Iriver Lplayer User Guide

Lplayer - User Guide Lplayer Free User Guide for Iriver Player, Manual

2015-08-19

: Iriver Iriver-Lplayer-User-Guide-787378 iriver-lplayer-user-guide-787378 iriver pdf

Open the PDF directly: View PDF PDF.
Page Count: 49

C o n t e n t s
Getting Started
Components 4
Locating the Controls 5
LCD Display 6
Installing iriver plus 3 8
Installing Windows Media
Player 11 9
Basic Operations
Turning the Product
on/off 12
Menu selection 13
Using HOLD and RESET 14
Connecting Products 15
Using the Product
Music 20
Videos 23
Pictures 25
Texts 27
FM Radio 29
Recordings 31
File Browser 32
Settings 33
Other Information
iriver plus 3 Using the Product 36
Using Windows Media Player 11 40
Copyrights/Certification/
Trademarks/Limited Liability 43
Safety Instructions 44
Troubleshooting 47
Components 4
Locating the Controls 5
LCD Display 6
Installing iriver plus 3 8
Installing Windows Media Player 11 9
01 Getting Started
4
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Lplayer Earphones
Quick Start Guide & Warranty Card Installation CD & Manual USB cable
Getting Started
Components
Components are subject to change without notice and may vary from images shown.
5
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Components are subject to change without notice and may vary from images shown.
Getting Started
Locating the Controls
RESET pinhole
HOLD switch
Volume button
MIC
POWER button
LCD
USB jack
Earphone jack
6
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
While playing music While playing video
Getting Started
LCD Display
Current video
File name
Elapsed time /
Total playing time
Rating
EQ
Play/Pause
Elapsed time /
Total playing time for
the current le
Play Mode
Current time
Album art
Album Info
Previous
Battery
Progress bar
Progress bar
Volume
Play next le
Playing previous le
HOLD Rewind
Fast Forward
7
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Getting Started
LCD Display
FM Radio While recording voice
Recording
quality
Current
frequency Preset On/O
Frequency indicator
Channel number
Current status
Recorded time /
Remaining time
8
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Getting Started
Installing iriver plus 3
iriver plus 3 is an integrated software application that efciently manages music, video, and picture les.
iriver plus 3 gives you freedom to transfer music, video and picture les from PC to the device.
Insert the installation CD into your PC to display the installation process screen.1.
Select iriver plus 3 and click the 2.
Install
button.
Complete the installation process by following the on-screen instructions.
Minimum requirements for using iriver plus 3
Windows® 2000/XP
Intel® Pentium® ll 233 MHz or higher processor speed 64 MB or greater memory 30 MB or greater hard disk space
16-bit enabled speaker and sound card Microsoft Internet Explorer version 6.0 or later
SVGA or high resolution monitor (1024x768 resolution or greater)
Windows® Vista (Windows® Vista only supports the 32-bit version and does not support the 64-bit version.)
Intel® Pentium® ll 800MHz or higher processor speed 512 MB or greater memory 20 GB or greater hard disk space
16-bit enabled speaker and sound card Microsoft Internet Explorer version 6.0 or later
SVGA or high resolution monitor (1024x768 resolution or greater)
For more information on using iriver plus 3, refer to pages 36 - 39.
Notice...
9
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Getting Started
Installing Windows Media Player 11
Insert the installation CD to your PC to display the installation process screen.1.
Select Windows Media Player 11 and click the 2.
Install
button.
Complete the installation process following the on-screen instructions.
Minimum requirements for using Windows Media Player 11
Windows® Vista
Intel® Pentium® ll 800MHz or higher processor speed 512 MB or greater memory 20 GB or greater hard disk space
16-bit enabled speaker and sound card Microsoft Internet Explorer version 6.0 or later
SVGA or high resolution monitor (1024x768 resolution or greater)
For more information on Windows Media Player 11 , refer to pages 40 - 42.
Notice...
Turning the Product on/off 12
Menu selection 13
Using HOLD and RESET 14
Connecting Products
- Connecting Earphones to the Lplayer 15
- Charging the product 15
- Connecting the Lplayer to your PC 16
- Copying files / folders to the product 17
- Deleting files / folders from the product 17
- Disconnecting the Lplayer from your PC 18
02 Basic Operations
12
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Basic Operations
Turning the Product on/off
Turning on the product
Press and hold the 1. button on the product to
turn it on.
