NS-24L240A13

User Guide

24" LCD TV

ii www.insigniaproducts.com

Contents

CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

CAUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . .4

Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

What connection should I use? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . 12

Connecting a DVD or Blu-ray player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting a camcorder or game console . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a basic home theater system . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a home theater system with multiple devices . . . . . . . . 18

Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

iii

Contents

www.insigniaproducts.com

On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Viewing channel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Viewing system information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Selecting the analog closed captioning mode . . . . . . . . . . . . . . . . . . . 34

Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . 34

Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Turning the input sensor on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Using a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

iv

Contents

www.insigniaproducts.com

Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Viewing photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Cleaning the TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

USB photo display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Programming universal remote controls . . . . . . . . . . . . . . . . . . . . . . . . 45

Programming a different universal remote control . . . . . . . . . . . . . . . 45

Common universal remote control codes . . . . . . . . . . . . . . . . . . . . . . . . 45

Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

One-year limited warranty - Insignia Televisions . . . . . . . . . . . . . . . . . 47

Definitions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

How long does the coverage last? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

What does this warranty cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

How to obtain warranty service? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Where is the warranty valid? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

What does the warranty not cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

1

www.insigniaproducts.com

As you enjoy your new product, keep these

safety tips in mind

The issue

The home theater entertainment experience is a growing trend, and larger TVs are popular

purchases. However, TVs are not always supported on the proper stands or installed

according to the manufacturer’s recommendations. We and the consumer electronics

industry are committed to making home entertainment enjoyable and safe.

TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or

carts may fall over and cause injury.

Tune into safety

•One size of TV stand does not fit all. Use only a TV stand

rated for the weight of your TV.

•Carefully read and understand all enclosed instructions

for proper use of this product.

•Don’t let children climb on or play with entertainment

system furniture and TVs.

•Don’t place TVs on furniture that can easily be used as

steps, such as a crate or chest of drawers.

•Remember that children can become excited while

watching a program, especially on a “larger-than-life” TV.

Make sure that you place or install the TV where it cannot

be pushed, pulled over, or knocked down.

•Make sure that you route all cords and cables so that they

cannot be pulled or grabbed by curious children.

Wall mounting

If you decide to wall mount your TV, always remember:

•One size of wall mount does not fit all. Use only a wall mount rated for the weight of

your TV and that has been recommended by this TV manufacturer, listed in this

manual, or otherwise listed by an independent laboratory as suitable for your TV.

•Follow all instructions supplied by the TV and wall mount manufacturers.

•If you have any doubts about your ability to safely wall mount your TV, get help from a

professional installer.

•Make sure that the wall where you are mounting the TV is

appropriate. Some wall mounts are not designed to be

mounted to walls backed with steel studs or cinder blocks. If

you are unsure, ask a professional installer.

TVs can be heavy. At least two people are required for safe wall mount installation.

f

CHILD SAFETY

It makes a difference how and where you use

your flat panel display

2

NS-24L240A13

www.insigniaproducts.com

Important Safety

Instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this apparatus near water.

6Clean only with dry cloth.

7Do not block any ventilation openings. Install in

accordance with the manufacturer's

instructions.

8Do not install near any heat sources such as

radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce

heat.

9Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized

plug has two blades with one wider than the

other. A grounding type plug has two blades

and a third grounding prong. The wide blade or

the third prong are provided for your safety. If

the provided plug does not fit into your outlet,

consult an electrician for replacement of the

obsolete outlet.

10 Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11 Only use attachments/accessories specified by

the manufacturer.

12 Use only with the cart, stand,

tripod, bracket, or table specified

by the manufacturer, or sold with

the apparatus. When a cart is used,

use caution when moving the

cart/apparatus combination to avoid injury from

tip-over.

13 Unplug this apparatus during lightning storms

or when unused for long periods of time.

14 Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as

power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or

has been dropped.

15 The wall plug is the disconnecting device. The

plug must remain readily operable.

16 An apparatus with three-prong, grounding-type

plug is a Class I apparatus which needs to be

grounded to prevent possible electric shock.

Make sure that you connect the Class I

apparatus to a grounding-type, three-prong

outlet.

17 Remote control batteries should not be exposed

to excessive heat such as sunshine, fire, or the

like.

18 The apparatus should not be exposed to

dripping or splashing and no objects filled with

liquids, such as vases, should be placed on the

apparatus.

WARNING

Electric shock hazard

To reduce the risk of fire or electric shock, do not

remove any cover or expose the device to rain or

moisture. No user-serviceable parts are inside. Refer

servicing to qualified service technicians.

Lightning

For added protection for your device receiver

during a lightning storm, or when it is left

unattended and unused for long periods of time,

unplug it from the power outlet and disconnect any

antenna or cable system. This helps prevent

property damage and personal injury from

lightning and power line surges.

Power lines

An outside antenna system should not be located in

the vicinity of overhead power lines or other

electric light or power circuits, or where it can fall

into such power lines or circuits. When installing an

outside antenna system, extreme care should be

taken to keep from touching such power lines or

circuits as contact with them might be fatal.

Handling the LCD panel

• Your TV’s screen is made of glass. Do not drop

your TV or hit, jolt, or press hard against the LCD

panel. If the screen breaks, be careful of broken

glass.

• If the LCD panel is broken, make absolutely sure

that you do not touch the liquid in the panel. This

may cause skin inflammation.

• If the liquid gets in your mouth, immediately

gargle, rinse, and consult with your doctor. Also, if

the liquid gets in your eyes or touches your skin,

consult with your doctor after rinsing for at least

15 minutes or longer in clean water.

Replacement parts

When replacement parts are required, make sure

that the service technician uses replacement parts

specified by the manufacturer that have the same

characteristics as the original part. Unauthorized

substitutions may result in fire, electric shock,

personal injury, or other hazards.

Safety check

After completing any service or repair to this device,

ask the service technician to perform routine safety

checks to determine that your TV is in correct

operating condition.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within your TV. This

label is located on the back of your TV.

This symbol indicates that there are

important operating and maintenance

instructions in the literature

accompanying your TV.

3

www.insigniaproducts.com

Power source

Operate your TV only from the type of power source

indicated on the marking label. If you are not sure

of the type of power supplied to your home, consult

an electrician or your local power company.

Servicing

These servicing instructions are for use by qualified

service personnel only. To reduce the risk of electric

shock, do not perform any servicing other than that

contained in the operating instructions unless you

are qualified to do so.

CAUTION

Damage requiring service

Unplug this TV from the power outlet and refer

servicing to qualified service personnel under the

following conditions:

• When the power supply cord or plug is damaged

or frayed.

• If liquid has been spilled or objects have fallen

into your TV.

• If your TV has been exposed to rain or water.

• If your TV does not operate normally by following

the operating instructions. Adjust only those

controls that are covered by the operating

instructions because incorrect adjustment of

other controls may result in damage and will

often require extensive work by a qualified

technician to restore your TV to its normal

operation.

• If your TV has been dropped or damaged in any

way.

• When your TV exhibits a distinct change in

performance.

Outdoor antenna grounding

If an outside antenna or cable system is connected

to your TV, make sure that the antenna or cable

system is grounded to provide some protection

against voltage surges and built-up static charges.

Article 810 of the National Electrical Code,

ANSI/NFPA No. 70, provides information with

respect to correct grounding of the mast and

supporting structure, grounding of the lead-in wire

to an antenna discharge unit, size of grounding

conductors, location of the antenna-discharge unit,

connection to grounding electrodes, and

requirements for the grounding electrode.

Note to CATV system installer

Article 820 of the National Electrical Code,

ANSI/NFPA No. 40 provides guidance for correct

grounding. Specifically, it states that the cable

ground must be connected to the grounding

system of the building as close to the point of cable

entry as practical.

Condensation

Moisture will form on the TV if the TV is brought

from cool surroundings into a warm room or if the

temperature of the room rises suddenly. When this

happens, the TV's performance may be impaired. To

prevent this, let the TV stand in its new

surroundings for about an hour before switching it

on, or make sure that the room temperature rises

gradually.

Condensation may also form during the summer if

the TV is exposed to the breeze from an air

conditioner. In such cases, change the location of

the TV.

Mobile telephone warning

To avoid interference with your TV picture and

sound, operating problems, or even damage, keep

your cordless and cellular telephones away from

the TV.

End of life directives

Your TV contains tin-lead solder and a fluorescent

lamp containing a small amount of mercury.

Disposal of these materials may be regulated for

environmental reasons. Your TV also contains

material that can be recycled and reused. For

disposal or recycling information, contact your local

authorities to find a recycler in your area.

Non-active pixels

The LCD panel contains almost 3 million thin film

transistors, which provide exceptionally sharp video

quality. Occasionally, a few non-active pixels may

appear on the screen as a fixed blue, green, or red

point. These non-active pixels do not adversely

affect the performance of your TV, and are not

considered defects.

Antenna lead-in wire

Grounding clamp

Antenna discharge unit

Grounding conductors

Ground clamps

Power service grounding electrode system

Electric service equipment

2

1

3

4

5

6

7

1

2

3

4

5

6

7

4

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Insignia 24" LCD TV

Introduction

Congratulations on your purchase of a high-quality

Insignia product. Your NS-24L240A13 represents

the state of the art in LCD TV design and is designed

for reliable and trouble-free performance.

Installing the stand or

wall-mount bracket

Installing the stand

To install the stand:

1Carefully place your TV screen face-down on a

cushioned, clean surface to protect the screen

from damages and scratches.

2Align the stand with the stand column, then

rotate the stand in the direction of the arrow

until you hear the stand lock into place.

Installing a wall-mount bracket

To attach your TV to a wall-mount bracket:

1Carefully place your TV screen face-down on a

cushioned, clean surface to protect the screen

from damages and scratches.

2If the stand is attached, press and hold the

PUSH button while you rotate the stand to

remove it.

3Remove the six screws that secure the stand

column to the TV screen.

4Remove the stand column.

Notes

• If you plan to wall-mount your TV, do not install

the stand.

• Store the stand and stand screws in case you

decide to use the stand in the future.

Warning

This TV is intended to be supported by a UL Listed

wall mount bracket with suitable weight/load. (See

“Miscellaneous” on page 44.)

5

Insignia 24" LCD TV

www.insigniaproducts.com

5Attach the wall-mount bracket to your TV using

the mounting holes on the back of your TV. See

the instructions that came with the wall-mount

bracket for information about how to correctly

hang your TV.

TV components

Package contents

• Remote control and batteries (2 AAA)

•Stand

• Quick Setup Guide

•Important Information

Front

Note

• The length of the wall-mount screws vary

depending on the wall-mount bracket you

purchased. See the instructions that came with

the wall-mount bracket for screw lengths.

• The mounting holes on the back of your TV take

type M4 screws.

7.84 in. (200 mm)

3.94 in. (100 mm)

Wall-mount brackets #Item Description

Power indicator Turns off when your TV is on.

Lights red when your TV is off (standby mode).

Remote control sensor Receives signals from the remote control. Do not block.

INPUT

Press to open the INPUT SOURCE list, press CH Sor

CH T to select a video input source, then press INPUT

again. For more information, see “Selecting the video

input source” on page 20.

In menu mode, press to confirm selections.

MENU Press to open the on-screen menu. For more

information, see “Navigating the menus” on page 21.

CH S/CH T

Press to go to the next or previous channel in the

channel list. For more information, see “Selecting a

channel” on page 22.

VOL+/VOL– Press to increase or decrease the volume.

POWER

Press to turn your TV on or off (Standby mode).

When your TV is off, power still flows into it. To

disconnect power, unplug the power cord.

34567

12

1

2

3

4

5

6

7

6

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Back

1

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R ANT / CABLE

9103

7

4 52 86

#Item Description

USB

Connect a USB flash drive to this jack to view

compatible JPEG picture files. For more information,

see “Connecting a USB flash drive” on page 16 and

“Using a USB flash drive” on page 38.

HDMI 1 and HDMI 2/DVI

Connect HDMI devices to these jacks. For more

information see “Using HDMI (best)” on page 9 or 12.

Connect the video for a DVI device to the HDMI 2/DVI

jack. For more information, see “Using DVI (same as

HDMI but requires a sound connection)” on

page 10 or 13.

VGA Connect the video for a computer to this jack. For more

information, see “Connecting a computer” on page 15.

PC/DVI AUDIO IN

Connect the audio for a computer to this jack. For more

information, see “Connecting a computer” on page 15.

OR

Connect the audio for a DVI device to the this jack. For

more information, see “Using DVI (same as HDMI but

requires a sound connection)” on page 10 or page 13.

DIGITAL OUTPUT

(coaxial)

Connect a digital audio amplifier or home theater

system to this jack to listen to TV audio through the

amplifier speakers. For more information, see “Using

digital audio” on page 17.

