Intel® Server Board SE7320SP2
Tested Hardware and Operating System List
Revision 1.7
July 2005
Enterprise Platforms and Services Marketing
![](asset-2.png)
Revision History Intel® Server Board SE7320SP2
ii Revision 1.7
Revision History
Date Revision
Number Modifications
June 2004 1.0 Initial release.
July 2004 1.1 Revised to be SE7320SP2 specific.
September 2004 1.2 Update validation information on SE7320SP2. Add similar adapter and
device information.
January 2005 1.3 Update adapter/HD list from Q4’04 regression test
February 2005 1.4 Updated the supported OS table in section3: Supported Operation Systems
to add listing of Microsoft* Windows* Small Business Server operation
systems for Intel® Server Boards that support Microsoft Windows Server
operation system, and a note describing the support commitment.
March 2005 1.5 Add Microsoft* 64-bit OS to tested OS list.
July 2005 1.6 OS: Add Microsoft* windows server 2003 Enterprise X64 Edition, Red Hat*
Enterprise Linux 4.0 Update 1 32bit & 64 bit version, SuSE* Linux
Enterprise Server 9.0 SP1 32bit & 64 bit version and Novell* Netware 6.5
SP3 to supported OS list.
Adapters: Items shaded are new or have modification of supported OS.
Hard Drives: Items shaded are new or have modification of supported OS.
Aug 2005 1.7 No update and have typo scrub
Disclaimers
THE INFORMATION IN THIS DOCUMENT IS PROVIDED "AS IS" WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY
WARRANTY OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE
ARISING OUT OF ANY PROPOSAL, SPECIFICATION, OR SAMPLE.
Information in this document is provided in connection with Intel® products. No license, express or implied, by estoppel or otherwise,
to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such
products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of
Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any
patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining
applications.
Intel retains the right to make changes to its test specifications at any time, without notice.
The hardware vendor remains solely responsible for the design, sale and functionality of its product, including any liability arising
from product infringement or product warranty.
Copyright © Intel Corporation 2004-2005. All rights reserved.
Intel, the Intel logo, and EtherExpress are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United
States and other countries.
† Other names or brands may be claimed as the property of others.
![](asset-3.png)
Intel® Server Board SE7320SP2 Table of Contents
Revision 1.7
iii
Table of Contents
1. Introduction ..........................................................................................................................5
1.1 Test Overview..........................................................................................................5
1.1.1 Basic Installation Testing.........................................................................................5
1.1.2 Adapter / Peripheral Compatibility and Stress Testing ............................................6
1.2 Pass/Fail Test Criteria .............................................................................................7
2. Intel® Server Board SE7320SP2 Base System Configurations ........................................8
3. Supported Operating Systems............................................................................................9
3.1 Operating System Certifications ............................................................................10
4. Adapters and Peripherals..................................................................................................12
4.1 PCI RAID ...............................................................................................................13
4.2 PCI SCSI ...............................................................................................................15
4.3 PCI Fiber Channel .................................................................................................16
4.4 PCI NIC..................................................................................................................17
4.5 Modems.................................................................................................................18
4.6 Human Interface Devices ......................................................................................18
4.7 CDROM Drives......................................................................................................19
4.8 DVD Drives............................................................................................................20
4.9 Tape Drives ...........................................................................................................21
4.10 Removable Drives .................................................................................................21
4.11 KVM.......................................................................................................................22
5. Hard Disk Drives.................................................................................................................23
5.1 SCSI Hard Disk Drives ..........................................................................................24
5.2 Parallel ATA Hard Disk Drives...............................................................................25
5.3 Serial ATA (SATA) Hard Disk Drives.....................................................................26
5.4 External Hard Disk Drives......................................................................................26
6. Tech Tips.............................................................................................................................27
6.1 Emulex* LP1050Ex and Qlogic* QLE2360 Fibre Channel Adpaters Experience
Delayed Write Failures during Extended Stress Testing .........................................................27
6.2 Emulex* LP9802DC PCI-X fibre channel host adapter issue under Netware 6.5..27
< This page left intentionally blank>
![](asset-4.png)
Table of Contents Intel® Server Board SE7320SP2
iv Revision 1.7
![](asset-5.png)
Intel® Server Board SE7320SP2 Introduction
Revision 1.7
5
1. Introduction
This document is intended to provide users of the Intel® server board SE7320SP2 with a guide
to the different operating systems, adapter cards, and peripherals tested by Intel on this
platform.
This document will continue to be updated as new add-in cards, peripherals, and operating
systems are tested until the Intel® server board SE7320SP2 is no longer in production. Each
new release of the document will present updated information as well as continue to provide the
information from previous releases.
Intel will only provide support to those add-in cards and peripherals under the specified system
configuration (System BIOS and firmware) and operating systems and versions to which they
were tested.
1.1 Test Overview
Testing performed on the Intel® server board SE7320SP2 is classified under two separate
categories: Basic Installation Testing, and Adapter / Peripheral Compatibility and Stress
Testing.
1.1.1 Basic Installation Testing
Basic installation testing is performed with each supported operating system. Basic installation
testing validates that the server board can install the operating system and that the base
hardware feature set is functional. A small set of peripherals is used for installation purposes
only. No add-in adapter cards are tested. Testing includes network connectivity and running of
proprietary and industry standard test suites.
The latest version of an operating system signifies the latest supported version
at the time of the actual test run. Each new release of this document may have
a newly supported release of a given operating system. Previous releases of a
supported operating system may not be tested beyond the basic installation
test process.
1.1.1.1 Support Commitment for Basic Installation Testing
Intel commits to provide the following level of customer support for operating systems that
receive only basic installation testing:
• Intel will provide and test operating system drivers for each of the server board’s
integrated controllers, provided that the controller vendor has a driver available upon
request. Vendors will not be required by Intel to develop drivers for operating systems
that they do not already support. This may limit the functionality of certain server board
integrated controllers.
• Intel will support customer issues that involve installation and/or functionality of
operating system with the server board’s integrated controllers only if a driver has been
made available from Intel.
![](asset-6.png)
Introduction Intel® Server Board SE7320SP2
6 Revision 1.7
• Intel will NOT provide support for issues related to use of any add-in adapters or
peripherals installed in the server system when an operating system that received basic
installation testing only is in use.
• Support is defined as assistance in root causing issues, and determining a customer
acceptable resolution to the issue associated with the operating system. The resolution
may include, but is not limited to, on-board controller driver changes, engaging the
vendor for resolution, BIOS changes, firmware changes, or determining a customer
acceptable workaround for the issue.
