MUSE USER’S MANUAL
Manufacturer: Interaxon Inc.
Address: 511 King Street West, Toronto, Ontario, Canada, M5V 1K4
Phone: 416-598-8989
Product Name : Class 2 Bluetooth Module
Model No. : MUSE
FCC ID: 2ABZI-MUSE
IC ID: 11834A-MUSE
Overview
The MUSE is a small form factor, low power, class 2 Bluetooth radio for designers who want to add
wireless capability to their products. The MUSE supports multiple interface protocols, is simple to design
in, and is fully certified, making it a complete embedded Bluetooth solution. With its high-performance,
on-chip antenna and support for Bluetooth EDR, the MUSE delivers up to a 3 Mbps data rate for
distances up to 20 meters.
Compliance Information
a. “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.”
b. “This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation
of the device.”
c. “Any changes or modifications of this product, not approved by manufacturer will void the
user’s authority to operate the equipment.”
d. “The FCC regulates marketing, sale and importation of radio frequency devices. When importing
a radio frequency (RF) device the importer or ultimate consignee, or their designated broker,
may be required to declare that the radio frequency device meets the FCC importation
conditions under Title 47 of the Code of Federal Regulation (CFR) Section 2.1204. See KDB
997198 Importation Guidelines for more details”
e. “The antenna must be installed such that it is a distance of at least 5mm between the antenna
and users.”
f. “The antenna must not transmit simultaneously with any other antenna or transmitter, except
in accordance with FCC multi transmitter product codes”
Guidance to Manufacturers Using the MUSE In Their Product
a. “The host product manufacturer is responsible for ensuring that the final product with the
module installed and fully operational complies with all applicable FCC equipment
authorizations regulations, requirements and equipment functions. Refer to CFR Title 47 Part 2
Subpart J Equipment Authorization Procedures, and KDB 784748 D01 V07 Labeling Guidelines.
b. “This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a distance of at least 5mm
between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.”
c. “This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.”
d. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
e. The final host must be labeled with: “Contains FCC ID: 2ABZI-MUSE,” “Contains IC ID: 11834A-
MUSE”