COMPONENT IN

Y, PB, PR

Connect the video for a component video device to

these jacks. For more information, see “Using

component video (better)” on page 10 or 13.

AV IN VIDEO

Connect the video for a composite video device to this

jack. For more information, see “Using composite

video (good)” on page 11 or 14.

AV IN L/R (audio)

The component video jacks (COMPONENT IN Y, PB,

and PR) share these audio jacks with the composite

video jack (AV IN VIDEO).

Connect the audio for a component video device to

these jacks. For more information, see “Using

component video (better)” on page 10 or 13.

OR

Connect the audio for a composite video device to

these jacks. For more information, see “Using

composite video (good)” on page 11 or 14.

ANT/CABLE

Connect an antenna or cable TV to this jack. For more

information, see “Connecting an antenna or cable TV

(no box)” on page 12.

(headphone)

Connect headphones to this jack. For more

information, see “Connecting headphones” on

page 17.

1

2

3

4

5

6

7

8

9

10

7

Insignia 24" LCD TV

www.insigniaproducts.com

Remote control

#Button Description

(power)

Press to turn your TV on or off (standby mode). When

your TV is off, power still flows through it. To

disconnect power, unplug the power cord.

Quick Launch Inputs

TV—Press to select your TV as the input source.

VIDEO—Press to select the device connected to the

COMPONENT IN jacks or AV IN VIDEO jack.

HDMI—Press one or more times to select the device

connected to the HDMI 1 or HDMI 2/DVI jack.

ACC—Has no function.

Numbers Press to enter channel numbers and the parental

control password.

Press to enter a digital sub-channel number. For more

information, see “Selecting a channel” on page 22.

ENTER Press to confirm selections or changes.

MENU Press to open the on-screen menu.

EXIT Press to close the on-screen menu.

INPUT

Press to open the INPUT SOURCE list, then press S or

T on the remote control to select the video input

source. For more information, see “Selecting the video

input source” on page 20.

CH-LIST Press to open the channel list.

*

1

2

3

4

5

6

7

8

9

/MUTE Press to mute the sound. Press again to restore the

sound.

VOL+/– Press to increase or decrease the volume.

SLEEP

Press to set the sleep timer. You can select Off, 5, 10,

15, 30, 60, 90, 120, 180, or 240 minutes. For more

information, see “Setting the sleep timer” on page 36.

ZOOM Press to select the aspect ratio. For more information,

see “Aspect ratio options” on page 23.

(return) Press to return to the previous channel.

S T W XPress to navigate in on-screen menus and to adjust

settings.

HOME Press to open the on-screen menu.

INFO

Press to display TV status information, such as the

channel number, channel name (if available), or signal

source. For more information, see “Viewing channel

information” on page 22.

CCD

Press to turn closed captioning on or off. You can select

CC Off, CC On, or CC on When Mute. For more

information, see “Turning closed captioning on or off”

on page 33.

FAVORITE

Press to open the Favorite channel list. For more

information, see “Setting up a favorite channel list” on

page 27 and “Viewing a favorite channel” on page 28.

CH /CH Press to change TV channels. For more information,

see “Selecting a channel” on page 22.


Press to select the picture mode. You can select Vivid,

Standard, Theater, Energy Savings, or Custom.

For more information, see “Picture Mode” in

“Adjusting the TV picture” on page 22.

MTS/SAP

Press to select the audio mode for an analog program.

You can select:

•STEREO—Select this option for programs

broadcast in stereo.

•MONO—Select this option if there is noise

or static on weak stereo broadcasts.

•SAP—Select this option to listen to a

secondary audio program, if available.

AUDIO

Press to select the sound mode. You can select

Standard, Theater, Music, News, or Custom. For

more information, see “Sound Mode” in “Adjusting

sound settings” on page 24.

Media controls These buttons have no function.

#Button Description

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

8

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Making connections

What connection should I use?

Your TV has several connection types for

connecting devices to your TV.

For the best video quality, you should connect a

device to the best available connection.

Use the following tables to identify cables:

You can use the HDMI 2/DVI jack on your TV to

connect a DVI device to your TV. You need to attach

an HDMI-to-DVI adapter to the end of the HDMI

cable that connects to the DVI device.

Connection type

and jack Video quality Cable connector

HDMI

video/audio Best (use this

if your devices

have HDMI)

Component

video (requires

an audio

connection)

Better than

composite or

coaxial

Composite video

(requires an

audio

connection) Better than

coaxial

Coaxial

video/audio

Good

Connection type

and jack Cable connectors

Optical coaxial

audio

Analog audio

VGA (computer)

video and audio

Cautions

• Check the jacks for position and type before

making any connections.

• Loose connections can result in image or color

problems. Make sure that all connections are

tight and secure.

• The external audio/video equipment shown

may be different from your equipment. If you

have questions, refer to the documentation that

came with your equipment.

• Always unplug the power cord when

connecting external equipment.

9

Insignia 24" LCD TV

www.insigniaproducts.com

Connecting power

To connect the power:

• Plug the AC power cord into a power outlet.

Connecting a cable or satellite box

Many cable or satellite TV boxes have more than

one connection type. To get the best video, you

should use the best connection type available. For

more information, see “What connection should I

use?” on page 8.

Using HDMI (best)

To connect a cable or satellite box using HDMI:

1Make sure that your TV’s power cord is

unplugged, and all connected equipment is

turned off.

2Connect the incoming cable from the cable wall

jack to the cable-in jack on the cable or satellite

box.

3Connect an HDMI cable (not provided) to one of

the HDMI jacks on the back of your TV and to

the HDMI OUT jack on the cable or satellite box.

4Plug your TV’s power cord into a power outlet,

turn on your TV, then turn on the cable or

satellite box.

5Go through the Setup Wizard on page 19.

Cautions

• Your TV should only be operated from the

power source indicated on the label.

• Always unplug the AC power cord from the

power outlet when you will not be using your

TV for an extended period of time.

Note

An HDMI cable carries both audio and video. You do

not need to use any audio cables.

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT Y

C

O

HDMI cable

Cable or satellite box

Back of TV

10

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Using DVI (same as HDMI but requires a sound

connection)

To connect a cable or satellite box using DVI:

1Make sure that your TV’s power cord is

unplugged, and all connected equipment is

turned off.

2Connect the incoming cable from the cable wall

jack to the cable-in jack on the cable or satellite

box.

3Connect an HDMI-DVI adapter (not provided) to

one end of an HDMI cable (not provided), then

connect the adapter to the DVI OUT jack on the

cable or satellite box.

4Connect the other end of the cable to the

HDMI 2/DVI jack on the back of your TV.

5Connect a 3.5mm audio cable (not provided) to

the PC/DVI AUDIO IN jack on the back of your

TV and to the AUDIO OUT jacks on the cable or

satellite TV box.

6Plug your TV’s power cord into a power outlet,

turn on your TV, then turn on the cable or

satellite TV box.

7Go through the Setup Wizard on page 19.

Using component video (better)

To connect a cable or satellite box using

component video:

1Make sure that your TV’s power cord is

unplugged, and all connected equipment is

turned off.

2Connect the incoming cable from the cable wall

jack to the cable-in jack on the cable or satellite

box.

3Connect a component video cable (not

provided) to the COMPONENT IN Y, PB, and PR

video jacks on the back of your TV and the

component video out jacks on the cable or

satellite box.

4Connect an audio cable (not provided) to the

AV IN L/R AUDIO jacks on the back of your TV

and to the audio out jacks on the cable or

satellite TV box.

5Plug your TV’s power cord into a power outlet,

turn on your TV, then turn on the cable or

satellite TV box.

6Go through the Setup Wizard on page 19.

Note

You must use the HDMI 2/DVI jack to connect a

cable or satellite box using DVI. If you use the HDMI 1

jack, you will not hear sound.

Note

When you connect the audio using the PC/DVI

AUDIO IN jack, the audio output is analog.

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT Y

C

O

Cable or satellite box

HDMI cable with

HDMI-DVI adapter

3.5mm audio cable

Back of TV

Note

•The COMPONENT IN video jacks share the

AV IN L/R AUDIO jacks with the AV IN VIDEO

jack.

• When you connect the audio using the

AV IN L/R AUDIO audio jacks, the audio output

is analog.

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R AN

T

Audio cable

Cable or satellite box

Cables are often

color-coded to match

color-coded jacks.

Component video cable

Back of TV

11

Insignia 24" LCD TV

www.insigniaproducts.com

Using composite video (good)

To connect a cable or satellite box using

composite video:

1Make sure that your TV’s power cord is

unplugged, and all connected equipment is

turned off.

2Connect the incoming cable from the cable wall

jack to the cable-in jack on the cable or satellite

box.

3Connect an AV cable (not provided) to the

AV IN VIDEO jack and L/RAUDIO jacks on the

back of your TV and to the composite video and

audio out jacks on the cable or satellite box.

4Plug your TV’s power cord into a power outlet,

turn on your TV, then turn on the cable or

satellite TV box.

5Go through the Setup Wizard on page 19.

Using coaxial (good)

To connect a cable or satellite box using coaxial:

1Make sure that your TV’s power cord is

unplugged, and all connected equipment is

turned off.

2Connect the incoming cable from the cable wall

jack to the cable-in jack on the cable or satellite

box.

3Connect a coaxial cable (not provided) to the

ANT/CABLE jack on the back of your TV and to

the coaxial out jack on the cable or satellite box.

4Plug your TV’s power cord into a power outlet,

turn on your TV, then turn on the cable or

satellite TV box.

5Go through the Setup Wizard on page 19.

Note

•The AV IN VIDEO jack shares the AV IN

L/RAUDIO jacks with the COMPONENT IN

video jacks.

• When you connect the audio using the AV IN

L/RAUDIO jacks, the audio output is analog.

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R AN

T

Cable or satellite box

AV cable

Cables are often color-coded

to match color-coded jacks.

Back of TV Notes

• Use a coaxial cable to eliminate interference and

noise from radio waves.

• Do not bundle the coaxial cable with the power

cord or other cables.

D

IGITAL

O

UTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R ANT / CABLE

Cable or satellite box

Coaxial cable

Back of TV

12

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Connecting an antenna or cable TV (no box)

To connect an antenna or cable TV (no box):

1Make sure that your TV’s power cord is

unplugged, and all connected equipment is

turned off.

2Connect a coaxial cable to the ANT/CABLE jack

on the back of your TV and to the antenna or

cable TV wall jack.

3Plug your TV’s power cord into a power outlet,

then turn on your TV.

4Go through the Setup Wizard on page 19.

Connecting a DVD or Blu-ray player

Using HDMI (best)

To connect a DVD or Blu-ray player using HDMI:

1Make sure that your TV’s power cord is

unplugged and the DVD or Blu-ray player is

turned off.

2Connect an HDMI cable (not provided) to one of

the HDMI jacks on the back of your TV and to

the HDMI OUT jack on the DVD or Blu-ray

player.

3Plug your TV’s power cord into a power outlet,

then turn on your TV.

4Turn on the DVD or Blu-ray player, then set it to

the correct output mode. For more information,

see the documentation that came with the

player.

5Press INPUT to open the INPUT SOURCE list.

6Press S or T to highlight HDMI 1or HDMI 2,

then press ENTER.

Notes

• Use a coaxial cable to eliminate interference and

noise from radio waves.

• Do not bundle the coaxial cable with the power

cord or other cables.

• If the antenna is not installed correctly, contact

qualified service personnel to correct the

problem.

• If the signal level for a channel is weak, the

picture may be distorted. Adjust the antenna or

use a highly directional outdoor or set-top

antenna with a built-in amplifier.

• If the picture quality is good on some channels

and poor on others, the problem may be caused

by a poor or weak signal from the broadcaster

or cable TV provider.

• If you connect to cable or satellite TV without a

set-top box and experience poor picture quality,

you may need to install a set-top box to improve

signal reception and picture quality. Contact

your cable or satellite TV provider about

upgrading to a set-top box.

• Many high-definition (HD) channels upscale

standard-definition (SD) content. The picture

displayed on your TV is still displayed as SD, thus

the picture quality will not be as clear or crisp as

it would be if the content was originally

recorded in HD.

D

IGITAL

O

UTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R ANT / CABLE

Coaxial cable

Antenna or

cable TV (no box)

Back of TV

Note

You can also press HDMI repeatedly to select the

DVD or Blu-ray player.

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT Y

C

O

DVD or Blu-ray player

HDMI cable

Back of TV

13

Insignia 24" LCD TV

www.insigniaproducts.com

Using DVI (same as HDMI but requires a sound

connection)

To connect a DVD or Blu-ray player using DVI:

1Make sure that your TV’s power cord is

unplugged and the DVD or Blu-ray player is

turned off.

