1.1 YOUR PHONE
1 GETTING STARTED
Congratulations on your new phone purchase.
This guide will help you quickly come up to speed on the important features
of your phone.
In-box Contents:
• Phone
• Charger
• USB 2.0 cable
Rear-Facing
Camera
3.5mm
Audio Jack
1.0 GETTING STARTED
NOTE: Screen images and icons are simulated for the purpose of this guide. Actual
displays may vary. Instructions in this guide may change depending on the software
version on your device.
Speaker
USB/Power Port
Volume
Power Button
SIM Card Tray
![](/img.php?id=2478300&img=bg4.png)
PAGE : 4
1.2 PHONE BUTTONS
Buttons Press to go back to the previous screen or to close a
menu or dialog box.
Press to return to the center panel of the Home
screen.
Press to display shortcuts to the most recently used
apps.
TIP: Press and hold and then swipe upward to quickly
launch Google in your browser.
Power button Press and hold to turn your phone on. To turn the phone
off, press and hold, then follow the onscreen instructions.
When your phone is on, press to wake your phone or put it
into sleep mode.
Volume Press on the top to increase the volume or on the bottom
to decrease the volume.
TIP: Press either top or bottom to silence an incoming call.
1.3 PHONE SLOTS, PORTS & JACKS
3.5 mm
audio jack
Plug in headphones or other audio device.
USB/Power port Connect USB cord to phone and power adapter to charge
the phone.
NOTE: You can plug the USB cord to phone and connect
to your PC.
SIM Card Tray Insert a SIM card.
Earpiece
1.0 GETTING STARTED
Microphone
Front-Facing Camera
![](/img.php?id=2478300&img=bg5.png)
PAGE : 5
1.5 TURN ON THE PHONE
To turn on the phone:
• Hold down the power button to turn the phone on.
TIP: One press puts your phone into Sleep mode. Pressing and holding allows
you to choose Airplane mode, Silent mode, or Vibrate.
To turn the phone off:
• Hold down the power button and touch Power Off.
1.4 CHARGE THE BATTERY
Before using your phone for the first time, charge the phone for three hours.
To charge the battery:
1. Attach one end of the USB cord to the phone’s USB/Power port and the
other end to the plug.
2. Plug the phone into the wall.
1.4.1 BATTERY TIPS
For the best battery life, let your battery drain down until the battery very low
icon appears in the status bar (usually below 15% charge ) before recharging,
and do not leave your phone plugged in after it is fully charged.
To make your charge last as long as possible:
• Change the screen timeout rate and display brightness
(see Display under Device).
• Disable Wi-Fi when not in use (see Wireless & Networks).
NOTE: For optimal charging, please use the USB cable and charger provided
with the phone.
1.0 GETTING STARTED
Connect this
end to phone’s
USB port.
Plug into wall.
Connect this
end to plug.
Hold down the power button,
then touch Power off to turn
the phone off.
Power Button
![](/img.php?id=2478300&img=bg6.png)
PAGE : 6
1.7 TOUCHSCREEN
Use your fingers on the touchscreen to perform actions, open objects, slide
the screen, and more.
Below are the different ways of interacting with your touchscreen.
• Drag: Touch and hold an object then drag the object to a new location. For
example, drag any icon on the Home screen to a new location.
• Double-tap: Quickly touch the screen twice to zoom in when using the
Gallery or on zoomed-out Browser pages. For example, double-touch a news
site to zoom in on the text.
• Pinch: When using Gallery or zoomed-out Browser pages, place two fingers
on the screen at once, then move your fingers together to zoom out or move
them apart to zoom in. For example, pinch your fingers apart to zoom out of
a news site in the Browser.
• Slide: Quickly move your finger from one edge of the screen to the opposite
edge to scroll the display up, down, left or right. For example, quickly move
your finger from the left side of the Home screen to the right to scroll the
Home screen to a different panel.
• Touch: Touch an object on the screen to select or open it. For example,
touch on the Home screen to open the Phone app.
• Touch and hold: Touch an object on the screen and continue to hold it to
reveal other options. For example, touch and hold an empty spot on the
Home screen to reveal options for adding items to the screen.
• 1.6 SLEEP & WAKE
When your phone is on, you can put the phone in sleep mode and lock your
phone. To save battery life, your phone will go into sleep mode if left idle.
You can wake and unlock your phone when you are ready to use it.
To put the phone in sleep mode:
• Briefly press the Power button.
Your phone goes into sleep mode, without disrupting any running
applications, downloads, or phone calls.
NOTE: If you press the power button for too long, you will see the power off
menu.
To wake the phone:
1. Press the Power button.
2. Place your finger on and slide it all the way to the right.
3. Your phone’s screen will resume display.
NOTE: If your phone is secured, you must enter your password, pin, or pattern
to wake it. See Securing your Phone for more details.
1.0 GETTING STARTED
When the phone is
in sleep mode, and
you want to wake the
phone, press the power
button and then drag
the lock to the right.
![](/img.php?id=2478300&img=bg7.png)
PAGE : 7
2 HOME SCREEN & BASIC FEATURES
The Home screen is a gateway to all of your phone’s applications and
features, and displays whenever you turn on your phone.
TIP: To move an icon, touch and hold the icon, then drag it to a
new location.
To open the Home screen:
• Open the Home screen at any time by pressing the button.
The Home screen is split into five panels, with the center panel displayed
when the Home screen opens.
2.0 HOME SCREEN & BASIC FEATURES
Touch to view all
apps.
Touch to make
a call.
Touch to browse
the web.
Swipe left or
right to see more
panels.
Touch Google to
search the web via
text input tray.
Touch and hold
to change the
wallpaper.
Touch an app to
open it.
Touch to send a
text message.
Touch to view
contacts.
To scroll the Home screen:
• Slide the screen to the left or right.
TIP: The bar at the bottom of the screen indicates which one of the five
panels is displayed.
To quickly access your phone’s main functions:
• Touch to make a call. For more information on calling, see Making &
Answering Calls.
• Touch to see your contacts. For more information on contacts, see
Making & Answering Calls.
• Touch to choose an app from the App Launcher. For more information
on apps and the App Launcher, see Using the App Launcher.
• Touch to send a message. For more information on Messaging, see
Sending & Receiving Messages.
• Touch to browse the web.
![](/img.php?id=2478300&img=bg8.png)
PAGE : 8
2.0 HOME SCREEN & BASIC FEATURES
TIP: Rearrange items on your screen by touching and holding them and then
dragging them to a new location. You can also delete them by touching and
holding and then dragging them to the trash.
You can perform the following actions with folders.
To open a folder Touch the folder. To make a new folder, stack
apps on top of each other in the home screen.
To add items to a folder Drag an item on your Home screen into the
folder.
NOTE: You cannot put shortcuts in a
contact folder.
To remove items from a
folder
Touch and hold an item in the folder,
then release it on the Home screen or on
the trash icon.
To rename a folder Open a folder, then touch and hold the title bar
and enter a new folder name.
2.1 CUSTOMIZING YOUR HOME SCREEN
You can easily customize your Home screen by changing the background
picture (or wallpaper).
To customize your Home screen:
• Touch and hold an empty space on the Home screen, then touch the type of
item you want to add and follow the prompts.
