Manual
5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598
Certification Exhibit
FCC ID: SK9ITR9002
IC: 864G-ITR9002
FCC Rule Part: 15.247
IC Radio Standards Specification: RSS-210
ACS Report Number: 11-0104.W06.11.A
Manufacturer: Itron Electricity Metering, Inc.
Model: ITR9002
Manual
UserInformationManual
Itron Module Model ITR9002
Labeling
The following requirements will be applied to any products that use this module:
The end product label will include the following text:
Contains:
FCC ID: SK9ITR9002
IC: 864G-ITR9002, Module: ITR9002
The user’s manual for any product that contains this module will contain the following text. If the device is large
enough, then this will also be placed on the label.
“This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.”
RegulatoryCompliance
The user’s manual for any product that contains this module will contain the following text:
FCC Part 15, Class B
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Industry Canada
This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
Cet appareillage numérique de la classe B répond à la norme Canadienne sur le matériel brouilleur. L'opération est
sujette aux deux conditions suivantes: (1) ce dispositif ne peut pas causer d'interférence nocive, et (2) ce dispositif
doit accepter n'importe quelle interférence reçue, y compris les interférences pouvant entraîner un fonctionnement
indésirable.
“To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that permitted for successful communication.”
“This device has been designed to operate with the antennas listed below, and
having a maximum gain of 5.1dB. Antennas not included in this list or having a gain
greater than 5.1dB are strictly prohibited for use with this device. The required
antenna impedance is 50 ohms.”
Listed Antennas*
Manufacturer: Comet
Model Number: R-2000
Gain: 5.1 dB
Connector: N-male
*Antennas of equal or lesser gain and same type may be substituted.
RF Exposure
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and
installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying
RF exposure compliance.
Miscellaneous
The user’s manual for any product that contains this module will contain the following text:
Professional Installation
This module is intended for professional installation by the integrator. The OEM integrator is still responsible for the
FCC compliance requirement of the end product, which integrates this module.
Modification and Repairs
To ensure FCC compliance and system performance, this device, antenna and/or coaxial assembly shall not be
changed or modified without the express written approval of Itron. Any unauthorized modification will void the
user’s authority to operate the equipment. WARNING! This device contains no user serviceable parts. Attempts to
repair this device by unauthorized personnel may subject the person to shock hazard if removal of protective covers
is attempted. Unauthorized repair will void the warranty and/or maintenance contract with your company.
General Description
The Itron ITR9002 is a transmitter module that operates in the 902 MHz to 928 MHz unlicensed band. The module
operates on direct current voltage which is supplied by a host device.
