Itron ITR24001 ITR24001 Module User Manual XX XXXX Exhibit Cover
Itron Electricity Metering, Inc. ITR24001 Module XX XXXX Exhibit Cover
Itron >
Manual
5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598
Certification Exhibit
FCC ID: SK9ITR24001
IC: 864G-ITR24001
FCC Rule Part: 15.247
IC Radio Standards Specification: RSS-210
ACS Report Number: 11-0105.W06.11.A
Manufacturer: Itron Electricity Metering, Inc.
Model: ITR24001
Manual
UserInformationManual
Itron Module Model ITR24001
Labeling
The following requirements will be applied to any products that use this module:
The end product label will include the following text:
Contains:
FCC ID: SK9ITR24001
IC: 864G-ITR24001, Module ITR24001
The user’s manual for any product that contains this module will contain the following text. If the device is
large enough, then this will also be placed on the label.
“This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.”
RegulatoryCompliance
The user’s manual for any product that contains this module will contain the following text:
FCC Part 15, Class B
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Industry Canada
This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment
Regulations. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Cet appareillage numérique de la classe B répond à la norme Canadienne sur le matériel brouilleur.
L'opération est sujette aux deux conditions suivantes: (1) ce dispositif ne peut pas causer d'interférence
nocive, et (2) ce dispositif doit accepter n'importe quelle interférence reçue, y compris les interférences
pouvant entraîner un fonctionnement indésirable.
“To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that permitted for successful communication.”
“This device has been designed to operate with the antennas listed below, and
having a maximum gain of 3.9 dB. Antennas not included in this list or having a gain
greater than 3.9 dB are strictly prohibited for use with this device. The required
antenna impedance is 50 ohms.”
Listed Antennas*
Manufacturer: WP Wireless
Model Number: WPANT30005-SA
Gain: 2.5 to 3.9 dB
Connector: Reverse polarity SMA male
*Antennas of equal or lesser gain and same type may be substituted.
RF Exposure
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm
from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter. End-users and installers must be provided with antenna installation instructions and transmitter
operating conditions for satisfying RF exposure compliance.
Miscellaneous
The user’s manual for any product that contains this module will contain the following text:
Professional Installation
This module is intended for professional installation by the integrator. The OEM integrator is still
responsible for the FCC compliance requirement of the end product, which integrates this module.
Modification and Repairs
To ensure FCC compliance and system performance, this device, antenna and/or coaxial assembly shall not
be changed or modified without the express written approval of Itron. Any unauthorized modification will
void the user’s authority to operate the equipment. WARNING! This device contains no user serviceable
parts. Attempts to repair this device by unauthorized personnel may subject the person to shock hazard if
removal of protective covers is attempted. Unauthorized repair will void the warranty and/or maintenance
contract with your company.
General Description
The Itron ITR24001 module is a CPU unit which acts as a Cell master within an electricity grid system.
Located in the ITR24001 module is a WiFi transmitter that operates in the 2400 MHz to 2484.5 MHz band.
The ITR24001 can be installed in a larger weatherproof box and control the functions of a GPRS or CDMA
modem and a 900 MHz LAN radio. The module operates on direct current voltage which is supplied by a
host device.