1.1.2 Adapter / Peripheral Compatibility and Stress Testing
Adapter / Peripheral Compatibility and Stress testing is performed only on the most current
release of a supported operating system at the time of a given validation run. The Adapter /
Peripheral Compatibility and Stress testing process consists of three areas: Base Platform,
Adapter Compatibility, and Stress.
Base Platform: Each base platform will successfully install a given operating system,
successfully run a disk stress test, and successfully run a network stress test.
Adapter Compatibility: Adapter compatibility validation (CV) testing uses test suites to gain an
accurate view of how the server performs with a wide variety of adapters under the primary
supported operating systems. These tests are designed to show hardware compatibility
between the cards and the server platform and include functional testing only. No heavy
stressing of the systems or the cards is performed for CV testing.
Stress Testing: This test sequence uses configurations that include add-in adapters in all
available slots, (depending on chassis used) for a minimum 72-hour test run without injecting
errors. Each configuration passes an installation test, a Network/Disk Stress test, and tape
backup test. Any fatal errors that occur will require a complete test restart.
1.1.2.1 Support Commitment for Adapter / Peripheral Compatibility and Stress
Testing
Intel commits to provide the following level of customer support for operating systems that
receive Adapter / Peripheral Compatibility and Stress testing:
• Intel will provide support for customer issues with these operating systems involving
installation and/or functionality of the server board with or without the adapters and
peripherals listed in this document as having been tested under the particular operating
system.
• Support is defined as assistance in root causing issues, and determining a customer
acceptable resolution to the issue associated with the operating system. The resolution
may include, but is not limited to, on-board controller driver changes, engaging the
vendor for resolution, BIOS changes, firmware changes, or determining a customer
acceptable workaround for the issue.
• Intel will provide and test operating system drivers for each onboard video, network, and
storage controller.
• Intel will enable vendors to provide driver support for add-in adapters using these
operating systems.
![](asset-7.png)
Intel® Server Board SE7320SP2 Introduction
Revision 1.7
7
• Intel will go through some of the steps to achieve certification to ensure its customers do
not run across any problems, but the actual certification is the responsibility of the
individual customer.
For operating systems, adapter cards, and peripherals not listed in this
document, there is no support commitment. Intel will consider support requests
on a case-by-case basis.
1.2 Pass/Fail Test Criteria
For each operating system, adapter, and peripheral configuration, a test passes if specific
criteria are met. Specific configurations may have had particular characteristics that were
addressed on a case-by-case basis. In general, a configuration passes testing if the following
conditions are met:
• The operating system installed without error.
- Manufacturer’s installation instructions or Intel’s best-known methods were used for
the operating system installation.
- No extraordinary workarounds were required during the operating system
installation.
- The server system behaved as expected during and after the operating system
installation.
- Application software installed and executed normally.
• Hardware compatibility tests ran to completion without error.
• Test software suites executed successfully
- Test and data files were created in the correct directories without error.
- Files copied from client to server and back compare to the original with zero errors
reported.
- Clients remain connected to the server system.
- Industry standard test suites run to completion with zero errors reported.
All Intel® Server Board SE7320SP2 testing was performed using the Intel® Server Chassis
SC5300.
![](asset-8.png)
Intel® Server Board SE7320SP2 Base System Configurations Intel® Server Board SE7320SP2
8 Revision 1.7
2. Intel® Server Board SE7320SP2 Base System
Configurations
The following table lists the base configurations tested. Base configurations will change as new
revisions of the Intel® server board SE7320SP2 are released and/or new system BIOS and
BMC firmware are introduced onto the board in Intel’s factory. Each base configuration is
assigned an identifier number that is referenced in the tables throughout this document. New
base configurations are added with each new release of this document.
Intel will only provide support for adapters and peripherals under the specified
base system configuration and operating systems versions with which they
were tested.
Base System
Identifier # Board Type Part Number BIOS
Revision mBMC
Revision FRU/SDR Notes
1 SE7320SP2 C49813-401 BC07 2.31 Ver 0.10
2 SE7320SP2
C49813-501
C49813-601 P03 2.31 Ver 1.20
Fab mounted with
C1 or C2 MCH
3 SE7320SP2 C49813-603 P06 2.40 Ver 1.40
Fab mounted with
C4 MCH
4 SE7320SP2 C49813-602 RC02.P08 2.40 Ver 1.49
![](asset-9.png)
Intel® Server Board SE7320SP2 Supported Operating Systems
Revision 1.7
9
3. Supported Operating Systems
The following table provides a list of supported operating systems for the Intel® server board
SE7320SP2. Each of the listed operating systems was tested for compatibility with a base Intel
server board SE7320SP2 configuration. Operating system compatibility testing verifies that the
operating system will install and function with all on-board devices.
The following table also indicates whether each operating system received Basic Installation
Testing, or Adapter / Peripheral Compatibility and Stress Testing. For information on the
support commitments for Basic Installation Testing vs. Adapter / Peripheral Compatibility and
Stress Testing, please reference Section 1 of this document.
Any variations to the standard operating system installation process are documented in the
Installation Guidelines section of this document. If there are no installation guidelines noted in
the following table, then the operating system installed as expected using manufacturer’s
installation instructions or Intel’s best-known methods.
Operating systems supported by Intel® Server Management software or
LANDesk* Client Manager software may be different than the operating
systems supported by the Intel Server Board SE7320SP2. Please reference
the Readme and User Guide documents that are included as part of each Intel
Server Management and LANDesk* Client Manager distribution for operating
systems that are supported by that release.
Operating System Base System
Configuration Tested
& Type of Testing
Notes
Microsoft* Windows 2000 Advanced Server,
Service Pack 4 / Microsoft Small Business
Server 2000, SP4
Configuration 2&3&4 –
Compatibility & Stress
Intel’s testing was completed with
Microsoft Windows 2000 Advanced
Server. The Intel Server Board
SE7320SP2 supports the operating
system portion of Microsoft Small
Business Server 2000 only. The
application portion is not tested or
supported.
Microsoft* Windows† Server 2003 Enterprise
Edition / Microsoft Windows Small Business
Server 2003, SP1
Configuration 2&3&4 –
Compatibility & Stress
Intel’s testing was completed with
Microsoft Windows Server 2003
Enterprise Edition. The Intel Server
Board SE7320SP2 supports the operating
system portion of Microsoft Windows
Small Business Server 2003 only. The
application portion is not tested or
supported.
