Instant Care FSMH01 Fall Sensor 433 Mobile Help User Manual MH433 FS 20170516x
Instant Care, Inc. Fall Sensor 433 Mobile Help MH433 FS 20170516x
Users Manual
1
Fall Sensor MH433-FS
This fall sensor is designed to activate the Control Panel by manual button press or auto fall detection to
summon help in emergency condition.
A. Identifying the Parts
1. Lanyard Loop
2. LED Indicator (Green and Red)
Green LED (Normal Operation)
Flashes twice: Powered On
Light on 2 seconds:
- Active/Pendant Button pressed.
- A Fall Detected.
RED LED ON (Under Low Battery Condition)
Slow Flash 3 times: Powered On
Flashes 2 for seconds:
- Active/Pendant Button pressed.
- A Fall Detected.
3. Active/Pendant Button
Press once: Activate the Control Panel.
4. Battery Compartment Cover
B. Supervision and Auto Low Battery Detection
The Fall Sensor will transmit supervision signal every 6 hours.
The Fall Sensor will transmit supervision signal every 24 hours under Low Battery.
C. Battery
The Fall Sensor uses one CR2477 3V lithium battery as its power source. The Fall Sensor will check
batter voltage automatically every 6 hours.
D. Learn In Fall Sensor
Step 1. Put the Control Panel into Learn Mode (Please refer to Control Panel manual for detail.)
Step 2. Press the Button on Fall Sensor, a radio signal will be transmitted to the control panel.
Step 3. Please refer to the operation manual of your control panel to complete the learning process.
E. Fall Detection and Alarm Activation
The Fall Sensor transmits a signal to Control Panel whenever it detects a fall. The user may also press the
button to activate an alarm manually.
F. Usage Recommendation
Wear the fall sensor outside of a coat. Do not cover it with any clothes.
Carefully place the fall sensor on a desk when you are not using it in order to avoid triggering a
false alarm.
2
If the fall sensor remains stationary for more than 3 hours, it will enter Sleep Mode. During Sleep
Mode, If movement is detected during sleep mode, the fall sensor will start a 1-minute countdown
to return to normal operation mode. Fall detection function is disabled during the 1-minute timer.
After the 1-minute timer expires, The Fall Sensor will return to normal operation. This function is
designed to allow user to don the Fall Sensor again after removing it for extended period without
activating false alarm.
User may also press the button during the 1-minute period to terminate timer manually and return
Fall Sensor to normal operation.
Due to the nature of fall detection mechanism, fall detection cannot be 100% accurate. False alarm
or detection failure during daily use could not be avoided completely, please utilize the Active
Button to activate alarm manually when needed to ensure safety.
G. Testing
During testing, do not trigger the fall sensor twice within a 10-second interval.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
FCC Caution:
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance may void the user's authority to operate this equipment. (Example - use only
shielded interface cables when connecting to computer or peripheral devices).