Press and hold the 1. button on the product to
turn it o.
This product has an automatic power saving function to save battery power.
Based on the settings in power save mode, the product will be automatically turned off after a pre-determined period without operation.
For more information on setting this mode, refer to Settings > Power Saving > Auto Power off. (Refer to page 33.)
Notice...
Turning o the product
13
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Basic Operations
Menu selection
In the main menu, press the [UP] / [DOWN] button to select the menu.1.
Press and hold the [LEFT] button to display the main menu from any operation screen.2.
14
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Basic Operations
Using HOLD and RESET
Using HOLD
Slide the 1. HOLD switch to the direction of arrow as
shown below to lock the product.
Slide the 2. HOLD switch the opposite direction to
unlock the product.
If the player stops and does not respond to any 1.
commands, press the RESET pinhole.
Using RESET
Performing RESET does not delete the date / time settings
and data in the integrated memory.
Notice...
15
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Basic Operations
Connecting Products
Charging the product
Turn on your PC and connect the Lplayer to it using the 1.
USB cable provided.
While the product is connected to a PC using the USB cable, the
integrated battery will be charged automatically.
Do not use any USB cable other than the one included with the
product. It may cause a malfunction.
Check if the Lplayer is connected to a high-power USB 2.0 port.
Some low-power USB ports built into certain peripheral devices,
such as some types of keyboards and USB hubs without integrated
power may not provide enough power to charge.
While the PC is switched to standby mode, the product may not
be charged.
Charge the product only at room temperature.
The product may not be charged in extreme hot or cold temperatures.
The charging time might be extended if you use the product while
charging.
Notice...
Connecting Earphones to the Lplayer
Connect earphones to the earphone jack.1.
16
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Basic Operations
Connecting Products
Connecting the Lplayer to your PC
Press and hold the 1. button on the product to turn
it on.
Turn on your PC and connect the Lplayer to it using the 2.
USB cable provided.
If properly connected, the LCD will display as below.3.
Power & Data : The product is currently being
charged and data is being transferred.
Power & Play : The product is currently being charged and
a le is being played.
Power Only :The product is currently being charged.
17
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Basic Operations
Connecting Products (Using as a removable disk)
Copying les / folders to the product
Select the desired les / folders in your PC and 1.
drag & drop to the drive which appears as the product.
After selecting the desired le / folder, right-click with 1.
your mouse and select Delete.
Click 2. Yes in the Conrm File Delete / Conrm Folder
Delete popup window to delete the le / folder.
Always connect the USB cable properly.
While transferring data using the USB cable, never disconnect it or turn off the power to protect your data from loss or damage.
Notice...
Deleting les / folders from the product
18
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Click the [Stop] button to conrm disconnection.2.
Basic Operations
Connecting Products
Disconnecting the Lplayer from your PC
Click the icon on the taskbar to disconnect the product 1.
using the Safely Remove Hardware menu.
The icon on the taskbar may be hidden in some operating systems.
Click Show hidden icons to display the hidden icon.
The Safely Remove Hardware function may not be available while using some applications such as Windows Explorer or Windows Media Player.
Close all applications first before performing the Safely Remove Hardware.
If the Safely Remove Hardware is not performed properly, try again after a few minutes.
If the product is removed without observing the above process, data in the product might be damaged.
Notice...
Music
- Selecting Music 20
- Playing Music 20
- Additional Features 21
Videos
- Selecting Video 23
- Playing Video 23
- Additional Features 24
Pictures
- Selecting Pictures 25
- Viewing Picture 25
- Additional Features 26
Texts
- Selecting Text 27
- Viewing Text 27
- Additional Features 28
FM Radio
- Listening to FM Radio 29
- Scanning FM Radio
Station 29
- Additional Features 30
Recordings
- Recording 31
- Additional Features 31
File Browser
- Browsing Device 32
- Deleting File 32
Settings
- Date & Time 33
- Display 33
- Power Saving 33
- Advanced 34
- Language 34
03 Using the Product
20
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Selecting Music
In the main menu, press the [UP] / [DOWN] button to 1.
select Music and press the [RIGHT] button.
Press the [UP] / [DOWN] button to select the item and 2.
press the [RIGHT] button.
Press the [UP] / [DOWN] button to select the le and 3.
press the [RIGHT] button.
Playing Music
Press the +/- button to control the volume. ●
Press the [RIGHT] button to pause or resume. ●
While playing, press the [UP] / [DOWN] button to play ●
the previous / next music.