Microsoft* Windows 2003 Enterprise X64 Edition Configuration 4 –
Compatibility & Stress
Red Hat Enterprise Linux 3.0, Update 2 Configuration 2&3 –
Compatibility & Stress
Red Hat Enterprise Linux 3.0, Update 2, EM64T Configuration 2&3 –
Compatibility & Stress
Red Hat Enterprise Linux 4.0, Update 1 Configuration 4-
![](asset-a.png)
Supported Operating Systems Intel® Server Board SE7320SP2
10 Revision 1.7
Operating System Base System
Configuration Tested
& Type of Testing
Notes
Compatibility & Stress
Red Hat Enterprise Linux 4.0, Update 1, EM64T Configuration 4-
Compatibility & Stress
SuSE Linux Enterprise Server 9, EM64T Configuration 2,3 –
Compatibility & Stress
SuSE Linux Enterprise Server 9, SP1 Configuration 4 –
Compatibility & Stress
SuSE Linux Enterprise Server 9, SP1, EM64T Configuration 4 –
Compatibility & Stress
Novell Netware† 6.5, SP2 Configuration 2&3 –
Compatibility & Stress
Novell NetWare† 6.5 SP3 Configuration 4 –
Compatibility & Stress
Microsoft* Windows NT 4.0 Advanced Server,
SP6 Congifuration 2&3 –
Basic Install
Red Hat Advanced Server 2.1 Configuration 2&3 &4–
Basic Install
SuSE Linux 9.1 Professional Configuration 2&3 &4 –
Basic Install
Novell Netware† 5.1, SP7 Configuration 2&3 –
Basic Install
SCO OpenServer 5.0.6a Configuration 2&3 –
Basic Install
3.1 Operating System Certifications
Listed below are the operating systems that Intel will certify on the SE7320SP2 Server board.
However, the customer is responsible for their own certification from the individual operating
system vendors. In many cases, the customer may leverage their operating system
certifications from Intel’s testing. See the “Comments” section next to each operating system in
the table below for additional information. Intel’s certifications, pre-certification, and operating
system testing may help reduce some of the risk in achieving customer certifications with the
operating system vendors.
Operating System Certification Listing Comments
Microsoft* Windows†
Server 2000 Advanced
Server
Intel® SE7320SP2
Server
OEM must request certification by Microsoft for their
specific product.
http://www.microsoft.com/whdc/hcl/default.mspx
(choose the prope catalog and search on SE7320SP2)
http://developer.intel.com/design/servers/whql.htm
![](asset-b.png)
Intel® Server Board SE7320SP2 Supported Operating Systems
Revision 1.7
11
Operating System Certification Listing Comments
Microsoft* Windows†
Server 2003 Enterprise
Edition
Intel® SE7320SP2
Server
OEM must request certification by Microsoft for their
specific product.
http://www.microsoft.com/whdc/hcl/default.mspx
(choose the proper catalog and search on SE7320SP2)
http://developer.intel.com/design/servers/whql.htm
Microsoft* Windows†
Server 2003 Enterprise
X64 Edition
Intel® SE7320SP2
Server
OEM must request certification by Microsoft for their
specific product.
http://www.microsoft.com/whdc/hcl/default.mspx
(choose the proper catalog and search on SE7320SP2)
http://developer.intel.com/design/servers/whql.htm
Red Hat Enterprise Linux
3.0 Intel® SE7320SP2
Server
http://hardware.redhat.com/hcl/?pagename=detail&hid=5
609
Novell NetWare† 6.5 Intel® SE7320SP2
Server
Cert. ID: 76235 (SE7320SP2 with SC5300)
Cert. ID: 76236 (SE7320SP2 with SC5275E)
![](asset-c.png)
Adapters and Peripherals Intel® Server Board SE7320SP2
12 Revision 1.7
4. Adapters and Peripherals
Add-in adapter-card, peripheral compatibility and stress testing will only be performed with the
latest version of an operating system at the time the validation testing occurred. The following
table shows the operating system and base configurations used to validate each device. The
adapters are divided into categories based on their functionality. All integrated on-board
devices are tested by default and are therefore not included in the following tables.
Note that not all adapter cards were tested under all operating systems. The following notation
is used in the tested adapters and peripherals table below to indicate the support level that Intel
provides for a particular adapter under a particular operating system:
Number (i.e. 1) This adapter or peripheral has been tested and is supported under the specific
configuration identified in the Base System Configurations Table in Section 2 of this
document.
Number in brackets (i.e. [1]) This adapter or peripheral has been tested, but is NOT supported under the specific
configuration identified in the Base System Configurations Table in Section 2 of this
document.
NT This adapter or peripheral has not been tested under this operating system and is not
supported under this operating system.
ND This adapter or peripheral has not been tested under this operating system due to
limitations in IHV driver availability, and is not supported under this operating system.
SA
This adapter has not been tested by Intel under this operating system, but it is
supported in this OS based on this adapter deemed as a subset of a successfully
tested superset adapter listed right-above. Intel has determined that these adapters
use the same FW and drivers and have nearly identical system interface. In addition,
Intel has secured IHV commitment to support the adapters equally. All guidelines for
the superset adapter apply to this subset adapter.
Any variations to the standard adapter installation process or to expected adapter functionality
are documented in the Installation Guidelines section of this document. If there are installation
guidelines affecting a particular adapter and operating system combination, these are
referenced in the following table. If there is no installation guidelines noted in the following
table, then the adapter installed and functioned as expected using manufacturer’s installation
instructions or Intel’s best-known methods.
Testing of adapter cards is normally performed with expansion ROMs for
unused add-in adapters and onboard controllers, disabled in BIOS Setup. Intel
recommends that customers disable the option ROM for add-in controllers
and/or the on-board controllers when not booting from the controller or needing
to use its built in utilities.