The following types of items are available:
• Gallery allows you to choose photos on your phone to set as the background
image for your screen.
• Social Gallery also allows you to choose photos on your phone.
• Live Wallpapers are animated background images for your screen.
• Wallpapers are static background images for your screen.
![](/img.php?id=2478300&img=bg9.png)
PAGE : 9
2.0 HOME SCREEN & BASIC FEATURES
2.2.1 QUICK SETTINGS
Quickly access many of your phone’s settings from the Notifications screen.
Owner (Your Name): View the quick contact info for the phone’s owner.
Brightness: Adjust the screen’s brightness automatically or select the desired
brightness. For the longest battery life, use the lowest comfortable brightness.
Settings: Access your phone’s settings.
Wi-Fi: Turn on Wi-Fi and configure any desired settings under Advanced Wi-Fi.
3G/4G Service: View the strength of your current 3G/4G connection and your
data usage statistics.
Battery: View the percentage of battery life remaining, along with battery usage
by individual apps.
Airplane Mode: Disable all wireless connections, including Bluetooth wireless
technology and 3G/4G.
Bluetooth: Turn on Bluetooth wireless technology and access settings.
2.2 STATUS & NOTIFICATION ICONS
The status bar at the top of the screen displays important information about
your phone.
To open the notifications panel:
• Drag the status bar to the bottom of the screen.
To respond to a notification:
• Touch a notification in the panel to open its application. For example,
touching a new email notification opens the Email app’s inbox.
To close the notifications panel:
• Drag the status bar back to the top of the screen.
Touch a
notification to
respond.
Drag down
to display
notifications.
Notification icons Status icons
Touch to clear
notifications.
Touch to launch
quick settings.
![](/img.php?id=2478300&img=bga.png)
PAGE : 10
2.0 HOME SCREEN & BASIC FEATURES
2.2.3 NOTIFICATION ICONS
New text or
multimedia message
More notifications
Problem with text
or multimedia
message delivery
Call in progress
New voicemail Call in progress using a
Bluetooth headset
Upcoming event Missed call
Data syncing Call forwarding on
Problem with sign-in or
sync
Song playing
USB storage full Uploading data
Phone connected via
USB cable
Downloading data
System update available Download finished
Phone sharing its
data connection via
USB tethering
Connected to or disconnected
from virtual private network
(VPN)
Phone sharing its data
connection as a Wi-Fi
hotspot
Application update available
Connected to Wireless
Display (WiDi)
Wi-Fi direct on
2.2.2 STATUS ICONS
Below are the status and notification icons you can expect to see.
NOTE: Installed apps may use their own unique notification icons.
Connected to mobile
network Alarm set
Mobile network in use Vibrate mode
Mobile network strength Ringer silenced
Roaming Battery very low
No signal Battery low
No SIM card installed Battery partially drained
Connected to Wi-Fi network Battery full
Bluetooth wireless
technology on Battery charging
Connected to wireless
product featuring
Bluetooth technology
GPS on
Airplane mode Receiving location data from
GPS
Headset plugged in
![](/img.php?id=2478300&img=bgb.png)
PAGE : 11
2.0 HOME SCREEN & BASIC FEATURES
2.3 SEARCH
Search on your phone and on the web with the built-in Search function.
To run a search:
1. Touch the Google search box at the top of the Home screen.
2. Type a search term. As you type, Search displays matching results.
3. Touch a matching result to open it.
2.3.1 SEARCH SETTINGS
You can change the default Search settings.
To change Search settings:
• From the Search screen, press Settings.
Google Now Toggle Google Now On or Off.
Voice Display options for setting language, SafeSearch, and
blocking offensive words.
Phone Search Select which applications to search by default.
NOTE: Only the selected applications will display and be
searched within the Search application.
Privacy and
accounts
Set your location and manage your Google search history.
2.4 SECURING YOUR PHONE
You can configure your phone to require a password, PIN, or pattern to turn it
on or wake it up. Securing your phone can help keep its contents private.
To secure your phone:
1. From the Home screen, touch Security.
2. Touch Screen lock to change the current security lock.
3. Select one of the following settings:
• None disables screen locking.
• Slide lets you drag an icon across the screen to unlock your phone.
• Face Unlock lets you use facial recognition to unlock your phone.
• Voice Unlock lets you use voice recognition to unlock your phone.
• Pattern lets you draw a custom pattern to unlock your phone.
• PIN lets you use a 4- to 16-digit number combination to unlock
your phone.
• Password lets you use a 4- to 16-character password to unlock your
phone. (Password must contain at least one letter.)
NOTE: Once you have selected a lock for your phone, you will need to enter
this lock each time you turn on or wake up your phone.
![](/img.php?id=2478300&img=bgc.png)
PAGE : 12
2.0 HOME SCREEN & BASIC FEATURES
2.5 USING THE APP LAUNCHER
Apps are small programs that add features to your phone. Many apps come
preinstalled, and additional apps can be purchased in the Play Store.
Widgets are apps that run directly on your Home screen, such as a music
player, newspaper, or clock.
You can use the App launcher to easily access all of your installed apps.
To use the app launcher:
• Touch , then touch an app to open it.
To add an app shortcut to the Home screen:
• Touch and hold an app. Once the Home screen displays, drop the app
onto an empty spot on the Home screen.
2.6 USING THE PLAY STORE
Almost any app you can imagine is available for purchase (and often for free)
in the Play Store.
To use the Play Store:
• Touch , then touch .
Search or browse for apps. You will be able to confirm that you want to
purchase an app and see the permissions it requires before installing it on
your phone.
TIP: Google™ Play Store can be used only when Google account is activated.
2. Touch an app to open it.
1. Touch to open the App tray.
2.7 VIEWING RECENTLY USED APPS
You can use the Recent button to easily access all of your recently used apps.
To view recently used apps:
• Touch , then touch an app to open it.
![](/img.php?id=2478300&img=bgd.png)
PAGE : 13
3.0 MAKING & ANSWERING CALLS
The following actions are available while you are on a call:
To hold a call Touch to hold or resume the current call.
To mute a call Touch to mute or unmute the call.
To use speakerphone Touch to turn speakerphone on or off.
Warning! To avoid damage to your hearing, do not
hold the phone against your ear when speakerphone
is turned on.
To use a Bluetooth
headset
Touch to automatically transfer your calls to a
connected Bluetooth headset. For more information,
see Wireless Bluetooth Connection.
To end a call Touch .
3 MAKING & ANSWERING CALLS
The Phone app allows you to make calls and store and find your contacts.
You can move between the phone dialer, call history, contacts, and favorites
by touching the tabs at the top of the Phone app.
3.1 USING THE PHONE TAB
To make a call:
1. From the Home screen, touch .
2. Touch the numbers on the dial pad to dial a number, using to make
corrections.
3. Touch to dial the number.
NOTE: For international calls, first touch and hold 0 to enter + and then dial
the number.
NOTE: You can switch to any application without ending the call. Return to
the phone screen by expanding the notifications bar and touching .
![](/img.php?id=2478300&img=bge.png)
PAGE : 14
3.0 MAKING & ANSWERING CALLS
3.1.2 CALL FORWARDING
You can set the forwarding behavior of your phone when receiving calls.