While playing, press and hold the [UP] / [DOWN] ●
button to play fast forward or reverse.
While playing, press the [LEFT] button to return to the ●
previous menu.
Supported file formats: MP3, WMA, OGG, FLAC, ASF
In the Music mode, only music files in the Music folder will be displayed.
To play other music files in any other folder, use the File Browser mode.
You can manage your own playlist using iriver plus 3.
In the main menu, press and hold the [RIGHT] button to play music
you have played recently.
Notice...
Using the Product
Music
21
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
Music
Additional Features
Press and hold the [RIGHT] button to display the Options screen.
A/B Repeat
Press the [RIGHT] button while playing to select the
beginning (A) point. Press it again to select the end (B)
point. The designated section between A and B will be
played. Press the [RIGHT] button again to deactivate the
repeat playback.
Play Mode
Selects the play mode which decides the playing order.
- Normal: Deactivates the play mode.
- Repeat: Repeats all les.
- Repeat One: Repeats one le.
- Shue: Randomly plays les in the current Database.
-
Shue + Repeat: Randomly repeats les in the current Database.
Study Mode
While playing, sets skip interval activated by pressing the
[UP] / [DOWN] button.
(The Study Mode is disabled when it is set to OFF.)
Select EQ
Selects the EQ to be used for playing music.
To avoid sound distortion, do not set the levels of Custom EQ and SRS WOW HD to high.
Notice...
22
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
Music
Repeat times
Sets the number of times for A-B repeat.
Repeat Interval
Sets the interval for A-B repeat.
Scan Speed
Sets the speed of fast forward and reverse.
Lyric Display
Sets lyric display of selected music.
Rate
Classies your favorite music by star ratings.
Add Bookmark
Bookmarks a specic point of time.
Delete File
Deletes the selected le.
Information
Displays information for the selected le.
Setup Sound
Sets the sound eect.
- Custom EQ: Changes levels of each frequency range to
create your own equalization.
- SRS WOW HD: Sets the levels of 3D sound eect.
- SRS: Customizes the SRS 3D sound eects.
- TruBass: Customizes the bass sound level
- Focus: Sets sound clarity.
-
WOW: Sets the proper boost level according to earphone type.
- Denition: Produces sharper and clearer sound.
- Fade-In: Volume increases gradually when playback starts.
23
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Selecting Video
In the main menu, press the [UP] / [DOWN] button to 1.
select Videos and press the [RIGHT] button.
Press the [UP] / [DOWN] button to select the item and 2.
press the [RIGHT] button.
Press the [UP] / [DOWN] button to select the le and 3.
press the [RIGHT] button to play it.
Playing Video
Press the +/- button to control the volume. ●
Press the [RIGHT] button to pause or resume. ●
Press and hold the [UP] / [DOWN] button to play fast ●
forward or reverse.
While playing, press the [LEFT] button to return to the ●
previous menu.
Supported file formats: AVI, WMV
In the Videos mode, only video files in the Video folder will be displayed.
To play other video files in any other folder, use the File Browser mode.
Max. playing time is variable depending on video type.
Be sure to use iriver plus 3 when transferring video files.
Otherwise, unexpected errors occur during video playback.
If there is a caption file (.smi), you can encode it together with video
file using iriver plus 3. (Be sure to match both names of video and
caption files.)
Notice...
Using the Product
Videos
24
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
Videos
Additional Features
Press and hold the [RIGHT] button to display the Options screen.
Play Mode
Sets the repeat playback mode of video le.
Scan Speed
Sets the speed of fast forward and reverse.
Resume
Selects whether video is resumed from the last
played point or from the beginning.
Sequential Play
Plays les with related names in sequential order.
Add Bookmark
Bookmarks a specic point of time
Delete File
Deletes the selected le.
Information
Displays information for the selected le.
25
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Selecting Pictures
In the main menu, press the [UP] / [DOWN] button to 1.
select Pictures and press the [RIGHT] button.
Press the [UP] / [DOWN] button to select the item and 2.
press the [RIGHT] button.
Play All Displays all pictures in the product.
Dir List Displaying saved picture les.
Picture Playlists Displays picture playlists made in iriver plus 3.
Press the [UP] / [DOWN] button to select the le and 3.
press the [RIGHT] button to display the picture on the
screen.
