Regulatory Information: Intel(R) PRO/Wireless
3965ABG Network Connection User Guide
Intel(R) PRO/Wireless 3965ABG Network Connection
Intel(R) PRO/Wireless 3945ABG Network Connection
Intel(R) PRO/Wireless 3945BG Network Connection
Intel(R) PRO/Wireless 2915ABG Network Connection
Intel(R) PRO/Wireless 2200BG Network Connection
Intel(R) PRO/Wireless 3965ABG Network Connection
Intel(R) PRO/Wireless 3945ABG Network Connection
Intel(R) PRO/Wireless 3945BG Network Connection
• Information for the User
• Regulatory Information
Intel(R) PRO/Wireless 2915ABG Network Connection
• Information for the User
• Regulatory Information
Intel(R) PRO/Wireless 2200BG Network Connection
• Information for the User
• Regulatory Information
Intel(R) PRO/Wireless 3965ABG Network Connection,
Intel(R) PRO/Wireless 3945ABG Network Connection
and the Intel(R) PRO/Wireless 3945BG Network
Connection
The information in this document applies to the following products:
Tri-mode wireless LAN adapters (802.11a/802.11b/802.11g )
Intel(R) PRO/Wireless 3965ABG Network Connection (model WM3965ABG)
Intel(R) PRO/Wireless 3945ABG Network Connection (model WM3945ABG)
Dual-mode wireless LAN adapters (802.11b/802.11g )
Intel(R) PRO/Wireless 3945BG Network Connection (model WM3945BG)
NOTE: Due to the evolving state of regulations and standards in the
wireless LAN field (IEEE 802.11 and similar standards), the information
provided herein is subject to change. Intel Corporation assumes no
responsibility for errors or omissions in this document. Nor does Intel
make any commitment to update the information contained herein.
Information for the user
Safety Notices
The FCC with its action in ET Docket 96-8 has adopted a safety standard for human
exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified
equipment. The Intel(R) PRO/Wireless 3965ABG Network Connection adapter,
Intel(R) PRO/Wireless 3945ABG Network Connection adapter, or the Intel(R)
PRO/Wireless 3945BG Network Connection adapter meet the Human Exposure limits
found in OET Bulletin 65, supplement C, 2001, and ANSI/IEEE C95.1, 1992. Proper
operation of this radio according to the instructions found in this manual will result in
exposure substantially below the FCC’s recommended limits.
The following safety precautions should be observed:
• Do not touch or move antenna while the unit is transmitting or receiving.
• Do not hold any component containing the radio such that the antenna is very
close or touching any exposed parts of the body, especially the face or eyes,
while transmitting.
• Do not operate the radio or attempt to transmit data unless the antenna is
connected; if not, the radio may be damaged.
• Use in specific environments:
• The use of wireless devices in hazardous locations is limited by the
constraints posed by the safety directors of such environments.
• The use of wireless devices on airplanes is governed by the Federal
Aviation Administration (FAA).
• The use of wireless devices in hospitals is restricted to the limits set
forth by each hospital.
• Antenna use:
• In order to comply with FCC RF exposure limits, low gain integrated
antennas should be located at a minimum distance of 20 cm (8 inches)
or more from the body of all persons.
• High-gain, wall-mount, or mast-mount antennas are designed to be
professionally installed and should be located at a minimum distance
of 30 cm (12 inches) or more from the body of all persons. Please
contact your professional installer, VAR, or antenna manufacturer for
proper installation requirements.
• Explosive Device Proximity Warning (see below)
• Antenna Warning (see below)
• Use on Aircraft Caution (see below)
• Other Wireless Devices (see below)
• Power Supply (Access Point) (see below)
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a wireless network
device) near unshielded blasting caps or in an explosive environment unless the
device has been modified to be qualified for such use.
Antenna Warnings
Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is
recommended for the Intel(R) PRO/Wireless 3965ABG Network Connection adapter,
Intel(R) PRO/Wireless 3945ABG Network Connection adapter, or the Intel(R)
PRO/Wireless 3945BG Network Connection adapter installed in a desktop or portable
computer, that the antenna for this device be installed so as to provide a separation
distance of al least 20 cm (8 inches) from all persons and that the antenna must not
be co-located or operating in conjunction with any other antenna or radio
transmitter. It is recommended that the user limit exposure time if the antenna is
positioned closer than 20 cm (8 inches).
Warning: Intel(R) PRO/Wireless LAN products are not designed for use with
high-gain directional antennas. Use of such antennas with these products is illegal.
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-
frequency wireless devices because their signals could interfere with critical aircraft
instruments.
Other Wireless Devices
Safety Notices for Other Devices in the Wireless Network: Refer to the
documentation supplied with wireless Ethernet adapters or other devices in the
wireless network.
Local Restrictions on 802.11a, 802.11b, and 802.11g Radio Usage
Caution: Due to the fact that the frequencies used by 802.11a, 802.11b and
802.11g wireless LAN devices may not yet be harmonized in all countries, 802.11a,
802.11b, and 802.11g products are designed for use only in specific countries, and
are not allowed to be operated in countries other than those of designated use. As a
user of these products, you are responsible for ensuring that the products are used
only in the countries for which they were intended and for verifying that they are
configured with the correct selection of frequency and channel for the country of use.
The device transmit power control (TPC) interface is part of the Intel(R)
PROSet/Wireless software. Operational restrictions for Equivalent Isotropic Radiated
Power (EIRP) are provided by the system manufacturer. Any deviation from the
permissible power and frequency settings for the country of use is an infringement of
national law and may be punished as such.
For country-specific information, see the additional compliance information supplied
with the product.
Wireless interoperability
The Intel(R) PRO/Wireless Intel(R) PRO/Wireless 3965ABG Network Connection
adapter, 3945ABG Network Connection adapter or the Intel(R) PRO/Wireless 3945BG
Network Connection are designed to be interoperable with other wireless LAN
products that are based on direct sequence spread spectrum (DSSS) radio
technology and to comply with the following standards:
• IEEE Std. 802.11b compliant Standard on Wireless LAN.
• IEEE Std. 802.11g compliant Standard on Wireless LAN.
• IEEE Std. 802.11a compliant Standard on Wireless LAN.
• Wireless Fidelity (WiFi) certification, as defined by the WECA (Wireless
Ethernet Compatibility Alliance).