To set up incoming call forwarding:
1. From the Phone app, press Settings Call forwarding.
2. Touch Always forward to enable or disable.
3. Touch the following options to input a phone number to which each type of
call will be forwarded:
• Always forward
• Forward when busy
• Forward when unanswered
• Forward when unreachable
NOTE: Once set, Call Forward conditional is active will appear on-screen.
3.1.1 CALL WAITING
The Call Waiting feature will notifiy you if the person you are calling is already
on another call.
Outgoing call waiting:
When you call someone who has Call Waiting activated on their phone,
and that person is already on the line in another call, you will see a “Call
waiting...” notification on the screen.
![](/img.php?id=2478300&img=bgf.png)
PAGE : 15
3.0 MAKING & ANSWERING CALLS
The following options are available when on a conference call:
To drop a
participant
Touch Manage, then touch .
To talk privately
to a participant
Touch Manage, then touch . When you are done
talking privately, touch Merge Calls to add the participant
back to the conference call.
To end the call Touch to end the conference call and disconnect
all callers.
3.1.4 VOICEMAIL
When you receive voicemail, the message notification icon appears in the
notifications panel.
To check voicemail:
• Within the Phone app, press and hold the 1 key. (May vary by carrier.)
TIP: You can also open the notifications panel and touch the message
notification.
3.1.3 WORKING WITH MULTIPLE CALLS
You can make another call while on a call.
To add a call:
• While on a call, touch and dial another number.
To move between calls:
• Touch to move between calls.
• To merge calls into a conference call:
• Touch to join two or more calls together into a single conference call.
![](/img.php?id=2478300&img=bg10.png)
PAGE : 16
3.0 MAKING & ANSWERING CALLS
3.3 USING THE CALL LOG TAB
The call log lists calls you have made, missed, and received. You can also call
entries, send messages, and add caller information to contacts.
To use the call log:
• From the Phone app, touch .
The following options are available from the call log.
To see more details Touch an entry.
To call the entry Touch .
To send a text
message
Touch the entry to see more details, then touch
.
For more information on messaging, see Sending &
Receiving Messages.
To add to contacts Touch the entry to see more details, then touch .
For more information on adding contacts, see Using
the Contacts Tab.
To remove an entry
from the call log Touch the entry to see more details, press , then
touch Remove from call log.
To remove all entries
from the call log Press Clear Call Log.
3.2 ANSWERING & REJECTING CALLS
When receiving a call, you will see the following at the bottom of the screen:
To accept a call:
• Drag the circle to .
If you are already in a call, that call will be placed on hold while you answer
the new call.
To reject a call:
• Drag the circle to .
The rejected call will automatically be directed to your voicemail.
To reject a call with a text message:
• Drag the circle to .
The call will be rejected, and the caller will recieve the automated text
message reply of your choice:
![](/img.php?id=2478300&img=bg11.png)
PAGE : 17
3.0 MAKING & ANSWERING CALLS
To communicate with contacts:
• Touch the contact, then touch one of the following icons:
Touch the phone number to call a contact.
Touch to send a text message.
Touch the email address to send an email.
To add a contact:
1. From the Contacts tab, touch .
2. Enter contact information, filling in as many or as few of the fields
as desired.
3. Touch Done to create a new contact, or press Discard to discard
the new contact without saving.
NOTE: If you have multiple accounts, select the account to which you want to
add the new contact.
3.4 USING THE CONTACTS TAB
The Contacts tab displays the contacts from your accounts along with any
contacts you have added.
3.4.1 CONTACT SYNCHRONIZATION
By default, contacts in your accounts and on your phone will be synchronized,
so that any changes to the contacts on your phone will be matched in your
accounts, and vice versa. See Accounts for more information.
Depending on your account settings, information you add or remove from your
phone will be synchronized with your external accounts. See Accounts for
more information.
To find a contact:
1. From the Phone app, touch the Contacts tab.
2. Scroll up and down to view all contacts.
3. Touch a name to call that contact.
![](/img.php?id=2478300&img=bg12.png)
PAGE : 18
3.0 MAKING & ANSWERING CALLS
TIP: Use the following controls to add information about the contact:
• Touch the arrow at the end of the name field to view more name fields.
• Touch and follow the prompts to choose or take a photo for your
contact’s icon.
To edit a contact:
1. From the homescreen, touch the Contacts icon and then touch a contact.
Press Edit.
2. Modify the contact information, as described above.
3. Touch Done.
To delete a contact:
1. From the homescreen, touch the Contacts icon and then touch a contact.
Press Delete.
2. Touch OK to confirm.
TIP: Log into your Google account to manage your contacts online. Add, edit,
or remove contacts, and they will automatically sync to your phone.
NOTE: Read-only contact information, such as that from an external app, will
only be hidden, not deleted.
![](/img.php?id=2478300&img=bg13.png)
PAGE : 19
4.0 SENDING & RECEIVING MESSAGES
4 SENDING & RECEIVING MESSAGES
The Message app allows you to send and receive text and multimedia
messaging threads (groups of sent and received messages).
To open the messaging app:
• From the Home screen, touch .
To view a message:
• Within the Message app, touch a message thread. The messages inside the
thread will be displayed, with the newest message at the top of the screen.
TIP: Threads with new messages are displayed in bold.
To view a multimedia attachment:
• If the message has a multimedia attachment, touch the attachment.
4.1 SENDING MESSAGES
To send a message:
1. From the Message app, touch .
2. Enter a recipient in the To field or touch .
Matching numbers and contacts appear as you type.
3. Touch a matching contact or number to select it or enter a new number to
message a new contact.
4. Touch the Type message field and enter a message.
5. Touch to send your message.
TIP: You can add smileys, subject headings, and more. See Message Options
below for more information.
TIP: You can send messages to groups.
![](/img.php?id=2478300&img=bg14.png)
PAGE : 20
4.0 SENDING & RECEIVING MESSAGES
To attach multimedia to a message:
1. Press Attach.
2. Select the desired type of attachment (for example, a music file or a
captured picture), then follow the prompts to send the message.
MESSAGE OPTIONS
The following actions are available while composing a message:
Save message as a draft Press .
ALTERNATE: Exiting the Message app will also
save any draft messages.
Resume working on a draft Touch the message thread you were composing
and resume entering your message.
Discard a draft Clear the message text.
Enter a smiley Press Insert Smiley and touch the smiley
you want to insert.
ALTERNATE: Touch and hold :-) on the onscreen
keyboard and select a smiley.
ALTERNATE: Enter the characters that make up
the smiley.
Add a subject heading to
your message Press Add subject and enter the subject
heading.
4.2 MANAGING MESSAGES
To delete a messaging thread:
• Open the messaging window, touch and hold a messaging thread,
then touch .
To forward a message:
1. Open the messaging window and touch a messaging thread.
2. Press Forward.
3. Enter a recipient and then touch Send to forward the message.
To delete all messaging threads:
1. Open the messaging window, then touch and hold a messaging thread.
2. Touch all other messaging threads to select them.
3. Touch .
4.3 MESSAGE SETTINGS
To specify message settings:
• From the main Messaging window, press Settings.
