LTE modules bring Alarm.com®’s secure wireless signaling,

real-time event notification and Web-based remote monitoring and

control capabilities to the Simon XT/XTi/XTi-5 panels.

The digital wireless communication enables secure alarm reporting

to a central monitoring station via SIA or Contact ID, regardless of

whether or not a phone line is installed at the system location. The

module also enables Simon XT/XTi/XTi-5 end users to monitor and

control their security system remotely via the Alarm.com web site

and mobile/PDA devices. These devices support two-way voice over

cellular, allowing users to speak directly to a central station in the

event of an emergency. Additionally, using the Z-Wave® enabled

modems provides the added functionality of controlling Z-Wave class

devices such as lighting and thermostats.

OVERVIEW

• Fits within existing Simon XT/XTi/XTi-5 housing for quick and

easy installation

• Remote monitoring and control provides homeowners with

convenient access to the system from virtually anywhere

• Remote programming via AirFx™ toolkit allows dealers to

troubleshoot and resolve issues without expensive "truck rolls"

• U.S. and Canadian cellular coverage covers more than 98% of

U.S. and Canada’s population

• Z-Wave class modems enable homeowners to control lighting,

thermostat, door locks and more

• Two-way voice over LTE allows homeowners to speak directly to a

central station during emergencies (standard on all models)

STANDARD FE AT URES

Specifications

Compatibility Simon XT/XTi/XTi-5 panels

Dimensions 4.06 x 1.875 in. (103.1 x 47.6mm)

Operating Temperature 32°F to 120°F (0°C to 49°C)

Humidity 90% relative humidity

Power requirements 6V nominal, 30mA standby current, 1.7A peak current, supplied by Simon XT/XTi/XTi-5 panels

Cellular network Verizon® LTE, AT&T™ LTE or Telus LTE

Ordering Information

600-1048-XT-LTE-VZ Verizon LTE Cellular Modem for Simon XT/XTi/XTi-5

Panels; Z-Wave Enabled

600-1048-XT-LTE-AT AT&T LTE Cellular Modem for Simon XT/XTi/XTi-5

Panels; Z-Wave Enabled

600-1048-XT-LTE-TL Telus LTE Cellular Modem for Simon XT/XTi/XTi-5

Panels; Z-Wave Enabled (Canada Use Only) Specifications subject to change without notice.

© 2017 United Technologies Corporation.

All rights reserved.

All trademarks are the property of their respective owners.

Interlogix is part of UTC Climate, Controls & Security

a unit of United Technologies Corporation.

2017/11 (GSP-2182)

interlogix.com

LTE Modules

Cellular communication module for

Simon® XT/XTi/XTi-5

Intrusion

*Based on publicly available information from cellular providers and industry reports.

Z-Wave ® is a registered US Trademark of Zensys A/S.

Complies with FCC and Industry Canada regulations.