The Intel(R) PRO/Wireless 3965ABG Network Connection adapter, Intel(R)
PRO/Wireless 3945ABG Network Connection adapter or the Intel(R)
PRO/Wireless 3945BG Network Connection adapter and your health
The Intel(R) PRO/Wireless 3965ABG Network Connection adapter, Intel(R)
PRO/Wireless 3945ABG Network Connection adapter or the the Intel(R) PRO/Wireless
3945BG Network Connection adapter, like other radio devices, emits radio frequency
electromagnetic energy. The level of energy emitted by this device, however, is less
than the electromagnetic energy emitted by other wireless devices such as mobile
phones. The Intel(R) PRO/Wireless 3965ABG Network Connection adapter, Intel(R)
PRO/Wireless 3945ABG Network Connection adapter, or the Intel(R) PRO/Wireless
3945BG Network Connection adapter wireless device operates within the guidelines
found in radio frequency safety standards and recommendations. These standards
and recommendations reflect the consensus of the scientific community and result
from deliberations of panels and committees of scientists who continually review and
interpret the extensive research literature. In some situations or environments, the
use of the Intel(R) PRO/Wireless 3965ABG Network Connection adapter, Intel(R)
PRO/Wireless 3945ABG Network Connection adapter, or the Intel(R) PRO/Wireless
3945BG Network Connection rinclude the following:
• Using the Intel(R) PRO/Wireless 3965ABG Network Connection adapter,
Intel(R) PRO/Wireless 3945ABG Network Connection adapter, or the Intel(R)
PRO/Wireless 3945BG Network Connection adapter equipment on board
airplanes, or
• Using the Intel(R) PRO/Wireless 3965ABG Network Connection, Intel(R)
PRO/Wireless 3945ABG Network Connection adapter or the Intel(R)
PRO/Wireless 3945BG Network Connection adapter equipment in any other
environment where the risk of interference with other devices or services is
perceived or identified as being harmful.
If you are uncertain of the policy that applies to the use of wireless devices in a
specific organization or environment (an airport, for example), you are encouraged
to ask for authorization to use the Intel(R) PRO/Wireless 3965ABG Network
Connection adapter, Intel(R) PRO/Wireless 3945ABG Network Connection adapter, or
the Intel(R) PRO/Wireless 3945BG Network Connection wireless devices before you
turn it on.
Regulatory information
Information for the OEMs and Integrators:
The following statement must be included with all versions of this document supplied
to an OEM or integrator, but should not be distributed to the end user.
• This device is intended for OEM integrators only.
• This device cannot be co-located with any other transmitter.
• Please refer to the full Grant of Equipment document for other restrictions.
• This device must be operated and used with a locally approved access point.
Information To Be Supplied to the End User by the OEM or
Integrator
The following regulatory and safety notices must be published in documentation
supplied to the end user of the product or system incorporating an Intel(R)
PRO/Wireless 3965ABG Network Connection, Intel(R) PRO/Wireless 3945ABG
Network Connection or an Intel(R) PRO/Wireless 3945BG Network Connection in
compliance with local regulations. Host system must be labeled with "Contains FCC
ID: XXXXXXXX", FCC ID displayed on label.
The Intel(R) PRO/Wireless 3965ABG Network Connection adapter, Intel(R)
PRO/Wireless 3945ABG Network Connection adapter, or the Intel(R) PRO/Wireless
3945BG Network Connection wireless network device must be installed and used in
strict accordance with the manufacturer's instructions as described in the user
documentation that comes with the product. For country-specific approvals, see
Radio approvals. Intel Corporation is not responsible for any radio or television
interference caused by unauthorized modification of the devices included with the
Intel(R) PRO/Wireless 3965ABG Network Connection, Intel(R) PRO/Wireless
3945ABG Network Connection or the Intel(R) PRO/Wireless 3945BG Network
Connection adapter kit, or the substitution or attachment of connecting cables and
equipment other than that specified by Intel Corporation. The correction of
interference caused by such unauthorized modification, substitution or attachment is
the responsibility of the user. Intel Corporation and its authorized resellers or
distributors are not liable for any damage or violation of government regulations that
may arise from the user failing to comply with these guidelines.
Local Restriction of 802.11a, 802.11b, and 802.11g Radio
Usage
The following statement on local restrictions must be published as part of the
compliance documentation for all 802.11a, 802.11b, and 802.11g products.
Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, and
802.11g wireless LAN devices may not yet be harmonized in all countries, 802.11a,
802.11b, and 802.11g products are designed for use only in specific countries, and
are not allowed to be operated in countries other than those of designated use. As a
user of these products, you are responsible for ensuring that the products are used
only in the countries for which they were intended and for verifying that they are
configured with the correct selection of frequency and channel for the country of use.
Any deviation from permissible settings and restrictions in the country of use could
be an infringement of national law and may be punished as such.
FCC Radio Frequency Interference Requirements
This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz
frequency range. FCC requires this product to be used indoors for the frequency
range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-
channel Mobile Satellite systems. High power radars are allocated as primary users
of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause
interference with and /or damage this device.
• This device is intended for OEM integrators only.
• This device cannot be co-located with any other transmitter.
USA—Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules. Operation of the device is subject
to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference that may cause undesired operation.
NOTE: The radiated output power of the Intel(R) PRO/Wireless
3965ABG Network Connection adapter, Intel(R) PRO/Wireless
3945ABG Network Connection adapter, or the Intel(R) PRO/Wireless
3945BG Network Connection adapter wireless network device is far
below the FCC radio frequency exposure limits. Nevertheless, the
Intel(R) PRO/Wireless LAN wireless network device should be used in
such a manner that the potential for human contact during normal
operation is minimized. To avoid the possibility of exceeding the FCC
radio frequency exposure limits, you should keep a distance of at least
20 cm between you (or any other person in the vicinity) and the
antenna that is built into the computer.
Interference statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy.
If the equipment is not installed and used in accordance with the instructions, the
equipment may cause harmful interference to radio communications. There is no
guarantee, however, that such interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception
(which can be determined by turning the equipment off and on), the user is
encouraged to try to correct the interference by taking one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE:The Intel(R) PRO/Wireless 3965ABG Network Connection
adapter, Intel(R) PRO/Wireless 3945ABG Network Connection adapter,
or the Intel(R) PRO/Wireless 3945BG Network Connection adapter
wireless network device must be installed and used in strict
accordance with the manufacturer's instructions as described in the
user documentation that comes with the product. Any other
installation or use will violate FCC Part 15 regulations.
Canada—Industry Canada (IC)
This device complies with RSS210 of Industry Canada.
Caution: When using IEEE 802.11a wireless LAN, this product is restricted to
indoor use due to its operation in the 5.15- to 5.25-GHz frequency range. Industry
Canada requires this product to be used indoors for the frequency range of 5.15 GHz
to 5.25 GHz to reduce the potential for harmful interference to co-channel mobile
satellite systems. High power radar is allocated as the primary user of the 5.25- to
5.35-GHz and 5.65 to 5.85-GHz bands. These radar stations can cause interference
with and/or damage to this device.
The maximum allowed antenna gain for use with this device is 6dBi in order to
comply with the E.I.R.P limit for the 5.25- to 5.35 and 5.725 to 5.85GHz frequency
range in point-to-point operation.
This Class B digital apparatus complies with Canadian ICES-003, Issue 4, and RSS-
210, No 4 (Dec 2000) and No 5 (Nov 2001).
