Interactive Toy Concepts 44030RX49 i-FLY DUCK HUNTER XTREME User Manual INS 44030 90423 US C B ai
Interactive Toy Concepts Limited i-FLY DUCK HUNTER XTREME INS 44030 90423 US C B ai
Users Manual
10+
1 Transmitter/
Portable Charger
1 Infra-red Shooter
5. Only fly the duck outdoors in calm, windless weather conditions with no precipitation.
4. The duck can also glide once it is in motion. By letting go of the throttle (left stick), the duck will glide in a natural flight simulation.
You can replace the original wings on your iFly DUCK HUNTER EXTREME if they become damaged. A new set of wings can be
purchased by contacting Interactive Toy Concepts listed above. To replace the wings, do the following:
1. Make sure the Duck, the Transmitter and the Shooter are turned off.
2. Gently remove the far corner of the wing that is tethered to the body by a ball joint.
3. The leading (front) edge of the wing is a thin carbon fiber rod. Gently pull this rod out of the gear box mechanism housing at the front.
4. Installation of the new wing is the reverse of the wing removal procedure with the following minor difference.
5. The carbon fiber rod has a slight notch cut into its end so that it will only fit properly into gear box mechanism
housing one way. Use caution when inserting the carbon fiber rod. If it is not going in smoothly, it is misaligned.
Do not modify your iFly DUCK HUNTER EXTREME! Do not point the antenna directly at the Duck! Do not use in strong winds, use only in VERY mild conditions! Do not use
in rain, snow or around heavy debris! Do not use near electrical lines or electricity! Do not use around smoke or flames! Do not use around water! Do not use in crowded
areas! Do not use around air conditioning! Do not use around air vents! Do not use around ceiling fans! Do not use around large obstacles! Do not use in very small spaces!
Do be conscious of changes in your area! Any changes or modifications to this product are strictly prohibited and will void product warranty. Keep moving wings away from
eyes, hands, hair and loose clothing. Always turn off your iFly DUCK HUNTER EXTREME, transmitter and shooter when not in use. Always remove batteries from
transmitter and shooter during storage. Always replace transmitter and shooter with NEW alkaline batteries for optimal performance. Keep your instruction manual for future
reference. Only use the provided charger included with the ifly DUCK HUNTER EXTREME to charge the lithium polymer battery installed in the ifly DUCK HUNTER EXTREME.
1. To obtain the most stable flight, use full throttle when launching.
2. To achieve a wave flight pattern once the duck has attained the desired altitude (8 to 10 feet or 2.5 to 3 meters), gently pulse the throttle.
3. To gain altitude in a confined area, it is easier to start climbing in a circle than in a straight line. Push the throttle (left stick) and apply
the right stick to either left or right in order for the duck to gain altitude in a small confined area.
(Note: this may fool your opponent into thinking that the duck was hit by the IR beam).
6. For optimizing your flying experience, you can apply some light weight Mylar tape to trim your duck to fly straight. If you
always turns to the right side, you should put the tape on the left tip of the wing (as shown) to adjust the center of gravi
Do the reverse if the duck always flies to the left.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This
device must accept any interference received including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly
technician for help.
and receiver - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV
try and correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna - Increase the separation between the equipment
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment. Note: This equipment
protection against harmful interference in a residential installation. This generates, uses and can radiate radio frequency energy and if not installed and used in accordance
has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These Limits are designed to provide reasonable
approved by the party responsible for compliance could void the user's authority to operate the equipment. The manufacturer is not responsible for any radio or TV
This radiocommunication device complies with all the requirements of Industry Canada Standard RSS-310. Operation is subject to the following two conditions: 1) This
device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Field
Strength and measurement distance: 27.145MHz – 60.1 dBμV/m at 3 meters. 49.860MHz - 45.27 dBμV/m at 3 meters.
Limited 30-day warranty
Product is warranted by Interactive Toy Concepts Limited against manufacturing defects
in material and workmanship under normal use for thirty (30) days from the date of purchase.
Warranty is validated upon receipt of proof or purchase
and confirmation of UPC code.
Proof of Purchase
Duck Hunter Extreme and iFly are registered trademarks of Interactive Toy Concepts Limited.
© 2009. All Rights Reserved. Manufactured by and distributed by InteractiveToy Concepts Ltd.
Patent Information: EU: EP1958681 US: US20080191100 Canada: CA2607358 Aus: AU2007231617
Products and colors may vary. MADE IN CHINA. INS-44030-90423-US
The ifly DUCK HUNTER EXTREME is a revolutionary new toy that brings a
greater challenge to the learning experience of hunting a duck in the complete
safety of a virtual environment. An evolution of the popular ifly DUCK HUNTER,
the ifly DUCK HUNTER EXTREME is a 2 or more player game which
combines the fun of hunting a virtual duck as well as radio controlled (RC) flight
of the world’s most responsive and reliable “ornithopter”. The ifly DUCK HUNTER
EXTREME shooter uses a narrow infra-red (IR) beam to shoot down a fully functional,
flying RC ornithopter duck. The duck will fly for up to 10 minutes from a 20-30 minute
charge. The body of the duck is made of an ultra-light and flexible foam which
provides excellent structure and resistance to damage during hard falls. Fly the ifly
DUCK HUNTER EXTREME indoors or outdoors. It takes 3 direct hits from the
infra-red shooter to defeat the flying duck. As an activity, the ifly DUCK HUNTER
EXTREME is very versatile. It is possible for two or more players to enjoy a
competitive game-play or for one player to practice the RC flight of the duck without
the shooting aspect and marvel at the flight of this patented mechanical device.
IMPORTANT BATTERY INFORMATION:
Do not mix old and new batteries, different types of batteries, standard carbon zinc, alkaline or rechargeable of
different capacities. Rechargeable batteries are only to be charged under adult supervision. Please respect the
correct polarity (-) or (+). Do not try to recharge non-rechargeable batteries. Do not throw batteries into the fire.
Replace all batteries of the same type/brand at the same time. The supply terminals are not to be short-circuited.
Remove exhausted batteries from the toy. Batteries should be replaced by adults. Remove batteries if the toy is
not going to be played with for some time. The packaging should be kept since it contains important information.
1 iFly “DUCK HUNTER EXTREME”
Flying Duck
IMPORTANT SAFETY INFORMATION
FCC NOTE: U.S. ONLY
INDUSTRY CANADA NOTICE: CANADA ONLY
REPLACING iFly DUCK HUNTER EXTREME MAIN WINGS
TIPS AND TRICKS
