Contents

Manual 8056

Table of Content
User Manual
&2.3 Volume Up (S2)
Increase the volume of ear piece
2.4 Buzzer
A long beep followed by a short beep to remind the user of an incoming call when
the buzzer is turned on.
2.5 Microphone
2.6 Volume Down (S3)
Redial the last dialed number
Decrease the volume of ear piece
2.7 Ear Piece
2.8 LED
There are two LED colors ( green and red) to indicate the state of this Buzzer
Pendant.
2.9 Buzzer On/Off Switch
You can turn on/off your buzzer when necessary.
2.10 Clip (Please refer to Fig.1 and Fig. 3)
Clip the Buzzer Pendant onto your clothes.
2.11 E (Please refer to Fig.1 )
(e.g. Nokia 3650 or equivalent models)
(Please refer to Fig. 2)
Thank you for buying the new Buzzer Pendant, Abe Before
first time use, it is important to charge the battery for 12 hours.
!
!
!
!
!
!
!
Notice: To mute/un-mute the microphone, please press S2 and S3 simultaneously.
.
arpieceholderonclip
II. How to use
1. Charging the battery
Bluetooth CS8056
2. Function (Please refer to Fig. 1)
2.1DCSocket
Charge the battery with AC Adaptor
2.2On/Off(S1)
If you press S1, you can:
Switch on and off
Perform a pairing
Answer a new call
Reject a new call
Make a new call using voice dialing
!
!
Bluetooth
2. Turning on the Buzzer Pendant
3. Turning off the Buzzer Pendant
4. Pairing the Buzzer Pendant with your mobile phone
5. Establishing Link
While the Buzzer Pendant is powered off, press and hold S1 for 2 seconds. A low
tone followed by a high tone will indicate that the Buzzer Pendant has powered on.
Green LED will turn on for 1 second. Afterwards, green LED will flash every 3
seconds.
While the Buzzer Pendant is powered on, press and hold S1 for 5 seconds. A high
tone followed by a low tone will indicate that the Buzzer Pendant is powered off. And
the LED will keep on Red until S1 is released.
4.1 Put the Buzzer Pendant in pairing mode
While the Buzzer Pendant is powered off, press and hold S1 for 4 seconds. Red and
Green LEDs flashing alternately will indicate that the Buzzer Pendant is in Pairing
Mode.
4.2 Put your mobile phone in pairing mode
Follow the operating instructions for your mobile phone to start the pairing
process. Typically, this has to be done by going to a setup or connect menu and then
selecting the options to discover devices. may take several
seconds to establish a connection.
Your phone s display should indicate that it has found the and asks if you
want to pair it. You should confirm this. The phone s display would prompt you for a
passkey or PIN. Enter a sequence of 0000 .
4.3 Pair the Buzzer Pendant with your h mobile phone
The Buzzer Pendant LED will flash Green every 3 seconds, indicating successful
pairing. Usually the phone will also ask whether you want to change the Buzzer
Pendant s name. We recommend you should approve the name and not
change it. You can pair as many Buzzer Pendant and devices as you wish in your
mobile phone.
After Pairing, the mobile phone will show connect then please select YES to
establish the link. Now you are ready to make and answer calls on the Buzzer
Pendant.
Notice: Make sure the Buzzer Pendant is fully charged
Notice: If pairing does not occur as expected. Turn off the Buzzer Pendant and phone
and wait for 10 seconds. Then, turn on the Buzzer Pendant and phone again. Then
repeat all steps from beginning.
Notice: For other phones, please follow their operation manuals to establish the link.
Bluetooth
Bluetooth Bluetooth
Bluetoot
'
'
""
""
'""
"", ""
Bluetooth
CS8056
CS8056
When an incoming call is present, you will hear the ring. Pressing S1 will answer the
call. The green LED will continue to flash fast once every second while the call is in
session.
When you are in session, calls can be transferred from the phone to the
Buzzer Pendant and vice versa.
8.1 From phone to the Buzzer Pendant
Press S1 once, the call will be transferred to the Buzzer Pendant.
8.2 From the Buzzer Pendant to the phone
Please follow the operating instructions of your phone.
9.1 To mute the microphone during an active call
Pressing both S2 and S3 buttons simultaneously for about a second, the microphone
will be muted. A periodic beep tone will be heard while the mute function is active.
6. Clip the Buzzer Pendant onto your clothes
7. Answering Incoming Calls
8. Transferring Calls
9. Muting the microphone
Notice: If the Buzzer is on, then both of your Buzzer and ear piece will ring; If the
Buzzer is off, only your ear piece will ring.
Bluetooth
Bluetooth
Bluetooth
--Turning on the buzzer
If you want to get a buzzer alert when calls are coming, you can turn on the Buzzer
On/Off Switch at the back of the Buzzer Pendant. A long beep followed by a short
beep will indicate an incoming call.
--Turning off the buzzer
If you don't want to get a buzzer alert when calls are coming, just turn off the
Buzzer On/Off Switch.
I. Profile and its function.................................................................................................1
1. Profile.............................................................................................................1
2. Function.............................................................................................................1
II. How to Use..................................................................................................................2
1. Charging the battery.........................................................................................2
2. Turning on the Buzzer Pendant .........................................................................3
