
Ignored => Timeout from last ring.
AC/Battery Off hook
Dialing On, Timeout (T1) Timeout restarts with each tone/keypress,
so applies if user leaves phone off hook.
Keypress
AC/Battery Call in progress On Incoming or outgoing call
Includes call waiting, conferencing
AC/Battery Hang up Timeout (T1) Timeout starts from hang up.
AC/Battery Viewing Sub-
screens On, Timeout (T1) Timeout starts from each HW button press.
After timeout, turn screen off. When user
pushes the button again, Home screen is
displayed.
AC/Battery Missed call state Timeout from last ring (incoming call event)
No special behavior for missed call ongoing
state.
AC/Battery Call Forwarding No special behavior
AC/Battery SW Update
download in
progress
No special behavior
AC/Battery SW Update ready
to install No special behavior
AC/Battery SW Update in
progress
(installation)
On After install, restart.
Normal T1 timeout.
AC/Battery SW Update
complete message Off Do not go back to Home screen – keep SW
message until user presses button.
Low Battery Startup On, Timeout (T2) If user does nothing, transition to Idle state
Low Battery Idle Off
Low Battery Incoming call
On, Timeout (T2) Timeout starts when user answers OR last
ring.
NOTE:
Screen will not show caller information.
Low Battery Off hook
Dialing On, Timeout (T2) Timeout restarts with each tone/keypress.
NOTE:
Screen will not show number dialed.
Low Battery Call in progress Off Timeout from last ring (incoming call) or dial
action (outgoing call).
Low Battery Call in progress,
incoming call (call
waiting)
On, Timeout (T2) As for normal incoming call.
Low Battery Call in progress,
outgoing call
(conferencing)
On, Timeout (T2) As for normal outgoing call.
Low Battery Hang up On, Timeout (T2) Timeout starts from hang up.
(If screen is already ON and time running,
restart time upon hang up)
NOVATEL WIRELESS, INC. T2000 User Manual
Rev.: R1.0
5
Low Battery Viewing Sub-
screens On, Timeout (T2) Timeout starts from each HW button press.
After timeout, turn screen off. When user
pushes the button again, Home screen is
displayed.
Low Battery Missed call state No special behavior during this state.
Incoming call will have turned screen – see
Incoming call.
Low Battery Call Forwarding No special behavior during this state.
Low Battery SW Update
download in
progress
n/a
Will not download
Low Battery SW Update ready
to install No special behavior
Low Battery SW Update in
progress
(installation)
n/a
Will not install
NOVATEL WIRELESS, INC. T2000 User Manual
Rev.: R1.0
6
4 BasicOperation
4.1 On-offdevice
Thepowerswitchislocatedinthebackofthedevice
1. Switchthepowerkeytothe”ON”position, youcanopenthedevice.
2. Switchthepowerkeytothe”OFF”position, youcanclosethedevice.
4.2 Makecalls
1. Poweronthedevice.
2. Pickupthehandset.
3. Todialthenumberuntilyouhearthetone.
4. Waitabout3S, thedevicewillcallout.
5. Whenthecallisconnected, youcantalkwitheachother.
6. Putdownthehandsetorpresstheendkey, thephonewillbehungup.
4.3 Answercalls
ThephoneofconnectingtoT2000willringwhenthere’sanincomingcall.
1. Pickupthehandset, thecallisconnecting.
2. Putdownthehandsetorpresstheendkey, thephonewillbehungup.
NOVATEL WIRELESS, INC. T2000 User Manual
Rev.: R1.0
7
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by
the part responsible for compliance could void the user’s authority to operate
the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference and
2) this device must accept any interference received, including interference that may
cause
undesired operation of the device.
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
a minimum distance of 20 centimeters between the radiator and your body.
Allowed maximum gain(dBi), including antenna cable loss
Frequency Band Antenna gain (dBi, including cable loss)
740 MHz ~ 800 MHz WWAN 2.53 dBi
1710 MHz ~ 1900 MHz WWAN 4.12 dBi
1910 MHz ~ 2200 MHz WWAN 3.88 dBi
End user product of external antennas available from vendors specified by the
equipment supplier. Pleasecontact the equipment supplier for end user antenna and
connector recommendations.