2Connect an HDMI-DVI adapter (not provided) to

one end of an HDMI cable (not provided), then

connect the adapter to the DVI OUT jack on the

DVD or Blu-ray player.

3Connect the other end of the cable to the

HDMI 2/DVI jack on the back of your TV.

4Connect a 3.5mm audio cable (not provided) to

the PC/DVI AUDIO IN jack on the back of your

TV and to the AUDIO OUT jacks on the DVD or

Blu-ray player.

5Plug your TV’s power cord into a power outlet,

then turn on your TV.

6Turn on the DVD or Blu-ray player, then set it to

the correct output mode. For more information,

see the documentation that came with the

player.

7Press INPUT to open the INPUT SOURCE list.

8Press S or T to select HDMI 2, then press

ENTER.

Using component video (better)

To connect a DVD or Blu-ray player using

component video:

1Make sure that your TV’s power cord is

unplugged and the DVD or Blu-ray player is

turned off.

2Connect a component video cable (not

provided) to the COMPONENT IN Y, PB, and PR

jacks on the back of your TV and to the

COMPONENT OUT jacks on the component

video device.

3Connect an audio cable to the AV IN L/R AUDIO

jacks on the back of your TV and to the L/R

AUDIO OUT jacks on the DVD or Blu-ray player.

4Plug your TV’s power cord into a power outlet,

then turn on your TV.

5Turn on the DVD or Blu-ray player, then set it to

the correct output mode. For more information,

see the documentation that came with the

player.

6Press INPUT to open the INPUT SOURCE list.

7Press S or T to select Component, then press

ENTER.

Note

You must use the HDMI 2/DVI jack to connect a DVD

or Blu-ray player using DVI. If you use the HDMI 1

jack, you will not hear sound from the TV speakers.

Note

You can also press HDMI one or more times to select

the DVD or Blu-ray player.

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT Y

C

O

DVD or Blu-ray player

HDMI cable

with HDMI-DVI

adapter

3.5mm audio

cable

Back of TV

Notes

•The COMPONENT IN video jacks share the

AV IN L/R AUDIO jacks with the AV IN VIDEO

jack.

• When you connect the audio using the AV IN

L/R AUDIO jacks, the audio output is analog.

Note

You can also press VIDEO to select the DVD or Blu-ray

player.

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R AN

T

Component video cable

Audio cable

Cables are often color-coded

to match color-coded jacks. DVD or Blu-ray player

Back of TV

14

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Using composite video (good)

To connect a DVD or Blu-ray player using

composite video:

1Make sure that your TV’s power cord is

unplugged and the DVD or Blu-ray player is

turned off.

2Connect an AV cable (not provided) to the

AV IN Video jack and L/R AUDIO jacks on the

back of your TV and to the AV OUT jacks on the

DVD or Blu-ray player.

3Plug your TV’s power cord into a power outlet,

then turn on your TV.

4Turn on the DVD or Blu-ray player, then set it to

the correct output mode. For more information,

see the documentation that came with the

player.

5Press INPUT to open the INPUT SOURCE list.

6Press S or T to select AV, then press ENTER.

Connecting a VCR

To connect a VCR:

1Make sure that your TV’s power cord is

unplugged and the VCR is turned off.

2Connect an AV cable (not provided) to the

AV IN VIDEO and L/R AUDIO jacks on the back

of your TV and to the AV OUT jacks on the VCR.

3Plug your TV’s power cord into a power outlet,

then turn on your TV and the VCR.

4Press INPUT to open the INPUT SOURCE list.

5Press S or T to select AV, then press ENTER.

6Insert a videotape in the VCR, then press PLAY

on the VCR.

Note

•The AV IN VIDEO jack shares the AV IN

L/R AUDIO jacks with the COMPONENT IN

video jacks.

• When you connect the audio using the AV IN

L/R AUDIO jacks, the audio output is analog.

Notes

You can also press VIDEO to select the DVD or Blu-ray

player.

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R AN

T

DVD or Blu-ray player

Cables are often color-coded to

match color-coded jacks.

AV cable

Back of TV

Note

•The AV IN VIDEO jack shares the AV IN

L/R AUDIO jacks with the COMPONENT IN

video jacks.

• When you connect the audio using the AV IN

L/R AUDIO jacks, the audio output is analog.

Note

You can also press VIDEO to select the VCR.

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R AN

T

VCR

Cables are often color-coded to

match color-coded jacks.

AV cable

Back of TV

15

Insignia 24" LCD TV

www.insigniaproducts.com

Connecting a camcorder or game console

To connect a camcorder or game console:

1Make sure that your TV’s power cord is

unplugged and the camcorder or game console

is turned off.

2Connect an AV cable (not provided) to the

AV IN VIDEO and L/RAUDIO jacks on the back

of your TV and to the AV OUT jacks on the

camcorder or game console.

3Plug your TV’s power cord into a power outlet,

then turn on your TV.

4Turn on the camcorder or game console, then

set it to the correct output mode. For more

information, see the documentation that came

with the camcorder or game console.

5Press INPUT to open the INPUT SOURCE list.

6Press S or T to select AV, then press ENTER.

Connecting a computer

Using VGA

To connect a computer using VGA:

1Make sure that your TV’s power cord is

unplugged and the computer is turned off.

2Connect a VGA cable (not provided) to the

PC IN VGA jack on the back of your TV and to

the VGA jack on the computer.

3Connect an audio cable with a stereo mini plug

(not included) to the PC/DVI AUDIO IN jack on

the back of your TV and to the AUDIO OUT jack

on the computer.

4Plug your TV’s power cord into a power outlet,

turn on your TV and the computer.

5Press INPUT to open the INPUT SOURCE list.

6Press S or T to select VGA, then press ENTER.

7Adjust the display properties on the computer,

if necessary.

Note

If your camcorder or game console has an HDMI

connection, we recommend that you use the HDMI

connection to get the best quality possible.

Note

•The AV IN VIDEO jack shares the AV IN

L/R AUDIO jacks with the COMPONENT IN

video jacks.

• When you connect the audio using the AV IN

L/R AUDIO jacks, the audio output is analog.

Notes

You can also press VIDEO to select the camcorder or

game console.

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R AN

T

Cables are often color-coded to

match color-coded jacks.

Camcorder or

game console

AV cable

Back of TV

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT Y

C

O

Audio cable with stereo mini plug

VGA cable

Back of TV

16

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Using HDMI

To connect a computer using HDMI:

1Make sure that your TV’s power cord is

unplugged and the computer is turned off.

2Connect an HDMI cable (not provided) to one of

the HDMI jacks on the back of your TV and to

the HDMI OUT jack on the computer.

3Plug your TV’s power cord into a power outlet,

then turn on your TV and the computer.

4Press INPUT to open the INPUT SOURCE list.

5Press S or T to highlight HDMI1or HDMI2, then

press ENTER.

6Adjust the display properties on the computer,

if necessary.

Connecting a USB flash drive

To connect a USB flash drive:

1Plug a USB flash drive into the USB port on the

back of your TV.

2Turn on your TV.

3Press INPUT to open the INPUT SOURCE list.

4Press S or T to select USB, then press ENTER.

Note

You can also press HDMI repeatedly to select the

computer.

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT Y

C

O

HDMI cable

Back of TV

Caution

Do not remove the USB flash drive or turn off your TV

while using the USB flash drive. You may lose data or

damage the USB flash drive.

Note

The Photos viewer only supports JPEG format

images (with “.jpg” file extensions) and not all JPEG

files are compatible with your TV.

For more information, see “Using a USB flash drive”

on page 38.

USB HDMI 1 HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT Y

C

O

USB flash

drive

Back of TV

17

Insignia 24" LCD TV

www.insigniaproducts.com

Connecting headphones

The TV speakers are muted when headphones are

attached.

To connect headphones:

• Connect the headphones to the

(headphone) jack on the back of your TV.

Connecting a basic home theater system

Using digital audio

To connect a basic home theater system using

digital audio:

1Make sure that your TV’s power cord is

unplugged and the home theater system is

turned off.

2Connect a digital coaxial audio cable (not

provided) to the DIGITAL OUTPUT jack on the

back of your TV and to the coaxial AUDIO IN

jack on the digital home theater system.

Warning

Loud noise can damage your hearing. When using

headphones, use the lowest volume setting on your

headphones that still lets you hear the sound.

T

AL

P

UT YP

BPRVIDEO

COMPONENT IN AV IN

L - AUDIO - R ANT / CABLE

Back of TV

HDMI 2 / DVI VGA

PC / DVI

AUDIO IN

DIGITAL

OUTPUT YP

BPRVI

D

COMPONENT IN

Digital coaxial audio cable

Home theater system

Back of TV

18

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Connecting a home theater system with

multiple devices

The connections you make depend on the video

and audio jacks available on your devices. Refer to

the documentation that came with your devices for

connection information.

Just remember to use the best connection types

available for the best picture and sound. For

information about connection types, see “What

connection should I use?” on page 8.

Using the remote control

Installing remote control batteries

To install remote control batteries:

1While pressing the release latch on the back of

the remote control, lift the battery

compartment cover off the remote control.

2Insert two AAA batteries into the battery

compartment. Make sure that you match the +

and – symbols on the batteries with the + and –

symbols in the battery compartment.

3Replace the battery compartment cover.

Aiming the remote control

To aim the remote control:

• Point the remote control towards the remote

sensor on the front of your TV.

Blu-ray player/DVD player/VCR Cable/satellite box

AV receiver

Camcorder/game console

USB flash drive

Computer

Antenna or cable

TV connected

directly to the

wall jack

Cautions

• Batteries should not be exposed to excessive

heat, such as sunshine, heat registers, or fire.

• Battery chemicals can cause a rash. If the

batteries leak, clean the battery compartment

with a cloth. If chemicals touch your skin, wash

immediately.

• Make sure that batteries are disposed of

correctly. Do not burn or incinerate.

Notes

• Do not mix batteries of different types.

• Do not mix old and new batteries.

• Remove batteries when the charge is depleted.

• If the remote control is not going to be used for

an extended period of time, remove the

batteries.

19

Insignia 24" LCD TV

www.insigniaproducts.com

Turning on your TV for the

first time

The first time you turn on your TV, the Setup Wizard

opens. The Setup Wizard guides you through

setting up basic settings including the menu

language, time setting, picture mode, TV signal

source, and the channel list.

To set up your TV:

1Make sure that you have:

• Installed the remote control batteries. (See

page 18 for details.)

• Connected an antenna, cable TV, or satellite

TV. (See page 9 through 12 for details.)

• Connected the power cord. (See page 9 for

details.)

2Press (power) to turn on your TV. The Choose

Your Menu Language screen opens.

3Press S or T to highlight the language you

want, then press ENTER. The Choose Your Time

Setting screen opens.

4Press S or T to highlight Mode, then press

Wor X to select Manual (to set the date and

time manually) or Auto (to set the date and time

automatically from a TV signal source based on

the time zone you select).

5Press S or T to highlight Time Zone, then press

W or X to select your time zone. You can select

Eastern, Central, Mountain, Pacific, Alaska,

Hawaii, Atlantic, or Newfoundland.

6Press S or T to highlight Daylight Savings,

then press W or X to select On (if your viewing

area observes Daylight Savings Time) or Off (if

your viewing area does not observe Daylight

Savings Time).

7If you selected Manual for Mode, set the date

by pressing S or T to highlight Year, Month, or

Day, then pressing W or X to adjust the setting.

8If you selected Manual for Mode, set the time

by pressing S or T to highlight Time, then

pressing W or X to select the hour, minute, or

AM/PM field. Press S or T to adjust the setting.

9Press ENTER. The Choose Your Picture Mode

screen opens.

10 Press S or T to highlight Home Mode or Retail

Mode, then press ENTER.

If you selected Retail Mode, the message “If you

select Retail Mode, then Energy savings is not

realized” appears. Select Ye s to continue using

Retail Mode, or select No to change your

selection, then press ENTER.

The Choose Your TV Source screen opens.

11 Press S or T to highlight Antenna, Cable, or

Satellite Box, then press ENTER.

A. If you select Antenna, your TV scans for

available channels. The scan may take several

minutes.

Note

If you select Auto, the displayed time will be

incorrect until your TV gets the correct time from a

TV signal source.

English

Fran ais

ç

Español

Choose Your Menu Language

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Set menu language to English, Franais, Español

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Choose Your Time Setting

Mode Auto

Time Zone Paclfic

Daylight Savings On

Year 2009

Month January

Day 01

Time 01:29 AM

If Automatic, options are automatically set by TV source

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Choose Your Picture Mode

Reduces total power consumption

Home Mode

Retail Mode

Antenna

Cable

Satellite Box

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Select if using an antenna for standard or HD TV.