Viewing Picture
While playing pictures, press the [RIGHT] button to ●
start / pause a slide show.
While playing, press the [UP] / [DOWN] button to ●
play the previous / next picture.
While playing, press the [LEFT] button to return to the ●
previous menu.
Supported file formats: JPG, BMP, PNG, GIF
(Some file types may not be fully compatible.)
In the Pictures mode, only picture files in the Picture folder will be displayed.
To play other picture files in any other folder, use the File Browser mode.
Be sure to use iriver plus 3 when you transfer image file.
Otherwise, unexpected errors might occur during image playback.
Notice...
Using the Product
Pictures
26
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
Pictures
Additional Features
Press and hold the [RIGHT] button to display the Options screen.
Image Delay
Selects the amount of time each picture is displayed on
the screen during a slide show.
Rotate
Sets the direction of displayed image.
Zoom
Enlarges the selected picture.
- Press the [RIGHT] button to return to the original size.
Delete File
Deletes the selected le.
Information
Displays information for the selected le.
The Additional Features screen is deactivated during a slide show.
Notice...
27
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Selecting Text
In the main menu, press the [UP] / [DOWN] button to 1.
select Tex ts and press the [RIGHT] button.
Press the [UP] / [DOWN] button to select the item and 2.
press the [RIGHT] button.
Dir List Displaying saved text list.
Bookmark List Displays the list of bookmarks.
Press the [UP] / [DOWN] button to select the le and 3.
press the [RIGHT] button to display the text on the
screen.
Viewing Text
Press the [RIGHT] button to start or stop the automatic ●
scroll function.
Press the [UP] / [DOWN] button to scroll up or down. ●
While playing, press the [LEFT] button to return to the ●
previous menu.
Supported file formats: TXT (You cannot open the file over 10 MB.)
In the Texts mode, only text files in the Text folder will be displayed.
To play other text files in any other folder, use the File Browser mode.
Notice...
Using the Product
Texts
28
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
Texts
Additional Features
Press and hold the [RIGHT] button to display the Options screen.
Skip to
Press [UP] / [DOWN] to skip the amount of text based on
the designated percentage.
Auto Scroll Speed
Sets the scroll speed.
Font Size
Selects font size.
Add Bookmark
Bookmarks a specic point in the le.
Delete File
Deletes the selected le.
The Additional Features screen is deactivated when the automatic scroll function is activated.
Notice...
29
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Listening to FM Radio
In the main menu, press the [UP] / [DOWN] button to 1.
select FM Radio and press the [RIGHT] button.
Press the [UP] / [DOWN] button to select the FM radio 2.
station.
Scanning FM Radio Station
Press the [UP] / [DOWN] button to move to the ●
next / previous frequency.
Press the [RIGHT] button to activate the preset and ●
press the [UP] / [DOWN] button to move to the
available next / previous frequency.
Press the [RIGHT] button to activate the preset and ●
press the [UP] / [DOWN] button to move to the next /
previous channel.
While playing, press the [LEFT] button to return to the ●
previous menu.
FM radio won’t be working properly if earphone is not plugged in.
Notice...
Using the Product
FM Radio
30
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
FM Radio
Additional Features
Press and hold the [RIGHT] button to display the Options screen.
Record
Records the FM radio which you are listening to.
- Press the [
RIGHT]
button to start / stop recording.
FM Recording Quality
Sets the recording quality of radio broadcasting.
Save Preset / Delete Preset
Saves / deletes the current frequency to / from preset channel.
Auto Preset
Automatically scans and stores frequencies to the channels.
- Up to 20 channels can be stored.
Preset List
Displays saved channel list.
- Press the [UP] / [DOWN] button to select the channel and
press the [
RIGHT]
button to listen to it.
Tuner Region
Sets the frequency range based on local standards.
- Korea / US: 87.5 - 108.0MHz
- Japan: 76.0 - 108.0MHz
- Europe: 87.50 - 108.00 MHz
You cannot control the volume while recording FM radio.
If the remaining memory space or power is insufficient, recording will
be automatically stopped.
The file size per minute varies with recording quality.
Low: Approximately 480 K / Middle: Approximately 720 K / High: Approximately 960 K
The recorded file will be saved in the Recordings/FM Radio folder in
the following format:
TUNERYYMMDDXXX.WMA
(YY: Year, MM: Month, DD: Day, XXX: Sequential number)
Notice...
