Compliance Insert
1
IP2L RFID Snap-On Reader Non-Incendive (NI) Safety
Instructions
Models 1000AA09-NI
Users of this product are cautioned to use accessories and peripherals approved by Intermec Technologies Corporation. The use of accessories
other than those recommended, or changes to this product that are not approved by Intermec Technologies Corporation, may void the
compliance of this product and may result in the loss of the user’s authority to operate the equipment.
Non-Incendive Device Important Operating Instructions
The 1000AA09-NI RFID Snap-on Reader has been qualified by Underwriters Laboratories Inc. to the requirements of the U.S.A. and Canada
for use in Division 2, Class I – Groups A, B, C, D and Non-Hazardous locations only when used with Intermec CN70 NI Series Models:
1000CP01x-NI and 1000CP02x-NI. This product has a T6 temperature code.
Note: This product has no operator replaceable parts. Repair of this unit must be performed by trained Intermec service personnel.
Additional Recommendations for Safety
The following additional recommendations must be observed for the safety of the operator and others while in Division 2 locations:
•These products must only be used with the ambient temperature is between -20°C and 50°C (-4°F and 114°F).
•While in a Division 2, Class I environment do not connect anything to the bottom connector of the IP2L NI RFID Reader. Do not attempt
to charge the combination of the IP2L NI and the CN70 Series NI while in a Division 2 environment.
Radiation Exposure Statement
When installing and using this product, a 20 cm (8 in.) passing distance must be maintained from the body or head of the user or nearby
persons and the antenna. The antenna must not be touched during transmitter operation.
U.S.A. Digital Emissions Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference received, including interference that can cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the radio or television receiving antenna.
•Increase the separation between the computer equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the radio or television receiver is connected.
•Consult the dealer or an experienced radio television technician for help.
Caution: This marking indicates that the user should read all included documentation before use. Retain this supplement for future
reference.
Warning: Explosion Hazard – Substitution of components may impair suitability for use in Division 2, Class I locations.
Warning: Explosion Hazard – The CN70 NI series computer when attached to the IP2L NI RFID Reader renders the system of the
two components as suitable for Div. 2, Class I Groups A, B, C & D only. This combination must not be used in Div. 2, Class II or
Class III environments.
Warning: Explosion Hazard – The connection/disconnection between the CN70 NI series computer and the IP2L NI RFID Reader
must only occur in an area known to be non-hazardous.
Caution: When charging the combination of the CN70 Series and IP2L through the I/O connector at the base of the IP2L use
Intermec power supply Models 9001AE02 or 9002AX02. When charging this combination in a communications dock use Intermec
Models 1002UU01, 1002UU02, 1002UU03, 1002UU04, or 1002UU05. Use of incorrect charger may present a risk of fire or
explosion.
Warning: This equipment complies with International Commission on Non-Ionizing Radiation Protection (ICNIRP), IEEE C95.1,
Federal Communications Commission Office of Engineering and Technology (OET) Bulletin 65, Canada RSS-102, and European
Committee for Electrotechnical Standardization (CENELEC) limits for exposure to radio frequency (RF) radiation.
Worldwide Headquarters
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel 425.348.2600
fax 425.355.9551
www.intermec.com
© 2013 Intermec Technologies
Corporation. All rights reserved.
IP2L RFID Snap-On Reader Non-Incendive (NI) Safety Instructions
*933-321-001*
P/N 933-321-001, Revision A
Canadian Digital Apparatus Compliance
This device complies with Industry Canada license-exempt RSS standards. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
CAN ICES-3 (B)/NMB-3 (B)
Pour les utilisateurs canadiens (fr)
Les utilisateurs de ce produit sont mis en garde contre l’utilisation d’accessoires et de périphériques qui ne sont pas approuvés par Intermec
Technologies Corporation. L’utilisation d’accessoires autres que ceux recommandés ou des changements à ce produit qui ne sont pas
approuvés par Intermec Technologies Corporation peuvent annuler la conformité de ce produit et mettre fin au droit qu’a l’usager d’utiliser
l’équipement.
Non-Incendive Device Important Operating Instructions
The 1000AA09-NI RFID Snap-on Reader has been qualified by Underwriters Laboratories Inc. to the requirements of the U.S.A. and Canada
for use in Division 2, Class I – Groups A, B, C, D and Non-Hazardous locations only when used with Intermec CN70 NI Series Models:
1000CP01x-NI and 1000CP02x-NI. This product has a T6 temperature code.
Note: This product has no operator replaceable parts. Repair of this unit must be performed by trained Intermec service personnel.
Additional Recommendations for Safety
The following additional recommendations must be observed for the safety of the operator and others while in Division 2 locations:
•These products must only be used with the ambient temperature is between -20°C and 50°C (-4°F and 114°F).
•While in a Division 2, Class I environment do not connect anything to the bottom connector of the IP2L NI RFID Reader. Do not attempt
to charge the combination of the IP2L NI and the CN70 Series NI while in a Division 2 environment.
Énoncé sur l'exposition aux radiations
When installing and using this product, a 20 cm (8 in.) passing distance must be maintained from the body or head of the user or nearby
persons and the antenna. The antenna must not be touched during transmitter operation.
Conformité aux normes sur les émissions numériques
Cet appareil est conforme aux normes RSS avec exemption de licence d’Industrie Canada. L’utilisation est assujettie aux deux conditions
suivantes: (1) Ce dispositif ne doit pas causer d’interférence dommageable et (2) Ce dispositif doit tolérer toute interférence, incluant
l’interférence pouvant causer un fonctionnement indésirable.
CAN ICES-3 (B)/NMB-3 (B)
Mise en garde: Cette marque indique que l’utilisateur doit lire toute la documentation incluse avant l’utilisation. Conservez ce
supplément pour référence future.
Warning: Explosion Hazard – Substitution of components may impair suitability for use in Division 2, Class I locations.
Warning: Explosion Hazard – The CN70 NI series computer when attached to the IP2L NI RFID Reader renders the system of the
two components as suitable for Div. 2, Class I Groups A, B, C & D only. This combination must not be used in Div. 2, Class II or Class
III environments.
Warning: Explosion Hazard – The connection/disconnection between the CN70 NI series computer and the IP2L NI RFID Reader
must only occur in an area known to be non-hazardous.
Caution: When charging the combination of the CN70 Series and IP2L through the I/O connector at the base of the IP2L use
Intermec power supply Models 9001AE02 or 9002AX02. When charging this combination in a communications dock use Intermec
Models 1002UU01, 1002UU02, 1002UU03, 1002UU04, or 1002UU05. Use of incorrect charger may present a risk of fire or
explosion.
Avertissement: Cet appareil est conforme à la International Commission on non-Ionizing Radiation Protection (ICNIRP), à la
norme IEEE C95.1, au Bulletin 65 du Federal Communications Commission Office of Engineering and Technology (OET), à la
norme Canada RSS-102 et aux limites d'exposition au rayonnement à fréquence radioélectrique du CENELEC.