Cet appariel numérique de la classe B est conforme à la norme NMB-003, No. 4, et
CNR-210, No 4 (Dec 2000) et No 5 (Nov 2001)..
"To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment
(or its transmit antenna) that is installed outdoors is subject to licensing."
« Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une
licence, il doit être utilisé a l'intérieur et devrait être placé loin des fenêtres afinde
fournir un écran de blindage maximal. Si le matériel (ou son antenne d'émission) est
installé à l'extérieur, il doit faire l'objet d'une licence. »
Europe Frequency Bands
2.400 - 2.4835 GHz (Europe ETSI)
5.15 - 5.35 GHz and 5.47-5.725 GHz (Europe ETSI)
Low band 5.25 - 5.35 GHz is for indoor use only
5.47 - 5.725 GHz is current not allowed in Czech Republic and France.
Declaration of Conformity
This equipment complies with the essential requirements of the European Union
directive 1999/5/EC.
Czech Intel(R) Corporation tímto prohlašuje, že tento Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) je ve
shodě se základními požadavky a dalšími příslušnými ustanoveními
směrnice 1999/5/ES."
Danish Undertegnede Intel(R) Corporation erklærer herved, at følgende udstyr
Intel(R) PRO/Wireless 3965ABG Network Connection (Intel(R)
PRO/Wireless 3945ABG Network Connection, Intel(R) PRO/Wireless
3945BG Network Connection) overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF.
Hierbij verklaart Intel(R) Corporation dat het toestel Intel(R)
PRO/Wireless 3965ABG Network Connection (Intel(R) PRO/Wireless
3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network
Connection)in overeenstemming is met de essentiële eisen en de andere
relevante bepalingen van richtlijn 1999/5/EG.
Dutch
Bij deze verklaart Intel(R) Corporation dat deze Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection)voldoet
aan de essentiële eisen en aan de overige relevante bepalingen van
Richtlijn 1999/5/EC.
English Hereby, Intel(R) Corporation, declares that this Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) is in
compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Estonian Käesolevaga kinnitab Intel(R) Corporation seadme Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection)
vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist
tulenevatele teistele asjakohastele sätetele.
Finnish Intel(R) Corporation vakuuttaa täten että Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network
Connection) tyyppinen laite on direktiivin 1999/5/EY oleellisten
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
French Par la présente Intel(R) Corporation déclare que l'appareil Intel(R)
PRO/Wireless 3965ABG Network Connection (Intel(R) PRO/Wireless
3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network
Connection) est conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE.
Par la présente, Intel(R) Corporation déclare que ce Intel(R)
PRO/Wireless 3965ABG Network Connection (Intel(R) PRO/Wireless
3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network
Connection) est conforme aux exigences essentielles et aux autres
dispositions de la directive 1999/5/CE qui lui sont applicables.
Hiermit erklärt Intel(R) Corporation, dass sich dieser/diese/dieses
Intel(R) PRO/Wireless 3965ABG Network Connection (Intel(R)
PRO/Wireless 3945ABG Network Connection, Intel(R) PRO/Wireless
3945BG Network Connection) in Übereinstimmung mit den
grundlegenden Anforderungen und den anderen relevanten Vorschriften
der Richtlinie 1999/5/EG befindet". (BMWi)
German
Hiermit erklärt Intel(R) Corporation die Übereinstimmung des Gerätes
Intel(R) PRO/Wireless 3965ABG Network Connection (Intel(R)
PRO/Wireless 3945ABG Network Connection, Intel(R) PRO/Wireless
3945BG Network Connection) mit den grundlegenden Anforderungen
und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG.
(Wien)
Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Intel(R) Corporation ΔΗΛΩΝΕΙ ΟΤΙ Intel(R)
PRO/Wireless 3965ABG Network Connection (Intel(R) PRO/Wireless
3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network
Connection)ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ
ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ
Hungary Alulírott, Intel(R) Corporation nyilatkozom, hogy a Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection)megfelel
a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv
egyéb elõírásainak
Icelandic Intel lysir her med yfir að thessi bunadur, Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection),
uppfyllir allar grunnkrofur, sem gerdar eru i R&TTE tilskipun ESB nr
1999/5/EC
Italian
Con la presente Intel(R) Corporation dichiara che questo Intel(R)
PRO/Wireless 3965ABG Network Connection (Intel(R) PRO/Wireless
3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network
Connection) è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Latvian Ar šo Intel(R) Corporation deklarē, ka Intel(R) PRO/Wireless 3965ABG
Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) atbilst
Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem
noteikumiem
Lithuanian Intel(R) Corporation deklaruoja, kad Intel(R) PRO/Wireless 3965ABG
Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) atitinka
1999/5/EC Direktyvos esminius reikalavimus ir kitas nuostatas".
Malti Hawnhekk, Intel(R) Corporation, jiddikjara li dan Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection)
jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti
li hemm fid-Dirrettiva 1999/5/EC
Polish Niniejszym, Intel(R) Corporation, deklaruję, że Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) spełnia
wymagania zasadnicze oraz stosowne postanowienia zawarte Dyrektywie
1999/5/EC.
Portuguese Intel(R) Corporation declara que este Intel(R) PRO/Wireless 3965ABG
Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) está
conforme com os requisitos essenciais e outras disposições da Directiva
1999/5/CE.
Slovak Intel(R) Corporation týmto vyhlasuje, že Intel(R) PRO/Wireless 3965ABG
Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) spĺňa
základné požiadavky a všetky príslušné ustanovenia Smernice
1999/5/ES.
Slovenia Šiuo Intel(R) Corporation deklaruoja, kad šis Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) atitinka
esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Spanish Por medio de la presente Intel(R) Corporation declara que el Intel(R)
PRO/Wireless 3965ABG Network Connection (Intel(R) PRO/Wireless
3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network
Connection) cumple con los requisitos esenciales y cualesquiera otras
disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Swedish Härmed intygar Intel(R) Corporation att denna Intel(R) PRO/Wireless
3965ABG Network Connection (Intel(R) PRO/Wireless 3945ABG Network
Connection, Intel(R) PRO/Wireless 3945BG Network Connection) står I
överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 1999/5/EG.
France
Pour la France métropolitaine
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur
2.400 -2.454 GHz (canaux 1 à 7) autorisé en usage extérieur
Pour la Guyane et la Réunion
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur .
2.420 - 2.4835 GHz (canaux 5 à 13) autorisé en usage extérieur
Pour tout le territoire Fan-cais:
Seulement 5.15 -5.35 GHz autorisé pour le 802.11a
Belgium
Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-dessus d'un
espace public, aucun enregistrement n'est nécessaire pour une distance de moins de
300m. Pour une distance supérieure à 300m un enregistrement auprès de l'IBPT est
requise. Pour les enregistrements et licences, veuillez contacter l'IBPT.