![](asset-d.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 13
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
4.1 PCI RAID
Adaptec† ASR-2200S ASR-2200S PCI, 64/66 SCSI, BIOS:
V4.2-0[Build
7349] [1],2,3 4 [1],2 [1],2,3 NT NT 4 NT 4 [1],2 2 [1],2
Adaptec† ASR-2120S ASR-2120S PCI, 64/66 SCSI SA SA SA SA NT NT SA NT SA SA SA SA
Adaptec† ASR-2110S ASR-2110S PCI 64/66 SCSI [1] NT 1 1 NT NT NT NT NT [1] NT [1]
ICP Vortex† GDT8524RZ GDT8524RZ PCI, 64/66 SCSI 1,2,3 NT 1,2 1,2,3 NT ND ND ND ND [1],2 NT [1],2
ICP Vortex† GDT8514RZ GDT8514RZ PCI, 64/66 SCSI 1,2,3 NT 1,2,3 1,2 NT ND ND ND ND [1],2 NT 1,2
Intel SRCU32U SRCU32U PCI, 64/66 SCSI [1],2,3 NT [1],2,3 [1],2,3 NT ND ND NT NT [1],2,[3] NT [1],2,3
Intel SRCU42L SRCU42L PCI, 64/66 SCSI 1,2,3 NT 1,2,3 1,2,3 NT ND ND NT NT [1],2,[3] 2 1,2,3
Intel SRCU42X SRCU42X PCI-X, 133 SCSI,
BIOS:H429
F/W:414A 2,[3],4 4 2,[3],4 2,[3] 2 4 4 4 4 2,[3] 2 2,[3]
Intel SRCU42E SRCU42E PCI-E, x8 SCSI 3 NT 3 3 NT ND ND NT NT 3 NT 3
LSI Logic† Express 500
(MegaRAID
475) MegaRAID 475 PCI, 64/66 SCSI 1,2 ND 1,2 1,2 2 ND ND ND ND [1],2 2 1,2
LSI Logic† Elite 1600
(MegaRAID
493) 4932010232A SCSI [1],[2] ND [1],[2] NT NT ND ND ND ND [1] NT [1],[2]
LSI Logic† MegaRAID 320-
2X MegaRAID 320-
2X PCI-X, 133 SCSI [1],2,[3] NT 1,2,[3] 1,2,[3] 2 ND ND ND ND [1],2,[3] 2 1,2,[3]
![](asset-e.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 14
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
LSI Logic† MegaRAID 320-
4X MegaRAID 320-
4X PCI-X, 133 SCSI SA NT SA SA SA ND ND ND ND SA SA SA
LSI Logic† MegaRAID 320-
2E MegaRAID 320-E PCI-E, x8 SCSI,
BIOS:H423
F/W:514F 3 4 3 3 NT NT 4 NT 4 3 NT 3
3Ware† Escalade 8506-
8 8506-8 PCI, 64/66 SATA 3 ND 3 3 NT ND ND ND ND 3 NT [3]
3Ware† Escalade
9500S-8 9500S-8 PCI-X, 66 SATA,
BIOS:G119
F/W:713N 4 4 4 ND ND ND ND ND ND ND ND ND
3Ware† Escalade
9500S-8ML 9500S-8ML PCI-X, 66 SATA SA SA SA ND ND ND ND ND ND ND ND ND
3Ware† Escalade
9500S-4LP 9500S-4LP PCI-X, 66 SATA SA SA SA ND ND ND ND ND ND ND ND ND
3Ware† Escalade
9500S-12 9500S-12 PCI-X, 66 SATA SA SA SA ND ND ND ND ND ND ND ND ND
3Ware† Escalade
9500S-12ML 9500S-12ML PCI-X, 66 SATA SA SA SA ND ND ND ND ND ND ND ND ND
Adaptec† AAR-2410SA AAR-2410SA PCI, 64/66 SATA 2,3 NT 2,3 2,3 2 ND ND ND ND 2,3 2 2,3
Adaptec† AAR-21610SA AAR-21610SA PCI, 64/66 SATA 3 NT 3 3 NT ND ND ND ND [3] NT 3
Adaptec† AAR-2810SA AAR-2810SA PCI, 64/66 SATA SA NT SA SA NT ND ND ND ND SA NT SA
ICP vortex GDT8546RZ GDT8546RZ PCI, 64/66 SATA 1,2,3 NT 1,2,[3] 1,2,3 NT ND ND ND ND [1],2,3 NT 1,2,3
Intel SRCS14L SRCS14L PCI, 64/66 SATA 1,2,3 NT 1,2,3 1,2,3 2 ND ND NT NT [1],2,3 2 1,2,3
Intel SRCS16 SRCS16 PCI. 64/66 SATA 2,3 NT 2,3 2,3 2 ND ND NT NT 2,3 2 2,3
![](asset-f.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 15
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
Intel SRCS28X SRCS28X PCI-X, 133 SATA,
BIOS:H424
F/W:813D 4 ND 4 NT NT ND ND ND ND NT NT ND
LSI Logic† MegaRAID
SATA150-6 MegaRAID
SATA150-6 PCI, 64/66 SATA,
BIOS:G119
F/W:713N 1,2,3 4 1,2,3 1,2,3 NT NT 4 NT 4 [1],2,3 NT 1,2,3
LSI Logic† MegaRAID
SATA150-4 MegaRAID
SATA150-4 PCI, 64/66 SATA SA SA SA SA NT NT SA NT SA SA NT SA
4.2 PCI SCSI
Adaptec† ASC-29160LP ASC-29160LP PCI, 64/66 1,2,3 NT [1],2,3 1,2,3 2 NT NT NT NT [1],2,3 2 1,2,3
Adaptec† ASC-29160N ASC-29160N PCI, 64/66 SA NT SA SA SA NT NT NT NT SA SA SA
Adaptec† ASC-29160* ASC-29160 PCI,64/66 BIOS:V3.10 1,2,3,4 4 [1],2,3,4 1,2,3,4 2,4 4 4 4 4 [1],2,3,4 2,4 1,2,3,4
Adaptec† ASC-29320ALP ASC-29320ALP PCI-X, 133 1,2,3 NT 1,2,3 1,[2],3 NT ND ND ND ND [1],[2],3 NT 1,2,3
Adaptec† ASC-29320LP-
R ASC-29320LP-R PCI-X, 133 SA NT SA SA NT ND ND ND ND SA NT SA
Adaptec† ASC-29320-R ASC-29320-R PCI-X, 133 SA NT SA SA NT ND ND ND ND SA NT SA
Adaptec† ASC-39320A ASC-39320A PCI-X, 133 BIOS:V4.30 [1],[2],3 NT 1,[2] 1,[2],3 NT NT 4 NT 4 [1],[2] NT NT
Adaptec† ASC-39320D-R ASC-39320D-R PCI-X, 133 SA NT SA SA NT NT SA NT SA SA NT NT
Adaptec† ASC-39320-R ASC-39320-R PCI-X, 133 SA NT SA SA NT NT SA NT SA SA NT NT
LSI Logic† LSI20160LP LSI20160LP PCI, 32/33 1,2,3 NT 1,2,3 1,2,3 2 ND ND ND ND [1],2,3 2 1,2,3
![](asset-10.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 16
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
