5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598
Certification Exhibit
FCC ID: QHC-KVEVZE41
FCC Rule Part: 15.247
ACS Project Number: 14-0144
Manufacturer: Itron
Model: 570974-001
Manual
kV2c-AMPZE User Information Manual
Labeling
The following requirements will be applied to any products that use this module:
The end product label will include the following text:
Contains:
FCC ID: QHC-KVEVZE41
Model: 570974-001
The user’s manual for any product that contains this module will contain the following test. If the device is
large enough, this information will also placed on the label:
“THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS. (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,
AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.”
Regulatory Compliance
The user’s manual for any product that contains this module will contain the following text:
FCC Part 15, Class B
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
kV2c-AMPZE User Information Manual
RF Exposure
The antennas used for this transmitter must be installed to provide a minimum separation
distance of 20 cm from all persons, and must not be co-located or operate in conjunction with any
other antenna or transmitter. End users and installers must be provided with antenna installation
procedures and transmitter operating conditions for satisfying RF exposure compliance.
Miscellaneous
The user’s manual for any product that contains this module will contain the following text:
Professional Installation
This module is intended for professional installation by the integrator. The OEM integrator is still
responsible for the FCC compliance requirement of the end product which uses this module.
Modification and Repairs
To ensure FCC compliance and system performance, this device, antenna and/or coaxial assembly shall
not be changed or modified without the express written approval of Itron. Any unauthorized modification
will void the user’s authority to operate the equipment.
WARNING! This device contains no user serviceable parts. Attempts to repair this device by unauthorized
personnel may subject the person to shock hazard if removal of protective covers is attempted.
Unauthorized repair will void the warranty and/or any maintenance contract with your company.
General Description
The Itron 570974-001 (kV2c-AMPZE) is an electricity metering module which includes a Cellular EVDO
WAN module operating in the GSM 800 MHz and PCS 1900 MHz bands,a HAN transmitter operating in
the 2.4 GHz band, and a LAN transmitter operating in the 900MHz ISM band. The module operates on
direct current which is supplied by the host meter device.
kV2c-AMPZE User Information Manual
ANTENNAS
WAN Antenna: Under Glass Ribbon Gain:
+0 dBi 800 & 1900 band
PASSBAND: 824-894 Cellular Band & 1850-1990 PCS Band
External Mono-Pole Gain :
+3dBi 800 band
+4dBi 1900 band
PASSBAND: 824-894 Cellular Band & 1850-1990 PCS Band
HAN Antenna: PCB antenna embedded in the module:
GAIN: +3.3dBi
PASSBAND: 2405 to 2480 MHz
LAN Antenna: Slot antenna:
GAIN: 0dBi
PASSBAND: 900 to 990 MHz