In geval van privé-gebruik, buiten een gebouw, op een openbare plaats, is geen
registratie nodig, wanneer de afstand minder dan 300m is. Voor een afstand groter
dan 300m is een registratie bij BIPT vereist. Voor registraties en licenties, gelieve
BIPT te contacteren.
5 GHz interface is not allowed at this time.
Japan
Latvia
A license is required for outdoor use for operation in 2.4 GHz band.
Italia
A general authorization is requested for outdoor use in Italy
The use of these equipments is regulated by:
- D.L.gs 1.8.2003, n. 259, article 104 (activity subject to general authorization) for
outdoor use and article 105 (free use) for indoor use, in both cases for private use.
- D.M. 28.5.03, for supply to public of RLAN access to networks and telecom
services.
L’uso degli apparati è regolamentato da:
- D.L.gs 1.8.2003, n. 259, articoli 104 (attività soggette ad autorizzazione generale)
se utilizzati al di fuori del proprio fondo e 105 (libero uso) se utilizzati entro il proprio
fondo, in entrambi i casi per uso privato;
- D.M. 28.5.03, per la fornitura al pubblico dell’accesso R-LAN alle reti e ai servizi di
telecomunicazioni.
Greece
A license is required for the outdoor use of band 5.470 – 5.725 GHz.
Belarus
2.4 GHz OFDM (802.11g) is not allowed at this time.
Indonesia
5 GHz interface is not allowed at this time.
Korea
Kuwait
5 GHz interface is not allowed at this time.
Oman
If the modules are less than 100 milliwatts they are unlicensed but if they are more
than 100 milliwatts, the user is responsible for getting a license to operate from
Telecommunications Regulatory Authority (TRA) in Sultanate of Oman.
Taiwan
Pakistan
Pakistan Telecommunication Authority (PTA) Approved
UAE
5 GHz interface is not allowed at this time.
Ukraine
5 GHz interface is not allowed at this time.
Radio approvals
To determine whether you are allowed to use your wireless network device in a
specific country, please check to see if the radio type number that is printed on the
identification label of your device is listed in the manufacture OEM Regulatory
Guidance document.
Underwriters Laboratories Inc. (UL) Regulatory Warning
For use in (or with) UL Listed personal computers or compatible.
Intel(R) PRO/Wireless 2915ABG Network Connection
The information in this document applies to the following products:
Tri-mode wireless LAN adapters (802.11a/802.11b/802.11g )
Intel(R) PRO/Wireless 2915ABG Network Connection (model WM3B2915ABG)
Intel(R) PRO/Wireless 2915ABG Network Connection (model WM3A2915ABG)
NOTE: Due to the evolving state of regulations and standards in the
wireless LAN field (IEEE 802.11 and similar standards), the information
provided herein is subject to change. Intel Corporation assumes no
responsibility for errors or omissions in this document. Nor does Intel
make any commitment to update the information contained herein.
Information for the user
Safety Notices
The FCC with its action in ET Docket 96-8 has adopted a safety standard for human
exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified
equipment. The Intel(R) PRO/Wireless 2915ABG Network Connection adapter meets
the Human Exposure limits found in OET Bulletin 65, supplement C, 2001, and
ANSI/IEEE C95.1, 1992. Proper operation of this radio according to the instructions
found in this manual will result in exposure substantially below the FCC’s
recommended limits.
The following safety precautions should be observed:
• Do not touch or move antenna while the unit is transmitting or receiving.
• Do not hold any component containing the radio such that the antenna is very
close or touching any exposed parts of the body, especially the face or eyes,
while transmitting.
• Do not operate the radio or attempt to transmit data unless the antenna is
connected; if not, the radio may be damaged.
• Use in specific environments:
• The use of wireless devices in hazardous locations is limited by the
constraints posed by the safety directors of such environments.
• The use of wireless devices on airplanes is governed by the Federal
Aviation Administration (FAA).
• The use of wireless devices in hospitals is restricted to the limits set
forth by each hospital.
• Antenna use:
• In order to comply with FCC RF exposure limits, low gain integrated
antennas should be located at a minimum distance of 20 cm (8 inches)
or more from the body of all persons.
• High-gain, wall-mount, or mast-mount antennas are designed to be
professionally installed and should be located at a minimum distance
of 30 cm (12 inches) or more from the body of all persons. Please
contact your professional installer, VAR, or antenna manufacturer for
proper installation requirements.
• Explosive Device Proximity Warning (see below)
• Antenna Warning (see below)
• Use on Aircraft Caution (see below)
• Other Wireless Devices (see below)
• Power Supply (Access Point) (see below)
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a wireless network
device) near unshielded blasting caps or in an explosive environment unless the
device has been modified to be qualified for such use.
Antenna Warnings
Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is
recommended for the Intel(R) PRO/Wireless 2915ABG Network Connection adapter
installed in a desktop or portable computer, that the antenna for this device be
installed so as to provide a separation distance of al least 20 cm (8 inches) from all
persons and that the antenna must not be co-located or operating in conjunction
with any other antenna or radio transmitter. It is recommended that the user limit
exposure time if the antenna is positioned closer than 20 cm (8 inches).
Warning: Intel(R) PRO/Wireless LAN products are not designed for use with
high-gain directional antennas. Use of such antennas with these products is illegal.
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-
frequency wireless devices because their signals could interfere with critical aircraft
instruments.
Other Wireless Devices
Safety Notices for Other Devices in the Wireless Network: Refer to the
documentation supplied with wireless Ethernet adapters or other devices in the
wireless network.
Local Restrictions on 802.11a, 802.11b, and 802.11g Radio Usage
Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, and
802.11g wireless LAN devices may not yet be harmonized in all countries, 802.11a,
802.11b, and 802.11g products are designed for use only in specific countries, and
are not allowed to be operated in countries other than those of designated use. As a
user of these products, you are responsible for ensuring that the products are used
only in the countries for which they were intended and for verifying that they are
configured with the correct selection of frequency and channel for the country of use.
The device transmit power control (TPC) interface is part of the Intel(R)
PROSet/Wireless software. Operational restrictions for Equivalent Isotropic Radiated
Power (EIRP) are provided by the system manufacturer. Any deviation from the
permissible power and frequency settings for the country of use is an infringement of
national law and may be punished as such.
For country-specific information, see the additional compliance information supplied
with the product.
Wireless interoperability
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter is designed to be
interoperable with other wireless LAN products that are based on direct sequence
spread spectrum (DSSS) radio technology and to comply with the following
standards:
• IEEE Std. 802.11b compliant Standard on Wireless LAN.
• IEEE Std. 802.11g compliant Standard on Wireless LAN.
• IEEE Std. 802.11a compliant Standard on Wireless LAN.
• Wireless Fidelity (WiFi) certification, as defined by the WECA (Wireless
Ethernet Compatibility Alliance).