LSI Logic† LSI20160 LSI20160 PCI, 32/33 SA NT SA SA SA ND ND ND ND SA SA SA
LSI Logic† LSI22320-R LSI22320-R PCI-X, 133 BIOS:5.11.0.0 1,2,3 4 1,2 1,2,3 2 NT 4 NT 4 [1],2 2 1,2
LSI Logic† LSI20320-R LSI20320-R PCI-X, 133 2 NT 2 2 2 NT NT NT TN 2 2 2
4.3 PCI Fiber Channel
Emulex† LP9002LP LP9002LP-F PCI, 64/66 1,2,3 NT 1,2 [1],2,3 [2] ND ND NT NT [1] 2 1,2
Emulex† LP952L LP952L-F PCI, 64/66 SA NT SA SA SA ND ND NT NT SA SA SA
Emulex† LP9802DC LP9802DC-F2 PCI-X, 133 1,2,3 NT 1,2 [1],2,3 2 ND ND NT NT [1] 2 [1],[2]
Emulex† LP9802 LP9802-F2 PCI-X, 133 SA NT SA SA SA ND ND NT NT SA SA SA
Emulex† LP982 LP982-F2 PCI-X, 133 SA NT SA SA SA ND ND NT NT SA SA SA
Emulex† LP10000DC-Ex LP10000DC-Ex PCI-E, x8 3 NT 3 3 NT ND ND NT NT 3 NT 3
Emulex† LP1050Ex LP1050Ex-F2 PCI-E, x4 [2] NT NT 2 NT ND ND NT NT NT NT 2
Qlogic † QLA2312 QLA2312 PCI-X, 133 1 NT [1] 1 NT ND ND NT NT [1] NT [1]
Qlogic † QLA2342 QLA2342 PCI-X, 133 2,3 NT 2 2,3 2 NT NT NT NT 2 2 2
Qlogic † QLA2340 QLA2340 PCI-X, 133 SA NT SA SA SA NT NT NT NT SA SA SA
Qlogic † QLE2360 QLE2360 PCI-E, x4 [2] NT NT 2 NT NT NT NT NT NT NT 2
![](asset-11.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 17
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
4.4 PCI NIC
3COM† Etherlink 10/100
PCI 3C980C-TXM PCI, 32/33 1,2,3 ND 1,2,3 1,2,3 2 ND ND ND ND 1,2,3 2 1,2,3
3COM† Gigabit Server
Adapter 3C996B-T PCI-X, 133 1,2,3 ND 1,2,3 1,2,3 2 ND ND ND ND 1,2,3 2 1,2,3
Intel PRO/100+ S
Server Adapter PILA8470D3 PCI, 32/33 1,2 NT 1,2 1,2 2 NT NT NT NT 1,2 2 1,2
Intel PRO/100+ S
Server Adapter PILA8470C3 PCI, 32/33 SA NT SA SA SA NT NT NT NT SA SA SA
Intel PRO/100S Dual
Port PILA8472C3 PCI, 64/66 1,2,[3] 4 1,2,[3] 1,2,[3] 2 NT 4 NT 4 1,2,[3] 2 1,2,[3]
Intel PRO/1000MT
Gigabit Server
Adapter PWLA8490MT PCI-X, 133 1,2,3 NT 1,2,3 1,2,3 2 NT NT NT NT 1,2,3 2 1,2,3
Intel PRO/1000MT
Gigabit Server
Adapter PWLA8490MF PCI-X, 133 Fiber SA NT SA SA SA NT NT NT NT SA SA SA
Intel PRO/1000XT
Gigabit Server
Adapter PWLA8490XT PCI-X, 133 1,2,3 NT 1,2,3 1,2,3 2 NT NT NT NT 1,2,3 2 1,2,3
Intel PRO/1000XT
Gigabit Server
Adapter PWLA8490XTL PCI-X, 133 Low-Profile SA NT SA SA SA NT NT NT NT SA SA SA
Intel PRO/1000XT
Gigabit Server
Adapter PWLA8490XF PCI-X, 133 Fiber SA NT SA SA SA NT NT NT NT SA SA SA
Intel PRO/1000XT
Gigabit Server
Adapter PWLA8490XFL PCI-X, 133
Fiber, Low-
Profile SA NT SA SA SA NT NT NT NT SA SA SA
![](asset-12.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 18
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
Intel PRO/1000MT
Dual port
Gigabit Adapter PWLA8492MT PCI-X, 133 1,2,4 4 1,2 1,2 2 NT 4 NT 4 1,2 2 1,2
Intel PRO/1000MT
Dual port
Gigabit Adapter PWLA8492MF PCI-X, 133 Fiber SA 4 SA SA SA NT 4 NT 4 SA SA SA
Syskonnect† SK-9E21D SK-9E21D PCI-E, x1 2,3 NT 3 2,3 NT NT NT NT NT 3 NT 2,3
4.5 Modems
3COM† V.Everything
56K Corporate 3CP3453 RS-232 External 1,2,3 NT 1,2,3 1,2,3 2 NT NT NT NT 1,2,3 [2] NT
3COM† USR5610B USR5610B PCI, 32/33 Internal NT 4 NT NT NT NT 4 NT [4] NT NT NT
4.6 Human Interface Devices
Keytronic† PROpilot PROpilot PS2 1,2,3 4 1,2,3 1,2,3 2 NT 4 NT 4 1,2,3 2 1,2,3
Keytronic† E06101USB-C E06101USB-C USB 3 4 3 3 NT NT 4 NT 4 3 NT 3
Logitech† Optical Mouse 930582-0403 PS2 1,2,3 NT 1,2,3 1,2,3 2 NT NT NT NT 1,2,3 2 1,2,3
Logitech† Internet
Navigator 930582-0403 PS2 SA NT SA SA SA NT NT NT NT SA SA SA
Logitech† Optical Mouse 930582-0121 USB 1,2,3 4 1,2,3 1,2,3 2 NT 4 NT 4 1,2,3 2 1,2,3
Logitech† Internet
Navigator 930582-0121 USB SA NT SA SA SA NT NT NT NT SA SA SA
![](asset-13.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 19
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
Logitech† M-S61 NT 4 NT NT NT NT 4 NT 4 NT NT NT
Microsoft† Intellimouse
Optical PS2/USB 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Rainbow† Sentinal Duo
Hardware Key Sentinal Duo USB 1,[2] NT 1,2 [1],[2] NT NT NT NT NT [1],[2] NT [1],[2]
4.7 CDROM Drives
IOMega† CD-RW
48x24x48 32721 USB2
External, CD-
R/RW 1,2,3 NT [1],2,3 1,2,3 NT NT NT NT NT 1,2,3 NT 1,2,3
Mitsumi† SR244W1 SR244W1 ATA33 Slimline, CD-
ROM 1,2,3 4 1,2,3 1,2,3 NT NT 4 NT 4 1,2,3 NT 1,2,3
Plextor† Plexwriter
40x12x40U CD-RW
40x12x40 USB External, CD-
R/RW 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Plextor† Plexwriter
40x12x40S PX-
