www.siemens.com/wm
Be inspired
Small is beautiful! With MC55/MC56 Siemens
mobile presents the world’s smallest, double
Tri-Band GSM/GPRS modules! This miniaturized,
complete voice- and data solution enables infinite
flexibility in the design and creation of next
generation’s mobile devices. Opt for MC55/MC56
and convert your ideas into revolutionary
solutions for global markets! The application
possibilities are virtually unlimited:
•
Mobile computing devices
•
Smart phones
•
Computing accessory cards
•
And much more to enable your customers
wireless connectivity
The MC55/MC56 modules are full type approved
and optimized for easy and fast integration in
mobile devices. Utilizing the MC55/MC56 will
reduce your development risk and investment as
well as cost and time to market.
For contact and more information please visit
www.siemens.com/wm
MC55/MC56
Wireless
Modules
Power-up your
wireless business
At only 3.0 mm, these revolutionary GSM/GPRS modules open up new integration possibilities for a wide
spectrum of mobile computing devices, such as PDAs, smart phones and other handhelds. The easy
integration path enables a wide range of applications. The MC55/MC56 modules are full type approved
for worldwide operation.
Siemens MC55/MC56 – the world’s most
treasured Tri-Band GSM/GPRS modules:
ultra-light, ultra-flat, ultra-flexible.
General features:
• Tri-Band GSM/GPRS
900/
1800/1900 MHz (MC55)
• Tri-Band GSM/GPRS
850/
1800/1900 MHz (MC56)
• GPRS multi-slot class 10
• GPRS mobile station class B
•
Compliant to GSM phase 2/2+
•
Output power:
– 2 W for EGSM850
– 2 W for EGSM900
– 1 W for GSM1800
– 1 W for GSM1900
•
Dimensions: 35 x 32.5 x 3.0 mm
(btb-connector: 3.3 mm)
•
Weight: 5.5 g
•
Control via AT commands
(GSM 07.07 and 07.05)
•
SIM application toolkit
•
WAP compliant
•
MMS compliant
• Supply voltage range 3.3
...
4.8 V
• Low power consumption
•
Ambient temperature:
–20 °C to +55 °C
•
Auto switch-off at +70 °C
Specifications for fax:
•
Group 3, class 2
Specifications for data:
•
GPRS class 10: max. 85.6 kbps
(downlink)
• PBCCH support
•
Coding schemes CS 1, 2, 3, 4
•
CSD up to 14.4 kbps
•
USSD
•
Non transparent mode
•
V.110
•
PPP-stack
Specifications for SMS
via GSM and GPRS:
•
Point-to-point MO and MT
•
SMS cell broadcast
•
Text and PDU mode
Specifications for voice:
•
Tricodec
– Half rate (HR)
– Full rate (FR)
– Enhanced Full rate (EFR)
•
Adaptive multi rate (AMR)
• Hands-free operation
(echo cacellation)
•
Noise reduction
Drivers:
•
Microsoft® Windows Mobile™ RIL
Driver
•
MUX Driver
Approvals:
•
R&TTE
•
FCC
•
IC
•
GCF
•
PCCRB
•
Local approvals and mobile
operator certifications
Interfaces:
•
Interface to external SIM
•
Board-to-board connector
•
Digital and analog audio
interfaces
•
AT commands via serial interface
•
Two serial interfaces
•
Power supply 3.3
...
4.8 V
•
Antenna connector and antenna
pad
•
Battery charger
Compatibility:
•
AT cellular command interface
More about
Siemens Wireless Modules at:
www.siemens.com/wm
Copyright 2003, Siemens AG
Information and Communication
Mobile
Wireless Modules
Haidenauplatz 1
81667 Munich, Germany
Subject to changes in technology,
design and availability
Order No.:
A31001-W25-A218-X-7600
Printed in Germany
Wireless Modules
Benefits and hard facts
Original size