Choose Your TV Source

20

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

B. If you select Cable, a message asks if you have

a cable box.

• Select No if no cable box is connected.

Your TV scans for available channels. The

scan may take several minutes.

• Select Ye s if a cable box is connected. A

message asks how you connected the

cable box to your TV.

• Select AV, Component, or HDMI if you

connected a cable box to your TV using

one of these cables. Read the message,

then press ENTER to close the wizard.

• Select Coaxial if you connected a cable

box to your TV using a coaxial cable.

Read the message, then press ENTER to

start the channel scan (VHF channels

only).

C. If you select Satellite Box, a message asks

how you connected the satellite box to your

TV.

• Select AV, Component, or HDMI if you

connected a satellite box to your TV using

one of these cables. Read the message,

then press ENTER to close the wizard.

• Select Coaxial if you connected a satellite

box to your TV using a coaxial cable. Read

the message, then press ENTER to start the

channel scan (VHF channels only).

12 To watch TV, press INPUT, press S or T to

highlight the video input source for your TV in

the INPUT SOURCE list, then press ENTER.

• If your TV is connected to an antenna, cable TV

(no box), or cable or satellite TV box using a

coaxial cable, select TV.

• If your TV is connected to a cable or satellite

box using an HDMI cable or HDMI cable with a

DVI adapter, select HDMI 1 or HDMI 2.

• If your TV is connected to a cable or satellite

box using a component video cable, select

Component.

• If your TV is connected to a cable or satellite

box using a composite video cable, select AV.

Understanding the basics

Turning your TV on or off

To turn your TV on or off:

1Make sure that the power cord is connected to a

power outlet.

2Press (power) to turn on your TV. The power

indicator turns blue.

3Press (power) again to turn off your TV. Your

TV enters standby mode, and the power

indicator LED turns red.

Selecting the video input source

To select the video input source:

1Turn on your TV, then press INPUT. The INPUT

SOURCE list opens.

2Press S or T to select a video input source, then

press ENTER.

Do you have a Cable Box?

No

Yes

Move

OK

ENTER

ME NU EXIT

Exit

Previous

Se lec t

How did you connect the

AV, Component, or HDMI

Coaxial

Move

OK

ENTER

ME NU EXIT

Exit

Previous

Se lec t

cable box to the TV?

How did you connect the

AV, Component, or HDMI

Coaxial

Move

OK

ENTER

ME NU EXIT

Exit

Previous

Se lec t

satellite box to the TV?

Note

You can press EXIT to stop the auto channel search,

but you will need to run the auto channel search

again to create a channel list.

Warning

When your TV is in standby mode, it is still receiving

power. To completely disconnect power, unplug the

power cord.

Note

If your TV does not receive an input signal for several

minutes, it automatically goes into standby mode.

TV

AV

HDMI 1

HDMI 2

USB

INPUT SOURCE

Component

VGA

21

Insignia 24" LCD TV

www.insigniaproducts.com

You can also press a Quick Launch Input button to

select the video input source.

• Press TV to select TV (if your TV is connected to

an antenna, cable TV (no box), or cable or satellite

TV using a coaxial cable).

• Press VIDEO to select component or composite

input.

•Press HDMI one or more times to cycle between

the HDMI inputs.

On-screen menu overview

Picture menu (TV mode)

Audio menu (TV mode)

Channels menu (TV mode)

Settings menu (TV mode)

Photos menu (USB mode)

Navigating the menus

Notes

• Depending on the signal source selected, you

may see different options on your screen. The

following menus are shown in TV mode (except

the Photos menu).

• Menu items that are not selectable are grayed

out.

• Menus in this manual are described in TV mode,

unless otherwise indicated.

• The screens shown in this manual are for

explanation purposes and may vary from the

actual screens on your TV.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Audio

Sound Mode Standard

Balance 0

Advanced Audio

Reset Audio Settings

Adjust settings to affect sound quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Channels

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Channel Strength

Audio Only

Auto Zoom

Off

On

Adjust channel options


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Parental Controls

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set various TV options


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

View files from a USB device that is connected to the TV

OK

ENTER

MENU EXIT

Exit

Previous

Select


Photos


CHANNELS

SETTINGS

PHOTOS

AUDIO

Press MENU to open the on-screen menu.

Press the right or left arrow to move the

cursor on the screen or to adjust a selected

item.

Press the up or down arrow to select menu

options.

Press ENTER to confirm a selection or enter a

sub-menu.

Press MENU to return to the previous menu.

Press EXIT to close the menu.

22

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Selecting a channel

To select a channel:

• Press CH or CH to go to the next or previous

channel on the memorized channel list.

• Press the number buttons to enter the analog or

main digital channel number you want, then wait

for the channel to change or press ENTER to

immediately change the channel.

• To select a digital sub-channel, press the number

buttons to select the main digital channel, press

(dot), then press the number button for the

sub-channel. Wait for the channel to change, or

press ENTER to immediately change the channel.

For example, to tune to channel 5.1, press 5,

(dot), then 1.

• Press (return) to go to the last viewed channel.

• Press CH-LIST to open the channel list, press S or

T to highlight a channel, then press ENTER.

Hidden channels are grayed and cannot be

selected. See “Hiding channels” on page 26.

• Press FAVORITE to open the favorite channel list,

press S or T to highlight a channel, then press

ENTER.

Adjusting the volume

To adjust the volume:

• Press VOL+ or VOL– to increase or decrease the

volume.

• Press MUTE to turn off the sound. Press

MUTE again to turn the sound back on.

Viewing channel information

To view channel information:

• Press INFO to view an information banner. The

information banner shows the current program

information such as channel number, video input

source, and resolution.

• Digital channel information—Displays the

channel number, station name, channel label,

broadcast program name, TV rating, signal

type, audio information, resolution, CC mode,

current time, and current program start and

end times.

• Analog channel information—Displays

channel number, channel label (if present),

signal type, audio information, and resolution.

Viewing system information

To view system information:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

3Press S or T to highlight System Info, then

press ENTER. Information about the TV software

version is displayed.

4Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting the picture

Adjusting the TV picture

To adjust the TV picture:

1Press MENU. The on-screen menu opens with

the Picture menu displayed.

2Press T or ENTER to access the menu.

3Press S or T to highlight an option, then press

ENTER to access the option. You can select:

Note

Button presses must be within three seconds of each

other.

Note

If a list has more than one page, press S or T to

scroll through the pages.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

MOVE

OK

ENTER

MENU EXIT

EXIT

PREVIOUS

SELECT

Settings

Input Labels

Computer Settings

Parental Controls

Closed Caption

Time

Menu Language English

Auto Input Senstin On

System Info

Reset to Default

Set options for when a computer is connected to the TV


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

23

Insignia 24" LCD TV

www.insigniaproducts.com

•Picture Mode—Selects the picture mode. You

can select:

•Vivid—(a bright and vivid picture).

Significantly increases the contrast,

brightness, and sharpness. This selection is

good for video games, animation, and in

bright light environments.

•Standard—(a standard picture).

Moderately increases the contrast,

brightness, and sharpness. This selection is

good for standard TV broadcasts.

•Energy Savings—(the backlight

brightness is decreased). Your TV has a

backlight that provides light for displaying

a picture. By reducing the amount of light,

your TV uses less energy.

•Theater—(a finely detailed picture).

Adjusts the brightness and contrast and

lowers the sharpness for a more realistic

picture. This selection is good for watching

the highest quality video such as Blu-ray

Discs, DVDs, and HDTV.

•Custom—(customized picture). Lets you

manually adjust picture settings such as

brightness, contrast, and sharpness.

•Brightness—Adjusts the brightness of the

dark areas of the picture.

•Contrast—Adjusts the brightness of the light

areas of the picture.

•Color—Adjusts the color intensity of the

picture. A low setting may make the color look

faded. A high setting may make the color look

artificial.

•Tint—Adjusts the color balance of the picture.

Use this control to make skin tones look more

natural.

•Sharpness—Adjusts the color detail of

images. If you set this control too high, dark

images may appear with light or white edges.

•Advanced Video—Opens the

Picture-Advanced Video menu where you can

adjust additional video options.

•Backlight—Sets the overall brilliance of

the screen. When Dynamic Backlight

(DCR) is turned on, you cannot change the

Backlight setting.

•Aspect Ratio—Selects the aspect ratio of

the picture.

•Color Temperature—Selects the color

temperature. You can select Cool (to

enhance the blues), Normal, or Warm (to

enhance the reds).

•Overscan—Adjusts the picture’s

reproduction rate. You can select On or

Off.

•Noise Reduction—Selects the noise

reduction mode to reduce picture noise

(snow). You can select Low, Middle, High,

or Off.

•Adaptive Contrast—Automatically

adjusts picture detail and brightness. You

can select On or Off.

•Dynamic Backlight (DCR)—Enhances the

contrast ratio between light and dark areas

of the picture. You can select Off, Low, or

High.

•Reset Picture Settings—Resets all picture

settings to factory mode.

4Press W or X to adjust the option, or press S or

T to select a setting.

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Note

You can also press PICTURE to select the picture

mode.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Picture . Advanced Video

Aspect Ratio

Overscan

Color Temperature

Noise Reduction

Backlight

Adaptive Contrast

Auto

On

Warm

Middle

100

On

Dynamic Backlight(DCR) Off

Adjust to control overall brilliance of the screen


CHANNELS

SETTINGS

PHOTOS

AUDIO

Aspect ratio options Example

Normal:

Displays the original 4:3 aspect

ratio with vertical black bars on

the left and right of the image.

Zoom:

Expands the image to fill the

screen. The top and bottom of

the image may be cropped.

Wide:

Use this option to view content

recorded in a 16:9

(wide-screen) aspect ratio.

Cinema:

Stretches the image at the

edges, but keeps a clear image

in the center.

Auto:

Automatically adjusts the

image based on the screen size

and the TV program.

Note: Auto is only available

when Auto Zoom in the

Channels menu is set to On.

Note

You can also press ZOOM to select the aspect ratio.

24

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Adjusting the computer image

To adjust the computer image:

1Make sure that your TV is in VGA mode. For

more information, see “Selecting the video

input source” on page 20.

2Press MENU. The on-screen menu opens.

3Press W or X to highlight SETTINGS, then press

ENTER. The Settings menu opens.

4Press S or T to highlight Computer Settings,

then press ENTER. The Settings-Computer

Settings menu opens.

5Press S or T to highlight an option, then press

ENTER to access the option. You can select:

•Auto Adjust—Automatically adjusts the

image settings such as position and phase.

•H. Position—Moves the image right or left.

•V. Position—Moves the image up or down.

•Clock—Adjusts the sample frequency.

•Phase—Adjusts the focus of stable images.

•Reset Computer Settings—Resets all

computer settings to factory mode.

6Press W or X to adjust the option, or press S or

T to select a setting.

7Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting the sound

Adjusting sound settings

To adjust sound settings:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight AUDIO, then press T or

ENTER. The Audio menu opens.

3Press S or T to highlight an option, then press

ENTER to access the option. You can select:

•Sound Mode—Selects the sound mode. You

can select:

•Standard—Balances treble and bass. This

setting is good for watching standard TV

broadcasts.

•News—Enhances vocals for TV audio. This

setting is good for watching news

broadcasts.

•Music—Preserves the original sound. This

setting is good for listening to music.

•Theater—Enhances treble and bass for a

rich sound experience. This setting is good

for watching DVDs, Blu-ray discs, and

HDTV.

•Custom—Lets you manually adjust sound

settings.

•Balance—Adjusts the balance between the

left and right audio channels.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

MOVE

OK

ENTER

MENU EXIT

EXIT

PREVIOUS

SELECT

Settings

Input Labels

Computer Settings

Parental Controls

Closed Caption

Time

Menu Language English

Auto Input Senstin On

System Info

Reset to Default

Set options for when a computer is connected to the TV


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-

Auto Adjust

Computer Settings

H. Position

V. Position

Clock

Phase

Reset Computer Settings

Adjust to the PC signal timing automatically when ON

00

00

00

00


CHANNELS

SETTINGS

PHOTOS

AUDIO

Note

You can also press AUDIO to select the Sound Mode.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Audio

Sound Mode Standard

Balance 0

Advanced Audio

Reset Audio Settings

Adjust settings to affect sound quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

25

Insignia 24" LCD TV

www.insigniaproducts.com

•Advanced Audio—Opens the

Audio-Advanced Audio menu where you can

adjust additional audio options.

•Bass—Adjusts the low sounds.

•Treble—Adjusts the high sounds.