W4012TS/SW SCSI-UW CD-R/RW 1,2,3 NT 1,2,3 1,2,3 NT NT NT NT NT 1,2,3 NT 1,2,3
Plextor† Plexwriter
52/32/52 Premium-U USB2 External, CD-
R/RW 3 NT 3 3 NT NT NT NT NT 3 NT 3
Samsung† SC-152 SC-152 ATA33 CD-ROM 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Sony† CRX230AD/K CRX230AD/K ATA33 CR-R/RW NT 4 NT NT NT NT 4 NT 4 NT NT NT
Teac† CDWF540/kit CDWF540/kit USB2 CD-ROM 1,2 NT [1],2 1,2, NT NT NT NT NT 1,2 NT 1,2
Teac† CD-552E CD-552E ATA33 CD-ROM 3 NT 3 3 NT NT NT NT NT 3 NT 3
![](asset-14.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 20
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
4.8 DVD Drives
HLDS† GCC-4521 GCC-4521 ATA33 CD-RW/DVD-
ROM combo NT 4 NT NT NT NT 4 NT 4 NT NT NT
HLDS† GDR-8163 GDR-8163 ATA33 CD-RW/DVD-
ROM combo NT 4 NT NT NT NT 4 NT 4 NT NT NT
Lite On† SOHC-5235K SOHC-5235K ATA33 CD-RW/DVD-
ROM combo NT 4 NT NT NT NT 4 NT 4 NT NT NT
Lite On† LSC-24082KX LSC-24082KX USB2.0 CD-RW/DVD-
ROM combo NT 4 NT NT NT NT 4 NT 4 NT NT NT
Mitsumi† SR242BS SR242BS ATA33 DVD-ROM 1,2,3 NT 1,2,3 1,2,3 NT NT NT NT NT 1,2,3 NT 1,2,3
Pioneer† DVD-305S DVD-305S SCSI-N DVD-ROM 1,2,3 NT 1,2,3 1,2,3 NT NT NT NT NT 1,2,3 NT 1,2,3
Pioneer† DVD-S606 DVD-S606 USB2 DVD-ROM 3 NT 3 3 NT NT NT NT NT 3 NT 3
Samsung† SD-616 SD-616 ATA33 DVD-ROM 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Sony† CRX-835E CRX-835E ATA33 CD-RW/DVD-
ROM combo NT 4 NT NT NT NT 4 NT 4 NT NT NT
Sony† DRU500AX DRU500AX ATA33
DVD±R/RW,
CD-R/RW 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Sony† DRU-510A DRU-510A ATA33 DVD+RW,
CD-R/RW NT 4 NT NT NT NT 4 NT 4 NT NT NT
Teac† DV-28E B82 DV-28E B82 ATA33 Slimline, CD-
RW/DVD-
ROM combo NT 4 NT NT NT NT 4 NT 4 NT NT NT
Toshiba† SD-M1401 SD-M1401 ATA33 DVD-ROM 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
![](asset-15.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 21
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
Toshiba† SD-M1712 SD-M1712 ATA33 DVD-ROM 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Toshiba† SD-M1912-S SD-M1912-S ATA33 DVD-ROM NT 4 NT NT NT NT 4 NT 4 NT NT NT
Toshiba† SD-R2512 SD-R2512 UDMA33 DVD-ROM 3 NT 3 3 NT NT NT NT NT 3 NT 3
Panasonic† CW-8123B CW-8123B ATA33
CD-RW/DVD-
ROM combo 3 NT 3 3 NT NT NT NT NT 3 NT 3
Teac† DV-28E-BP3 DV-28E-BP3 ATA33
CD-RW/DVD-
ROM combo 3 NT 3 3 NT NT NT NT NT 3 NT 3
4.9 Tape Drives
Certance† STD2401LW-S STD2401LW-S SCSI-U2 20/40g DAT
DDS4 5.25HH 4 4 4 NT NT 4 4 4 4 NT NT 4
Quantum† DLT, VS160 BH2AA-YS [1],2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT [1],[2]
Quantum† Super DLT,
SDLT320 TRS23BA-YF 1,2 NT [1],2 1,2 NT NT NT NT NT 1,2 NT [1],[2]
Seagate† Scorpion 40
DDS4 DAT STD2401LW-S 3 NT 3 3 NT NT NT NT NT 3 NT 3
4.10 Removable Drives
IOMega† Zip 750MB USB
2.0 32324 USB2 External 1,2,3 4 1,2,3 1,2,3 NT NT 4 NT 4 1,2,3 NT 1,2,3
Sony† VAIO External
USB floppy PCGA-UFD5 USB External 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Teac† FD235-HF FD235-HF 1,2,3 4 1,2,3 1,2,3 NT NT 4 NT 4 1,2,3 NT 1,2,3
![](asset-16.png)
Intel® Server Board SE7320SP2 Adapters and Peripherals
Revision 1.7 22
Manufacturer Model Name Model Number Interface Comments
Microsoft Windows†
Server 2003 Enterprise
Edition SP1
Microsoft Windows†
Server 2003 Enterprise
X64 Edition
Microsoft Windows†
2000 AS SP4
Red Hat Enterprise
Linux† 3.0 Update2
Red Hat Enterprise
Linux† 3.0 Update2
EM64T
Red Hat Enterprise
Linux† 4.0 Update1
Red Hat Enterprise
Linux† 4.0 Update1
EM64T
SuSE Linux Enterprise
9.0 SP1
SuSE Linux Enterprise
9.0 SP1 EM64T
SuSE Linux 9.0
Professional
SuSE Linux 9.1
Professional EM64T
Novell Netware† 6.5
4.11 KVM
Avocent† 1160ES 1160ES 16-port 1,2 NT 1,2 1,2 NT NT NT NT NT 1,2 NT 1,2
Belkin† Omniview
PRO2 F1DA108T 8-port 1,2,3 4 1,2,3 1,2,3 NT NT 4 NT 4 1,2,3 NT 1,2,3
*The validation of Adaptec† ASC-29160 SCSI card on configuration No.4 system is only for tape drives.
![](asset-17.png)
Intel® Server Board SE7320SP2
Revision 1.7
5. Hard Disk Drives
The hard drives listed in the following table have been tested with the Intel® server board
SE7320SP2 by Intel in its validation labs and/or by individual drive vendors. The following
operating system identifiers are used in the table to specify which OS each drive was tested
under.
