Integrated Microwave Technologies 23WBMLT WIDEBAND MICROLITE HD COFDM TRANSMITTER 23WBMLT User Manual 931 0005 000 R

Integrated Microwave Technologies, LLC. WIDEBAND MICROLITE HD COFDM TRANSMITTER 23WBMLT 931 0005 000 R

Contents

Antenna

ANTENNA FACTOR PART NUMBER
ANT-2.4-CW-HWR-SMA
931-0005-000-R
ANTENNA 2.4GHZ
1/2WAV WHIP SMA
KAM 11/23//10
02/24/11
Typical VSWR
™
ANT-2.4-CW-HWR-xxx DATA SHEET
Product Dimensions Description
Features
Electrical Specifications
Ordering Information
HWR Series 1/2-wave center-fed dipole antennas deliver
outstanding performance in a rugged and cosmetically
attractive package. The articulating base allows the
antenna to tilt 90 degrees and rotate 360 degrees. The
antenna's internal counterpoise eliminates external ground
plane dependence and maximizes performance. HWR
Series antennas attach via a standard SMA or Part 15
compliant RP-SMA connector. Custom colors and
connectors are available for volume OEM customers.
5.59”
(142.0)
1.02”
(26.0)
0.32”
(8.2)
Electrical specifications and plots measured on 4.00” x 4.00” reference ground plane
0.39”
(10.0)
4.57”
(116.0)
Polar Plot & Gain Information
Antenna Factor 159 Ort Lane Merlin, OR 97532 www.antennafactor.com
541-956-0931 (phone) 541-471-6251 (fax) Rev 07-27-10
•Internal counterpoise
•Low cost
•Tilts and rotates
•Omni-directional pattern
•Outstanding VSWR
•Rugged & damage-resistant