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter and your
health
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter, like other radio
devices, emits radio frequency electromagnetic energy. The level of energy emitted
by this device, however, is less than the electromagnetic energy emitted by other
wireless devices such as mobile phones. The Intel(R) PRO/Wireless 2915ABG
Network Connection adapter wireless device operates within the guidelines found in
radio frequency safety standards and recommendations. These standards and
recommendations reflect the consensus of the scientific community and result from
deliberations of panels and committees of scientists who continually review and
interpret the extensive research literature. In some situations or environments, the
use of the Intel(R) PRO/Wireless 2915ABG Network Connection adapter wireless
device may be restricted by the proprietor of the building or responsible
representatives of the applicable organization. Examples of such situations include
the following:
• Using the Intel(R) PRO/Wireless 2915ABG Network Connection adapter
equipment on board airplanes, or
• Using the Intel(R) PRO/Wireless 2915ABG Network Connection adapter
equipment in any other environment where the risk of interference with other
devices or services is perceived or identified as being harmful
If you are uncertain of the policy that applies to the use of wireless devices in a
specific organization or environment (an airport, for example), you are encouraged
to ask for authorization to use the Intel(R) PRO/Wireless 2915ABG Network
Connection adapter wireless device before you turn it on.
Regulatory information
Information for the OEMs and Integrators:
The following statement must be included with all versions of this document supplied
to an OEM or integrator, but should not be distributed to the end user.
• This device is intended for OEM integrators only.
• This device cannot be co-located with any other transmitter.
• Please refer to the full Grant of Equipment document for other restrictions.
• This device must be operated and used with a locally approved access point.
Information To Be Supplied to the End User by the OEM or
Integrator
The following regulatory and safety notices must be published in documentation
supplied to the end user of the product or system incorporating an Intel(R)
PRO/Wireless 2915ABG Network Connection in compliance with local regulations.
Host system must be labeled with "Contains FCC ID: XXXXXXXX", FCC ID displayed
on label.
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter wireless network
device must be installed and used in strict accordance with the manufacturer's
instructions as described in the user documentation that comes with the product. For
country-specific approvals, see Radio approvals. Intel Corporation is not responsible
for any radio or television interference caused by unauthorized modification of the
devices included with the Intel(R) PRO/Wireless 2915ABG Network Connection
adapter kit, or the substitution or attachment of connecting cables and equipment
other than that specified by Intel Corporation. The correction of interference caused
by such unauthorized modification, substitution or attachment is the responsibility of
the user. Intel Corporation and its authorized resellers or distributors are not liable
for any damage or violation of government regulations that may arise from the user
failing to comply with these guidelines.
Local Restriction of 802.11a, 802.11b, and 802.11g Radio
Usage
The following statement on local restrictions must be published as part of the
compliance documentation for all 802.11a, 802.11b, and 802.11g products.
Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, and
802.11g wireless LAN devices may not yet be harmonized in all countries, 802.11a,
802.11b, and 802.11g products are designed for use only in specific countries, and
are not allowed to be operated in countries other than those of designated use. As a
user of these products, you are responsible for ensuring that the products are used
only in the countries for which they were intended and for verifying that they are
configured with the correct selection of frequency and channel for the country of use.
Any deviation from permissible settings and restrictions in the country of use could
be an infringement of national law and may be punished as such.
FCC Radio Frequency Interference Requirements
This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz
frequency range. FCC requires this product to be used indoors for the frequency
range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-
channel Mobile Satellite systems. High power radars are allocated as primary users
of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause
interference with and /or damage this device.
• This device is intended for OEM integrators only.
• This device cannot be co-located with any other transmitter.
USA—Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules. Operation of the device is subject
to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference that may cause undesired operation.
NOTE: The radiated output power of the Intel(R) PRO/Wireless
2915ABG Network Connection adapter wireless network device is far
below the FCC radio frequency exposure limits. Nevertheless, the
Intel(R) PRO/Wireless LAN wireless network device should be used in
such a manner that the potential for human contact during normal
operation is minimized. To avoid the possibility of exceeding the FCC
radio frequency exposure limits, you should keep a distance of at least
20 cm between you (or any other person in the vicinity) and the
antenna that is built into the computer.
Interference statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy.
If the equipment is not installed and used in accordance with the instructions, the
equipment may cause harmful interference to radio communications. There is no
guarantee, however, that such interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception
(which can be determined by turning the equipment off and on), the user is
encouraged to try to correct the interference by taking one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: The Intel(R) PRO/Wireless 2915ABG Network Connection
adapter wireless network device must be installed and used in strict
accordance with the manufacturer's instructions as described in the
user documentation that comes with the product. Any other
installation or use will violate FCC Part 15 regulations.
Canada—Industry Canada (IC)
This device complies with RSS210 of Industry Canada.
This Class B digital apparatus complies with Canadian ICES-003, Issue 4, and RSS-
210, No 4 (Dec 2000) and No 5 (Nov 2001).
Cet appariel numérique de la classe B est conforme à la norme NMB-003, No. 4, et
CNR-210, No 4 (Dec 2000) et No 5 (Nov 2001)..
"To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment
(or its transmit antenna) that is installed outdoors is subject to licensing."
« Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une
licence, il doit être utilisé a l'intérieur et devrait être placé loin des fenêtres afinde
fournir un écran de blindage maximal. Si le matériel (ou son antenne d'émission) est
installé à l'extérieur, il doit faire l'objet d'une licence. »
Europe Frequency Bands
2.400 - 2.4835 GHz (Europe ETSI)
5.15 - 5.35 GHz and 5.47-5.725 GHz (Europe ETSI)
Low band 5.25 - 5.35 GHz is for indoor use only
5.47 - 5.725 GHz is current not allowed in Czech Republic and France.
Declaration of Conformity
Declaration of Conformity
This equipment complies with the essential requirements of the European Union
directive 1999/5/EC.
Czech Intel(R) Corporation tímto prohlašuje, že tento Intel(R) PRO/Wireless
2915ABG Network Connection je ve shodě se základními požadavky a
dalšími příslušnými ustanoveními směrnice 1999/5/ES."
Danish Undertegnede Intel(R) Corporation erklærer herved, at følgende udstyr
Intel(R) PRO/Wireless 2915ABG Network Connection overholder de
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF
Hierbij verklaart Intel(R) Corporation dat het toestel Intel(R)
PRO/Wireless 2915ABG Network Connection in overeenstemming is met
de essentiële eisen en de andere relevante bepalingen van richtlijn
1999/5/EG
Dutch
Bij deze verklaart Intel(R) Corporation dat deze Intel(R) PRO/Wireless
2915ABG Network Connection voldoet aan de essentiële eisen en aan de
overige relevante bepalingen van Richtlijn 1999/5/EC.
English Hereby, Intel(R) Corporation, declares that this Intel(R) PRO/Wireless
2915ABG Network Connection is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Estonian Käesolevaga kinnitab Intel(R) Corporation seadme Intel(R) PRO/Wireless
2915ABG Network Connection vastavust direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele
sätetele.
