INSTANT HOT WATER DISPENSERS

Submittal Sheet

Stainless Steel Tank dispenses filtered

near-boiling 200°F water instantly.

•

•

Form No. HWD 301-05H-19-12

The Emerson logo is a trademark and

a service mark of Emerson Electric Co.

In-Sink-Erator is a division of

Emerson Electric Co.

©IN-SINK-ERATOR Printed in USA

Job Specifications

Stainless Steel Tank with F-201 Filtration System*

Model SST-FLTR

DRAIN PLUG

ADJUSTABLE

THERMOSTAT

11"

6.125"

Dimensions

DEPTH IS 6.75"

Specifications

Capacity

Electrical

Thermostat

Insulation

Shipping Weight

gallon tank

dispenses 60 cups of

200ºF water per hour

120 volts A.C., 750

watts, 6.25 amp

heating element

with grounded

three (3) prong

plug

Snap-action,

adjustable from

160ºF to 210ºF

(factory pre-set

at 200ºF)

Meets U.L. 94HF-1

flammability

specification

Recommended

Supply Pressure

30-125 psi

Approximately

4.2 lbs.

• F-201 Filtration System included for

fresher tasting water

• 35% more near-boiling water from larger

gallon stainless steel tank

• Easy to adjust temperature control

• Tool-free tank connections and dry start

protection to ease installation

• Provides 60 cups/hour of near-boiling water

• 3-Year We Come To You™ In-Home

Service Warranty*

• 120 volts, 750 watts, 6.25 amps

• For use with In-Sink-Erator Series 1100 and

other dispenser models (Not for use with Model Hot1)

* The complete In-Sink-Erator warranty is

included in the Installation, Care & Use Booklet

packed with each unit.

Sample Specification

• Capacity: gallon tank dispenses 60 cups of

200°F water per hour

• Electrical: 120 volts A.C., 750 watts, 6.25 amp

heating element with grounded three (3)

prong plug

• Thermostat: Snap action, adjustable from 160°F

to 210°F (factory pre-set at approximately 200°F)

• Insulation: Meets U.L. 94HF-1 flammability

specification

• Shipping Weight: Approximately 4.2 lbs.

• Recommended Supply Pressure: 30-125 psi

To ensure optimum performance, maximum

distance between tank and dispenser head

should be 16" or less.

*Water dispenser sold separately