The following settings are available:
NOTIFICATION SETTINGS
Delete old messages Toggle on/off to delete old messages as limits are
reached.
Text message limit Touch to set number of text messages to save.
Multimedia message limit Touch to set number of multimedia messages to
save.
TEXT (SMS) MESSAGES
Delivery reports Request a delivery report whenever you send a
text message.
MULTIMEDIA (MMS) MESSAGES
Delivery reports Request a delivery report whenever you send a
multimedia message.
Read reports Request reports when your multimedia messages
are read or deleted.
Auto-retrieve Automatically download attachments from
incoming multimedia messages.
Roaming auto-retrieve Turn on auto-retrieve even when on another
carrier’s network.
NOTE: Turning this option off prevents data
roaming costs.
NOTIFICATION SETTINGS
Notifications Set to show message content, to only show
sender, or to not show notification.
Sound Choose a ringtone to play whenever a new
message is received.
Vibrate Toggle on/off to cause phone to vibrate whenever
a new message is received.
![](/img.php?id=2478300&img=bg15.png)
PAGE : 21
4.0 SENDING & RECEIVING MESSAGES
4.4 ADDITIONAL MESSAGING FEATURES
While using the Messaging app, you can take advantage of several features
that make advanced tasks even easier.
The following features are available:
Zoom in/out While reading a message, pinch your fingers to
zoom in or out on the message text.
Select multiple messages
to delete or forward
1. Touch and hold an individual message.
2. Touch other messages to select them.
3. Touch to delete selected messages
Or
Touch to forward selected messages.
![](/img.php?id=2478300&img=bg16.png)
PAGE : 22
5.0 TAKING PHOTOS & VIDEOS
5 TAKING PHOTOS & VIDEOS
The Camera 2.0 app lets you take and share pictures and videos.
To start the Camera 2.0 app:
• In the App Launcher, touch .
Camera buttons and icons
Once opened, the Camera 2.0 app displays the following icons and buttons:
Touch to switch mode: Photo, Video, Burst, PerfectShot, and
Panorama. Smile mode will be available only in Photo mode.
Selecting a new mode changes the icon on the shutter button to
match the current mode.
Use the Shutter button to take a picture or shoot a video.
Touch to switch between rear-facing and front-facing cameras.
Touch to toggle Face Detection on/off.
Touch to adjust Flash settings.
Touch to access Hints, Geo Location, Picture Size, Scenes,
Exposure, White Balance, ISO setting, and Self-Timer.
TIP: To zoom in or out, pinch in the view window to bring up the zoom slider.
Slide the dot up to zoom in (+); slide the dot down to zoom out (-)
To take a picture:
1. Frame your subject in the display.
2. Touch the Shutter button to take your picture and save the image to the
Social Gallery.
To shoot a video:
1. From the Camera 2.0 app, touch the Mode button, and then select .
2. Touch the Shutter button to begin recording. When done, press the Shutter
button again to stop recording and save the video to the Social Gallery.
Use Camera HDR mode:
Select High Dynamic Range mode to give your pictures the most vivid colors
and richest details.
Use Camera Smile mode:
In this mode, the camera will automatically snap a photo as soon as it detects
that all subjects are smiling. (The shutter button is effectively disabled.)
Use Camera Burst mode:
When the camera is set to Burst mode, each shutter press will capture a
series of ten images and save them to the Gallery. Select Fast or Slow to
determine the amount of time between images.
Use Camera PerfectShot mode:
When you press the shutter button in PerfectShot mode, the camera will
automatically snap ten photos and save the best one to the Gallery.
Use Camera Panorama mode:
Select the Panorama mode to sweep across a scene (horizontally or vertically)
and capture multiple images that will be automatically stitched together into
a single panoramic image. During Continuous capture, several on-screen
elements assist in capturing and aligning images:
• The arrow indicates the direction to move the camera for the next shot.
• Touch the shutter button to finish capturing multiple images.
• The counter displays the number of images collected for this panorama.
• A semi-transparent overlay of the previous image assists in aligning the next
image in the sequence. Simply move the camera until key details on the
two images are aligned, and the next image is automatically captured.
NOTE: When using Panorama Mode, you must pan far enough to take at least
two pictures. If you do not touch the shutter button, the camera will stop
taking pictures when it reaches the maximum number of shots.
![](/img.php?id=2478300&img=bg17.png)
PAGE : 23
5.0 TAKING PHOTOS & VIDEOS
To change advanced settings:
Camera settings are available at any time by pressing .
Geo Location: Touch to toggle on/off. When on, location information will be
captured and stored with your photos.
Picture Size: Touch to choose widescreen image or standard 4:3 format. Three
different video sizes are available: 1080p Full HD, 720p HD, or SD.
Scenes: Touch to choose an appropriate shooting scene.
Exposure: Touch to adjust exposure (brightness) settings.
White Balance: Touch to adjust the white balance of your photos.
ISO setting: Touch to adjust ISO sensitivity.
Self-Timer: Touch to set a timer for 3, 5, or 10 seconds.
TIP: Set the camera to Camera Mode to change Picture Size. Set the camera
to Video Mode to change Video Size settings.
5.1 VIEW YOUR PICTURES & VIDEO
Pictures and videos taken with the Camera 2.0 app are stored in the Gallery
app, but they can be viewed and shared from within the main camera screen,
also. To view a picture, touch the small thumbnail image in the lower right of
the screen. You will see the following screen:
While viewing a picture, touch the picture to access the following actions:
Touch to return to the Camera 2.0 app to take more pictures.
Touch to launch the Gallery app to see all the pictures on your
phone.
Touch to share the picture you are currently viewing, then touch
your preferred method of sharing (Google Drive, Gmail, Google+,
wireless Bluetooth technology-enabled device, Picasa web album,
text message, etc).
Touch to delete the picture you are currently viewing.
Touch to access advanced settings (Edit, Rotate, Crop, etc).
NOTE: The Gallery app displays the pictures and videos you have taken on
your phone, downloaded from the web, or (where available) uploaded to a
synchronized Picasa account (Google’s web-based photo storage).
![](/img.php?id=2478300&img=bg18.png)
PAGE : 24
6.0 CONNECTIONS
6 CONNECTIONS
Your phone can connect to Wi-Fi networks, Bluetooth wireless technology-
enabled products (such as headsets), and your computer. You can also
connect to virtual private networks (or VPNs) and use your phone as a hotspot.
6.1 USING WI-FI
Connect to Wi-Fi networks to browse the internet, check your email, and more.
TIP: Use a Wi-Fi connection to help save on data costs.
To connect to a wireless network:
1. From the Home screen, press Settings Wi-Fi.
2. If Wi-Fi is OFF, touch OFF to toggle it on.
3. The available networks will be displayed.
4. Touch a network, then touch Connect.
NOTE: For secured networks, enter the requested security information, then
touch Connect.
To add a network:
1. From the Home screen, press Settings Wi-Fi.
2. Touch .
3. Enter the network’s SSID (the name of the network).
4. Touch Save. Your phone saves the information you entered and uses it to
connect to the network whenever it is available.