Identifier
number Operating System
1 Microsoft Windows† Server 2003 Enterprise Edition with
service pack 1
2 Microsoft Windows† 2000 Advanced Server with service pack
4
3 Red Hat Linux† 3.0 AS Update 2
4 Novell NetWare† 6.5
5 SuSE† 9.0 Professional
6 Microsoft Windows† Server 2003 Enterprise X64 Edition
7 Red Hat† Enterprise Linux 4.0 Update 1 EM64T
8 SuSE† Linux Enterprise Server 9, SP1, EM64T
Note that not all hard drives were tested under all operating systems. The following notation is
used in the tested hard drives table below to indicate the support level that Intel provides for a
particular hard drive with a particular operating system:
Number (i.e. 1) This hard drive has been tested and is supported under the operating system identified
by the operating system identification number.
Number in brackets (i.e. [1]) This hard drive has been tested, but is NOT supported under the operating system
identified by the operating system identification number.
SD (Similar Drive)
This hard drive model/capacity was not tested with this server board, but it is
supported on corresponding operating systems based on successful testing of a larger
capacity hard drive from the same hard drive family. This drive has been determined
to use the exact same firmware and drivers as a larger capacity hard drive that has
been successfully tested with this server board. The only difference between this drive
and the one that was used in testing is the storage capacity. Intel provides the same
level of support for all hard drives listed in this document, regardless of whether the
drive was tested or not. Customers should always test hard drives as part of the final
system configuration prior to deployment.
IHVT (IHV Tested)
The hard disk drive was tested according to Intel-approved guidelines and test
procedures by the Independent Hardware Vendor (IHV) that manufactured the drive.
Intel provides the same level of support for all hard drives listed in this document,
regardless of whether the drive was tested in an Intel lab or not. IHV test reports
remain the property of the IHV (Intel cannot provide copies of these reports).
![](asset-18.png)
Intel® Server Board SE7320SP2 Hard Disk Drives
Revision 1.7 24
Manufacturer Product Family Model Number Interface RPM Drive Size (GB) Tested Operating Systems Comments
5.1 SCSI Hard Disk Drives
Fujitsu† Alegro 8LE MAP3147NC U320 SCSI SCA 10,000 147GB 1,2,3,4,5
Fujitsu† Alegro 8LE MAP3735NC U320 SCSI SCA 10,000 73GB SD
Fujitsu† Alegro 8LE MAP3367NC U320 SCSI SCA 10,000 36GB SD
Fujitsu† Alegro 8LX MAS3735NC U320 SCSI SCA 15,000 73GB 1,2,3,4,5
Fujitsu† Alegro 8LX MAS2267NC U320 SCSI SCA 15,000 36GB SD
Fujitsu† Alegro 8LX MAS3184NC U320 SCSI SCA 15,000 18GB SD
Hitachi† DK32EJ DK32EJ-14 U320 SCSI SCA 10,000 147GB 1,2,3,4,5
Hitachi† DK32EJ DK32EJ-72 U320 SCSI SCA 10,000 72GB SD
Hitachi† DK32EJ DK32EJ-36 U320 SCSI SCA 10,000 36GB SD
Hitachi† UltraStar 10K300 UltraStar 10K300 U320 SCSI SCA 10,000 300GB 1,2,3,4,5
Hitachi† UltraStar 15K73 HUS157373EL3800 U320 SCSI SCA 15,000 73GB 1,2,3,4,5
Hitachi† UltraStar 15K73 HUS157373EL3600 U320 SCSI 68 pin 15,000 73GB SD
Hitachi† UltraStar 15K73 HUS157336EL3800 U320 SCSI SCA 15,000 36GB SD
Hitachi† UltraStar 15K73 HUS157336EL3600 U320 SCSI 68 pin 15,000 36GB SD
Maxtor† Atlas 10K IV 8B146J0 U320 SCSI SCA 10,000 146GB 1,2,3,4,5
Maxtor† Atlas 10K IV 8B074J0 U320 SCSI SCA 10,000 74GB SD
Maxtor† Atlas 10K IV 8B036J0 U320 SCSI SCA 10,000 36GB SD
Maxtor† Atlas 10K V 8D300J0 U320 SCSI SCA 10,000 300GB 1,2,3,4,5,6,7,8
Maxtor† Atlas 10K V 8D147J0 U320 SCSI SCA 10,000 147GB SD
Maxtor† Atlas 10K V 8D073J0 U320 SCSI SCA 10,000 73GB SD
Maxtor† Atlas 15K 8C073J0 U320 SCSI SCA 15,000 73GB 1,2,3,4,5
Maxtor† Atlas 15K 8C036J0 U320 SCSI SCA 15,000 36GB SD
Maxtor† Atlas 15K 8C018J0 U320 SCSI SCA 15,000 18GB SD
Maxtor† Atlas 15K II 8E147J0 U320 SCSI SCA 15,000 147GB 1,2,3,4,5
Maxtor† Atlas 15K II 8E073J0 U320 SCSI SCA 15,000 73GB SD
Maxtor† Atlas 15K II 8E036J0 U320 SCSI SCA 15,000 36GB SD
![](asset-19.png)
Intel® Server Board SE7320SP2 Hard Disk Drives
Revision 1.7 25
Manufacturer Product Family Model Number Interface RPM Drive Size (GB) Tested Operating Systems Comments
Seagate† Cheetah 10K.6 ST3146807LC U320 SCSI SCA 10,000 146GB 1,2,3,4,5
Seagate† Cheetah 10K.6 ST373307LC U320 SCSI SCA 10,000 73GB SD
Seagate† Cheetah 10K.6 ST336607LC U320 SCSI SCA 10,000 36GB SD
Seagate† Cheetah X15K.3 ST373453LC U320 SCSI SCA 15,000 73GB 1,2,3,4,5
Seagate† Cheetah X15K.3 ST336753LC U320 SCSI SCA 15,000 36GB SD
Seagate† Cheetah X15K.3 ST318453LC U320 SCSI SCA 15,000 18GB SD
Seagate† Cheetah 10K.7 ST3300007LC U320 SCSI SCA 10,000 300GB 1,2,3,4,5
Seagate† Cheetah 10K.7 ST3146007LC U320 SCSI SCA 10,000 146GB SD
Seagate† Cheetah 10K.7 ST3073007LC U320 SCSI SCA 10,000 73GB SD
5.2 Parallel ATA Hard Disk Drives
Hitachi† Deskstar 180GXP IC35L180AVV207-1 ATA100 7,200 180GB 1,2,3,4,5
Hitachi† Deskstar 180GXP IC35L120AVV207-1 ATA100 7,200 120GB SD
Hitachi† Deskstar 180GXP IC35L090AVV207-1 ATA100 7,200 90GB SD