31
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Recording
In the main menu, press the [UP] / [DOWN] button to 1.
select Recordings and press the [RIGHT] button.
In recording standby screen, press the [RIGHT] button 2.
to start recording. Press again to pause recording.
Press the [RIGHT] button to stop recording. 3.
You cannot control the volume while recording.
If the remaining memory space or power is insufficient, recording will
be automatically stopped.
The file size per minute varies with recording quality.
Low: Approximately 480 K / Middle: Approximately 720 K / High: Approximately 960 K
The recorded file will be saved in the following format:
(YY: Year, MM: Month, DD: Day, XXX: Sequential number)
[Recordings > Voice] VOICEYYMMDDXXX.WMA
Notice...
Using the Product
Recordings
Additional Features
In recording standby mode, press and hold the [RIGHT] button
to display the Options screen.
Recording Quality
Sets the quality of recordings.
32
iriver Music Videos Pictures Texts FM Radio Recordings SettingsFile Browser
Browsing Device
In the main menu, press the [UP] / [DOWN] button to 1.
select File Browser and press the [RIGHT] button.
In le (folder) list, press the [UP] / [DOWN] button to 2.
select the previous / next le (folder).
Press the [RIGHT] button to move to the subfolder or 3.
play the selected le.
Press the [LEFT] button to move to the upper folder.4.
Using the Product
File Browser
You can manually check and play various media saved in the iriver Lplayer.
Deleting File
After selecting the le, press and hold th1. e [RIGHT]
button.
33
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
Settings
The iriver Lplayer supports customizable congurations.
The menu congurations are subject to change with different rmware versions.
Power Saving
Auto Power off
Automatically turns the power o after a
pre-determined period without operation.
Sleep
Automatically turns the power o after a
predetermined time.
Date & Time
Sets the current date and time
- [RIGHT] button : Moves among elds.
- [UP] / [DOWN] button : Sets the value of each eld.
Display
Backlight
Sets the amount of time to keep the backlight ON.
Brightness
Changes LCD display brightness.
Thema
changes theme of the main display.
Display Orientation
Inverts screen display orientation and key
directions by 180 degree.
34
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Using the Product
Settings
Advanced
Rebuild DB
Rebuilds library data of a le.
Connection Type
Selects PC le transfer type.
- MSC(UMS) : Using iriver plus 3, transfers les via an
MSC connection.
* Mass Storage Class (MSC) is a traditional UMS type.
- MTP : Using Windows Media Player 11, transfers les via
an MTP connection.
Format
Deletes all data saved in memory.
System Information
Displays system information of the product.
Reset All Settings
Resets the product to the factory setting.
Language
Menu Language
Selects language for menu.
Countries
Selects language for tag and text.
It is necessary to backup all valuable files before formatting, since deleted files cannot be recovered.
(iriver recommends formatting the memory using the Lplayer.)
Always check remaining battery power before you start formatting.
Notice...
iriver plus 3 Using the Product
- Adding Media to Library 36
- Ripping Songs from a CD 36
- Transferring Media to the iriver Lplayer 37
- Supported File Formats 38
- Initializing Disk 39
- Upgrading Firmware 39
Using Windows Media Player 11
- Adding Media to Library 40
- Ripping Songs from a CD 40
- Transferring Media to the Lplayer 41
- Initializing Disk 42
-
Firmware upgrade in Windows Media Player 11 42
Copyrights/Certification/Trademarks/
Limited Liability 43
Safety Instructions 44
Troubleshooting 47
04 Other Information
36
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Adding Media to Library
When you run iriver plus 3 for the rst time, the Add 1.
Media Wizard will start.
Follow the on-screen instructions on the PC to add 2.
media les such as music and pictures to the library.
Insert an audio CD into the CD drive and run iriver plus 3.1.
In iriver plus 3, select the checkbox from 2.
Music > CD Drive and click CD Ripping in bottom left.
After ripping a song, select the 3. All Music to check
whether the ripped song has been added to the library.
Ripping Songs from a CD
Other Information
iriver plus 3 Using the Product
To connect the product to iriver plus 3, select Settings > Advanced > Connection type
and set to MSC (UMS).
37
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
iriver plus 3 Using the Product
Transferring Media to the iriver Lplayer
iriver plus 3 Using the Product
Connect the product to the USB jack of your PC using 1.
the USB cable and run iriver plus 3.
Select the checkbox beside the le to transfer and click 2.
.