NOTE: If the network is secured, enter the security information by touching
None (under Security) and selecting the type of network security that
the network uses (for example, WEP or WPA/WPA2 PSK). Then enter the
requested security information, such as a password.
To remove or modify a saved network:
1. From the Home screen, press Settings Wi-Fi.
2. Touch and hold the network, then touch Forget network or Modify network.
6.2 WIRELESS BLUETOOTH® CONNECTION
To connect to a Bluetooth wireless technology-enabled product for the
first time, you must pair it with your phone. Once paired, your phone will
automatically connect to paired products. You can use your phone to connect
to wireless products featuring Bluetooth technology up to eight meters away.
To pair phone with Bluetooth wireless technology-enabled product:
1. From the Home screen, press Settings Bluetooth.
2. If Bluetooth is OFF, touch OFF to toggle it on. The available Bluetooth
wireless technology-enabled products will then be displayed.
3. Select the product you wish to pair.
4. Confirm the product number and touch Pair to pair the product. Once
paired, your phone will automatically connect with the product.
NOTE: If the product requires a pass code before pairing, try entering 0000 or
1234 or check the product’s documentation. If your phone does not display
the Bluetooth wireless technology-enabled product, touch Search for devices
to rescan. See the documentation that came with your product to learn how to
configure it to be discoverable by phone.
To disconnect a Bluetooth wireless technology-enabled product:
1. From the Home screen, press Settings Bluetooth.
2. Touch a connected product, then touch OK to disconnect.
To reconnect a paired Bluetooth wireless technology-enabled product:
1. From the Home screen, press Settings Bluetooth.
2. Touch a paired product that you want to connect.
To unpair Bluetooth wireless technology-enabled product:
1. From the Home screen, press Settings Bluetooth.
2. Touch next to a paired but disconnected product, then touch Unpair.
![](/img.php?id=2478300&img=bg19.png)
PAGE : 25
6.0 CONNECTIONS
6.2.1 SHARE FILES VIA WIRELESS BLUETOOTH® CONNECTION
To share files via wireless Bluetooth connection:
1. Select the files to share by touching and holding one file and then
selecting others if required.
2. Touch and then select Bluetooth from the pop-up list.
3. Select a paired device from the Bluetooth device picker list, and the file
will be shared via wireless Bluetooth connection.
6.3 TRANSFERRING FILES BETWEEN YOUR PHONE & COMPUTER
Transfer files between your phone and computer by connecting your phone to
your computer’s USB port.
To transfer files between your phone and your computer:
1. Use the USB cable that came with your phone (the “cord” of your phone’s
power cord) to connect your phone to your computer’s USB port.
Warning! Follow any instructions that appear on your computer when
connecting to the USB port. Failure to follow these instructions may result
in damage to your files.
2. Once connected, drag down the notification panel and touch Connected as
a media device to change connection type: Media device (MTP) or Camera
(PTP).
6.4 CONNECTING TO VIRTUAL PRIVATE NETWORKS
Virtual private networks (VPNs) allow you to connect to a secured local
network from outside the network. VPNs are commonly deployed by schools,
corporations, and other institutions that rely primarily on an on-location
network but allow secure access from the outside.
To connect to a VPN for the first time, add that VPN to your phone. You can
then connect to it automatically at any time.
To add a VPN to your phone:
1. From the Home screen, press Settings More... (under the
Wireless & Networks section) VPN.
2. Touch and then follow your network administrator’s instructions to
configure each component of the VPN’s settings.
3. When you are done configuring the VPN, touch Save.
To connect to a previously-added VPN:
1. From the Home screen, press Settings More... (under the
Wireless & Networks section) VPN.
The VPNs you have added are listed at the top of the screen.
2. Touch the desired VPN. Enter any requested information.
3. Touch Connect.
To disconnect from a VPN:
• Open the notifications panel, touch the active VPN notification, and touch
Disconnect.
TIP: You must set a lock screen PIN or password before connecting to a VPN
(Virtual Private Network).
6.5 SHARING YOUR PHONE’S DATA CONNECTION VIA USB TETHERING
You can share your phone’s data connection with a computer, allowing that
computer to access the internet by using USB tethering (as long as you are
not currently using the USB port to share files).
NOTE: Not all carriers support sharing your phone’s data connection. Please
check with your carrier to learn more.
NOTE: Some operating systems, such as Windows XP, require you to prepare
your computer before enabling USB tethering. Visit www.android.com/tether
for more information.
To tether your phone:
1. Use the USB cable that came with your phone to connect your phone to
your computer’s USB port.
1. From the Home screen, press Settings More... (under the
Wireless & Networks section) Tethering.
2. Touch USB tethering to enable tethering.
Your phone will begin sharing its data connection with your computer.
3. When you are finished, uncheck USB tethering or simply disconnect the
USB cable.
Go to http://software.intel.com/en-us/articles/intel-usb-driver-for-android-devices
![](/img.php?id=2478300&img=bg1a.png)
PAGE : 26
6.0 CONNECTIONS
for the latest drivers.
6.6 SHARE YOUR PHONE’S DATA CONNECTION AS A WI-FI HOTSPOT
You can turn your phone into a Wi-Fi hotspot to let other computers and
devices use your phone’s data connection as a wireless network.
To turn your phone into a Wi-Fi hotspot:
1. From the Home screen, press Settings Hotspot
2. If Hotspot is OFF, touch OFF to toggle it on.
Your phone will broadcast its Wi-Fi SSID and can be connected to like any
other wireless network.
Touch Hotspot Set up Wi-Fi hotspot to edit your phone’s data connection.
6.7 CONNECTING TO A WIRELESS DISPLAY (WIDI)
You can enjoy all of your personal and online content on your big screen—by
wirelessly connecting your phone to your TV.
To set up Wireless Display:
1. From the Home screen, touch Settings Wi-Fi.
2. Touch Wi-Fi Direct.
3. When searching completes, touch an adapter name to connect to it.
4. Enter the 8-digit pin code shown on the TV screen and touch OK.
NOTE: Once connected, the icon next to the adapter name will change
to .
To disconnect Wireless Display:
1. From the Home screen, touch Settings Wi-Fi.
2. Touch Wi-Fi Direct.
3. Touch the name of the adapter you are currently using.
4. Touch Disconnect.
TIP: Follow the first two steps above and then choose Rename Device to give
this adapter a custom name, such as Living Room, My Place, etc.
Touch the names of devices to turn on Wi-Fi direct and connect directly to
nearby peer devices over Wi-Fi for more reliable, higher-speed communication.
(No internet connection or tethering is needed.) Through third-party apps, you
can connect to compatible devices to take advantage of new features such as
instant sharing of files, photos, or other media; streaming video or audio from
another device; or connecting to compatible printers or other devices.
6.8 CONTROL YOUR PHONE FROM A PC
MOBILedit! allows you to control your phone from a PC. Download MOBILedit!
to any computer and connect your phone via cable, wireless Bluetooth
connection, or IrDA. You will be able to view the contents of your phone, as
well as synchronize, add, edit, or delete items.
Go to www.mobiledit.com/oem and enter the code intel-001303 to register and
then download the MOBILedit! software.