•TV Speakers—Selects where to play TV

audio. You can select On (default setting)

to play audio through TV speakers, or

select Off to play audio through the

speakers on an external audio system.

•Digital Audio/SPDIF—Sends digital audio

to an external audio system. You can select

PCM (to output audio in 2-channel stereo),

or RAW (to pass through the original

digital audio sound).

•MTS/SAP—(Analog channels only) Selects

the audio mode. You can select:

•MONO—Select this option if there is

noise or static on weak stereo

broadcasts.

•STEREO—Select this option for

programs broadcast in stereo.

•SAP—Select this option to listen to a

secondary audio program, if available.

•Audio Language—(Digital channels only)

Selects an alternate audio language, if

available.

•Reset Audio Settings—Reset all audio

settings to factory defaults.

4Press W or X to adjust the option, or press S or

T to select a setting.

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Playing TV audio only

You can turn off the picture on your TV and listen to

the program audio only.

To play TV audio only:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight CHANNELS, then press

T or ENTER. The Channels menu opens.

3Press S or T to highlight Audio Only, then

press ENTER.

4Press S or T to select On.

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Note

You can also press MTS/SAP one or

more times to select the audio mode.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Audio.Advanced Audio

Adjust low frequency sound


CHANNELS

SETTINGS

PHOTOS

AUDIO

TV Speakers On

Notes

•Audio Only works only when the input source is

TV, and your TV is receiving a broadcast signal.

• To exit audio only mode, press any button.

When you exit audio only mode, the Audio

Only option is automatically reset to Off.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

On

On

Channels

Channel Strength

Auto Zoom

Audio Only

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Play the audio with the picture turned off


CHANNELS

SETTINGS

PHOTOS

AUDIO

26

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Changing channel settings

Automatically scanning for channels

When you scan for channels, your TV searches for

channels with signals and stores the channel

information in the channel list. When you press

CH or CH , your TV goes to the next or

previous channel in the channel list.

If the TV signal source changes, for example you

change from an outdoor antenna to cable TV (no

box), you need to scan for channels.

To automatically scan for channels:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight CHANNELS, then press

T or ENTER. The Channels menu opens.

3Press S or T to highlight Auto Channel Search,

then press ENTER. The Channels-Auto Channel

Search screen opens.

4Press S or T to highlight Antenna, Cable, or

Satellite Box, then press ENTER.

A. If you select Antenna, your TV scans for

available channels. The scan may take several

minutes.

B. If you select Cable, a message asks if you have

a cable box.

• Select No if no cable box is connected.

Your TV scans for available channels. The

scan may take several minutes.

• Select Yes if a cable box is connected. A

message asks how you connected the

cable box to your TV.

• Select AV, Component, or HDMI if you

connected a cable box to your TV using

one of these cables. Read the message,

then press ENTER to close the wizard.

• Select Coaxial if you connected a cable

box to your TV using a coaxial cable.

Read the message, then press ENTER to

start the channel scan (VHF channels

only).

C. If you select Satellite Box, a message asks

how you connected the satellite box to your

TV.

• Select AV, Component, or HDMI if you

connected a satellite box to your TV using

one of these cables. Read the message,

then press ENTER to close the wizard.

• Select Coaxial if you connected a satellite

box to your TV using a coaxial cable. Read

the message, then press ENTER to start the

channel scan (VHF channels only).

Hiding channels

You can hide channels in the channel list. When you

press CH or CH , your TV skips the hidden

channels. You can still tune to a hidden channel by

pressing the number buttons for the channel.

To hide channels:

1Press MENU. The on-screen menu opens.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

On

On

Channels

Channel Strength

Audio Only

Audio Zoom

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Automatically search for channels


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Choose Your TV source

Antenna

Cable

Satellite Box

Select if using an antenna for standard or HD TV.

Channels-

Auto Channel Search


CHANNELS

SETTINGS

PHOTOS

AUDIO

Note

You can press EXIT to stop the auto channel search,

but you will need to run the auto channel search

again to create a channel list.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

27

Insignia 24" LCD TV

www.insigniaproducts.com

2Press W or X to highlight CHANNELS, then press

T or ENTER. The Channels menu opens.

3Press S or T to highlight Add/Skip Channels,

then press ENTER. The Channels-Add/Skip

Channels screen opens.

4Press S T W or X to highlight the channel you

want to hide, then press ENTER. The check mark

disappears.

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Setting up a favorite channel list

You can create a favorite channel list so you can

quickly browse through your favorite channels by

pressing FAVORITE, then selecting a channel from

the favorite channel list.

To set up a favorite channel list:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight CHANNELS, then press

T or ENTER. The Channels menu opens.

3Press S or T to highlight Favorites, then press

ENTER. The Channels-Favorites screen opens.

Notes

• A channel with a check mark is not hidden. A

channel with no check mark is hidden.

• If the list has more than one page, press S or T

to scroll through the pages.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Off

Channels

Channel Strength

Audio Only

On

Audio Zoom

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Manually add and skip channels in your program list


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Manually add and skip channels in your program list

Channels- Add/Skip Channels

2.1 WGBH-SD

2.10 WGBH-DX

6 Analog

12 Analog

19 Analog

28 Analog

1.1 Ch1

2.2 PBS-HD

3 Analog

7 Analog

14 Analog

21 Analog

43 Analog

1.2 Sencore


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Channels

Add channels to create a favorite list

Off

On

Channel Strength

Audio Only

Audio Zoom

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Favorites

Channels-

Favorites

2.1 WGBH-SD

2.10 WGBH-DX

6 Analog

12 Analog

19 Analog

28 Analog

1.1 Ch1

2.2 PBS-HD

3 Analog

7 Analog

14 Analog

21 Analog

43 Analog

1.2 Sencore


CHANNELS

SETTINGS

PHOTOS

AUDIO

28

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

4Press S T W or X to highlight the channel you

want to add to the favorites list, then press

ENTER. A check mark appears next to the

channel.

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Viewing a favorite channel

To view a favorite channel:

1Press FAVORITE. The favorite channel list opens.

2Press S or T to highlight a channel, then press

ENTER.

Adding or changing a channel label

If a channel is not already labeled, you can label the

channel to make it easier to identify. You can also

relabel a channel that is already labeled.

To add or change a channel label:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight Channels, then press

T or ENTER. The Channels menu opens.

3Press S or T to highlight Channel Labels, then

press ENTER. The Channels-Channel Labels

screen opens with the channel number field

highlighted.

4Press S or T to select the channel you want to

label, then press X to move to the channel label

field.

5Press S or T to select a character, then press W

or X to move to the previous or next character

position. Repeat this step to enter additional

characters. You can enter as many as 11

characters.

6When you have completed the label, press

MENU.

7Press EXIT to close the menu.

Checking the digital signal strength

You can check the digital signal strength to

determine if you need to adjust your antenna or

digital cable input. The higher the signal strength,

the less likely you are to experience picture

degradation.

To check the digital signal strength:

1Press MENU. The on-screen menu opens.

Notes

• To remove a channel from the favorites list,

highlight the channel, then press ENTER. The

check mark disappears and the channel is

removed from the list.

• If the list has more than one page, press S or T

to scroll through the pages.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Off

Channels

Channel Strength

Audio Only

On

Audio Zoom

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Create labels for channels, up to 11 characters

Use blank character to create a space.


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Channels-

Channel Labels

CH 2.0

Create labels for channels, up to 11 characters

Use blank character to create a space.

S e n c o r s


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Channels-

Channel Labels

CH 2.0

Create labels for channels, up to 11 characters

Use blank character to create a space.

S e n c e r e


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

29

Insignia 24" LCD TV

www.insigniaproducts.com

2Press W or X to highlight CHANNELS, then press

T or ENTER. The Channels menu opens.

3Press S or T to highlight Channel Strength,

then press ENTER. The signal strength meter is

displayed.

4Press MENU to return to the previous menu, or

press EXIT to close the menu.

Setting parental controls

Setting or changing the password

Parental controls let you prevent your children from

watching inappropriate material on TV. When set,

parental controls read the rating of the program

(with some exceptions, such as news and sports)

and deny access to programs that exceed the

ratings level you select. To watch programs that

exceed the selected rating, you must enter a

password.

To set or change the password:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens with

Parental Controls highlighted.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter the four-digit

password. The default password is 0000. You

should change the password to a number you

can remember. The Settings-Parental Controls

menu opens.

5Press S or T to highlight Change Password,

then press ENTER. The Settings-Parental

Controls-Change Password screen opens.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Off

Channels

Channel Strength

Audio Only

On

Audio Zoom

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Display signal strength of selected digital channels


CHANNELS

SETTINGS

PHOTOS

AUDIO

Now 67%

0100

Peak 67%

Channel Strength

CH 2

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set TV parental controls

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Parental Controls

Enter your 4-digit password. Default is 0000. Please change your

password.

Enter Password


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-

Parental Controls

Change Password

Button Lock

Block Unrated TV

USA Parental Locks

Canadian Parental Locks

Enter a new 4-digit password then re-enter it to confirm

Off

Off

RRT5

Reset RRT5


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-

Parental Controls-Change Password

Enter New Password

Enter a new 4-digit password then re-enter it to confirm


CHANNELS

SETTINGS

PHOTOS

AUDIO

Confirm new password

30

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

6Press the number buttons to enter a password,

then enter the password again.

7Press MENU to return to the previous menu, or

press EXIT to close the menu.

Locking control buttons

When the button lock is turned On, the buttons on

the side of your TV are locked, and you can only

operate your TV using the remote control.

To lock control buttons:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens with

Parental Controls highlighted.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter the four-digit

password. The Settings-Parental Controls menu

opens with Button Lock highlighted.

5Press ENTER.

6Press S or T to select On (locks the buttons) or

Off (unlocks the buttons).

7Press MENU to return to the previous menu, or

press EXIT to close the menu.

Blocking unrated TV

To block unrated TV:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens with

Parental Controls highlighted.

Note

If you forget your password, enter 9999.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set TV parental controls

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Parental Controls

Enter your 4-digit password. Default is 0000. Please change your

password.

Enter Password


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Parental Controls

Change Password

Button Lock

Block Unrated TV

USA Parental Locks

Canadian Parental Locks

Lock the buttons on the TV and only operate the TV with the

remote control

Off

RRT5

Reset RRT5

On

Off


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set TV parental controls

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

31

Insignia 24" LCD TV

www.insigniaproducts.com

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter the four-digit

password. The Settings-Parental Controls menu

opens.

5Press S or T to highlight Block Unrated TV,

then press ENTER.

6Press S or T to select On (to block unrated TV)

or Off (to unblock unrated TV).

7Press MENU to return to the previous menu, or

press EXIT to close the menu.

Setting parental control levels

You can set parental controls for the U.S. and

Canada.

U.S. rating levels

Some of the age-based TV Parental Guidelines

ratings also have content-based ratings.

Canadian rating levels

U.S. TV ratings

NONE Not rated

TV-Y All children

TV-Y7 Suitable for children 7 and older

TV-G General audiences

TV-PG Parental guidance suggested

TV-14 Parental guidance strongly suggested

TV-MA Mature audiences only

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Parental Controls

Enter your 4-digit password. Default is 0000. Please change your

password.

Enter Password


CHANNELS

SETTINGS

PHOTOS

AUDIO

MOVE

OK

ENTER

MENU EXIT

EXIT

PREVIOUS

SELECT

Settings- Parental Controls

Change Password

Button Lock

Block Unrated TV

USA Parental Locks

Canadian Parental Locks

Do not block TV programs that do not have a rating

RRT5

Reset RRT5

Off

On

Off


CHANNELS

SETTINGS

PHOTOS

AUDIO

U.S. TV content ratings

All All ratings are blocked

FV Fantasy violence

LStrong language

SSexual situations

VViolence

DSuggestive dialog

U.S. movie (MPAA) ratings

None Movie not rated

GGeneral audiences

PG Parental guidance suggested

PG-13 Suitable for children 13 and older

R Parental guidance suggested for

children under 17

NC-17 Not suitable for children under 17

X Adults only

Canadian English ratings

EExempt programming

CSuitable for all children

C8+ Suitable for children 8 and older

GGeneral audiences

PG Parental guidance suggested

14+ Suitable for children 14 and older

18+ Adult only

Canadian French ratings

EExempt programming

GGeneral audiences

8ans+ Suitable for children 8 and older

13ans+ Suitable for children 13 and older

16ans+ Suitable for children 16 and older

18ans+ Adult only

32

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

To set parental control levels:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens with

Parental Controls highlighted.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter the four-digit

password. The Settings-Parental Controls menu

opens.

5Press S or T to highlight USA Parental Locks,

then press ENTER. (To set Canadian ratings,

select Canadian Parental Locks.)