Finnish Intel(R) Corporation vakuuttaa täten että Intel(R) PRO/Wireless
2915ABG Network Connection tyyppinen laite on direktiivin 1999/5/EY
oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen
mukainen.
Par la présente Intel(R) Corporation déclare que l'appareil Intel(R)
PRO/Wireless 2915ABG Network Connection est conforme aux exigences
essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE.
French
Par la présente, Intel(R) Corporation déclare que ce Intel(R)
PRO/Wireless 2915ABG Network Connection est conforme aux exigences
essentielles et aux autres dispositions de la directive 1999/5/CE qui lui
sont applicables.
Hiermit erklärt Intel(R) Corporation, dass sich dieser/diese/dieses
Intel(R) PRO/Wireless 2915ABG Network Connection in Übereinstimmung
mit den grundlegenden Anforderungen und den anderen relevanten
Vorschriften der Richtlinie 1999/5/EG befindet". (BMWi)
German
Hiermit erklärt Intel(R) Corporation die Übereinstimmung des Gerätes
Intel(R) PRO/Wireless 2915ABG Network Connection mit den
grundlegenden Anforderungen und den anderen relevanten Festlegungen
der Richtlinie 1999/5/EG. (Wien).=
Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Intel(R) Corporation ΔΗΛΩΝΕΙ ΟΤΙ Intel(R)
PRO/Wireless 2915ABG Network Connection ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ
ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Hungary Alulírott, Intel(R) Corporation nyilatkozom, hogy a Intel(R) PRO/Wireless
2915ABG Network Connection megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Icelandic Intel lysir her med yfir að thessi bunadur, Intel(R) PRO/Wireless
2915ABG Network Connection , uppfyllir allar grunnkrofur, sem gerdar
eru i R&TTE tilskipun ESB nr 1999/5/EC
Italian Con la presente Intel(R) Corporation dichiara che questo Intel(R)
PRO/Wireless 2915ABG Network Connection è conforme ai requisiti
essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Latvian Ar šo Intel(R) Corporation deklarē, ka Intel(R) PRO/Wireless 2915ABG
Network Connection atbilst Direktīvas 1999/5/EK būtiskajām prasībām
un citiem ar to saistītajiem noteikumiem.
Lithuanian Intel(R) Corporation deklaruoja, kad Intel(R) Pro/Wireless 2915ABG
Network Connectionatitinka 1999/5/EC Direktyvos esminius reikalavimus
ir kitas nuostatas".
Malti Hawnhekk, Intel(R) Corporation, jiddikjara li dan Intel(R) PRO/Wireless
2915ABG Network Connection jikkonforma mal-ħtiġijiet essenzjali u ma
provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Polish Niniejszym, Intel(R) Corporation, deklaruję, że Intel(R) PRO/Wireless
2915ABG Network Connection spełnia wymagania zasadnicze oraz
stosowne postanowienia zawarte
Dyrektywie 1999/5/EC.
Portuguese Intel(R) Corporation declara que este Intel(R) PRO/Wireless 2915ABG
Network Connection está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.
Slovak Intel(R) Corporation týmto vyhlasuje, že Intel(R) PRO/Wireless 2915ABG
Network Connection spĺňa základné požiadavky a všetky príslušné
ustanovenia Smernice 1999/5/ES.
Slovenia Šiuo Intel(R) Corporation deklaruoja, kad šis Intel(R) PRO/Wireless
2915ABG Network Connection atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
Spanish Por medio de la presente Intel(R) Corporation declara que el Intel(R)
PRO/Wireless 2915ABG Network Connection cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la
Directiva 1999/5/CE.
Swedish Härmed intygar Intel(R) Corporation att denna Intel(R) PRO/Wireless
2915ABG Network Connection står I överensstämmelse med de
väsentliga egenskapskrav och övriga relevanta bestämmelser som
framgår av direktiv 1999/5/EG.
France
Pour la France métropolitaine
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur
2.400 -2.454 GHz (canaux 1 à 7) autorisé en usage extérieur
Pour la Guyane et la Réunion
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur .
2.420 - 2.4835 GHz (canaux 5 à 13) autorisé en usage extérieur
Pour tout le territoire Fancais:
Seulement 5.15 -5.35 GHz autorisé pour le 802.11a
Belgium
Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-dessus d'un
espace public, aucun enregistrement n'est nécessaire pour une distance de moins de
300m. Pour une distance supérieure à 300m un enregistrement auprès de l'IBPT est
requise. Pour les enregistrements et licences, veuillez contacter l'IBPT.
In geval van privé-gebruik, buiten een gebouw, op een openbare plaats, is geen
registratie nodig, wanneer de afstand minder dan 300m is. Voor een afstand groter
dan 300m is een registratie bij BIPT vereist. Voor registraties en licenties, gelieve
BIPT te contacteren.
Japan
Latvia
A license is required for outdoor use for operation in 2.4 GHz band. (Translation?)
Italia
A general authorization is requested for outdoor use in Italy
The use of these equipments is regulated by:
- D.L.gs 1.8.2003, n. 259, article 104 (activity subject to general authorization) for
outdoor use and article 105 (free use) for indoor use, in both cases for private use.
- D.M. 28.5.03, for supply to public of RLAN access to networks and telecom
services.
L’uso degli apparati è regolamentato da:
- D.L.gs 1.8.2003, n. 259, articoli 104 (attività soggette ad autorizzazione generale)
se utilizzati al di fuori del proprio fondo e 105 (libero uso) se utilizzati entro il proprio
fondo, in entrambi i casi per uso privato ;
- D.M. 28.5.03, per la fornitura al pubblico dell’accesso R-LAN alle reti e ai servizi di
telecomunicazioni.
Greece
A license is required for the outdoor use of band 5.470 – 5.725 GHz.
Belarus
2.4 GHz OFDM (802.11g) is not allowed at this time.
Indonesia
5 GHz interface is not allowed at this time.
Korea
Kuwait
5 GHz interface is not allowed at this time.
Oman
If the modules are less than 100 milliwatts they are unlicensed but if they are more
than 100 milliwatts, the user is responsible for getting a license to operate from
Telecommunications Regulatory Authority (TRA) in Sultanate of Oman.
Taiwan
Pakistan
Pakistan Telecommunication Authority (PTA) Approved
UAE
5 GHz interface is not allowed at this time.
Ukraine
5 GHz interface is not allowed at this time.
Radio approvals
To determine whether you are allowed to use your wireless network device in a
specific country, please check to see if the radio type number that is printed on the
identification label of your device is listed in the manufacture OEM Regulatory
Guidance document.
Underwriters Laboratories Inc. (UL) Regulatory Warning
For use in (or with) UL Listed personal computers or compatible.