![](/img.php?id=2478300&img=bg1b.png)
PAGE : 27
7.0 ACCOUNTS
7 ACCOUNTS
You can keep your phone synchronized with your Google, email, and corporate
accounts, as well as synchronizing contacts with other applications.
To add an account to your phone:
1. From the Home screen, press Settings + Add account.
2. Select the type of account to add, such as a corporate account
(using Microsoft Exchange) or a Google account.
3. Follow the on-screen instructions for configuring your account.
NOTE: The first time you open an app using accounts (such as Email,
Calendar, or Gmail), you will be prompted to add an account. The process for
adding an account within these apps is identical to that described above.
To remove an account from your phone:
1. From the Home screen, press Settings and then touch the name
of the account.
2. Touch the email address of the account.
3. Touch Remove account.
4. Touch Remove account to confirm removal.
To change an account’s synchronization settings:
1. From the Home screen, press Settings and then touch the name
of the account.
2. Touch the email address of the account.
3. In the next screen, check or uncheck the type of information you want
synchronized. For example, your Google account lets you enable or disable
synchronization of your Browser, Contacts, Calendar, Google Photos, Picasa
Web Albums (where available), Google+, Gmail, and more.
NOTE: Previously synchronized data remains on your phone until you
manually delete it.
To manually synchronize an account:
1. From the Home screen, press Settings and then touch the name
of the account.
2. Touch the email address of the account.
3. Press Sync now.
NOTE: Data charges may be incurred during the synchronization process.
![](/img.php?id=2478300&img=bg1c.png)
PAGE : 28
8.0 CHANGING PHONE SETTINGS
8 CHANGING PHONE SETTINGS
The settings window displays all of the settings that affect how your phone
looks and works.
To open the settings window:
• From the Home screen, press Settings.
8.1 WIRELESS & NETWORKS
The Wireless & networks section configures your phone’s connections, such as
Wi-Fi, Bluetooth wireless technology, VPN, and more.
Wi-Fi Turn on Wi-Fi and configure any desired settings
under Advanced Wi-Fi.
For information on using Wi-Fi, see Using Wi-Fi.
Advanced
Wi-Fi
From Settings, touch Wi-Fi Advanced.
• Network notification: Receive a notification when an open
Wi-Fi network becomes available.
• Keep Wi-Fi on during sleep: Choose when to keep Wi-Fi
turned on.
• Avoid poor connections: Choose whether to use Wi-Fi
networks with poor internet connections.
• Wi-Fi frequency band: Specify the frequency range.
• MAC address: Displays your current MAC address.
• IP address: Displays your current IP address.
Bluetooth Turn on Bluetooth wireless technology. To see available
devices, touch Bluetooth. From this Bluetooth screen, touch
for options: Rename phone, Visibility timeout, and Show
received files.
For more information on pairing your phone with a Bluetooth
wireless technology-enabled product, see Wireless Bluetooth
Connection.
Data usage View your phone’s data usage. Touch for options: Restrict
background data, Auto-sync data, and Mobile hotspots.
Touch More... to access the following options:
Airplane
mode
Disable all wireless connections, including Bluetooth wireless
technology and 3G.
Activating airplane mode greys out some other settings.
VPN Configure your Virtual Private Network.
Tethering Configure your phone for tethering:
• USB tethering: Share your phone’s mobile data network
connection with your computer via a USB connection.
• Bluetooth tethering: Share your phone’s mobile data
network connection via a Bluetooth connection.
Mobile
networks
Configure your mobile data network using the following:
• Data enabled: Clear this checkbox to prevent your phone
from transmitting data on any mobile network. This is
useful when you are traveling and wish to avoid charges
for data use on a local carrier’s network, and it also can
decrease the battery usage.
Disabling data does not prevent your phone from
transmitting data on other networks, such as Wi-Fi or
Bluetooth wireless technology-enabled products.
• Data roaming: Clear this checkbox to prevent your phone
from using other carrier’s mobile networks when your own
is unavailable.
• Network Mode: Select your preferred network mode.
• Access Point Names: Select from the available access
points.
• Network operators: Scan for and select a network operator.
![](/img.php?id=2478300&img=bg1d.png)
PAGE : 29
8.0 CHANGING PHONE SETTINGS
8.2 DEVICE
Sound settings let you configure your phone’s sounds.
Volumes Set the volume for each sound made by your phone, such
as media or incoming calls.
Phone ringtone Select the ringtone for a phone call.
Vibrate when
ringing
Turn on to make the phone vibrate when it rings.
Default
notification
Select the notification ringtone.
Dial pad touch
tones
Turn on to hear key presses when you dial numbers.
Touch sounds Turn on to hear sounds when you touch items.
Screen lock
sound
Turn on to hear a sound when you lock/unlock the screen.
Vibrate on
touch
Turn on to make the phone vibrate when you touch items.
Display settings configure your phone’s screen, such as its brightness or
rotation.
Brightness Adjust the screen’s brightness automatically or select the
desired brightness. For the longest battery life, use the
lowest comfortable brightness.
Wallpaper Select an image on your phone to display as your phone’s
wallpaper.
Auto-rotate
screen
Check to automatically rotate the orientation of the screen
as you turn the phone sideways or upright.
Sleep Set how long a phone will idle before the phone enters
sleep mode. For the longest battery life, use the shortest
timeout.
Daydream Toggle Daydream mode (a screensaver type of app) ON/OFF,
select what to display, and choose whether to Daydream
while docked, while charging, or either.
Font size Change the size of the text displayed on your phone.
Wireless
Display
Toggle WIDI ON/OFF and view available devices.
HDMI displays the phone’s HD video display settings.
Storage displays the usage of internal storage and USB storage.
Battery displays the battery’s current charge, along with the battery usage of
applications.
Apps launches Manage apps.
Sensor calibration calibrates your phone’s gyroscope and compass.
Intel Smart Video allows you to toggle video improvements ON/OFF.
8.3 PERSONAL
Location
access
Toggle ON/OFF GPS and search features that use your
current location.
Security Secure your phone with a Slide, Face Unlock, Voice Unlock,
Pattern, PIN, or Password.
See Securing your Phone for more information.
• Automatically lock: Set how quickly your phone locks
itself.
• Power button instantly locks: Toggle whether pressing the
power button locks your phone.
• Encrypt phone: Require a numerical PIN or password to
decrypt your phone each time that you turn it on.
• Make passwords visible: Turn on to briefly display each
character of your password.
Asterisks are displayed by default.
• Device administrators: View or deactivate device
administrators.
• Verify apps: Toggle whether you are warned before
installation of apps that may cause harm to your phone.
• Uknown sources: Allow installation of non-Market apps.
• Trusted credentials: Display trusted CA certificates.
• Install from SD card: Install certificates from SD card.
• Clear credentials: Remove all certificates.
![](/img.php?id=2478300&img=bg1e.png)
PAGE : 30
Language &
input
Touch Language to choose a new language.
• Spell checker: Toggle ON/OFF.
• Personal dictionary: Display the user dictionary used to
identify words you type.
Touch the red X next to a word to delete it. Touch a word
to edit it. Touch the plus sign to add a new word.
• Keyboard & Input Methods: Display the onscreen
keyboards available on your phone. Touch the sliders on
the right to configure a keyboard.
