J Communications Co BAG-2000 Bluetooth Audio Gateway User Manual Charging a

J Communications Co Ltd Bluetooth Audio Gateway Charging a

Contents

User Manual

AGM(BAG-2000) of User Manual
Overview
BAG-2000(with BH-1000) utilizes 2.4GHz Bluetooth technology to provide hands-free
and wire-free communication for your headset-ready mobile phone.
Designed for maximum comfort and ease of use, this is tailored to suit mobile phone.
And This guide will help you set up and use BAG-2000(with BH-1000).
BAG-2000 supports the Headset Profile as an Audio Gateway device.
It makes you wireless connection between the mobile phones
which recognize ring sounds through a ear phone jack and the Bluetooth Headset.
Connecting to your handset.(BAG-2000)
1. Select a location on your Handset to attach
BAG-2000 and attach BAG-2000.
2. Connect BAG-2000 cord to the headset-jack
on your handset
Putting On the Headset.(BH-1000) Ear hook
①
Microphone
1. Put on the Headset with the ear
hook behind your ear.
2. Make sure the microphone is pointing
towards your mouth. ②
Pairing the Headset with BAG-2000
Before you start using the Headset for the first time, you must pair the Headset with
the BAG-2000.
-Before you start pairing, you must reset the Headset. And then Headset will go to
pairing mode.
1. Press the three keys, Volume Up, Down and Talk button simultaneously with
the Headset turned on.
To ensure, press the keys(Up, Down and Talk button) in 2 or three times.
Up
Down
Talk ON/OFF
2. Wait until hear a short melody tone and then turn the Headset off .
-To pair the Headset(BH-1000)t with a
Bluetooth
Audio-gateway(BAG-2000)
1. With a BAG-2000 turned on, press and hold the rest button for up to 2 or
3seconds.
Indicator ON/OFF
Reset
2. Turn a BAG-2000 off and turn it on.
3. At this time, turn the Headset on again and will be disappeared the indicator
light flash on BAG-2000 if the pairing has been completed in successful.
Make sure the Headset and a BAG-2000 are not too far apart.
4. Turn the BAG-2000 and Headset off and turn on, at this time you can hear
short melody from Headset
.
5. Attach a BAG-2000 to the handset.
Making call and Receiving Calls.
Once you have paired the Headset(BH-1000) with your BAG-2000, you can make and
receiving calls using the Headset as long as it is turned on and within range of the
phone ( up to 10 m./30ft. with no solid objects in the way)
In connection with making and receiving calls you press the Headset Talk button to
. make a call
. answer a call
. end a call
. transfer the sound from the phone to the Headset.
Making Call
To make a call using the Headset Talk button
1. Press the Talk button on your headset to establish a connection between the
Headset and BAG-2000. You will hear a short melody from Headset and
Indicator light on the BAG-2000.
2. Your mobile phone will call last dialed number, or pre-programmed number.
3. When your call is complete, press the Talk button on your headset to
disconnect the BAG-2000. and then you can hear different long melody.
Answering Calls
To answer a call using the Headset Talk button
1. When the phone rings, press the Headset Talk button once. And then
you can hear melody(short).
2. End the call by pressing the Headset Talk button, At this time also you can hear
different long melody.
Adjusting the Volume
You can adjust the volume in the Headset earpiece via either the Headset volume
buttons or by using the phone.
To changing the listening volume using the phone
1. Use the volume control keys as you normally would
To changing the listening vo ume using the Headset earpiece l
1. Use Up key to increase the volume, or Down key to decrease the volume.
Charging
The BAG-2000 comes with a built-in rechargeable battery(Li-Polymer).
The batteries are not fully charged when you buy the Headset and we recommend that
you charge the Headset until the indicator light turns green before using these for the
first time.
How to charge the Headset
Charging Jack
1. Connect AC/DC Adapter(power supply) to
the cradle.
2. Connect BAG-2000 charging code from
BAG-2000 charging jack to the cradle
charging jack.
the cradle indicator light(HD)
flashes green. If the battery is low,
the light flashes red. BAG-2000 Charging Indicator
NOTE: Charging jack of BAG-2000 is able to using ear-set jack with jumper setting
from inside BAG-2000.
Battery Information
The battery delivered with your Headset and Audio-gateway are not fully charged. We
recommend that you fully charge these before you use these for the first time.
* Notice1 : The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
* IMPORTANT NOTE : To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to the antenna or the device
could result in the device exceeding the RF exposure requirements and void user’s authority to
operate the device.
FCC INFORMATION
The Federal Communication Commission Radio Frequency Interference Statement
includes the following paragraph:
The equipment has been tested and found to comply with the limits for a Class B
Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction, may cause harmful interference to radio communication.
However, there is no grantee that interference will not occur in a particular installation. If this
equipment dose cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The user should not modify or change this equipment without written approval Form J
communications Co., Ltd. Modification could void authority to use this equipment.