3. Turning off the Buzzer Pendant .........................................................................3
4. Pair the Buzzer Pendant with your mobile phone................................................3
5. Establishing Link................................................................................3
6. Clip the Buzzer Pendant onto your clothes..........................................................4
7. Answering incoming calls..................................................................................4
8. Transferring calls................................................................................................4
9. Muting the microphone.......................................................................................4
10. Ending calls.......................................................................................................5
11. Make a new call in two ways..............................................................................5
12. Adjusting the ear piece volume..........................................................................5
13. Battery recharging...............................................................................................6
III.Maintenance and safe use............................................................................................6
IV.Accessories table ........................................................................................................7
FCC Interference statement................................................................................................8
Declaration of conformity....................................................................................................9
Bluetooth
Bluetooth Buzzer Pendant
CS8056 Fig. 1
1. DC Socket
2.On/Off (S1)
3.Volume Up (S2)
4.Buzzer
5.Microphone
6.Volume Down (S3)
7.Ear Piece
8.LED
AC Adaptor
Buzzer Pendant
Fig. 2
(1)
(2) (4)
(3)
I. Profile and its function
1. Profile
http://www.abe-hk.com
TM
2
1
3
4
5
7
8
6
Fig. 3
9
10
11
9.Buzzer On/Off Switch
10.Clip
11. Earpiece holder
on clip
A / C Adaptor Provided
Provided
Accessories Table Description Status
Green LED
dim once every 3 sec
Red LED
dim once every 3 sec
Turn on
Turn off
Under charging
Buzzer
Pendant Fully charged
Green LED on
Red LED on
13. Battery recharging
13.1 Low battery indication
The Buzzer Pendant LED will flash red instead of green when the battery is low.
There will also be a short beep every few minutes.
13.2 Battery recharging
To recharge the battery, connect the charger cable to the Buzzer Pendant . During
recharging, the LED shows a steady red light if the Buzzer Pendant is turned off but
the red light will dim once every 3 seconds while Buzzer Pendant is on.
13.3 Fully charge
When the battery is fully charged, the indicators of red light will change into green. A
steady green light represents the Buzzer Pendant is off and is fully charged.
Green light dims once every 3 seconds represents the Buzzer Pendant is on and
fully charged.
Notice: When the battery level is too low, the Buzzer Pendant will automatically
power off. It cannot be powered on again unless the battery is charged for 5 minutes.
III. Maintenance and safe use
Use dry cloth to clean the Bluetooth Buzzer Pendant!
Do not expose it to liquid or moisture!
Do not expose it to fire or open flames!
9.2 To end the mute function
When the microphone is muted, press on both S2 and S3 buttons simultaneously
will end the mute function and the periodic beep tone will stop.
While a call is in session on the Buzzer Pendant, pressing S1 will disconnect the
call. After the call is disconnected, the green LED will flash normally.
To reject a call
When the Buzzer Pendant rings, press and hold S1 until you hear a long beep tone.
11.1 Using voice dialing
Press S1 on the Buzzer Pendant shortly. After the beep tone on the Buzzer
Pendant, voice dial as you normally would by saying the name of the person on the
Buzzer Pendant. The call will be connected in a few seconds.
Press S1 on the Buzzer Pendant shortly. After the beep tone on the mobile phone,
voice dial as you normally would and the call will be connected in a few seconds.
11.2 Redialing last dialed number
To redial the last dialed number, press and hold S3 for 2 seconds. Short low tones
will indicate an attempt to redial.
While a call is in session, pressing and releasing S2 will increase the earpiece
volume; pressing and releasing S3 will decrease the earpiece volume on the Buzzer
Pendant. There is a key tone to indicate volume increase or decrease.
10. Ending Calls
11. Making a new call in two ways
12. Adjusting the ear piece volume
When using a Bluetooth mobile phone:
When using a mobile phone without Bluetooth built-in and requiring a Bluetooth
dongle :
Notice: Make sure the voice dialing function is probably set up in the mobile phone
and it is within the range of the Buzzer Pendant.
Notice: Make sure the voice dialing function is probably set up in the mobile phone
and it is within the range of the Buzzer Pendant.
Notice: A warning tone will be heard when the volume level reaches its maximum or
minimum.
Disclaimer:
Talk time and stand-by time of the Buzzer Pendant will vary depending on
mobile phone model being used.
Note:
BQB, CE and FCC approved
The word mark and logos are owned by the SIG, Inc. and any use of
such marks by In-Tech Electronics Ltd. is under license. Other trademarks and trade
names are those of their respective owners.
Bluetooth
Bluetooth Bluetooth
(9)(7)(5)
(10)(8)(6)
Note
IV.
Neck Strap
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:

Navigation menu