• Voice Search: Display options for setting language,
SafeSearch, and blocking offensive words.
• Text-to-speech output: Change the text-to-speech engine,
adjust the speed at which text is spoken, and listen to an
example.
• Pointer speed: Adjust the speed of any mouse or track
pad that is connected to or controlled by your phone.
Backup & reset Use this setting to manage your personal information.
• Back up my data: Back up certain personal data to Google
servers. If you replace your phone, you can restore the
data you have backed up.
The following data can be backed up and restored:
Browser bookmarks. Some third-party applications may
also take advantage of this feature.
Unchecking this option stops data back-up and deletes
any existing backups.
• Backup account: Set an account as your backup account.
• Automatic restore: Restore your settings and other data
when you reinstall an application using your current
Google account.
• Factory data reset: Erase all of your personal data from
internal phone storage. Resetting the phone does not
erase any software updates you have downloaded.
You can also erase data downloaded to USB storage.
After resetting your phone, you will be returned to the
Google wizard when you next restart your phone.
Accounts Add, remove, and manage your accounts (including Google
and Microsoft Exchange accounts.) For more information on
working with accounts, see Accounts.
8.4 SYSTEM
Date & time The Date & time settings screen configures how the date
and time are displayed on your phone. You can also use
this screen to manually enter the date and time, rather than
obtaining the current time from the mobile network.
• Automatic date & time: Uncheck to set the date and time
on the phone manually, rather than obtaining the current
time from the mobile network.
• Automatic time zone: Uncheck to set the time zone on the
phone manually, rather than obtaining the current time
zone from the mobile network.
• Set date/Set time/Select time zone: Manually set the
phone’s date, time zone, and time. This setting is only
available if the Automatic setting, above, is unchecked.
• Use 24-hour format: Display the time using 24-hour time
format—for example, 13:00 rather than 1:00 PM.
• Choose date format: Select the date format.
Accessibility Toggle ON/OFF features such as TalkBack, magnification
gestures, large text, and an accessibility shortcut; using the
power button to end calls; screen auto-rotate; and spoken
passwords. Configure text-to-speech output, the length
of the touch and hold delay, and install web scripts from
Google that make web content more accessible.
Developer
options
Advanced options for developers.
About phone Display information about your phone.
• System updates: Check for Android system software
updates.
• Status: Touch to open the Status screen.
• Legal information: Display legal information about the
software included with your phone.
8.0 CHANGING PHONE SETTINGS
![](/img.php?id=2478300&img=bg1f.png)
PAGE : 31
9.0 SAFETY, REGULATORY & LEGAL
9 SAFETY, REGULATORY & LEGAL
SAFETY GUIDELINES
IMPORTANT: Review and adhere to these guidelines. Failure to do so may
incur risk of injury or property damage.
Safety for AC Adapter (charger)
WARNING: Risk of electric shock. Indoor use only. Do not use AC adapter in a
wet location. There are no user serviceable parts inside the AC adapter - do
not open enclosure. Connect only to a properly wired and grounded outlet.
WARNING: Risk of electric shock. Do not connect/disconnect any cables or
perform installation or maintenance of this device or its AC adapter during an
electrical storm (such as a lightning storm or thunder storm).
WARNING: Risk of electric shock, fire, or burn if using an AC adapter other
than the one provided with this device. Do not replace with an alternate AC
adapter. Replace only with adapter SC1402 from Salcomp.
The AC adapter must be plugged into an easily accessible AC mains power
socket when charging the device. The only way to turn off the AC adapter after
the device is fully charged is to unplug it from AC mains.
Safety Guidelines for the Battery
This device uses a non-removable lithium-ion battery. Do not attempt to
disassemble the device enclosure to access or remove the battery. The battery
is intended to be serviced and disposed by qualified Intel service personnel
only.
WARNING: Risk of fire, explosion, or chemical burn if battery is mistreated
(punctured or crushed). Do not attempt to disassemble. Do not incinerate. Do
not heat the battery above +55˚C (131˚F).
WARNING: Risk of fire, explosion, or chemical burn if using a battery other
than the one provided with this device.
Safety Guidelines for the Phone
This device and its accessories are intended for use when the ambient
temperature is between -10˚C and +55˚C (14˚F and 131˚F). Avoid placing
this device next to heat sources, leaving it in the direct sunlight for extended
periods, or in a place where the temperature may exceed the specified range
(such as a parked car on a hot day).
DANGER: Risk of fire or explosion. Do not operate this device in potentially
explosive environments such as fueling stations, fueling areas, fuel or
chemical storage facilities, or areas where the air may contain chemical or
dust particles such as grain particles or metal powders. If possible, physically
remove this device from any such environment. Do not connect any accessory
cables or press any the device’s buttons until outside of these environments.
WARNING: Risk of injury due to interference with medical devices. This device
may interfere with the operation of some pacemakers, hearing aids or other
medical devices. To reduce the risk of potential interference, maintain a
separation distance of 20cm (8 inches) between this device and the medical
device. Refer to the medical device’s instructions or consult your medical
service provider for additional information.
WARNING: Risk of choking on removable parts (for example the SIM card and
SIM tray). Keep this device and accessories away from and out of reach of
children.
Caution: Risk of permanent hearing loss from using earphones or headphones
with this device at high volume. Before placing headphones or earphones near
the ear, 1) Find a quiet environment, 2) Turn the volume down on this device
to the minimum setting, 3) Connect the earphone or headphone to the device,
4) Place the earphone or headphone near or on the ear and 5) Slowly increase
the volume on the device to a comfortable level. Avoid increasing the volume
above this level. Increasing the volume to be louder than a noisy environment,
such as a city street, may exceed safe listening levels. If you experience
discomfort or buzzing in your ears, reduce the volume or discontinue use of
your earphones or headphones.
Risk of permanent hearing loss from using the loudspeaker in close proximity
to the ear. Ring tones, info tones, and hands-free talking may be reproduced
through the loudspeaker. Do not hold the device to the ear when it rings or
when using the handsfree function.
Caution: Risk of cut from broken glass. This device has a glass display that,
if broken, may shatter and create sharp edges. If the display glass breaks, do
not touch the broken area. Please return the device to Intel for service.
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
![](/img.php?id=2478300&img=bg20.png)
PAGE : 32
9.0 SAFETY, REGULATORY & LEGAL
WEEE (WASTE ELECTRICAL AND ELECTRONIC
EQUIPMENT) STATEMENT
In the European Union, this symbol indicates that this product
including battery must not be disposed of with household waste.
It is your responsibility to return the device and all its accessories
to Intel for the recycling of waste electrical and electronic
equipment.
Caution: Risk of injury due to flashing lights. Some people may be susceptible
to blackouts, seizures or debilitating headaches when exposed to bright,
flashing light such as, for example, when playing video games or watching
other video content on this device. If you have experienced such medical
issues in the past, please consult your physician before engaging in such
activity on this device.
Caution: Risk of injury due to repetitive motion. Repetitive motion of certain
actions, such as pressing keys or other repetitive finger gestures, may cause
discomfort in your hands, wrists, arms, shoulders, neck and other parts of
your body. If you experience any such discomfort, please discontinue such
actions until you have had an opportunity to consult with your physician.
