Permanent inline monitoring and analysis
The USRobotics Gigabit Fiber Taps provide an easy method to rapidly and effectively
deploy analysis tools to observe and monitor traffic non-intrusively between two devices
on a fiber network. By design, fiber taps are totally passive, fault-tolerant, and invisible
to the network which means they will not affect network performance or integrity and can
be trusted for permanent installations on a fiber network. These rock solid devices are
ideal for real-time monitoring and analysis of any traffic between critical network devices
such as switches, routers and firewalls and continue to pass errors that aren’t seen using
SPAN ports. Topology independent, the taps can be used for ATM, Gigabit, OC3-OC48, or
SONET protocols and are available for both Singlemode and Multimode fiber networks.
Monitoring &
Analysis
•Capturesanddeliversacopyof alltrafctoanyanalysistool
•100%visibilityintothenetwork-includingVLANtags
•Viewalltrafconbothsidesof fullduplexlinks
•Reducesdegradationof switchperformanceduetoportmirroring
•ViewLayer1and2errorssuchasruntsandCRCerrorsnotseenwhenperformingnetwork
monitoringusingSPANports
•Fullduplexmonitoring
•Bestmethodtomeasurenetworklink’sperformance
•Greatfornetworkanalysisandtroubleshooting,IDSandmonitoringapplications
Network Stability •Idealfor24x7permanentaccess-eliminatingtheneedtoconnecttoolseachtimealinkneedstobe
monitored
•Non-intrusivewaytoconnectanetworktool
•Minimizetrafcdelay
•Fault-tolerantdesign
Secure & Reliable •Passiveaccessmeansnointerferenceof networktrafc
•Invisibleonthenetwork-noIPaddressmeansadditionalsecurity
•Nosinglepointof failure
•Networktrafcwillcontinuetopassuninterrupted
Excellent
Compatibility
•50/50splitratio
•Multimodemodelsavailableinboth1Gand10G
•Singlemodemodelsavailableinboth1Gand10G
•Supportsmultipletopologies:GigabitEthernet,ATM,OC3-48,andSONET
Simple installation •Plugandplay
•Nopowerrequired
•Connectorsonfrontforeasyaccessandoperation
•Comeswithconvenientbuilt-inrackmountadapterforusewiththeoptionalUSR4500-RMK1U3
unitrackmount.
Ethernet Taps
USR4511, USR4512
SX & LX Gigabit Fiber Taps
With 1 network and 1 Monitor Connection
www.usr.com
Copyright©2013U.S.RoboticsCorporation,aDivisionof UNICOMGlobal.Allrightsreserved.U.S.Robotics
andUSRoboticsareregisteredtrademarksof U.S.RoboticsCorporation.Otherbrandnamesandproductnames
areforidenticationpurposesonlyandmaybetrademarksorregisteredtrademarksof theirrespectivecompanies.
RoHS
Compliant
2011/65/EU
This product has been tested for user safety and adheres to the CE marking , compliance and safety standards.
USR4500-RMK-1URackMountChassisholdingupto3Taps
Physical
• Metal1Uchassis
• TwoTX/RXSCFiberNetworkPorts
• TwosimplexTXSCFiberMonitorPorts
Fiber
• SCFiberconnectors
• 50/50SplitRatio
• 4.0dBInsertionLoss
• SX:50micronberdiameter,wavelength850nm
• LX:9micronberdiameter,wavelength1310/1550nm
Environmental
• Temperature:
▪ OperatingTemperature:0°to40°C
▪ Non-OperatingTemperature:-30°to65°C
• Humidity:
▪ Lessthan95%non-condensingoperatingornon-operating
Regulatory & Certifications
• CEapproved
• RoHSCompliant
• WEEECompliant
Package Dimensions/Weight
• 15.75x11.5x4.25in(40.01x29.21x10.80cm)
• 1.58lbs.(.72kg)
Product Dimensions/Weight
• 1.10x5.75x5.75in.(2.8x14.6x14.6cm)withrackmountbracket
• .65lbs(.29kg)
Package Contents
• USRoboticsFiberTapwithrackmountbracket
Product Numbers
• USR45111000SXMultimodeFiberTap(50Micron50/50)
• USR45121000LXSinglemodeFiberTap(9Micron50/50)
• USR451510GigabitSRMultimodeFiberTap(50Micron50/50)
• USR451610GigabitLRSinglemodeFiberTap(9Micron50/50)
• USR4500-RMKOptional3Unit1UTapRackMountChassis
Warranty
• 2-yearlimitedmanufacturerwarrantyfromdateof purchase
Specifications & Standards
Models 4511, 4512
Gigabit Fiber Taps
