JADAK JDK-1901 VIBE Installation Guide for RFID Modular Approval
For FCC compliance, the label on the final system must include a statement: “Contains FCC ID: 2AAVI-
JDK1901”
For IC compliance, the label on the final system must include a statement: “Contains IC ID: 11355A-
JDK1901”
The JDK-1901 RFID modular radio should not be installed within a system operating simultaneously with
other transmitters.
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by JADAK LLC (the party responsible for compliance)
could void the user's authority to operate the equipment.
IC Compliance (Canada)
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Installation Instructions
The JADAK JDK-1901 VIBE module is intended for installation in a system that provides the correct
mechanical mounting hole pattern, and mating electrical connector that contains power and
communication signals. There should be no metallic surfaces placed in front of the antenna (Note: the
antenna encircles the optical lens).
The JDK-1901 VIBE module should be installed by authorized and trained service personnel.
Step 1-Install the unit by attaching the mounting ears to the system using appropriate hardware to
secure the housing in three locations.
Step 2-attach the JDK-1901 VIBE connector to a mating connector with the following connections:
![](/img.php?id=2184027&img=bg2.png)
Pin
Use
Description
1
Ground
VIBE present signal
2
GND
Supply and signal
ground
3
RX+
Positive differential
receive pin
4
RX-
Negative differential
receive pin
5
PWR
Supply voltage input
6
3.3v GPIO
Future use.
7
TX+
Positive differential
transmit pin
8
TX-
Negative differential
transmit pin
The power supply voltage must be 5.0 VDC +/- 0.250 VDC for proper operation. The maximum
operating current is 500 mA and the maximum standby current is 165 mA.
The JDK-1901 VIBE is designed to communicate using a RS485 hybrid bidirectional communication
interface. Communication is achieved using a Texas Instrument’s SN65176BD differential bus
transceiver.
Step 3-Apply power to the host system. Install a plug containing an appropriate HF (13.56 MHz) RFID tag
to ensure that the host system reads the tag contents.