Caution: Risk of injury due to impact. Do not place the device or its
accessories on or near an automotive air bag.
There are no user serviceable parts inside this device. Refer all service to
qualified Intel service personnel if the device no longer functions as a result
of being dropped, exposed to liquids, damage to ports, or for any other reason.
OPERATIONAL AND LEGAL GUIDELINES
Please return the device and all its accessories to Intel prior to disposal.
Always comply with all local legal requirements or restrictions when using the
device, for example, in airplanes, gas or petrol stations, in hospitals, or while
driving.
Your device may be equipped with Global Positioning System (GPS) or
Assisted GPS (AGPS) technology, which may be used to determine the
approximate location of the device. When connected to a wireless network,
the device may transmit location-based information, including to third-party
application providers. Please check the settings of any installed applications
to ensure that you manage these location based services in accordance with
your privacy preferences.
Connect only to USB interfaces with USB 2.0 version or higher.
FCC STATEMENTS
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Intel Corporation could
void the user’s authority to operate the equipment.
PAGE : 33
9.0 SAFETY, REGULATORY & LEGAL
RF EXPOSURE (SPECIFIC ABSORPTION RATE)
INFORMATION
This device is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. Government, Industry Canada
(IC) and other national regulatory agencies.
The RF exposure standard applicable to this device employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR limit
set by the FCC and IC is 1.6 W/kg averaged over any 1 gram of tissue. Tests
for SAR are conducted using standard operating positions accepted by the
FCC and IC with the device transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is determined at the highest
certified power level, the actual power level of the device while operating
can be well below the maximum certified value. This is because the device
is designed to operate at multiple power levels and to use only the power
required to reach the network. The most conservative SAR measured for this
device is:
SAR US 1.16 W/kg @ 1g (head) ---- 1.44 W/kg @ 1g (body)
While there may be differences between the SAR levels of various devices
and at various positions, Intel products meet the government requirements.
Equipment Authorization has been granted to this model with all reported
SAR levels evaluated as in compliance with the FCC and IC RF exposure
guidelines. SAR information on this device is on file with the FCC and can
be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: O2Z-EP110. SAR information on this device is on file
with Industry Canada and can be found by searching the Industry Canada
Radio Equipment List (REL) at http://www.ic.gc.ca/app/sitt/reltel/srch/
nwRdSrch.do?lang=eng and entering the certification number IC: 1000W-
EP110.
For body worn operation, this device has been tested and meets the RF
exposure guidelines for use with an accessory that contains no metal and
which keeps a distance of at least 1cm between the device and the body.
Use of the device within 1cm of the body may not ensure compliance with
RF exposure guidelines. Intel encourages the end user to use a body-worn
accessory that will maintain a distance of at least 1cm from the body when
the phone is turned on. If you do not use a body-worn accessory and are not
holding the device at the ear, position the device a minimum of 1cm from
your body when the device is switched on.
INDUSTRY CANADA STATEMENTS
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Cet appareil est conçu et fabriqué afin de ne pas excéder les limites
d’émission pour l’exposition à l’énergie de radiofréquence établies par
Industrie Canada.
La norme applicable à cet appareil en ce qui a trait à l’exposition à la
radiofréquence utilise une unité de mesure connue sous le nom de débit
d’absorption spécifique, ou DAS. La limite de DAS établie par Industrie
Canada est de 1,6 W par kilogramme (moyenne mesurée à partir de 1
gramme de tissu). Les tests de DAS sont menés à l’aide de positions de
fonctionnement standard acceptées par Industrie Canada, alors que l’appareil
émet à sa puissance certifiée la plus élevée à toutes les bandes de fréquences
testées. Même si le DAS est déterminé au niveau de puissance certifié le
plus élevé, le niveau de puissance réel de l’appareil lorsqu’il fonctionne peut
être bien en dessous de la valeur certifiée maximale. Cela est dû au fait que
l’appareil est conçu pour fonctionner à plusieurs niveaux de puissance et pour
utiliser seulement la puissance nécessaire pour accéder au réseau. La mesure
du DAS la plus modeste pour cet appareil est :
DAS = 1.16 W/kg @ 1g (tête) ---- 1.44 W/kg @ 1g (corps)
Même si les niveaux de DAS de différents appareils à différentes positions
peuvent varier, les produits Intel respectent les normes gouvernementales.
L’autorisation d’équipement a été accordée pour ce modèle et tous les
niveaux de DAS ont été jugés conformes aux directives d’exposition à la
radiofréquence d’Industrie Canada. L’information sur le DAS pour cet appareil
a été déposée auprès d’Industrie Canada et figure dans la nomenclature du
matériel radio (NMR) d’Industrie Canada, à l’adresse http://www.ic.gc.ca/
app/sitt/reltel/srch/nwRdSrch.do?lang=fra. Le numéro de certification est le
1000W-EP110.
![](/img.php?id=2478300&img=bg22.png)
PAGE : 34
NOTICE
The information contained herein is subject to change without notice. All
statements, information and recommendations contained herein do not
constitute a warranty of any kind, either expressed or implied. Please review
this product guide thoroughly, with particular attention paid to any safety
sections, to make sure that you use your device safely.
This publication is protected by copyright. No part of the publication may be
used, reproduced, or translated, in any form, without the prior written consent
of Intel Corporation.
Intel, the Intel logo, Intel Atom, Intel Inside, and the Intel Inside logo are
trademarks of Intel Corporation in the U.S. and/or other countries.
Google, Gmail, Google Maps, YouTube, Google Calendar, Android, and Android
Market are trademarks of Google, Inc. Use of these trademarks is subject to
Google’s permission.
Other names and brands may be claimed as the property of others.
Copyright © 2014 Intel Corporation. All rights reserved.
En ce qui a trait au port de l’appareil sur le corps, l’appareil a été testé et
satisfait aux directives d’exposition à la radiofréquence d’Industrie Canada
pour un usage avec un accessoire exempt de métal et qui permet de garder
une distance d’au moins 1 cm entre l’appareil et le corps. L’usage de
l’appareil à moins de 1 cm du corps peut ne pas satisfaire aux directives
d’exposition à la radiofréquence d’Industrie Canada. Intel encourage
l’utilisateur final à utiliser un accessoire porté sur le corps permettant de
garder une distance d’au moins 1 cm avec le corps lorsque le téléphone est
allumé. Si vous n’utilisez pas un accessoire porté sur le corps et ne tenez pas
l’appareil au niveau de l’oreille, placez-le à une distance d’au moins 1 cm de
votre corps lorsqu’il est allumé.
Changes or modifications not expressly approved by Intel Corporation could
void the user’s authority to operate the equipment.
Tout changement ou toute modification qui ne sont pas approuvés
expressément par Intel Corporation pourrait annuler l’autorisation de
l’utilisateur à se servir de l’équipement.
NOTE: This device is restricted to indoor operation when using the WiFi radio
between 5.15GHz and 5.25GHz in Canada.
REMARQUE : Cet appareil est restreint à un usage intérieur lors de
l’utilisation de la radio Wi-Fi entre 5,15 GHz et 5,25 GHz au Canada.