USA Parental Locks

Canadian Parental Locks

6Press W or X to highlight:

•Movie Ratings or TV Ratings for USA ratings.

•English Rating or French Rating for Canadian

ratings.

7Press S or T to select the rating. If a rating has

sub-ratings, press W or X to highlight a

sub-rating.

8Press ENTER to confirm. A lock symbol appears

when a rating is blocked.

9Press MENU to return to the previous menu, or

press EXIT to close the menu.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set TV parental controls

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Parental Controls

Enter your 4-digit password. Default is 0000. Please change your

password.

Enter Password


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-

Parental Controls

Change Password

USA Parental Locks

Off

Off

RRT5

Reset RRT5


CHANNELS

SETTINGS

PHOTOS

AUDIO

Note

When you block a rating, that rating and all higher

ratings are blocked.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Parental

Movie

Ratings

TV Ratings

None

G

PG

PG-13

R

NC-17

X

None

TV-Y

TV-Y7

TV-G

TV-PG

TV14


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Canadian

Parental Canadian English

E

C

C8+

G

PG

14+

18+

E

G

8 ans+

13 ans+

16 ans+

18 ans+


CHANNELS

SETTINGS

PHOTOS

AUDIO

33

Insignia 24" LCD TV

www.insigniaproducts.com

Downloading rating information

You can download rating information to use when

setting parental controls.

To download rating information:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens with

Parental Controls highlighted.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter the four-digit

password. The Settings-Parental Controls menu

opens.

5Press S or T to highlight RRT5, then press

ENTER.

If the program is broadcast with RRT5 rating

information, the information is downloaded

automatically and can be used for parental

controls.

6Press MENU to return to the previous menu, or

press EXIT to close the menu.

Using closed captioning

Turning closed captioning on or off

To turn closed captioning on or off:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set TV parental controls

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Parental Controls

Enter your 4-digit password. Default is 0000. Please change your

password.

Enter Password


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

SETTINGS-

Parental Controls

Change Password

Button Lock

Block Unrated TV

USA Parental Locks

Canadian Parental Locks

Off

Off

RRT5

Reset RRT5


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Adjust Closed Captioning settings

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

34

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

3Press S or T to highlight Closed Caption, then

press ENTER. The Settings-Closed Caption menu

opens.

4Press S or T to highlight Caption Control, then

press ENTER. A menu opens.

5Press S or T to select CC Off (turns off closed

captioning), CC On (turns on closed captioning),

or CC on Mute (turns on closed captioning

when the sound is muted).

6Press MENU to return to the previous menu, or

press EXIT to close the menu.

Selecting the analog closed captioning mode

To select the analog closed captioning mode:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

3Press S or T to highlight Closed Caption, then

press ENTER. The Settings-Closed Caption menu

opens.

4Press S or T to highlight Analog Caption, then

press ENTER. A menu opens.

5Press S or T to select an analog caption setting.

You can select:

•CC1 through CC4—Closed captioning

appears in a small banner across the bottom

of the screen. CC1 is usually the “printed”

version of the audio. CC2 through CC4 display

content provided by the broadcaster.

•Text1 through Text4—Closed captioning

covers half or all of the screen. Text1 through

Text4 display content provided by the

broadcaster.

6Press MENU to return to the previous menu, or

press EXIT to close the menu.

Customizing digital closed captioning styles

To customize digital closed captioning styles:

1Press MENU. The on-screen menu opens.

Note

You can also press CCD to turn closed captioning on

or off.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings- Closed Caption

Analog Caption

Digital Caption

Digital CC Settings

CC1

CS1

Caption Control CC Off

Adjust Closed Captioning settings


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Adjust Closed Captioning settings

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-

Closed Caption

Analog Caption

Digital Caption

Digital CC Settings

CC1

CS1

Caption Control CC Off

Adjust Closed Captioning for (analog) programs


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-

Closed Caption

Analog Caption

Digital Caption

Digital CC Settings

Caption Control

Adjust Closed Captioning for (analog) programs

CC1

CC2

CC3

CC4

Text1

Text2

Text3

Text4


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

35

Insignia 24" LCD TV

www.insigniaproducts.com

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

3Press S or T to highlight Closed Caption, then

press ENTER. The Settings-Closed Caption menu

opens.

4Press S or T to highlight Digital Caption, then

press ENTER. A menu opens.

5Press S or T to highlight a digital caption

setting, then press ENTER. You can select CS1

through CS6.

6Press MENU to return to the previous menu.

7Press S or T to highlight Digital CC Settings,

then press ENTER. The Settings-Closed

Caption-Digital CC Settings menu opens with

Style highlighted.

8Press ENTER, then press W or X to select

Custom.

9Press S or T to highlight an option, then press

ENTER. You can select:

•Size—Selects the font size.

•Font—Selects the font style.

•Text Color—Selects the color for the words.

•Text Opacity—Selects the opacity level for

the words.

•Background Color—Selects the color for the

background.

•Background Opacity—Selects the opacity

level for the background.

•Edge Effect—Selects the edge style.

•Edge Color—Selects the edge color.

10 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting time settings

Setting the clock

To set the clock:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Adjust Closed Captioning settings

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings- Closed Caption

Analog Caption

Digital Caption

CC1

CS1

Caption Control CC Off

Set Closed Caption for digital programs


CHANNELS

SETTINGS

PHOTOS

AUDIO

MOVE

OK

ENTER

MENU EXIT

EXIT

PREVIOUS

SELECT

Style

Size

Font

Text Color

Text Opacity

Background Color

Background Opacity

Edge Effect

Edge Color

Automatic

Set the look of digital CC. Automatic uses broadcaster’s style


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Menu Language


CHANNELS

SETTINGS

PHOTOS

AUDIO

36

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

3Press S or T to highlight Time, then press

ENTER. The Settings-Time menu opens.

4Press S or T to highlight Date/Time, then press

ENTER. The Settings-Time-Date/Time menu

opens.

5Press S or T to highlight Mode, then press

ENTER. A menu opens.

6Press S or T to highlight Manual (to set the

options manually) or Auto (the options are

automatically set by the TV signal source).

7Press ENTER to close the menu.

8Press S or T to highlight Time Zone, then press

ENTER. The Time-Time Zone menu opens.

9Press S or T to select your time zone, then press

ENTER. You can select Eastern, Central,

Mountain, Pacific, Alaska, Hawaii, Atlantic or

Newfoundland.

10 Press ENTER to close the menu.

11 If your viewing area observes daylight savings

time, press S or T to highlight Daylight

Savings, then press ENTER.

12 Press S or T to select On or Off, then press

ENTER to close the menu.

13 If you selected Manual for Mode:

• Press S or T to highlight Year, Month, or Day,

press W or X to adjust the setting, then press

ENTER.

• Press S or T to highlight Time, press W or X to

highlight the hour, minute, or AM/PM field,

then press S or T to adjust the setting. When

you are finished, press ENTER.

14 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Setting the sleep timer

You can specify the amount of time before your TV

automatically turns off.

To set the sleep timer:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

3Press S or T to highlight Time, then press

ENTER. The Settings-Time menu opens.

4Press S or T to highlight Sleep Timer, then

press ENTER. A menu opens.

5Press S or T to select the amount of time before

your TV turns off automatically. You can select

Off, 5 minutes, 10 minutes, 15 minutes, 30

minutes, 60 minutes, 90 minutes, 120

minutes, 180 minutes, or 240 minutes.

To turn off the sleep timer, select Off.

6Press MENU to return to the previous menu, or

press EXIT to close the menu.

MOVE

OK

ENTER

MENU EXIT

EXIT

PREVIOUS

SELECT

Date/Time

Off


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Day

Mode

Daylight Savings

Y

28

01 : 24 AM

Auto

Off

2009


CHANNELS

SETTINGS

PHOTOS

AUDIO

Note

You can also press SLEEP to set the sleep timer.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Menu Language


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-

Sleep Timer Off


CHANNELS

SETTINGS

PHOTOS

AUDIO

37

Insignia 24" LCD TV

www.insigniaproducts.com

Adjusting menu settings

Selecting the menu language

To select the menu language:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

p

3Press S or T to highlight Menu Language, then

press ENTER. A menu opens.

4Press S or T to highlight a language, then press

ENTER. You can select English, Français, or

Español.

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Turning the input sensor on or off

When the input sensor is turned on, your TV

automatically detects which video jacks have

devices connected to them. Your TV uses this

information to determine what options you can

select on the INPUT SOURCE list when you press

INPUT.

To turn the input sensor on or off:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

3Press S or T to highlight Auto Input Sensing,

then press ENTER. A menu opens.

4Press S or T to select On (turns on the input

sensor) or Off (turns off the input sensor).

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Labeling an input source

You can add a label to an input source to make it

easier to identify.

To label an input source:

1Press MENU. The on-screen menu opens.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language English

On

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set menu language to English, Franais, Español

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language English

On

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Set menu language to English, Franais, Español

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

38

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

3Press S or T to highlight Input Labels, then

press ENTER. The Settings-Input Labels screen

opens with the input source field highlighted.

4Press S or T to select the input source you want

to label, then press X to move to the custom

label field.

5Press S or T to select a character, then press

Wor X to move to the previous or next character

position. Repeat this step to enter additional

characters. You can enter as many as 11

characters.

6When you have completed the label, press

MENU. The next time you press INPUT, your

label will appear in the INPUT SOURCE list.

7Press EXIT to close the menu.

Restoring settings to the defaults

When you restore default settings, all the settings

you have customized (except the password and

parental rating) are reset.

To restore settings to the defaults:

1Press MENU. The on-screen menu opens.

2Press W or X to highlight SETTINGS, then press

T or ENTER. The Settings menu opens.

3Press S or T to highlight Reset to Default, then

press ENTER. A confirmation message opens.

4Press W or X to select Ye s (to reset) or No (to not

reset), then press ENTER.

5Press MENU to return to the previous menu, or

press EXIT to close the menu.

Using a USB flash drive

You can connect a USB flash drive to your TV to

view compatible JPEG pictures.

Switching to USB mode

To switch to USB mode:

1Make sure that you have connected the USB

flash drive to the USB port on your TV.

2Press INPUT. The INPUT SOURCE list opens.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Create labels for the devices connected to your TV

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Input

Labels

TV

Create your own label name

TV


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings-Input

Labels

TV

Create your own label name

TV


CHANNELS

SETTINGS

PHOTOS

AUDIO

Notes

• Never remove the USB flash drive or turn off

your TV while viewing JPEG pictures.

• The JPEG picture viewer only supports JPEG

format images (with “.jpg” file extensions) and

not all JPEG files are compatible with your TV.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select


Picture Mode Energy Savings

Brightness 00

Contrast 00

Color 00

Tint 00

Sharpness 00

Advanced Video

Reset Picture Settings

Adjust settings to affect picture quallty


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Settings

Closed Caption

Time

Menu Language

Auto Input Sensing

Input Labels

Computer Settings

System Info

Reset to Default

Reset to Default

Parental Controls


CHANNELS

SETTINGS

PHOTOS

AUDIO

39

Insignia 24" LCD TV

www.insigniaproducts.com

3Press S or T to highlight USB, then press

ENTER.

Browsing photos

To browse photos:

1Switch to USB mode. See “Switching to USB

mode” on page 38.

2Press MENU. The on-screen menu opens.

3Press ENTER. The Photos menu opens.

4Press S or T to highlight Browse Photos, then

press ENTER. The screen displays folder names

and photo files stored on the USB flash drive in a

thumbnail index with the first photo or folder

highlighted. A control bar appears at the

bottom of the screen.

5To navigate the thumbnail index screen, press:

•S T W or X to browse through the files and

folders.

•ENTER to view a highlighted photo full-screen

or open a highlighted folder.

•MENU to open the Photo menu.

•FAVORITE to add or remove a photo from the

favorite photo list. A heart appears on a photo

that has been added to the favorite photo list.

• Press EXIT to close the control bar.

When a photo is displayed full-screen, a

control bar appears at the bottom of the

photo. The file name, picture resolution, size,

and date are displayed on the bottom of the

control bar. If you do not press a button within

10 seconds, the control bar closes. Press any

button to open the control bar again.

6To navigate on the photo screen, press:

•W or S to go to the previous photo.

•X or T to go to the next photo.

•ENTER to rotate the photo clockwise.

•ZOOM one or more times to enlarge the

image by 1×, 2×, or 4× or to select Fill (to fill

the screen). You can press S T W or X to pan

the photo.

•EXIT to return to the thumbnail index.

•MENU to return to the Photo menu.

Viewing favorite photos

After you created your favorite photo list, you can

browse among your favorite photos quickly.