The selected le starts to transfer and the progress status 3.
is displayed in the Status window on bottom left.
Now you can nd the selected music in your library.4.
Using Windows Explorer
Connect the product to the USB jack of your PC using the 1.
USB cable.
Copy the contents to proper folders as below.2.
Text: iriver Lplayer/Text
Music: iriver Lplayer/Music
Pictures: iriver Lplayer/Pictures
Videos: iriver Lplayer/Video
38
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
iriver plus 3 Using the Product
Supported File Formats
Type Extension Format Type Extension Format
Music
MP3
WMA
OGG
ASF
FLAC
8~320Kbps
Q1~Q10
FLAC0~FLAC8
Video
AVI
Video
MPEG4 SP (Simple Prole), less than 30
frames/sec, 2 Mbps
Resolution
QVGA(320X240)
Text TXT Unicode text, local code text
Audio Supports MP3 up to 320 Kbps and
recommends 44.1 KHz, CBR
Pic-
ture
JPG
BMP
PNG
GIF
Baseline JPG (Progressive JPG is not supported.)
WMV
Video
WMV9 SP, less than 30 frames/sec. 768 Kbps
Resolution
QVGA(320X240)
Audio
Supports WMA up to 320 Kbps
39
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
iriver plus 3 Using the Product
Initializing Disk
Connect the product to the USB jack of your PC using 1.
the USB cable and run iriver plus 3.
Select 2. Tools > Portable Device > Initialize Disk and click
Start when the initialization conrmation message
appears.
The initialization process is completed and the product 3.
is disconnected from your PC.
After connecting the product to the USB jack of your 1.
PC using the USB cable, run iriver plus 3.
The PC should be connected to the internet.
Select 2. Tools > Portable Device > Firmware Upgrade
and complete the upgrade process by following the
on-screen instructions.
Upgrading Firmware
You need to backup the necessary files before initialization,
since formatted files cannot be recovered.
Notice...
Do not disconnect the product from PC while downloading the
firmware upgrade file. Once the download is completed,
disconnect the cable to activate the firmware upgrade.
If the latest version of the firmware is already installed, the
message to confirm the latest version appears.
Messages regarding any available firmware updates will appear
automatically when you connect the product to your PC.
Notice...
40
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Using Windows Media Player 11
Adding Media to Library
When you run Windows Media Player 11 for the rst time, 1.
the Add Media Wizard will start.
Follow the on-screen instructions on the PC to add media 2.
les such as music and picture to the librar.
Insert an audio CD into the CD drive and run 1.
Windows Media Player 11.
Select the 2. Ripping tab from Windows Media Player 11.
Select the checkbox beside music to rip and click the
Start Ripping in bottom left.
The ripped music will be stored in 3. My Documents >
My Music and automatically added to library.
Ripping Songs from a CD
To connect the product to Windows Media Player 11.
select [Settings > Advanced > Connection type] and set it to [MTP].
41
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Using Windows Media Player 11
Transferring Media to the Lplayer
After connecting the product to the USB jack of our 1.
PC using the USB cable, run Windows Media player 11.
After selecting the le in your PC, drag & drop it 2.
to the right pane.
Click 3. Start Synchronizing to start transferring le.
Now you can nd the selected music in your library.4.
42
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Using Windows Media Player 11
Initializing Disk
After connecting the product to the USB jack of 1.
your PC using the USB cable, run Windows Media
player 11.
After selecting [Lplayer], click the right mouse 2.
button and select Format. Click OK when the
message to conrm initialization appears.
The initialization process is completed and the 3.
product is disconnected from your PC.
Connect the product to the USB jack of your PC.1.
Run iriver Firmware Updater application in the installation 2.
CD and complete the upgrade process by following the
on-screen instructions.
Firmware upgrade in Windows Media Player 11
You need to backup the necessary files before initialization as
formatted files cannot be recovered.
Notice...
Do not disconnect the product from PC while upgrading
firmware.
Notice...
43
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Copyrights/Certification/Trademarks/Limited Liability
Copyrights
iriver Limited holds all rights for the patent, trademark, literary property
and intellectual property related to this manual.
You may not copy or reproduce any part of this manual unless autho-
rized by iriver Limited. You may be subject to criminal penalties for ille-
gal use of any part of this manual. Software, audio and video including
intellectual property are protected by copyright and international laws.
Reproduction or distribution of contents created with this product is
the responsibility of the user.
