Inventec Appliances CX-66 802.11b Wireless LAN Card User Manual CX66

Inventec Appliances Corp. 802.11b Wireless LAN Card CX66

Contents

Users Manual Revised

TI-Navigator™ CX6601B 1
TI-Navigator™ CX6601B
The TI-Navigator™ components and Wireless LAN radio cards comply
with the following standards when installed and used as directed with
the components provided.
USA FCC Information Concerning Radio Frequency
Interference
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by
Texas Instruments could void the user's authority to operate this
equipment.
Product Name: TI-Navigator™
Model Number/Name: CX6601B FCC ID: POTCX-66
This device is intended only for OEM integrators under the following
conditions:
1) The antenna must be installed such that 20 cm is maintained between the
antenna and users, and
2) The transmitter module may not be co-located with any other transmitter
or antenna.
As long as 2 conditions above are met, further transmitter test will not be
required. However, the OEM integrator is still responsible for testing their
end-product for any additional compliance requirements required with this
module installed (for example, digital device emissions, PC peripheral
requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for
example laptop configurations or co-location with another transmitter),
then the FCC authorization is no longer considered valid and the FCC ID can
not be used on the final product. In these circumstances, the OEM integrator
will be responsible for re-evaluating the end product (including the transmitter)
and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the
antenna may be installed such that 20 cm may be maintained between the
antenna and users. The final end product must be labeled in a visible area
with the following: “Contains TX FCC ID:POTCX-66¨.
Manual Information That Must be Included
The OEM integrator has to be aware not to provide information to the end
user regarding how to install or remove this RF module in the users manual of
the end product which integrate this module.
The users manual for OEM integrators must include the following information
in a prominent location “ IMPORTANT NOTE: To comply with FCC RF
exposure compliance requirements, the antenna used for this transmitter
must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other
antenna or transmitter.
3) The Tx must be integrated internally so that the end user can not remove or instal by themselves.
2 TI-Navigator™ CX6601B
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator and your
body.
This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
IMPORTANT NOTE:
To comply with FCC RF exposure compliance requirements, the antenna
used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter.
We declare that CX6601B (FCC ID: POTCX-66) is limited in CH1~CH11 by
specified firmware controlled in U.S.A.
Europe — EU Declaration of Conformity
Complies with the provisions of the EMC Directive 89/336/EEC according
the following standards as applicable to the particular component:
• EN 55022 Class B, “Limits and methods of measurement of radio
interference characteristics of information technology equipment”
• EN 50082-1, “Electromagnetic compatibility — Generic immunity
standard”
• EN 60590 "Safety of Information Technology Equipment.
This device complies with the essential requirements of the R&TTE
Directive 1999/5/EC with essential test suites as per standards:
• ETS EN 300 328-2 Technical requirements for radio equipment.
• ETS EN 301 489-1/-17 General EMC requirements for radio
equipment.
Restrictions
France
Outdoor use limited to 10 mW e.i.r.p. within the band 2454 - 2483.5 MHz.
TI-Navigator™ CX6601B 3
Italy
If used outside of own premises, general authorization is required.
Canada — Industry Canada (IC)
To prevent radio interference to the licensed service, this device is
intended to be operated indoors and away from windows to provide
maximum shielding. Equipment (or its transmit antenna) that is installed
outdoors is subject to licensing.
Exposure to Radio Frequency Radiation
The radiated output power of the wireless LAN radio cards provided are
certified by the radio card manufacturers to be below the FCC radio
frequency exposure limits. Nevertheless, the equipment should be used
in such a manner that the potential for human contact during normal
operation is minimized.
4 TI-Navigator™ CX6601B
Texas Instruments Support and Service
For general information
For TI-Navigator™ technical questions
For product (hardware) service
Customers in the U.S., Canada, Mexico, Puerto Rico and Virgin Islands:
Always contact Texas Instruments Customer Support before returning a
product for service.
All other customers: Refer to the leaflet enclosed with this product
(hardware) or contact your local Texas Instruments retailer/distributor.
Home Page: education.ti.com
KnowledgeBase
and e-mail
inquiries:
education.ti.com/support
Phone: (800) TI-CARES / (800) 842-2737
For U.S., Canada, Mexico, Puerto Rico, and
Virgin Islands only
International
information: education.ti.com/international
E-mail: ti-navigator@ti.com
Phone: (866) TI-NAVIGATOR / (866) 846-2844