To view favorite photos:

1Switch to USB mode. See “Switching to USB

mode” on page 38.

2Press MENU. The on-screen menu opens.

Note

To exit USB mode, press INPUT to open the INPUT

SOURCE list, then select another input source, or

press a Quick Launch Input button.

Move

View files from a USB device that is connected to the TV

OK

ENTER

MENU EXIT

Exit

Previous

Select


Photos


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Photos

Browse Photos

Favorite Photos

View Slideshow

Settings

Find photos that are on the USB flash drive.


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Name: xxxxxxxxx.jpg

Resolution: 500 x 375 Size: 72.2 KB Date:

Name: 6081.jpg

OK

ENTER

MENU EXIT

Exit

Previous

Rotate

Move

Resolution: 800 x 600 Size: 163.2KB Date: 2010/12/16

ZOOM

Zoom

Move

View files from a USB device that is connected to the TV

OK

ENTER

MENU EXIT

Exit

Previous

Select


Photos


CHANNELS

SETTINGS

PHOTOS

AUDIO

40

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

3Press ENTER. The Photos menu opens.

4Press S or T to highlight Favorite Photos, then

press ENTER. A thumbnail index of your favorite

photos opens with a control bar at the bottom

of the screen. A heart appears on a favorite

photo.

You select photos and navigate on the photo

screen in the same way you do when you are

browsing through photos. For more

information, see “Browsing photos” on page 39.

Viewing photos in a slideshow

You can view your photos in a slideshow.

To view photos in a slideshow:

1Switch to USB mode. See “Switching to USB

mode” on page 38.

2Press MENU. The on-screen menu opens.

3Press ENTER. The Photos menu opens.

4Press S or T to highlight View Slideshow, then

press ENTER. A slideshow starts with the first

photo in the current folder.

5To control the slideshow, press:

•ENTER to pause or start the slideshow.

•EXIT to exit the slideshow and return to

thumbnail index.

•MENU to go to the PHOTO menu.

Customizing slideshow settings

You can customize the slideshow settings,

including Repeat, Shuffle, Speed, and Transition.

To customize slideshow settings:

1Switch to USB mode. See “Switching to USB

mode” on page 38.

2Press MENU. The on-screen menu opens.

3Press ENTER. The Photos menu opens.

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Photos

Browse Photos

Favorite Photos

View Slideshow

Settings

View only the photos you selected as your favorites


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Name: xxxxxxxxx.jpg

Resolution: 500 x 375 Size: 72.2 KB Date:

Move

View files from a USB device that is connected to the TV

OK

ENTER

MENU EXIT

Exit

Previous

Select


Photos


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Photos

Browse Photos

Favorite Photos

View Slideshow

Settings

View only the photos you selected as your favorites


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

View files from a USB device that is connected to the TV

OK

ENTER

MENU EXIT

Exit

Previous

Select


Photos


CHANNELS

SETTINGS

PHOTOS

AUDIO

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Photos

Browse Photos

Favorite Photos

View Slideshow

Settings

Change slideshow settings


CHANNELS

SETTINGS

PHOTOS

AUDIO

41

Insignia 24" LCD TV

www.insigniaproducts.com

4Press S or T to highlight Settings, then press

ENTER. The Photos-Settings menu opens.

5Press S or T to highlight an option, then press

ENTER. You can select:

•Repeat—Repeats the slideshow when it

reaches the end. You can select On or Off.

•Shuffle—Displays the slideshow photos in

random order. You can select On or Off.

•Speed—Sets the amount of time a photo is

displayed before the slideshow moves to the

next photo. You can select 4Sec, 6Sec, or

8Sec.

•Transition—Selects the way photos transition

when moving to the next file in the slideshow.

You can select:

•None—No transition effect.

•Fade to Black—Fades the screen to black

between photos.

•Vertical Wipe—Wipes the screen from left

to right between photos.

•Horizontal Wipe—Wipes the screen from

top to bottom between photos.

•Random—Randomly selects a transition

effect.

6Press EXIT to close the menu.

Maintaining

• Do not use your TV in areas that are too hot or too

cold, because the cabinet may warp or the screen

may malfunction. Your TV works best in

temperatures that are comfortable to you.

• Storage temperatures are 32° to 122°F (0° to 50°C).

• Working temperatures are 41° to 104°F

(5° to 40°C).

• Do not place your TV in direct sunlight or near a

heat source.

Cleaning the TV cabinet

Clean the cabinet with a soft, lint-free cloth. If the

cabinet is especially dirty, moisten a soft, lint-free

cloth in a weak detergent solution, squeeze the

excess moisture from the cloth, then wipe the

cabinet with the cloth. Use a clean cloth to dry the

cabinet.

Cleaning the TV screen

Clean the screen with a soft, lint-free cloth.

Troubleshooting

Video and audio

Move

OK

ENTER

MENU EXIT

Exit

Previous

Select

Photo- Settings

Repeat

Shuffle

Speed

Transition

Off

Off

4 sec

None

Repeat the slideshow when it reaches the end


CHANNELS

SETTINGS

PHOTOS

AUDIO

Warning

Do not try to repair your TV yourself. Contact

authorized service personnel.

Problem Solution

Picture does not fill the

screen. There are black bars

around the picture.

• Change the aspect ratio. An increasing amount

of digital TV and movies are presented in wide

screen (16:9). See “Aspect ratio options” on

page 23.

No picture (screen is not lit)

and no sound. • Press on the TV or the remote control.

• Make sure that the Audio Only option is set to

Off. See “Playing TV audio only” on page 25.

• Make sure that the video cables are connected

securely to your TV.

• Adjust the contrast and brightness. See

“Adjusting the TV picture” on page 22.

• Make sure that the power cord is plugged in.

• Make sure that the correct video input source is

selected. See “Selecting the video input source”

on page 20.

• Try another channel. The station may be

experiencing problems.

• Make sure that the incoming signal is

compatible.

• Make sure that the antenna or cable TV is

connected correctly and securely. See

“Connecting a cable or satellite box” on page 9

or “Connecting an antenna or cable TV (no box)”

on page 12.

• Check the closed caption settings. Some TEXT

modes can block the screen.

Dark, poor, or no picture

(screen is lit), but sound is

good.

• Try another channel. The station may be

experiencing problems.

• Make sure that the antenna or cable TV is

connected correctly and securely. See

“Connecting a cable or satellite box” on page 9

or “Connecting an antenna or cable TV (no box)”

on page 12.

• Adjust the brightness. See “Adjusting the TV

picture” on page 22.

• Make sure that the correct picture mode is

selected. See “Adjusting the TV picture” on

page 22.

• If you are using an antenna, the digital channel

signal may be low. To check the digital channel

signal strength, see “Checking the digital signal

strength” on page 28.

• If you are using an antenna and the signal

strength is low, adjust the antenna or use a

highly directional outdoor antenna or set-top

antenna with a built-in amplifier.

• Make sure that the video cables are connected

securely to your TV.

• The video cable(s) you are using may be bad. Try

a new set.

• Try another channel. The station may be

experiencing problems.

42

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

No color, dark picture, or

color is not correct. • Try another channel. The station may be

experiencing problems.

• Adjust the color settings. See “Adjusting the TV

picture” on page 22.

• Make sure that the video cables are connected

correctly and securely to your TV.

• Make sure that the antenna or cable TV is

connected correctly and securely. See

“Connecting a cable or satellite box” on page 9

or “Connecting an antenna or cable TV (no box)”

on page 12.

• If you are using an antenna, the digital channel

signal may be low. To check the digital channel

signal strength, see “Checking the digital signal

strength” on page 28.

• If you are using an antenna and the signal

strength is low, adjust the antenna or use a

highly directional outdoor antenna or set-top

antenna with a built-in amplifier.

Only snow (noise) appears

on the screen. • Try another channel. The station may be

experiencing problems.

• Make sure that the antenna or cable TV is

connected correctly and securely. See

“Connecting a cable or satellite box” on page 9

or “Connecting an antenna or cable TV (no box)”

on page 12.

• If you are using an antenna, the digital channel

signal may be low. To check the digital channel

signal strength, see “Checking the digital signal

strength” on page 28.

• If you are using an antenna and the signal

strength is low, adjust the antenna or use a

highly directional outdoor antenna or set-top

antenna with a built-in amplifier.

Picture quality is good on

some channels and poor on

others. Sound is good.

• The problem may be caused by a poor or weak

signal from the broadcaster or cable TV provider.

• If you connect to cable or satellite TV without a

set-top box and experience poor picture quality,

you may need to install a set-top box to improve

signal reception and picture quality. Contact

your cable or satellite TV provider about

upgrading to a set-top box.

Dotted lines or stripes

appear on the screen. • Make sure that the antenna or cable TV is

connected correctly and securely. See

“Connecting a cable or satellite box” on page 9

or “Connecting an antenna or cable TV (no box)”

on page 12.

• If you are using an antenna, the digital channel

signal may be low. To check the digital channel

signal strength, see “Checking the digital signal

strength” on page 28.

• If you are using an antenna and the signal

strength is low, adjust the antenna or use a

highly directional outdoor antenna or set-top

antenna with a built-in amplifier.

• Make sure that the video cables are connected

securely to your TV.

• The video cable(s) you are using may be bad. Try

a new set.

• Other devices (for example, a surround sound

receiver, external speakers, fans, or hair dryers)

may be interfering with your TV. Try turning off

one device at a time to determine which device

is causing interference. After you have

determined which device is causing

interference, move it further from the TV to

eliminate the interference.

Double images. • Use a highly directional outdoor antenna, cable

TV, or satellite TV.

Problem Solution

The picture has a few bright

or dark spots. • A few bright or dark spots on an LCD screen is

normal. It does not affect the operation of

your TV.

Good picture, but no sound. • Increase the volume.

• Make sure that the sound is not muted.

• Make sure you do not have headphones

connected. When headphones are connected,

no sound comes from the TV speakers.

• Make sure that the correct audio mode is

selected.

• Make sure that the audio cables are connected

correctly and securely to your TV.

• Make sure that the antenna or cable TV is

connected correctly and securely. See

“Connecting a cable or satellite box” on page 9

or “Connecting an antenna or cable TV (no box)”

on page 12.

• If you are using an antenna, the digital channel

signal may be low. To check the digital channel

signal strength, see “Checking the digital signal

strength” on page 28.

• The audio cable(s) you are using may be bad. Try

a new set.

Poor picture. • Make sure that the room is not too bright. Light

reflecting off the screen can make the picture

difficult to see.

• If an S-VHS camera or a camcorder is connected

while another connected device is turned on,

the picture may be poor. Turn off one or more

devices.

Good sound but poor color. • Adjust the contrast, color, and brightness

settings. See “Adjusting the TV picture” on

page 22.

Audio noise. • Other devices (for example, a surround sound

receiver, external speakers, fans, or hair dryers)

may be interfering with your TV. Try turning off

one device at a time to determine which device

is causing interference. After you have

determined which device is causing

interference, move it further from the TV to

eliminate the interference.

No output from one of the

speakers. • Adjust the audio balance. See “Adjusting sound

settings” on page 24.

• Make sure that the audio cables are connected

correctly and securely to your TV.

After images appear. • Do not display a still image, such as a logo,

game, or computer image, for an extended

period of time. This can cause a permanent

after-image to be burned into the screen. This

type of damage is not covered by your warranty.

Problem Solution

43

Insignia 24" LCD TV

www.insigniaproducts.com

Remote control

General

USB photo display

Problem Solution

Remote control does not

work. • Make sure that the power cord is correctly

connected to your TV and a power outlet.

• Make sure that there are no obstructions

between the remote control and the remote

control sensor on the front of the TV.

• Point the remote control directly at the remote

control sensor on your TV. For the location of the

remote control sensor, see “Aiming the remote

control” on page 18.

• The supplied batteries are wrapped tightly in

clear plastic. Make sure that you have removed

this plastic from the batteries.

• Make sure that the batteries are installed

correctly. See “Installing remote control

batteries” on page 18.

• Replace dead batteries with new batteries. See

“Installing remote control batteries” on page 18.

Trouble programming your

existing universal remote

control.

• See instructions and a table of common codes in

“Programming a different universal remote

control” on page 45.

• Codes are subject to change. For up-to-date

codes, go to

www.insigniaproducts.com/remotecodes

• Replace dead batteries with new batteries. See

“Installing remote control batteries” on page 18.

• Refer to the User Guide that accompanied your

universal remote control and contact the

manufacturer if problems persist.

Problem Solution

No power. • Make sure that the power cord is correctly

connected to your TV and a power outlet.

• Unplug the power cord, wait 60 seconds, then

plug the cord back in and turn on your TV.