Regulatory Information: Intel(R) PRO/Wireless
2200BG Network Connection
Information for the User
Regulatory Information
Information for the user
Safety Notices
The FCC with its action in ET Docket 96-8 has adopted a safety standard for human
exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified
equipment. The Intel(R) PRO/Wireless 2200BG Network Connection meets the
Human Exposure limits found in OET Bulletin 65, 2001, and ANSI/IEEE C95.1, 1992.
Proper operation of this radio according to the instructions found in this manual will
result in exposure substantially below the FCC’s recommended limits.
The following safety precautions should be observed:
• Do not touch or move antenna while the unit is transmitting or receiving.
• Do not hold any component containing the radio such that the antenna is very
close or touching any exposed parts of the body, especially the face or eyes,
while transmitting.
• Do not operate the radio or attempt to transmit data unless the antenna is
connected; if not, the radio may be damaged.
• Use in specific environments:
• The use of wireless devices in hazardous locations is limited by the
constraints posed by the safety directors of such environments.
• The use of wireless devices on airplanes is governed by the Federal
Aviation Administration (FAA).
• The use of wireless devices in hospitals is restricted to the limits set
forth by each hospital.
• Explosive Device Proximity Warning (see below)
• Antenna Warning (see below)
• Use on Aircraft Caution (see below)
• Other Wireless Devices (see below)
• Power Supply (Access Point) (see below)
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a wireless network
device) near unshielded blasting caps or in an explosive environment unless the
device has been modified to be qualified for such use.
Antenna Warnings
Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is
recommended for the Intel(R) PRO/Wireless 2200BG Network Connection installed in
a desktop or portable computer, that the antenna for this device be installed so as to
provide a separation distance of al least 20 cm (8 inches) from all persons and that
the antenna must not be co-located or operating in conjunction with any other
antenna or radio transmitter. It is recommended that the user limit exposure time if
the antenna is positioned closer than 20 cm (8 inches).
Warning: The Intel(R) PRO/Wireless 2200BG Network Connection product is not
designed for use with high-gain directional antennas. Use of such antennas with
these products is illegal.
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-
frequency wireless devices because their signals could interfere with critical aircraft
instruments.
Local Restrictions on 802.11b and 802.11g Radio Usage
All frequencies used by 802.11b and 802.11g are harmonized. Some countries
though may not allow 802.11g.
Wireless interoperability
The Intel(R) PRO/Wireless 2200BG Network Connection adapter is designed to be
interoperable with any wireless LAN product that is based on direct sequence spread
spectrum (DSSS) radio technology and to comply with the following standards:
• IEEE Std. 802.11b-1999. Standard on Wireless LAN.
• IEEE Std. 802.11g compliant. Standard on Wireless LAN.
• Wireless Fidelity (WiFi(R)) certification, as defined by the WECA (Wireless
Ethernet Compatibility Alliance).
The Intel(R) PRO/Wireless LAN 2200BG Mini PCI adapter and your health
The Intel(R) PRO/Wireless 2200BG Network Connection adapter, like other radio
devices, emits radio frequency electromagnetic energy. The level of energy emitted
by this device, however, is less than the electromagnetic energy emitted by other
wireless devices such as mobile phones. The Intel(R) PRO/Wireless 2200BG Network
Connection adapter wireless device operates within the guidelines found in radio
frequency safety standards and recommendations. These standards and
recommendations reflect the consensus of the scientific community and result from
deliberations of panels and committees of scientists who continually review and
interpret the extensive research literature. In some situations or environments, the
use of the Intel(R) PRO/Wireless 2200BG Network Connection adapter wireless
device may be restricted by the proprietor of the building or responsible
representatives of the applicable organization. Examples of such situations include
the following:
• Using the Intel(R) PRO/Wireless 2200BG Network Connection adapter
equipment on board airplanes, or
• Using the Intel(R) PRO/Wireless 2200BG Network Connection adapter
equipment in any other environment where the risk of interference with other
devices or services is perceived or identified as being harmful.
If you are uncertain of the policy that applies to the use of wireless devices in a
specific organization or environment (an airport, for example), you are encouraged
to ask for authorization to use the Intel(R) PRO/Wireless 2200BG Network
Connection adapter wireless device before you turn it on.
Regulatory information
The Intel(R) PRO/Wireless 2200BG Network Connection adapter wireless network
device must be installed and used in strict accordance with the manufacturer's
instructions as described in the user documentation that comes with the product. For
country-specific approvals, see Radio approvals. Intel Corporation is not responsible
for any radio or television interference caused by unauthorized modification of the
devices included with the Intel(R) PRO/Wireless 2200BG Network Connection adapter
kit, or the substitution or attachment of connecting cables and equipment other than
that specified by Intel Corporation. The correction of interference caused by such
unauthorized modification, substitution or attachment is the responsibility of the
user. Intel Corporation and its authorized resellers or distributors are not liable for
any damage or violation of government regulations that may arise from the user
failing to comply with these guidelines.
USA—Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules. Operation of the device is subject
to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference that may cause undesired operation.
NOTE: The radiated output power of the Intel(R) PRO/Wireless
2200BG Network Connection adapter wireless network device is far
below the FCC radio frequency exposure limits. Nevertheless, the Intel
PROSet/Wireless LAN wireless network device should be used in such a
manner that the potential for human contact during normal operation
is minimized. To avoid the possibility of exceeding the FCC radio
frequency exposure limits, you should keep a distance of at least 2 cm
between you (or any other person in the vicinity) and the antenna that
is built into the computer.
Interference statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy.
If the equipment is not installed and used in accordance with the instructions, the
equipment may cause harmful interference to radio communications. There is no
guarantee, however, that such interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception
(which can be determined by turning the equipment off and on), the user is
encouraged to try to correct the interference by taking one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: The Intel(R) PRO/Wireless 2200BG Network Connection
adapter wireless network device must be installed and used in strict
accordance with the manufacturer's instructions as described in the
user documentation that comes with the product. Any other
installation or use will violate FCC Part 15 regulations.
U.S. Frequency Bands
2.400 - 2.462 GHz
Canada—Industry Canada (IC)
This Class B digital apparatus complies with Canadian ICES-003, Issue 2, and RSS-
210, Issue 4 (Dec. 2000).
Cet appariel numérique de la classe B est conforme à la norme NMB-003, No. 2, et
CNR-210, No 4 (Dec 2000).
To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment
(or its transmit antenna) that is installed outdoors is subject to licensing."
« Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une
licence, il doit être utilisé a l'intérieur et devrait être placé loin des fenêtres afinde
fournir un écran de blindage maximal. Si le matériel (ou son antenne d'émission) est
installé à l'extérieur, il doit faire l'objet d'une licence. »
Europe—EU Declaration of Conformity
Europe Frequency Bands
2.400 - 2.4835 GHz (Europe ETSI)
Declaration of Conformity
This equipment complies with the essential requirements of the European Union
directive 1999/5/EC.
