users manual
1
FCC ID:LK4GB-1000
GB-1000 Iwill four ports thin server
THIN SERVER
A
CPU PGA370
GTL 1
CHIPSET VIA693A+596B
PCI SLOT 1 W/RISER CARD
LAN INTEL82559 * 4
ULTRA 160(Optional) N/A
ATA66 IDE*2 YES
FDD YES
KEYBOARD YES W/CABLE
PS/2 MOUSE N/A
Hardware A20gate YES
CPU FAN 1
SYS FAN 2
DOC DIP32*1 OR SMD32*2
USB 1
2S, 1P YES
POWER CON. ATX 20PIN
LAN LED FORNT+BACK
SCSI 68PIN N/A
FORNT CON. RESET+IDE+POWER
CMOS CLEAR YES
PCB SIZE 24*17CM
HDD DEVICE N/A
POWER SUPPLY 180W 5V 16A/12V 7A
ACPI N/A
2
User manual
Fan Connector
JP1 FAN1
JP11 FAN2
JP12 FAN3
JP13 FAN4
CPU ratio JP3
ratio 1-5 2-6 3-7 4-8
3.5X ON OFF ON OFF
4X OFF ON ON ON
4.5X OFF ON ON OFF
5X OFF OFF ON ON
5.5X OFF OFF ON OFF
6X ON ON OFF ON
6.5 ON ON OFF OFF
7X ON OFF OFF ON
7.5X ON OFF OFF OFF
8X OFF ON OFF ON
FSB speed JP5
FSB JP5 (OTHER OFF)
66Mhz 8-7,6-5(DEFAULT)
100Mhz 8-7
133Mhz OFF
FORNT PANEL JP6
RESET:1-2
POWER LED: 3-4
IDE LED:5-6
CMOS RAM CLEAN JP7
1-2 NORMAL
2-3 CLEAN (MUST ON POWER-OFF SETTING)
3
DOC SELECTOR JP8 (SMD TYPE U23,24)
ADDRESS JP8 OTHER OFF
C800-C9FF 1-2 ON
D000-D1FF 3-4 ON
D800-D9FF 5-6 ON
DOC SELECTOR JP9 (DIP TYPE U21)
ADDRESS JP9 OTHER OFF
C800-C9FF 1-2 ON
D000-D1FF 3-4 ON
D800-D9FF 5-6 ON
LAN PORT LED JP10
100MBPS ACTIVE/LINK
LAN PORT 1 1-3 2-4
LAN PORT 2 5-7 6-8
LAN PORT 3 9-11 10-12
LAN PORT 4 13-15 14-16
P S/2 keyboard connector J6
1 Keyboard Data
2 NC
3 GND
4 VCC
5 Keyboard Clock
FCC GUIDELINES
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
♦ Reorient or relocate the receiving antenna
♦ Increase the separation between the equipment and receiver
♦ Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
♦ Consult the dealer or an experienced radio/TV technician for help.
♦ Use only shielded cables to connect I/O devices to this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference. (2) This device must
accept any interference received, including interference that may cause undesired
operation.
Information to User:
F Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment. Shielded interface cable, if any, must be used in order to comply
with emission limits.
IBM AT and PS/2 are registered trademarks of International Business Machines Corporation.
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and/or other countries.
All other trademarks are trademarks of their respective holders.
3100504464
Version 1.0
November 1999
Printed in
China