• Other devices (for example, a surround sound

receiver, external speakers, fans, or hair dryers)

may be interfering with your TV. Try turning off

one device at a time to determine which device

is causing interference. After you have

determined which device is causing

interference, move it further from the TV to

eliminate the interference.

“No signal” error

message is displayed. •Press INPUT and make sure that you have

selected the correct input for the device or

service you are trying to use.

• If you are using a cable or satellite box, use the

remote that came with that box to change

channels.

• Make sure that you have the correct input

selected to view channels from the cable or

satellite box.

After Auto Channel

Search, there are no

channels.

• Reception can vary by channel depending on the

broadcast power level of a given station. Contact

your cable or satellite TV provider.

• Make sure that the antenna or cable/satellite TV

is connected securely to your TV.

• Try replacing the cable between the

antenna/cable or cable/satellite box and your

TV.

One or more channels

do not display. • Make sure that the channels are not blocked. See

“Setting parental control levels” on page 31.

• Make sure that the channels are not hidden. The

channel may have been deleted from the

channel list. You can tune to the channel by

pressing the number buttons or you can add the

channel back to the channel list. See “Hiding

channels” on page 26.

• If you are using a cable or satellite box, use the

remote that came with that box to change

channels.

• Make sure that you have the correct input

selected to view channels from the cable or

satellite box.

• If you are using an antenna, the digital channel

signal may be low. To check the digital channel

signal strength, see “Checking the digital signal

strength” on page 28.

Password is lost. •Enter 9999 to access parental controls, then set

a new password. See “Setting or changing the

password” on page 29.

Some settings cannot be

accessed. • If a setting is grayed, the setting is not available

in the current video input mode.

TV cabinet creaks. • When the TV is in use, the temperature rises

naturally and may cause the cabinet to expand

or contract which can cause a creaking noise.

This is not a malfunction.

Control buttons do not

work. • Make sure that the Button Lock option is set to

Off. See “Locking control buttons” on page 30.

• Unplug the power cord, wait a few seconds, then

plug the cord back in and turn on your TV.

TV keeps turning off. • Make sure that the sleep timer is not turned on.

See “Setting the sleep timer” on page 36.

Problem Solution

Photos are not displayed • Make sure that your USB flash drive is connected

securely to the USB jack on the back of your TV.

See “Connecting a USB flash drive” on page 16.

•Press INPUT and make sure that USB (Photos)

is selected. See “Selecting the video input

source” on page 20.

• Make sure that the photos on the USB flash drive

are JPEG image files with “.jpg” as the file

extension.

Slideshow does not start • Make sure that you select slideshow when you

are in thumbnail mode. See “Viewing photos in

a slideshow” on page 40.

Note

If the problem is not solved by using these

troubleshooting instructions, turn off your TV, then

turn it on again.

Problem Solution

44

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Specifications

Specifications are subject to change without notice.

Dimensions and weight

Screen

Display resolutions

Tuner

Inputs

Outputs

Audio

Power

Miscellaneous

Without stand 23.03 × 3.98 × 15.59in. (58.5 × 10.1 × 39.6 cm)

10.56 lbs. (4.8 kg)

With stand 23.03 × 7.87 ×17.17 in. (58.5 × 20 × 43.6 cm)

11.22 lbs. (5.1 kg)

Screen size measured

diagonally 23.6 in.

Display type LCD

Panel 60 Hz vs.120 Hz 60Hz

Display resolution 1080p

Panel resolution 1920 (H) × 1080 (V)

Aspect ratio 16:9

Contrast ratio (typical)–panel 800:1

Dynamic contrast ratio–

list value 3000:1

Brightness (center typical)

cd/m2 300 nits

Comb filter 3d y/c digital

Response time 6 ms

Horizontal viewing angle 160

Vertical viewing angle 150

HDMI 1.3 1080p, 1080i, 720p, 480p, 480i

Component video 1080i, 720p, 480p, 480i

Analog NTSC

Digital ATSC, 8-VSB, Clear-QAM

HDMI 2 (back)

E-EDID compliant

HDCP compliant

Component video 1 (back)

Composite video 1 (back)

Shared audio (component

and composite) Yes

S-Video No

PC/VGA 1 (back)

3.5mm PC audio input 1 (back)

USB 1 (back)

Support JPEG and firmware upgrade

Video No

Analog audio No

Digital audio 1 coaxial (back)

WiFi No

Ethernet No

Headphone 1 (back)

Speakers Number: 2

Watts per channel: 3W

Power consumption On: 58 W

Standby: <1W

Power input 120V/60Hz

OSD languages English, French, Spanish

INlink No

Game Mode No

ENERGY STAR qualified No

Internet connectable No

TV base screws No

V-Chip (version 2.0) Yes

Sleep timer Yes

Channel labeling Yes

VESA mount (mm)

(horizontal × vertical)

200 × 100

Note

The length of the wall-mount screws vary depending on the

wall-mount bracket you purchased. See the instructions that

came with the wall-mount bracket for screw lengths.

45

Insignia 24" LCD TV

www.insigniaproducts.com

Programming universal

remote controls

Programming a different universal remote

control

You can operate your Insignia TV with a new or

existing universal remote control.

To program a different universal remote control:

1See the table in “Common universal remote

control codes” for common codes. If you have

problems programming your remote or need a

different remote control code, visit

www.insigniaproducts.com/remotecodes for

the latest remote control code information.

2Follow your universal remote control’s

instructions to enter the TV code you found in

Step 1.

For additional help and information:

•Visit:

http://www.insigniaproducts.com/remotecodes

• Call technical support for the universal remote

control or cable/satellite company of the

remote/set-top box you are trying to program.

• Call the Insignia Customer Care Center

1-877-467-4289.

Common universal remote control codes

The following is a list of the most common remote

control codes. Codes for other remote controls are

available online at:

http://www.insigniaproducts.com/remotecodes

or check with your cable or satellite TV provider for

the remote control code.

Insignia TV codes for universal remote controls (for all

Insignia TVs manufactured after Jan. 1, 2007)

Tips

• If your universal remote control has a code

search feature, run a code search to identify a

code that matches your TV. See your universal

remote control’s instructions for details.

• If your universal remote control has a “Learn”

feature, you can manually program it using the

Insignia TV remote to “teach” the commands

one at a time. See your universal remote

control’s instructions for details.

Universal remote control makes and models

One for All 0054

Phillips 0198, 0490

RCA 135

Sony 068, 069, 078, 096, 100, 164, 168, 229,

026

Set-top box makes and models

Cablevision 068, 069, 078, 096, 100, 164, 168, 229,

026

Charter

2002, 1204, 1423, 1517, 0171, 1963,

0463, 1463, 0842, 1326, 167, 415, 424,

450, 456, 461, 507, 523, 567, 577, 586

Comcast

10171, 11204, 11326, 11463, 11517,

11641, 11780, 11785, 11892, 11963,

12002

Cox 1326, 1463

DirectTV 10171, 11204, 11326, 11517, 11564,

11641, 11963, 12002

Dish Network 720

Time Warner 400, 450, 461, 456, 10463, 1463, 0463

TiVo 0091

Verizon 0198, 0490

Tips

• The brand name is often visible on the front of

the universal remote control, and the model

number is often visible on the back.

• If your universal remote control isn’t listed on

the chart, refer to your universal remote

control’s instructions and try codes for the

brands Orion, Emerson, Memorex, Sansui,

Sylvania, or Zenith. You may need to try several

codes before finding a match.

46

NS-24L240A13 Insignia 24" LCD TV

www.insigniaproducts.com

Legal notices

FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation of

this product is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device

must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and found to comply within the

limits for a class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician

for help.

FCC warning

Changes or modifications not expressly approved by the party

responsible for compliance with the FCC Rules could void the

user’s authority to operate this equipment.

Cables

Connections to this device must be made with shielded cables

with metallic RF/EMI connector hoods to maintain compliance

with FCC Rules and Regulations.

Canada ICES-003 statement

This Class B digital apparatus complies with Canadian ICES-003.

Standard Television Receiving Apparatus — Appareil de

réception télévision ordinaire, Canada BETS-7 / NTMR-7

Dolby License Notice and Trademark Acknowledgement

Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol

are trademarks of Dolby Laboratories.

HDMI

HDMI, the HDMI logo, and High-Definition

Multimedia Interface are trademarks or

registered trademarks of HDMI Licensing LLC.

47

Insignia 24" LCD TV

www.insigniaproducts.com

One-year limited warranty -

Insignia Televisions

Definitions:

Insignia Products (“Insignia”) warrants to you, the original

purchaser of this new Insignia-branded television (“Product”),

that the Product shall be free of defects in the original

manufacturer of the material or workmanship for a period of one

(1) year from the date of your purchase of the Product (“Warranty

Period”). For this warranty to apply, your Product must be

purchased in the United States or Canada from a Best Buy or

Future Shop authorized dealer of Insignia brand products only

that are packaged with this warranty statement.

How long does the coverage last?

The Warranty Period lasts for 1 year (365 days) from the date you

purchased the Product. Your purchase date is printed on the

receipt you received with the Product.

What does this warranty cover?

During the Warranty Period, if the original manufacture of the

material or workmanship of the Product is determined to be

defective by an authorized Insignia repair center or store

personnel, Insignia will (at its sole option): (1) repair the Product

with new or rebuilt parts; or (2) replace the Product at no charge

with new or rebuilt comparable products or parts. Products and

parts replaced under this warranty become the property of

Insignia and are not returned to you. If service of Products or

parts are required after the Warranty Period expires, you must

pay all labor and parts charges. This warranty lasts as long as you

own your Insignia Product during the Warranty Period. Warranty

coverage terminates if you sell or otherwise transfer the Product.

How to obtain warranty service?

If you purchased the Product at a Best Buy or Future Shop retail

store location and your television Product has a screen size of

less than 42 inches, please take your original receipt and the

Product to any Best Buy or Future Shop store. Make sure that you

place the Product in its original packaging or packaging that

provides the same amount of protection as the original

packaging. If you purchased the Product from a Best Buy or

Future Shop online web site, mail your original receipt and the

Product to the address listed on the web site. Make sure that you

put the Product in its original packaging or packaging that

provides the same amount of protection as the original

packaging.

To obtain in-home warranty service for a television with a screen

42 inches or larger, in the United States call 1-888-BESTBUY,

Canada call 1-866-BESTBUY for Future Shop call 1-800-663-2275.

Call agents will diagnose and correct the issue over the phone or

will have a Insignia-approved repair technician dispatched to

your home.

Where is the warranty valid?

This warranty is valid only in the United States and Canada at

Best Buy or Future Shop branded retail stores or websites to the

original purchaser of the product in the county where the

original purchase was made.

What does the warranty not cover?

This warranty does not cover:

• Customer instruction/education

• Installation

•Set up adjustments

•Cosmetic damage

• Damage due to acts of God, such as power surges

•Accident(s)

•Misuse

•Abuse

• Negligence

• Commercial purposes/use, including but not limited to use

in a place of business or in communal areas of a multiple

dwelling condominium or apartment complex, or

otherwise used in a place of other than a private home.

• Modification of any part of the Product, including the

antenna

• Plasma display panel damaged by static (non-moving)

images applied for lengthy periods (burn-in).

• Damage due to incorrect operation or maintenance

• Connection to an incorrect voltage or power supply

• Attempted repair by any person not authorized by Insignia

to service the Product

• Products sold “as is” or “with all faults”

• Consumables, including but not limited to batteries (i.e. AA,

AAA, C etc.)

• Products where the factory applied serial number has been

altered or removed

• Loss or Theft of this product or any part of the product

• Up to three (3) pixel failures (dots that are dark or

incorrectly illuminated) grouped in an area smaller than

one tenth (1/10) of the display size or up to five (5) pixel

failures throughout the display. (Pixel based displays may

contain a limited number of pixels that may not function

normally.)

• Failures or Damage caused by any contact including but

not limited to liquids, gels or pastes.

REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS

YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA

SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR

CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS

OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT

NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT,

LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES

NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE

PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE

PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED

WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN

DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND

NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY

AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND

JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN

IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT

APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY

FROM STATE TO STATE OR PROVINCE TO PROVINCE.

Contact Insignia:

For customer service please call 1-877-467-4289

www.insigniaproducts.com

Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richfield, Minnesota, U.S.A.

55423-3645

© 2012 BBY Solutions, Inc.

All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc.

Registered in some countries. All other products and brand

names are trademarks of their respective owners.

www.insigniaproducts.com (877) 467-4289

Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richfield, MN 55423-3645 USA

© 2012 BBY Solutions, Inc.

All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries.

All other products and brand names are trademarks of their respective owners. ENGLISH

11-1284