The companies, institutions, products, people and events used in
examples are for demonstration purposes only. Their appearance in this
manual does not imply any aliation between iriver and other parties.
Users are responsible for observing all copyrights and intellectual
property laws.
© 1999~2008 iriver Limited. All rights reserved.
Certication
MIC, FCC, CE
Class B Digital Device (Residential Communication Device). This equip-
ment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation.
Trademarks
Windows 2000, Windows XP, Windows Vista and Windows Media Player are
the registered trademarks of Microsoft Corp.
is a trademark of SRS Labs, Inc.
WOW HD technology is incorporated under license from SRS Labs, Inc.
Limited Liability
Neither the manufacturer, importers nor dealers are responsible for any
accidental damage, including bodily injury or any damages resulting
from misuse or inappropriate operation on behalf of the user. The infor-
mation on this manual is prepared with the current player specications.
The manufacturer, iriver Limited, shall routinely add new features to the
product and may continuously apply new technologies hereafter. All
standards may be changed at any time without prior notice.
44
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Safety Instructions
Product Safety
Do not display the same image on the screen for an
extended amount of time since this may cause a
ghosting eect.
Do not place objects such as coins or hair pins inside
the product.
This may cause malfunction.
Do not place heavy objects on the product.
This may cause damage and malfunction.
Do not expose the player to sources of moisture such as
water, beverages, chemicals, cosmetics, and so on.
This may cause damage and malfunction.
Keep away from harsh environments including humid,
dusty, and smoky areas.
This may cause malfunction.
Keep out of direct sunlight and extreme heat and cold.
This may cause malfunction.
Do not keep the product close to magnetic substance
such as magnets, TVs, monitors, or speakers.
This may cause malfunction.
Never dismantle, repair, or rebuild your player without
authorization.
This may cause damage and malfunction.
Do not clean with chemicals or detergents.
This may cause malfunction.
45
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Safety Instructions
Do not drop or subject the device to impact.
This may cause damage and malfunction.
Do not press more than two buttons simultaneously.
This may cause damage and malfunction.
Do not disconnect the USB cable while transferring data.
This may cause malfunction.
Try when possible to connect the product to the rear
USB port in your PC.
In some custom- assembled PCs, improper USB port may cause
malfunction.
Do not connect any device or object other than earphones
to the Earphone jack.
This may cause damage and malfunction.
46
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Safety Instructions
Other
Do not use headphones / earphones while cycling,
driving, or operating any motorized vehicle.
This is dangerous and might be illegal in some areas.
Do not use the product while in motion, such as while
driving, walking, or mountain climbing.
Use the product in a safe place to avoid accidents.
Always be careful to steer clear of nearby objects if you
use the product while in motion.
It is not recommended to use the product during
electrical storms.
Reduce volume or stop using the player if you
experience ringing in your ears.
Do not listen to music via headphones/earphones at
high volume for a long time.
Keep headphone /earphone cords under control in
order to avoid getting caught on nearby objects.
Do not sleep with headphones / earphones in the ears.
Do not use headphones / earphones for excessive periods of
time.
47
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Troubleshooting
Please check out!
The player will not power on!
-
Check whether the battery is charged or not.
Charge the product using the USB cable and then
check again.
-
Insert a thin and pointed object (such as a straightened
paper clip) into the reset pinhole to reset the device.
The product cannot be charged after connecting power.
-
Check whether the USB cable is rmly connected.
The LCD display turns o frequently.
-
To save power consumption, the LCD is designed to be
turned o after a designated period of time.
Set this amount of time in Settings > Display > Backlight.
The product cannot be connected properly using the
USB cable.
-
Check whether the USB cable is rmly connected.
Poor radio reception with heavy interference!
-
Check whether the earphones jack is dirty.
-
Check whether the earphones are connected.
-
Adjust the position of the player and earphones.
-
Turn o any nearby electronic equipment to avoid
potential interference.
No sound during playback!
-
Check whether the volume is set to “0”.
-
Check whether the earphone plug or connection jack is dirty.
-
Check whether the music le is corrupted.
48
iriver Music Videos Pictures Texts FM Radio Recordings File Browser Settings
Other Information
Troubleshooting
The memory space has changed after formatting.
-
The memory space may be changed depending on the
operating system.
The start-up time is too long.
-
Check whether too many les are stored in the product.
It is recommended to store up to 1,000 music les and
2000 picture les.

Navigation menu