Hitachi† Deskstar 180GXP IC35L060AVV207-1 ATA100 7,200 60GB SD
Hitachi† Deskstar 180GXP IC35L030AVV207-1 ATA100 7,200 30GB SD
Hitachi† Deskstar 7K400 HDS724040KLAT80 ATA100 7,200 400GB 6,7,8
Maxtor† DiamondMax Plus 9 6Y160P0 ATA133 7,200 160GB 1,2,3,4,5
Maxtor† DiamondMax Plus 9 6Y200P0 ATA133 7,200 200GB SD
Maxtor† DiamondMax Plus 9 6Y120P0 ATA133 7,200 120GB SD
Maxtor† DiamondMax Plus 9 6Y080P0 ATA133 7,200 80GB SD
Maxtor† DiamondMax Plus 9(Maxline
Plus II) 6Y200P0 ATA133 7,200 200GB (8MB cache) 1,2,3,4,5
Seagate† Barracuda 5 ATA ST3120023A ATA100 7,200 120GB (8MB cache) 1,2,3,4,5
Western Digital† Caviar XL60 WD1200BB-00EEA1 ATA100 7,200 120GB 1,2,3,4,5
Western Digital† Caviar XL60 WD2000JB ATA100 7,200 200GB (8MB cache) 1,2,3,4,5
Western Digital† Caviar XL60 WD2500JB ATA100 7,200 250GB (8MB cache) SD
Western Digital† Caviar XL60 WD1800JB ATA100 7,200 180GB (8MB cache) SD
Western Digital† Caviar XL60 WD1200JB ATA100 7,200 120GB (8MB cache) SD
![](asset-1a.png)
Intel® Server Board SE7320SP2 Hard Disk Drives
Revision 1.7 26
Manufacturer Product Family Model Number Interface RPM Drive Size (GB) Tested Operating Systems Comments
5.3 Serial ATA (SATA) Hard Disk Drives
Hitachi† Deskstar 7K250 HDS722525VLST80 SATA 7,200 250GB 1,2,3,4,5
Hitachi† Deskstar 7K250 HDS722516VLST80 SATA 7,200 160GB SD
Hitachi† Deskstar 7K250 HDS722512VLST80 SATA 7,200 120GB SD
Hitachi† Deskstar 7K250 HDS722580VLST80 SATA 7,200 80GB SD
Hitachi† Deskstar 7K400 HDS724040KLSA80 SATA 7,200 400GB 1,2,3,4,5,6,7,8
Maxtor† DiamondMax Plus 9 6Y120M6 SATA 7,200 120GB 1,2,3,4,5
Maxtor† DiamondMax Plus 9 6Y250M6 SATA 7,200 250GB SD
Maxtor† DiamondMax Plus 9 6Y200M6 SATA 7,200 200GB SD
Maxtor† DiamondMax Plus 9 6Y160M6 SATA 7,200 160GB SD
Maxtor† DiamondMax Plus 9 6Y080M6 SATA 7,200 80GB SD
Maxtor† DiamondMax Plus 9 6Y060M6 SATA 7,200 60GB SD
Seagate† Barracuda 5 SATA ST3120023AS SATA 7,200 120GB 1,2,3,4,5
Western Digital† WD Raptor WD360GD SATA 10,000 36GB 1,2,3,4,5
Western Digital† WD Raptor WD740GD SATA 10,000 74GB SD
Western Digital† WD Caviar XL80 II WD1600JD-00HBB0 SATA 7,200 160GB 1,2,3,4,5
Western Digital† WD Caviar XL80 II WD2000JD-00HBB0 SATA 7,200 200GB SD
Western Digital† WD Caviar XL80 II WD2500JD-00HBB0 SATA 7,200 250GB SD
5.4 External Hard Disk Drives
Maxtor† 5000XT 5000XT / S01J250 USB2/1.1 & Firewire 250GB 1,2,3,4,5,6,7,8
Addonics† Combo HD Kit AEMED35AUM USB2 1,2,3,4,5
![](asset-1b.png)
Intel® Server Board SE7320SP2 Tech Tips
Revision 1.7 27
6. Tech Tips
6.1 Emulex* LP1050Ex and Qlogic* QLE2360 Fibre Channel
Adpaters Experience Delayed Write Failures during
Extended Stress Testing
Issue During Intel’s extended stress test runs, fibre channel hard drives attached to the
Emulex* LP1050Ex or Qlogic QLE2360 PCI Express fibre channel adapters begin
experiencing delayed write failures and were eventually marked offline. These
failures have only been seen when running under Microsoft* Windows* Server
2003. Failures have not been seen when running under Novell* Netware* 6.5 or
Red Hat* Advanced Server 3.0.
Implication Fibre channel hard drives may experience delayed write failures or the hard drives
may be marked offline if the Emulex* LP1050Ex or Qlogic QLE2360 PCI Express
fibre channel adapters are utilized in combination with Intel® Server Board
SE7320SP2, SE7520BD2, SE7520AF2, SE7520JR2, or SE7320VP2 and the
Microsoft* Windows* Server 2003 operating system, if the system is subjected to
extended periods of intensive I/O application stress.
Guideline The Emulex* LP1050E or Qlogic QLE2360 PCI Express fibre channel adapters
should not be utilized with the Intel® Server Board SE7320SP2, SE7520BD2,
SE7520AF2, SE7520JR2, or SE7320VP2 with the Microsoft* Windows* Server
2003 operating system. The Emulex LP1050Ex or Qlogic QLE236x PCI Express
fibre channel adpateres may be used with therse server boards with Novell*
Netware* 6.5 or Red Hat* Advanced Server 3.0.
Status Intel is currently working with Emulex and Qlogic to investigate a fix for this issue.
6.2 Emulex* LP9802DC PCI-X fibre channel host adapter issue
under Netware 6.5
Problem The Emulex* LP9802DC PCI-X fibre channel host adpater works as expected
when in Intel® Server Board on Microsoft Windows* and supported Linux
configurations. However, when the adapter is installed in an Intel system with
Netware 6.5, the driver is not recognized by Netware. Netware fails to recognize
both driver versions 2.00c and 2.02g. The likely source for this failure is a conflict
between the Netware operating system and the PCI-X bridge chip that is used on
the LP9802DC adapter.
Implication The Emulex* LP9802DC-F2 adapter driver is not recognized by Novell Netware*
6.5.
Guideline The Emulex* LP10000DC adpater is a compatible, next generation bridgeless
solution, which offers the same feature set with increased performance, work as
expected under Novell Netware 6.5 and has been validated as a supported
adapter on current Intel® platforms
Status Intel is currently working with Emulex to investigate a fix for this issue.