English Hereby, Intel(R) Corporation, declares that this Intel(R) PRO/Wireless
2200BG Network Connection is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Finnish Intel(R) Corporation vakuuttaa täten että Intel(R) PRO/Wireless 2200BG
Network Connection tyyppinen laite on direktiivin 1999/5/EY oleellisten
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Hierbij verklaart Intel(R) Corporation dat het toestel Intel(R)
PRO/Wireless 2200BG Network Connection in overeenstemming is met
de essentiële eisen en de andere relevante bepalingen van richtlijn
1999/5/EG.
Dutch
Bij deze verklaart Intel(R) Corporation dat deze Intel(R) PRO/Wireless
2200BG Network Connection voldoet aan de essentiële eisen en aan de
overige relevante bepalingen van Richtlijn 1999/5/EC.
Par la présente Intel(R) Corporation déclare que l'appareil Intel(R)
PRO/Wireless 2915ABG Network Connection est conforme aux exigences
essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE.
French
Par la présente, Intel(R) Corporation déclare que ce Intel(R)
PRO/Wireless 2200BG Network Connection est conforme aux exigences
essentielles et aux autres dispositions de la directive 1999/5/CE qui lui
sont applicables.
Swedish
Härmed intygar Intel(R) Corporation att denna Intel(R) PRO/Wireless
2200BG Network Connection står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av
direktiv 1999/5/EG.
Danish Undertegnede Intel(R) Corporation erklærer herved, at følgende udstyr
Intel(R) PRO/Wireless 2200BG Network Connection overholder de
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Hiermit erklärt Intel(R) Corporation, dass sich dieser/diese/dieses
Intel(R) PRO/Wireless 2200BG Network Connection in Übereinstimmung
mit den grundlegenden Anforderungen und den anderen relevanten
Vorschriften der Richtlinie 1999/5/EG befindet". (BMWi)
German
Hiermit erklärt Intel(R) Corporation die Übereinstimmung des Gerätes
Intel(R) PRO/Wireless 2200BG Network Connection mit den
grundlegenden Anforderungen und den anderen relevanten
Festlegungen der Richtlinie 1999/5/EG. (Wien)
Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Intel(R) Corporation ΔΗΛΩΝΕΙ ΟΤΙ Intel(R)
PRO/Wireless 2200BG Network Connection ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ
ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Icelandic Intel lysir her med yfir að thessi bunadur, Intel(R) PRO/Wireless 2200BG
Network Connection , uppfyllir allar grunnkrofur, sem gerdar eru i R&TTE
tilskipun ESB nr 1999/5/EC.
Italian Con la presente Intel(R) Corporation dichiara che questo Intel(R)
PRO/Wireless 2200BG Network Connection è conforme ai requisiti
essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Spanish Por medio de la presente Intel(R) Corporation declara que el Intel(R)
PRO/Wireless 2200BG Network Connection cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la
Directiva 1999/5/CE.
Portuguese Intel(R) Corporation declara que este Intel(R) PRO/Wireless 2200BG
Network Connection está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.
Malti Hawnhekk, Intel(R) Corporation, jiddikjara li dan Intel(R) PRO/Wireless
2200BG Network Connection jikkonforma mal-ħtiġijiet essenzjali u ma
provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC
New Member States requirements of Declaration of Conformity
Estonian Käesolevaga kinnitab Intel(R) Corporation seadme Intel(R) PRO/Wireless
2200BG Network Connection vastavust direktiivi 1999/5/EÜ põhinõuetele
ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
Hungary Alulírott, Intel(R) Corporation nyilatkozom, hogy a Intel(R) PRO/Wireless
2200BG Network Connection megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak
Slovak Intel(R) Corporation týmto vyhlasuje, že Intel(R) PRO/Wireless 2200BG
Network Connection spĺňa základné požiadavky a všetky príslušné
ustanovenia Smernice 1999/5/ES.
Czech Intel(R) Corporation tímto prohlašuje, že tento Intel(R) PRO/Wireless
2200BG Network Connection je ve shodě se základními požadavky a
dalšími příslušnými ustanoveními směrnice 1999/5/ES."
Slovenia Šiuo Intel(R) Corporation deklaruoja, kad šis Intel(R) PRO/Wireless
2200BGNetwork Connection atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
Latvian Ar šo Intel(R) Corporation deklarē, ka Intel(R) PRO/Wireless 2200BG
Network Connection atbilst Direktīvas 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem
Lithuanian Intel(R) Corporation deklaruoja, kad Intel(R) Pro/Wireless 2200BG
Network Connectionatitinka 1999/5/EC Direktyvos esminius reikalavimus
ir kitas nuostatas".
Polish Niniejszym, Intel(R) Corporation, deklaruję, że Intel(R) PRO/Wireless
2200BG Network Connection spełnia wymagania zasadnicze oraz
stosowne postanowienia zawarte
Dyrektywie 1999/5/EC.
France
Pour la France métropolitaine
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur
2.400 -2.454 GHz (canaux 1 à 7) autorisé en usage extérieur
Pour la Guyane et la Réunion
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur
2.420 - 2.4835 GHz (canaux 5 à 13) autorisé en usage extérieur
Pour tout le territoire Fan cais:
Seulement 5.15 -5.35 GHz autorisé pour le 802.1
Belgique
Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-dessus d'un
espace public, aucun enregistrement n'est nécessaire pour une distance de moins de
300m. Pour une distance supérieure à 300m un enregistrement auprès de l'IBPT est
requise. Pour les enregistrements et licences, veuillez contacter l'IBPT.
In geval van privé-gebruik, buiten een gebouw, op een openbare plaats, is geen
registratie nodig, wanneer de afstand minder dan 300m is. Voor een afstand groter
dan 300m is een registratie bij BIPT vereist. Voor registraties en licenties, gelieve
BIPT te contacteren.
Latvia
A license is required for outdoor use for operation in 2.4 GHz band.
Italia
The use of these equipments is regulated by:
- D.L.gs 1.8.2003, n. 259, article 104 (activity subject to general authorization) for
outdoor use and article 105 (free use) for indoor use, in both cases for private use.
- D.M. 28.5.03, for supply to public of RLAN access to networks and telecom
services.
L’uso degli apparati è regolamentato da:
- D.L.gs 1.8.2003, n. 259, articoli 104 (attività soggette ad autorizzazione generale)
se utilizzati al di fuori del proprio fondo e 105 (libero uso) se utilizzati entro il proprio
fondo, in entrambi i casi per uso privato;
- D.M. 28.5.03, per la fornitura al pubblico dell’accesso R-LAN alle reti e ai servizi di
telecomunicazioni.
Belarus
2.4 GHz OFDM (802.11g) is not allowed at this time.
Korea
Taiwan
Pakistan
Pakistan Telecommunication Authority (PTA) Approved
Radio approvals
To determine whether you are allowed to use your wireless network device in a
specific country, please check to see if the radio type number that is printed on the
identification label of your device is listed in the manufacture OEM Regulatory
Guidance document.
Back to Contents
